XWiki Presentation

1
XWiki Presentation
2
Web/Wiki History
(1) Representative event 1991 Web first used in a small, academic community Technologies becoming popular HTTP, HTML, GIF, JPEG Content viewedit Tim Berners Lee BrowserEditor HTML preprocessors
(2) 1997 E-commerce application Amazon.com IPO Presentation-oriented HTML, JavaScript, Java Applets, PHP WYSIWYG editors (FrontPage), Navigator and MS Explorer
(3) 2001 Collaborative content creation in Wikipedia.org starts CSS XHTML and XML-related markup J2EE Web Apps (servletsJSP) Web-based Content management systems (CMS), wiki-formats
(4) Since 2005 - AJAX, Web 2.0, www.37signals.com, Google Docs, Mashups, 2nd generation wikis. RubyRails, Semantic Web (RDF/OWL), SOA Content syndication (RSSRDF), portlets, wiki extensible by macros, plugins and scripting
3
"Long Tail" 2nd Generation Wikis

• Pareto principle (80-20 rule) and "Long Tail".
  Various software solutions - spellcheckers,
  Amazon.com, Google.com show that it is essential
  to handle "long tails" well.

- Applications like Atlassian Confluence and
XWiki claim to be the MS Access and MS Excel of
the Web age. - It should be easy to configure
simple Web forms and sort all kinds of simple
data and documents - to bring the advantages of
packaged development to the everyday user.
4
Remarks on XWiki Installation

• Windows installer - Jetty Web Server HSQLDB
  (usually a private XWiki)
• Multiple user XWiki - e.g. Apache2Tomcat5.5
  MySQL.

XWiki pre-defined objects/templates
Custom objects/templates
XWiki J2EE Web Application (Struts, Hibernate,
Maven2 modules...)

• Java Application Server
• Jetty
• Apache Tomcat
• Apache Geronimo
• Resin
• JBoss
• Oracle OC4J
• BEA WebLogic
• IBM WebSphere
• ... Anything that can run J2EE Servlet 2.4 spec.

• Database Server
• Hypersonic (HSQLDB)
• MySQL
• Postgre
• Oracle XE
• ... Anything one can connect via JDBC or ODBC.

5
Spaces

• Space - a logical grouping of pages
• Every page belongs to a space
• Easier to manage user permissions
• Wiki-Notation MySpace.MyPage external link
• http//localhost8080/xwiki/bin/view/MySpace/MyPag
  e
• Each space has default starting-page
  MySpace.WebHome external link
  http//localhost8080/xwiki/bin/view/MySpace/
  Note the ending slash (/)!
• Space "Main" is pre-defined Main.WebHome is
  the default homepage document

6
Creating a new page or space

• Create a link to an empty page Click on it!
• Links to nonexisting pages display with "?".
  Clicking that link also creates page.

7
Administer a Page or Space

• Pick a space, press Add Access Right Entry
• Select a group or a user pick level and
  allow/deny
• Levels admin/view/edit/comment/delete/register/pr
  ogramming

8
Headings

• Prefix line with number for heading
• 1 for heading
• 1.1 for sub-heading
• 1.1.1 for sub-sub-heading
• Etc
• Always use "1" and "1.1" (not "2", "2.3", etc.)
• Needs to be at the start of line
• Can also use html tags (like lth1gt...lt/h1gt etc.)

9
Table of Content - macro

• Note! Long Web documents are not good.
• Use velocity macro toc(init max number)
• Init Heading level to display
• Max Maximum number of nested levels
• Number Boolean, whether to number results
• Automatically creates links to headings
• Examples
• toc("" "" "") or, say,
• toc(1 5 true)

10
Text Effects

• Bold
• Surround text with asterisks i.e. Bold
• Equivalent to strong tag - ltstronggtBoldlt/stronggt
• Italics
• Surround text with tildes i.e.  Italics
• Equivalent to emphasized tag i.e.
  ltemgtItalicslt/emgt
• Strike
• Surround text with dashes i.e. Stricken
• Use deleted tag i.e. ltdelgtStrickenlt/delgt

11
Lists and Bullet Points

• Prefix text with (or 1. 1.1. 1.a )
• The number of s controls indent. Consider also
  using headings / toc
• Examples

• 1. First
• 1. Second
• 1. Second sub-bullet
• 1. Second sub-bullet
• Third. Should not introduce\\ line-breaks,
  except forced ones.
• 1a. Third A
• 1a. Third B
• 1. Fourth

