SQL-99

1
WG3 Database Languages
Stephen Cannan Convenor 2002-05-06
2
Agenda

• Working Group changes
• ISO/IEC 9075
• ISO/IEC 20606
• Recap of recent changes
• Sketch of planned changes

3
Working Group changes

• 3 ex-WG5 subprojects absorbed
• 20606-1 Authorization and Audit
• 20606-2 Distribution Schema
• 20606-3 Encompassing Transaction
• Effect on WG3 internal structure

4
ISO/IEC 9075

• Multi-part standard
• Part 1 SQL/Framework
• Part 2 SQL/Foundation
• Part 3 SQL/CLI
• Part 4 SQL/PSM
• Part 9 SQL/MED
• Part 10 SQL/OLB
• Part 11 SQL/Schemata
• Part 13 SQL/JRT
• Part 14 SQL/XML

5
Part 1 SQL/Framework

• Common definitions concepts
• Structure of multi-part standard
• Basic conformance structure statement
• About 85 pages

6
Part 2 SQL/Foundation

• The core of the standard
• Includes
• Traditional SQL
• Object-oriented SQL
• Module Language
• Host language bindings (except Java)
• Dynamic SQL
• Direct SQL
• Excludes
• Information Schema Definition Schema (in Part
  11)
• About 1300 pages

7
Part 3 SQL/CLI

• Call-Level Interface
• Best-known implementation ODBC
• About 400 pages

8
Part 4 SQL/PSM

• Persistent Stored Modules
• PSM-96 specified
• functions procedures
• SQL-server modules
• computational completeness
• In PSM1999, functions procedures moved to
  Foundation (same in 2003)
• Analogous to PL/SQL, Transact-SQL, etc.
• About 170 pages

9
Part 9 SQL/MED

• Management of External Data
• Foreign Servers, Foreign-Data Wrappers, Foreign
  Tables
• SQL-aware vs non-SQL-aware
• Datalinks
• Merge with 20606-2 Distribution Schema
• About 500 pages

10
Part 10 SQL/OLB

• Object Language Bindings
• Embedded SQL in Java
• SQLJ Part 0
• About 360 pages

11
Part 11 SQL/Schemata

• Information Schema
• Definition Schema
• About 300 pages

12
Part 13 SQL/JRT

• Java Routines and Types
• Java routines stored in an SQL database, and
  invoked from SQL statements
• Java classes used as data types of SQL columns
• About 200 pages

13
Part 14 SQL/XML

• Under construction
• Using SQL and XML together
• About 150 pages, but still growing

14
ISO/IEC 20206

• 20606-1 Authorization and Audit
• 20606-3 Encompassing Transaction

15
Project 20206 1Authorization and Audit

• Addresses issues of
• Authentication
• Access Control
• Transfer Integrity
• Transfer Confidentiality
• Non-repudiation
• No Working Draft available
• CD expected 2002-06-01
• John Hadjioannou listed as Editor but not present

16
Project 20206 3Encompassing Transaction

• Interacts with external Transaction Managers
• Support for xa_ interface
• 9075-6 XA Specialization (SQL/Transaction)
• Propagates Global Context information
• No Working Draft available
• CD expected 2002-06-01
• Bob Sunday listed as Editor but has withdrawn

17
Recap of recent changes ISO/IEC 9075 SQL2003

• Since 1999 we have already added
• Part 9 SQL/MED
• Part 10 SQL/OLB
• Part 13 SQL/JRT
• Addendum 1 SQL/OLAP
• SQL2003 will be the 4th generation
• 1987, 1992, 1999
• Consists of
• Many error corrections(TC stands at 376 pages
  and growing)
• A few new features
• Part 14 SQL/XML

18
New Features

• Data types
• Predicates
• Semantics
• Security
• Active Database

19
New Data Types

• BIGINT
• MULTISET

20
New Data Types BIGINT

• Exact numeric, scale 0
• Precision of BIGINT ? precision of INTEGER
• Must have same radix as SMALLINT and INTEGER

21
New Data Types MULTISET

• Varying-length, unordered collections of element
  having specified type
• COL1 INTEGER MULTISET
• COL2 ROW( F1 BIGINT, F2 VARHCAR(4000)
  ) MULTISET
• No (specified) maximum cardinality
• SQL2003 collection types include
• MULTISET
• ARRAY

22
New Data Types MULTISET

• INTEGER MULTISET()
• Empty multiset with integer element type (not
  null!)
• INTEGER MULTISET(2, 3, 5, 7)
• Integer multiset with first few primes
• INTEGER MULTISET(SELECT COL1
  FROM TBL1 WHERE COL2 gt 10)
• Integer multiset populated from values in column
  of table

23
New Data Types MULTISET

• CARDINALITY (value1)
• Type of value1 must be multiset
• Returns number of elements in value
• SET (value1)
• Type of value1 must be multiset
• Returns value1 with duplicate elements removed
• ELEMENT (value1)
• Type of value1 must be multiset
• Cardinality of value1 must be 1
• Returns the single element in value1

