JDBC and Java Access to DBMS

1
JDBC and Java Access to DBMSIntroduction to
Data Warehouses

• University of California, Berkeley
• School of Information
• IS 257 Database Management

2
Lecture Outline

• Review
• Object-Relational DBMS
• OR features in Oracle
• OR features in PostgreSQL
• Extending OR databases (examples from PostgreSQL)
• Java and JDBC
• Introduction to Data Warehouses

3
Lecture Outline

• Object-Relational DBMS
• OR features in Oracle
• OR features in PostgreSQL
• Extending OR databases (examples from PostgreSQL)
• Java and JDBC
• Introduction to Data Warehouses

4
Object Relational Data Model

• Class, instance, attribute, method, and integrity
  constraints
• OID per instance
• Encapsulation
• Multiple inheritance hierarchy of classes
• Class references via OID object references
• Set-Valued attributes
• Abstract Data Types

5
Object Relational Extended SQL (Illustra)

• CREATE TABLE tablename OF TYPE TypenameOF NEW
  TYPE typename (attr1 type1, attr2 type2,,attrn
  typen) UNDER parent_table_name
• CREATE TYPE typename (attribute_name type_desc,
  attribute2 type2, , attrn typen)
• CREATE FUNCTION functionname (type_name,
  type_name) RETURNS type_name AS sql_statement

6
Object-Relational SQL in ORACLE

• CREATE (OR REPLACE) TYPE typename AS OBJECT
  (attr_name, attr_type, )
• CREATE TABLE OF typename

7
Example

• CREATE TYPE ANIMAL_TY AS OBJECT (Breed
  VARCHAR2(25), Name VARCHAR2(25), Birthdate DATE)
• Creates a new type
• CREATE TABLE Animal of Animal_ty
• Creates Object Table

8
Constructor Functions

• INSERT INTO Animal values (ANIMAL_TY(Mule,
  Frances, TO_DATE(01-APR-1997,
  DD-MM-YYYY)))
• Insert a new ANIMAL_TY object into the table

9
PostgreSQL Classes

• The fundamental notion in Postgres is that of a
  class, which is a named collection of object
  instances. Each instance has the same collection
  of named attributes, and each attribute is of a
  specific type. Furthermore, each instance has a
  permanent object identifier (OID) that is unique
  throughout the installation. Because SQL syntax
  refers to tables, we will use the terms table and
  class interchangeably. Likewise, an SQL row is an
  instance and SQL columns are attributes.

10
Creating a Class

• You can create a new class by specifying the
  class name, along with all attribute names and
  their types
• CREATE TABLE weather (
• city varchar(80),
• temp_lo int, -- low
  temperature
• temp_hi int, -- high
  temperature
• prcp real, --
  precipitation
• date date
• )

11
PostgreSQL

• Postgres can be customized with an arbitrary
  number of user-defined data types. Consequently,
  type names are not syntactical keywords, except
  where required to support special cases in the
  SQL92 standard.
• So far, the Postgres CREATE command looks exactly
  like the command used to create a table in a
  traditional relational system. However, we will
  presently see that classes have properties that
  are extensions of the relational model.

12
Inheritance

• CREATE TABLE cities (
• name text,
• population float,
• altitude int -- (in ft)
• )
• CREATE TABLE capitals (
• state char(2)
• ) INHERITS (cities)

13
Inheritance

• In Postgres, a class can inherit from zero or
  more other classes.
• A query can reference either
• all instances of a class
• or all instances of a class plus all of its
  descendants

14
Non-Atomic Values - Arrays

• The preceding SQL command will create a class
  named SAL_EMP with a text string (name), a
  one-dimensional array of int4 (pay_by_quarter),
  which represents the employee's salary by quarter
  and a two-dimensional array of text (schedule),
  which represents the employee's weekly schedule
• Now we do some INSERTSs note that when appending
  to an array, we enclose the values within braces
  and separate them by commas.

15
PostgreSQL Extensibility

• Postgres is extensible because its operation is
  catalog-driven
• RDBMS store information about databases, tables,
  columns, etc., in what are commonly known as
  system catalogs. (Some systems call this the data
  dictionary).
• One key difference between Postgres and standard
  RDBMS is that Postgres stores much more
  information in its catalogs
• not only information about tables and columns,
  but also information about its types, functions,
  access methods, etc.
• These classes can be modified by the user, and
  since Postgres bases its internal operation on
  these classes, this means that Postgres can be
  extended by users
• By comparison, conventional database systems can
  only be extended by changing hardcoded procedures
  within the DBMS or by loading modules
  specially-written by the DBMS vendor.

