Fiber Stripper
Description:
Depending on the performance characteristics, insertion loss, and cost there are two techniques in fiber splicer of optical fibers. They are fusion splicing and mechanical splicing. During splicing the two optical fiber cables should be properly aligned and simultaneously its geometrical factors and the mechanical strength should be taken into consideration. – PowerPoint PPT presentation
Number of Views:49
Title: Fiber Stripper
1
WELCOME TO sunmafiber.com
2
Fiber Patch Cables
Pigtail
3
Fiber Patch Cables
Pigtail
4
Patchcord Line
SUNMA OP-5000 Fiber Polishing Machine(MPO/ MTP)
The 5000 also has fully programmable pressure and
speed ramp rates for slow starting the polishing
process. It also has programmable film change
counters and maintenance section for alerting
operators when to change film or provide service
to the machine. If the number of connectors
loaded into the polishing fixture is less than
the default that has been programmed, the
automatic pressure adjustment feature allows the
operator to enter the actual number of connectors
loaded.
5
Patchcord Line
AFCM-2000 Automatic Fiber Cable Cutting Machine
Automatic Opical Fiber Cable Cutting Machine is
applied for producing fiber patchcord, and it is
a professional equipment with measuring length /
cutting and winding fuctions. It could cut
different indoor optical fibers into required
length and wind cable into circularity.
6
Fiber Cable Tools
ST-5500 Fiber Optic Splicing Tool Kit
- Fixed position for every hand tools, Convenient
to pick up. Intergrated Tool Kit applies for
fiber optic cabling, splicing telecom system. - Easy maintenance, Cable Cut-Connect Operation
Gather many kinds of brand hand tools, Solve a
variety technical - Difficulties for fiber optic cable cutting
Cleaving / stripping / slitting / cleaning.
7
Wuhan Sunma Technology Co,.LTD. Address 88,
Mingyuan Road, Optic Valley, Hongshan, Wuhan
430074, Hubei, China Tel 86-27 8720 8018,
86-27 5177 9650 Fax 86-27 5177 8865 E-mail
info_at_sunmafiber.com Website http//www.sunmafibe
r.com/