24
New Data Types MULTISET

• UNNEST(value1) AS corr-name
• Type of value1 must be multiset
• Un-nests value1 and turns the elements into
  rows of a virtual table
• UNNEST MULTISET (2, 3, 5, 7) AS P

P
2
3
5
7
25
New Data Types MULTISET

• value1 MULTISET setop quantifier value2
• setop UNION or EXCEPT or INTERSECT
• quantifier ALL or DISTINCT
• SELECT col1 MULTISET INTERSECT DISTINCT
  col2 FROM tbl1 WHERE CARDINALITY(col2) gt 50
• Close analogs to ordinary set operators
• UNION, EXCEPT, and INTERSECT
• However, ALL is the default quantifier

26
New Data Types MULTISET

• New aggregates
• COLLECT Transform the values in a group into a
  multiset
• FUSION Form a union of the multisets in a group
  number of duplicates of a given value in the
  result is the sum of the number of duplicates in
  the multisets in the rows of the group
• INTERSECTION Form an intersection of the
  multisets in a group number of duplicates of a
  given value in the result is the minimum of the
  number of duplicates in the multisets in the rows
  of the group

27
New Predicates

• NORMALIZED
• If character string argument is in Unicode
  Normalization Form C (NFC), returns true
• MEMBER
• If first argument is a member of multiset in
  second argument, returns true
• SUBMULTISET
• If first argument is a submultiset of second
  argument, returns true
• SET
• If argument is a set (no duplicate values),
  returns true

28
NORMALIZED Predicate

• string_value IS NOT NORMALIZED
• Character repertoire of string_value must be UCS
• Encourages, but does not force, normalization to
  NFC

29
MEMBER Predicate

• value NOT MEMBER OF multiset
• multiset must be a multiset
• Type of value comparable to element type of
  multiset
• If multiset is empty, returns false
• If value is equal to some element of multiset,
  returns true
• Else, if some element of multiset is null,
  returns unknown

30
SUBMULTISET Predicate

• multiset1 NOT SUBMULTISET OF multiset2
• Both multiset1 and multiset2 must be multisets
• and their element types must be comparable
• If the cardinalities of multiset1 and multiset2
  are equal and if every value in multiset1 has a
  corresponding value in multiset2, then returns
  true

31
SET Predicate

• multiset IS NOT A SET
• multiset must be a multiset
• If there are no duplicate values in multiset,
  returns true
• Maximum of 1 null value in a set

32
New Semantics

• MERGE statement
• OLAP TABLESAMPLE
• Generated columns
• Identity columns and sequence generators

33
New Semantics MERGE

• If some row in the target table matches some row
  in the source table according to the specified
  predicate, then the row in the subject table is
  updated
• If no row in the target table matches a given row
  in the source table according to the specified
  predicate, then the row from the source table is
  inserted into the subject table

34
New Semantics MERGE

• MERGE INTO table-name AS correlation USING
  table-referenceON search-conditionWHEN MATCHED
  THEN SET col value
• MERGE INTO table-name AS correlation USING
  table-referenceON search-conditionWHEN NOT
  MATCHED THEN INSERT ( col-list ) VALUES (
  val-list )
• Both MATCHED and NOT MATCHED clauses permitted
  once each, in either order

35
TABLESAMPLE

• New feature in the OLAP capability
• Permits evaluation of aggregates on samples
  derived from database data
• Permits faster debugging when database is huge
• Two forms of sampling BERNOULLI and SYSTEM

36
TABLESAMPLE

• TABLESAMPLE method ( percentage ) repeatable

• method is either BERNOULLI or SYSTEM
• Bernoulli Sample table contains approximately
  percentage of the rows of the original table
  the probability of a given row of the original
  table appearing in the sample table is percentage
  , independently of every other row
• System Sample table contains approximately
  percentage of the rows of the original table
  the probability of a given row of the original
  table appearing in the sample table is percentage

• repeatable acts as a random number seed for
  sampling

37
Generated Columns

• Ordinary columns of base tables base columns
• Generated column value computed from values of
  zero or more base columns in same row
• CREATE TABLE EMPLOYEES ( EMP_ID INTEGER,
  SALARY DECIMAL(7,2), BONUS
  DECIMAL(7,2), TOTAL_COMP GENERATED ALWAYS AS
  ( SALARY BONUS ), HR_CLERK
  GENERATED ALWAYS AS ( CURRENT_USER
  ))

38
Identity columns Sequence generators

• Identity column Invented as mechanism to allow
  automatic population of table keys
• Sequence generator Invented to allow generation
  of next value in a sequence
• Together, they allow generation of keys for
  unique columns (or combinations of columns) when
  required
• Application chooses select value for identity
  column or let sequence generator make choice

39
Sequence generators

• Sequence generators
• Data type (exact numeric with scale zero)
• Starting value
• Increment (positive ascending, negative
  descending)
• Minimum and maximum values
• Cycle option
• External (explicit schema object) or internal
  (part of another schema object, such a column)