16
Rules System

• CREATE RULE name AS ON event
• TO object WHERE condition
• DO INSTEAD action NOTHING
• Rules can be triggered by any event (select,
  update, delete, etc.)

17
Views as Rules

• Views in Postgres are implemented using the rule
  system. In fact there is absolutely no difference
  between a
• CREATE VIEW myview AS SELECT FROM mytab
• compared against the two commands
• CREATE TABLE myview (same attribute list as for
  mytab)
• CREATE RULE "_RETmyview" AS ON SELECT TO myview
  DO INSTEAD
• SELECT FROM mytab

18
Extensions to Indexing

• Access Method extensions in Postgres
• GiST A Generalized Search Trees
• Joe Hellerstein, UC Berkeley

19
Indexing in OO/OR Systems

• Quick access to user-defined objects
• Support queries natural to the objects
• Two previous approaches
• Specialized Indices (ABCDEFG-trees)
• redundant code most trees are very similar
• concurrency control, etc. tricky!
• Extensible B-trees R-trees (Postgres/Illustra)
• B-tree or R-tree lookups only!
• E.g. WHERE movie.video lt Terminator 2

20
GiST Approach

• A generalized search tree. Must be
• Extensible in terms of queries
• General (B-tree, R-tree, etc.)
• Easy to extend
• Efficient (match specialized trees)
• Highly concurrent, recoverable, etc.

21
GiST Applications

• New indexes needed for new apps...
• find all supersets of S
• find all molecules that bind to M
• your favorite query here (multimedia?)
• ...and for new queries over old domains
• find all points in region from 12 to 2 oclock
• find all text elements estimated relevant to a
  query string

22
Lecture Outline

• Review
• Object-Relational DBMS
• OR features in Oracle
• OR features in PostgreSQL
• Extending OR databases (examples from PostgreSQL)
• Java and JDBC
• Introduction to Data Warehouses

23
Java and JDBC

• Java is probably the high-level language used in
  instruction and development today one of the
  earliest enterprise additions to Java was JDBC
• JDBC is an API that provides a mid-level access
  to DBMS from Java applications
• Intended to be an open cross-platform standard
  for database access in Java
• Similar in intent to Microsofts ODBC

24
JDBC Architecture

• The goal of JDBC is to be a generic SQL database
  access framework that works for any database
  system with no changes to the interface code

Java Applications
JDBC API
JDBC Driver Manager
Driver
Driver
Driver
Oracle
MySQL
Postgres
25
JDBC

• Provides a standard set of interfaces for any
  DBMS with a JDBC driver using SQL to specify
  the databases operations.

26
JDBC Simple Java Implementation
import java.sql. import oracle.jdbc. public
class JDBCSample public static void
main(java.lang.String args) try //
this is where the driver is loaded
//Class.forName("jdbc.oracle.thin")
DriverManager.registerDriver(new
OracleDriver()) catch (SQLException e)
System.out.println("Unable to load driver
Class") return
27
JDBC Simple Java Impl.
try //All DB access is within the
try/catch block... // make a connection to
ORACLE on Dream Connection con
DriverManager.getConnection(
"jdbcoraclethin_at_dream.sims.berkel
ey.edu1521dev", mylogin",
myoraclePW") // Do an SQL statement...
Statement stmt con.createStatement()
ResultSet rs stmt.executeQuery("SELECT NAME
FROM DIVECUST")
28
JDBC Simple Java Impl.
// show the Results... while(rs.next())
System.out.println(rs.getString("NAME"))
// Release the database
resources... rs.close()
stmt.close() con.close() catch
(SQLException se) // inform user of
errors... System.out.println("SQL Exception
" se.getMessage()) se.printStackTrace(Syst
em.out)
29
JDBC

• Once a connection has been made you can create
  three different types of statement objects
• Statement
• The basic SQL statement as in the example
• PreparedStatement
• A pre-compiled SQL statement
• CallableStatement
• Permits access to stored procedures in the
  Database

30
JDBC Resultset methods

• Next() to loop through rows in the resultset
• To access the attributes of each row you need to
  know its type, or you can use the generic
  getObject() which wraps the attribute as an
  object