Shopping List Cake  Flour  Eggs
Sugar  Bananas  Tomatoes
12
Creating a Hyperlink

• Syntax
• Link to external website - Text label gt
  http//www.accenture.lv or just
  http//www.accenture.lv
• Link with different display text label gt
  Space.Name or labelSpace.Name (pipe allows
  refactoring of links, when pages are renamed).
• Link to given space and page Space.SomeName
  (the link is displayed with space "Some Name").
• Link to page in same space SomeName

13
Quiz

• Question What is the difference between two
  links MyProject., MyProject.WebHome and
  MyProject if used in the document
  OtherSpace.Aa

• Answer The first two refer to the default page
  (WebHome) of the space "MyProject". The last one
  refers to a page "MyProject" in the current
  document space. Their links are respectively
• http//localhost8080/xwiki/bin/view/MyProject/
  and
• http//localhost8080/xwiki/bin/view/OtherSpace/My
  Project

14
Tables

• Creates an IBM formatted table
• Each row must be on its own line
• Example
• table
• Head1 Head2 Head3
• Row1.1 Row1.2 Row1.3
• Row2.1 Row2.2 Row 2.3
• table

15
Attachments and Pictures

• You can attach large files to a page
• To display a link to an attachment
• attachfilename.doc
• To display an image in the page
• imagepicture.jpg
• To display a remote image
• ltimg src/xwiki/bin/download/Space/Page/pictu
  re.jpg /gt

16
Escaping

• Use \ to escape individual characters
• Example
• \table , \Button\
• \\ to display \
• May need to use html to display certain
  characters
• lt instead of lt
• gt instead of gt
• x5C or 92 instead of \

17
Displaying Code

• Use codexml or code (i.e. codejava) tags
  to indicate that a block of text is code.
• Example
• codejava
• try
•         // Load the JDBC driver
•         String driverName "org.gjt.mm.mysql.Driv
  er"
•         Class.forName(driverName)
•     catch (ClassNotFoundException e)
•         // Could not find the driver
•
• code

18
Blocks of Plaintext

• Use PRE text /PRE to stop the wiki processing
  text.
• Use ltPREgt text lt/PREgt to stop HTML processing
  text.

19
Using Velocity macros

• toc('' '' '')
• Highlighted blocks
• info('Info message')
• warning('Warning message')
• error('Error message')
• floatingbox('Surrounded box with text')
• includeInContext("MySpace.MyPage")
• Find more (and define your own) under
  /xwiki/skins/albatross/macros.vm

20
XWiki Distributions

• XWiki Enterprise , an extensible Enterprise wiki,

• XWiki Enterprise Manager , an application for
  managing farms of wikis,
• XWiki Watch , a collaborative RSS reader with a
  UI built using GWT,
• Chronopolys, a project management application for
  managing portfolio of projects
• Nearbee, a wiki focused on work spaces with the
  ability to invite users to share them .

21
Editing Objects
1
2
3
22
Some Predefined Objects

• Open
• any article,
• a blog entry,
• a user page
• with "Edit"-gt "Objects".
• You should see something like this

23
Editing Objects

• From the Objects editor you can add new
  (predefined) objects to your document.
• Each document in some space is a list of zero or
  more objects (plus the template/text of the
  document itself).
• Typically each document contains one object - an
  instance of "XWiki.TagClass"

24
Various Modes of Looking at the Document

• "Edit" -gt "Objects" opens a predefined form with
  text-boxes.
• There are two more modes (simply) "view" and
  "inline" (or "inline form").

25
Defining Your own Object Classes

• http//localhost8080/xwiki/bin/view/XWiki/XWikiCl
  asses

26
Class "Todo" - Step 1

• Open some existing classes
• Create a new class - Todo

This is the default content for the TODO Class
wizard
27
Class "Todo" - Step 2

• First click "Edit the Class" and add the class
  attributes (i.e. the properties for all future
  "Todo" objects).
• It is not easy to remove properties once added -
  one can only Rollback the class definition or
  re-create it.