40
External sequence generators

• CREATE SEQUENCE seqname AS type START WITH
  value INCREMENT BY value MAXVALUE value
  CYCLE
• Variations
• NO CYCLE
• NO MAXVALUE, MINVALUE, NO MINVALUE
• Order of clauses can vary

Common sequence generator options
41
Sequence generators

• Every sequence generator has a current base
  value initially set to the start value
• Generate next value of a sequence generator
  NEXT VALUE FOR seqname
• Returns current base value N increment for
  some N ? 0
• If computed value gt MAXVALUE (or lt MINVALUE) and
  NO CYCLE, then raise an exception
• Otherwise, reset to MINVALUE (or MAXVALUE) and
  compute new value for some N.

42
Sequence generators

• INSERT INTO TBL ( COL1, COL2 ) VALUES ( 10,
  NEXT VALUE FOR seqgen )
• CALL myproc ( NEXT VALUE FOR seqgen )
• SET J J NEXT VALUE FOR seqgen

43
Sequence generators

• ALTER SEQUENCE seqname
• RESTART WITH newbase resets start of
  computation
• Common sequence generator options change start
  value, maximum or minimum, increment, cycle
  option
• DROP SEQUENCE seqname dropoption

44
Identity columns Sequence generators

• Base tables may optionally have a single identity
  column
• Data type exact numeric, scale 0 e.g., INTEGER
• Associated with internal sequence generator
• Start value
• Minimum and/or maximum value
• Increment value
• Cycle option

45
Identity columns Sequence generators

• GENERATED ALWAYS or GENERATED BY DEFAULT
• ALWAYS Not allowed to UPDATE column INSERT
  requires OVERRIDING SYSTEM VALUE
• BY DEFAULT Allowed to INSERT or UPDATE column
  if column not specified on INSERT, then value
  automatically generated

46
Identity columns Sequence generators

• CREATE TABLE employees ( EMP_ID INTEGER
  GENERATED ALWAYS AS IDENTITY START WITH
  100 INCREMENT 1 MINVALUE 10 NO
  MAXVALUE NO CYCLE, SALARY
  DECIMAL(7,2), ...,)

47
New part SQL/XML

• Out for FCD ballot
• Known not to be complete
• Current contents comprise infrastructure
  mappings of
• SQL identifiers to from XML QNames
• SQL types values onto XML schema types values
• SQL tables onto XML schema types
• Publishing functions (SQL data expressed as XML)
• New built-in type for SQL XML

48
To be addedInserting XML into an SQL database

• Transform character string containing XML text
  into an XML value
• INSERT INTO employees ( empxml )VALUES XMLPARSE
  ( 'ltemp id"15339"gtltnamegtGurney
  Hallecklt/namegtlthiredategt3998-04-25lt/hiredategtltde
  ptgtSecuritylt/deptgtlt/empgt'STRIP WHITESPACE )
• No concrete proposal yet (still working out
  issues)

49
To be addedInserting XML into an SQL database

• XMLPARSE does not validate
• But it does
• Syntax check all in-line DTDs
• Process entity references defined in such DTDs
• Apply default values defined in such DTDs
• Whitespace handling not finalized
• STRIP and
• PRESERVE are possible choices

50
To be added Validating XML in an SQL context

• Validate an XML value against an XML schema
  (possibly a DTD)
• INSERT INTO employees ( empxml )VALUES
  XMLVALIDATE ( XMLPARSE ( 'ltemp id"15339"gtltnamegtGu
  rney Hallecklt/namegtlthiredategt3998-04-25lt/hiredate
  gtltdeptgtSecuritylt/deptgtlt/empgt' STRIP WHITESPACE )
  )
• No concrete proposal yet (still working out
  issues)

51
To be added Validating XML in an SQL context

• Many remaining problems
• How to reference DTDs and schemas
• Security problems of referencing arbitrary DTDs
  and schemas
• Namespace considerations
• xsischemaLocation and xsinoNameSpaceSchemaLocati
  on might identify schemas outside the database
  a solution might involve caching schemas inside
  the database

52
To be added Retrieving XML from an SQL database

• Transform an XML value into a character string
  containing XML text
• SELECT XMLSERIALIZE ( e.empxml )INTO
  hostvarFROM emp AS eWHERE ...
• No concrete proposal yet (still working out
  issues)

53
To be addedRetrieving XML from an SQL database

• Numerous problems not yet resolved
• Precise SQL type of the function result
  (CHARACTER, CHARACTER VARYING, CHARACTER LARGE
  OBJECT)
• Actual character encoding (UTF8, UTF16, other)
  and SQLs specified character set
• Specified character encoding in prologue
• DTD or schema inference? Creation?

54
Summary

• ISO/IEC 9075
• Consolidation of changes since 1999
• Correction of errors
• New Part (SQL/XML)
• ISO/IEC 20206
• Area of concern
• Looking for
• National Body participation
• Editor(s)

55
Questions?