31
JDBC GetXXX() methods
SQL data type Java Type GetXXX()
CHAR String getString()
VARCHAR String getString()
LONGVARCHAR String getString()
NUMERIC Java.math.BigDecimal GetBigDecimal()
DECIMAL Java.math.BigDecimal GetBigDecimal()
BIT Boolean getBoolean()
TINYINT Byte getByte()
32
JDBC GetXXX() Methods
SQL data type Java Type GetXXX()
SMALLINT Integer (short) getShort()
INTEGER Integer getInt()
BIGINT Long getLong()
REAL Float getFloat()
FLOAT Double getDouble()
DOUBLE Double getDouble()
BINARY Byte getBytes()
VARBINARY Byte getBytes()
LONGVARBINARY Byte getBytes()
33
JDBC GetXXX() Methods
SQL data type Java Type GetXXX()
DATE java.sql.Date getDate()
TIME java.sql.Time getTime()
TIMESTAMP Java.sql.Timestamp getTimeStamp()
34
Large Object Handling

• Large binary data can be read from a resultset as
  streams using
• getAsciiStream()
• getBinaryStream()
• getUnicodeStream()

ResultSet rs stmt.executeQuery(SELECT IMAGE
FROM PICTURES WHERE
PID 1223)) if
(rs.next()) BufferedInputStream gifData new
BufferedInputSteam(

rs.getBinaryStream(IMAGE)) byte buf
new byte41024 // 4K buffer int len while
((len gifData.read(buf,0,buf.length)) ! -1)
out.write(buf, 0, len)
35
JDBC Metadata

• There are also methods to access the metadata
  associated with a resultSet
• ResultSetMetaData rsmd rs.getMetaData()
• Metadata methods include
• getColumnCount()
• getColumnLabel(col)
• getColumnTypeName(col)

36
JDBC access to MySQL

• The basic JDBC interface is the same, the only
  differences are in how the drivers are loaded

public class JDBCTestMysql public static
void main(java.lang.String args) try
// this is where the driver is loaded
Class.forName("com.mysql.jdbc.Driver").newInstance
() catch (InstantiationException i)
System.out.println("Unable to load driver
Class") return catch
(ClassNotFoundException e)
System.out.println("Unable to load driver
Class")
37
JDBC for MySQL
try //All DB access is within the
try/catch block... // make a connection to
MySQL on Dream Connection con
DriverManager.getConnection(
"jdbcmysql//localhost/ (this
is really one line) MyDatabase?userMyLogin
passwordMySQLPW") // Do an SQL
statement... Statement stmt
con.createStatement() ResultSet rs
stmt.executeQuery("SELECT NAME FROM DIVECUST")

• Otherwise everything is the same as in the Oracle
  example
• For connecting to the machine you are running
  the program on, you can use localhost instead
  of the machine name

38
Demo JDBC for MySQL

• Demo of JDBC code on Harbinger
• Code is available on class web site

39
Lecture Outline

• Review
• Object-Relational DBMS
• OR features in Oracle
• OR features in PostgreSQL
• Extending OR databases (examples from PostgreSQL)
• Java and JDBC
• Introduction to Data Warehouses

40
Overview

• Data Warehouses and Merging Information Resources
• What is a Data Warehouse?
• History of Data Warehousing
• Types of Data and Their Uses

41
Problem Heterogeneous Information Sources
Heterogeneities are everywhere
Personal Databases
World Wide Web
Scientific Databases
Digital Libraries

• Different interfaces
• Different data representations
• Duplicate and inconsistent information

Slide credit J. Hammer
42
Problem Data Management in Large Enterprises

• Vertical fragmentation of informational systems
  (vertical stove pipes)
• Result of application (user)-driven development
  of operational systems

Sales Planning
Suppliers
Num. Control
Stock Mngmt
Debt Mngmt
Inventory
...
...
...
Sales Administration
Finance
Manufacturing
...
Slide credit J. Hammer
43
Goal Unified Access to Data
Personal Databases
Digital Libraries
Scientific Databases

• Collects and combines information
• Provides integrated view, uniform user interface
• Supports sharing

Slide credit J. Hammer
44
The Traditional Research Approach

• Query-driven (lazy, on-demand)

Clients
Metadata
Integration System
. . .
Wrapper
Wrapper
Wrapper
. . .
Source
Source
Source
Slide credit J. Hammer
45
Disadvantages of Query-Driven Approach

• Delay in query processing
• Slow or unavailable information sources
• Complex filtering and integration
• Inefficient and potentially expensive for
  frequent queries
• Competes with local processing at sources
• Hasnt caught on in industry

Slide credit J. Hammer
46
The Warehousing Approach

• Information integrated in advance
• Stored in WH for direct querying and analysis

Slide credit J. Hammer
47
Advantages of Warehousing Approach

• High query performance
• But not necessarily most current information
• Doesnt interfere with local processing at
  sources
• Complex queries at warehouse
• OLTP at information sources
• Information copied at warehouse
• Can modify, annotate, summarize, restructure,
  etc.
• Can store historical information
• Security, no auditing
• Has caught on in industry