28
Script for Displaying Todo's

• 1 Todos
• set (hql ", BaseObject as obj where
  obj.namedoc.fullName
• and obj.className'XWiki.TodoClass' and
  obj.nameltgt'XWiki.TodoClassTemplate'")
• set (todos xwiki.searchDocuments(hql))
• table
• DescriptionAssigneeDateStatus
• foreach (todo in todos)
• set (todoDoc xwiki.getDocument(todo))
• set (todoObj todoDoc.getObject("XWiki.TodoC
  lass"))
• todoObj.Descriptiongttodo todoObj.Assignee
  todoObj.TargetDate todoObj.Status
• end
• table

29
Result to display Todo's

• For this to work robustly, use

30
Making Todo list sortable/filterable

• lttable id"todoTable" class"grid sortable
  filterable doOddEven" cellpadding"0"
  cellspacing"0" border"0"gt
• lttr class"sortHeader"gt
• ltthgtDescriptionlt/thgt
• ltthgtAssigneelt/thgt
• ltthgtDatelt/thgt
• ltth class"unsortable selectFilter"gtStatuslt/th
  gt
• lt/trgt
• foreach (todo in todos)
• lttrgt
• set (todoDoc xwiki.getDocument(todo))
• set (todoObj todoDoc.getObject("XWiki.Tod
  oClass"))
• lttdgttodoObj.Descriptiongttodolt/tdgt
• lttdgttodoObj.Assigneelt/tdgt
• lttdgttodoObj.TargetDatelt/tdgt
• lttdgttodoObj.Statuslt/tdgt
• lt/trgt
• end
• lt/tablegt

31
Resulting List of Todo's

• Also click to link "tags" (after you have tagged
  some documents).

32
Adding Pagination

• 1 Todos
• ltform...
• lt/formgt
• set(itemsPerPage 5)
• if(request.ipp)
• set(itemsPerPage xwiki.parseInt(request.ip
  p))
• end
• set(pageNumber 0)
• if(request.page)
• set(pageNumber xwiki.parseInt(request.page
  ))
• end
• set(startAt itemsPerPage pageNumber)
• if(startAt lt 0)
• set(startAt 0)
• end
• set (hql ", BaseObject as obj where
  obj.namedoc.fullName and obj.className'XWiki.Tod
  oClass' and obj.nameltgt'XWiki.TodoClassTemplate'")
• set (count xwiki.getXWiki().search("select
  count(doc) from XWikiDocument doc hql",
  context.context).get(0))
• set(endAt itemsPerPage (pageNumber 1))
• if(endAt gt count)

33
Resulting List of Todo's

• View your objects as paginated list ( have a
  simple form for creating new objects).

34
Add Todo's to the Panel

• http//localhost8080/xwiki/bin/view/Panels/

• Add a script between "panelheader" and
  "panelfooter"
• Should use Hibernate Query language (HQL)
• set (hql ... )
• foreach (todo in xwiki.searchDocuments(hql,
  5, 0))
• todo
• end

35
Extending XWiki Markup Language

• Can use Plugins as JARs or Groovy scripting.
• An example of adding LaTeX plugin to XWiki is
  seen http//www.ante.lv/xwiki/bin/view/MetaAnte/Re
  nderingLatex .

36
XWiki Admin Concerns

• Manage Users
• Manage Space and Page Access
• Configure private blogging spaces and similar
  spaces for users' private use
• Ensure that can migrate to newer versions
• Create backups for the whole wiki or some spaces
  only
• Ensure that XWiki content is available offline

37
AdministrationManaging Users

• Registered user typically has more rights than
  someone not logged in ("XWikiGuest" vs. a member
  of "XWiki All Group")
• User registration can be done with confirmation
  e-mail or just by declaring users data
  (first/last name, blog address, etc.)
• Reset password is
• Deleting user delete his/her object
• Log in as one of adminstrators
• Click top-right link "Administration"
• Open tab "Users Groups"
• In the "Users

38
Backups

• Export XAR files - essentially ZIP archives,
  which contain XWiki-markup pages (with
  meta-information).
• Readable and nice XAR files can be easily edited
  to select only those spaces you want to import
  back, etc.
• Downside - XAR mechanism does not work for
  sufficiently large XWiki sites (around 10M).
• Use "mysqldump" or similar database backup.

39
XWiki Offline

• http//code.xwiki.org/xwiki/bin/view/Extensions/XE
  clipseExtension
• Export XWiki and import to your local machine.
• Create the browsable off-line HTML (standard
  Web-Crawler)

40
Examples

• http//wiki.bonita.objectweb.org/xwiki/bin/view/Ma
  in/WebHome - Workflow system Bonita
• http//club.mandriva.com/xwiki/bin/view/Main/2008_
  released - Mandriva user forum

41
References

• http//www.xwiki.org/xwiki/bin/view/Main/
