Scaling up Quality of Experience-driven Delivery of Image-rich Web Applications

1
EACH IMAGE MATTERS, EVEN AMONG MILLIONS SCALING
UP QOE-DRIVEN DELIVERY OF IMAGE-RICH WEB
APPLICATIONS
BY PARVEZ AHAMMAD
2
It comes as no surprise that when it comes to
image-rich web applications, every single image
matters in defining the quality of experience
(QoE) for the end user. So how does one offer
individually-tuned settings for optimal image
delivery while being able to scale up to millions
of images across the entire web delivery
pipeline? Theres some fun math that goes into
answering this question at Instart Logic, we
call it SmartVision technology. Today, aligned
with the public release of our first formal
academic publication describing SmartVision
technology, let me use this blog post to give you
the basic ideas behind the technical core of this
technology and how it enables optimized delivery
of image-rich web applications as a whole, while
selecting individually-tuned settings for each
image within a given web application.
3
Intuitively speaking, the key to optimal delivery
of an image is to have a content-dependent
signature (or hash code) for computing the impact
of web delivery on the given image, and using
said signature to prioritize various constituent
parts of the image file. In our work, we
developed a simple computational signature that
captures the impact of web delivery pipeline on
image quality we call it VoQS (variation of
quality signature). In our experiments, we also
discovered that large corpuses of images can be
effectively split into coherent clusters based on
the VoQS similarity. Taken together, these two
simple insights combine to result in an efficient
algorithmic approach SmartVision for finding
adaptive settings for each individual image,
delivered via a web delivery service. For
technical details on the algorithm and
experimental results on empirical datasets,
please see the academic publication that we are
presenting today at the ACM (Association for
Computing Machinery) Multimedia Conference. While
there is a large body of research out there on
the topics of image categorization and computer
vision-based image content analysis, our paper is
one of the first publications (to our knowledge)
where quality-dependent image categorization in
the context of web delivery is directly addressed.
4
The following flowchart shows how the SmartVision
algorithm works
5
As you can see in the flowchart, the
categorization part can be done offline (with
intermittent updates) to adapt to a changing
image corpus pooled across the web delivery
service. The real-time aspect simply depends on
efficient computation of VoQS and a
nearest-neighbor lookup against the pre-stored
exemplars, that were estimated during the offline
categorization step. While message-passing
algorithms such as Affinity Propagation Frey
Dueck, 2007 offer the advantage that one doesnt
need to pre-specify the number of expected
clusters as well as get the cluster-specific
exemplars as a side product, the algorithmic
complexity of Affinity Propagation makes it
impractical for really large image datasets (such
as the ones we encounter with our Software-Defined
Application Delivery service). In scenarios
where the image corpus is very large, one can use
faster algorithms such as K-means (with
appropriate care and safety checks) for
clustering, and choose the image exemplars by
minimizing aggregate distance in the VoQS metric
space. It is worth noting that the entire
algorithmic flow (and the categorization aspect)
happens in an unsupervised fashion so it is
highly amenable to automation in the context of
an always-on web delivery service. In our
experiments, we found that we could find optimal
delivery thresholds for a large corpus of images
quickly, while minimizing the loss of visual
quality (see Figure-3 in our ACM-Multimedia
paper). In addition, our approach is not really
dependent on any particular image format thus,
we can apply it for most of the popular image
formats used by the web community.
6
At Instart Logic, we use the SmartVision
algorithmic pipeline in two related but different
contexts. One application scenario (termed True
Fidelity Image Streaming) is to divide the image
into parts such that most relevant bits of the
image file useful for optimizing users quality
of experience (QoE) are delivered up-front in a
first-pass. This quick first-pass allows an
image-rich web application to load quickly and
delivers fast user interaction. Meanwhile,
Instart Logics client-cloud architecture
continually works in the background to enable a
seamless backfill so that the remaining details
are incorporated into the image quickly, without
impacting the interaction time, while ensuring
that the full-quality of the original image is
delivered. (Note though, that such a streaming
approach requires the user to have our thin
JavaScript-based client Nanovisor.js running in
their web browser.) So what can you do when the
client isnt installed on the target device, such
as is the case with a native mobile
application? For users who do not have an
environment that can run our JavaScript client,
we can use the SmartVision technology to
automatically determine the optimal threshold on
the server-side, and just send the part of the
image file that delivers a good QoE compared to
the original. In congested mobile networks, or
for users with low-complexity user-devices, or
other scenarios where network footprint comes at
a premium, such a server-side approach can
deliver dramatic improvement in web application
interactivity without significantly sacrificing
the visual quality-of-experience (QoE). We term
this application scenario Image Transcoding with
SmartVision. This approach allows us to improve
application delivery performance through a
server-side transformation. For further
technical details and empirical experimental
results, click on this link to access our ACM
Multimedia publication.
7
To learn more, visit our Blog