Slide credit J. Hammer
48
Not Either-Or Decision

• Query-driven approach still better for
• Rapidly changing information
• Rapidly changing information sources
• Truly vast amounts of data from large numbers of
  sources
• Clients with unpredictable needs

Slide credit J. Hammer
49
Data Warehouse Evolution
Building the DW Inmon (1992)
Data Replication Tools
Relational Databases
Company DWs
2000
1995
1990
1985
1980
1960
1975
Information- Based Management
Data Revolution
Middle Ages
Prehistoric Times
TIME
PCs and Spreadsheets
End-user Interfaces
1st DW Article
DW Confs.
Vendor DW Frameworks
Slide credit J. Hammer
50
What is a Data Warehouse?

• A Data Warehouse is a
• subject-oriented,
• integrated,
• time-variant,
• non-volatile
• collection of data used in support of management
  decision making processes.
• -- Inmon Hackathorn, 1994 viz. Hoffer, Chap 11

51
DW Definition

• Subject-Oriented
• The data warehouse is organized around the key
  subjects (or high-level entities) of the
  enterprise. Major subjects include
• Customers
• Patients
• Students
• Products
• Etc.

52
DW Definition

• Integrated
• The data housed in the data warehouse are defined
  using consistent
• Naming conventions
• Formats
• Encoding Structures
• Related Characteristics

53
DW Definition

• Time-variant
• The data in the warehouse contain a time
  dimension so that they may be used as a
  historical record of the business

54
DW Definition

• Non-volatile
• Data in the data warehouse are loaded and
  refreshed from operational systems, but cannot be
  updated by end-users

55
What is a Data Warehouse?A Practitioners
Viewpoint

• A data warehouse is simply a single, complete,
  and consistent store of data obtained from a
  variety of sources and made available to end
  users in a way they can understand and use it in
  a business context.
• -- Barry Devlin, IBM Consultant

Slide credit J. Hammer
56
A Data Warehouse is...

• Stored collection of diverse data
• A solution to data integration problem
• Single repository of information
• Subject-oriented
• Organized by subject, not by application
• Used for analysis, data mining, etc.
• Optimized differently from transaction-oriented
  db
• User interface aimed at executive decision makers
  and analysts

57
Contd

• Large volume of data (Gb, Tb)
• Non-volatile
• Historical
• Time attributes are important
• Updates infrequent
• May be append-only
• Examples
• All transactions ever at WalMart
• Complete client histories at insurance firm
• Stockbroker financial information and portfolios

Slide credit J. Hammer
58
Warehouse is a Specialized DB

• Standard DB
• Mostly updates
• Many small transactions
• Mb - Gb of data
• Current snapshot
• Index/hash on p.k.
• Raw data
• Thousands of users (e.g., clerical users)

• Warehouse
• Mostly reads
• Queries are long and complex
• Gb - Tb of data
• History
• Lots of scans
• Summarized, reconciled data
• Hundreds of users (e.g., decision-makers,
  analysts)

Slide credit J. Hammer
59
Summary
Business Information Guide
Business Information Interface
Data Warehouse
Data Warehouse Catalog
Data Warehouse Population
Operational Systems
Enterprise Modeling
Slide credit J. Hammer
60
Warehousing and Industry

• Warehousing is big business
• 2 billion in 1995
• 3.5 billion in early 1997
• Predicted 8 billion in 1998 Metagroup
• Wal-Mart is said to have the largest warehouse
• 1000-CPU, 583 Terabyte, Teradata system
  (InformationWeek, Jan 9, 2006)
• Half a Petabyte in warehouse (Ziff Davis
  Internet, October 13, 2004)
• 1 billion rows of data or more are updated every
  day (InformationWeek, Jan 9, 2006)
• Some Government and Scientific database are
  larger, however

Slide credit J. Hammer
61
Other Large Data Warehouses

• Not including Wal-Mart and Ebay

(InformationWeek, Jan 9, 2006)
62
Types of Data

• Business Data - represents meaning
• Real-time data (ultimate source of all business
  data)
• Reconciled data
• Derived data
• Metadata - describes meaning
• Build-time metadata
• Control metadata
• Usage metadata
• Data as a product - intrinsic meaning
• Produced and stored for its own intrinsic value
• e.g., the contents of a text-book

Slide credit J. Hammer
63
Next Time

• More on Data Warehouses
• Introduction to data mining
