RNA

1
RNA NKS Erik A. Schultes Hedgehog
Research hedgehogresearch.info June 16, 2006
2
Ribonucleic Acid Universal biopolymer
Linear, polarized
5
3
3
Ribonucleic Acid Universal biopolymer
Linear, polarized 4 distinct nitrogenous
bases (nt) RNA can store genetic info (like
DNA)
5
Cytosine
Uracil
Adenine
Guanine
3
4
Ribonucleic Acid Universal biopolymer
Linear, polarized 4 distinct nitrogenous
bases RNA can store genetic info (like DNA)
Base-pairing rules A with U C with G
5
Cytosine
Uracil
Adenine
Guanine
3
5
3
5
Guanine
Cytosine
Adenine
Uracil
Adenine
Uracil
Guanine
Cytosine
5
3
6
Double-stranded RNA Helix
7
Ribonucleic Acid Universal biopolymer
Linear, polarized 4 distinct nitrogenous
bases RNA can store genetic info (like DNA)
Base-pairing rules A with U C with G RNA
can act as an enzyme (like proteins)
5
Cytosine
Uracil
Adenine
Guanine
3
8
Single-stranded RNA
Primary Structure
9
Single-stranded RNA
Secondary Structure
Primary Structure
10
Single-stranded RNA
Secondary Structure
Primary Structure
Tertiary Structure
11
Single-stranded RNA
VS
Group I
Hammer head
HDV
Hairpin
Group II
RNAse P
12
Single-stranded RNA
16S rRNA
13
16S rRNA Universal Tree of Life
14
A New Kind of Science by Stephen Wolfram
In our everyday experience with computers, the
programs that we encounter are normally set up
to perform very definite tasks.
15
A New Kind of Science by Stephen Wolfram
In our everyday experience with computers, the
programs that we encounter are normally set up
to perform very definite tasks. Key idea What
happens if one instead just looks at simple
arbitrarily chosen programs, created without any
specific task in mind.
16
A New Kind of Science by Stephen Wolfram
In our everyday experience with computers, the
programs that we encounter are normally set up
to perform very definite tasks. Key idea What
happens if one instead just looks at simple
arbitrarily chosen programs, created without any
specific task in mind. How do such programs
typically behave?
17
A New Kind of Science by Stephen Wolfram
In our everyday experience with computers, the
programs that we encounter are normally set up
to perform very definite tasks. Key idea What
happens if one instead just looks at simple
arbitrarily chosen programs, created without any
specific task in mind. How do such programs
typically behave?
computer (hardware) ? RNA molecule program
(software) ? nucleotide sequence
18
A New Kind of Science by Stephen Wolfram
In our everyday experience with RNAs, the
sequences that we encounter are normally set up
to perform very definite tasks. Key idea What
happens if one instead just looks at simple
arbitrarily chosen sequences, created without
any specific task in mind. How do such
sequences typically behave?
/. computer (hardware) ? RNA molecule /.
program (software) ? nucleotide sequence
19
RNA NKS
What do we mean by
Arbitrary sequence? RNA behavior?
20
RNA NKS
What do we mean by
generated by random process
Arbitrary sequence? RNA behavior?
21
RNA NKS
What do we mean by
generated by random process
Arbitrary sequence? RNA behavior?
folding dynamics
22
RNA NKS
What do we mean by
generated by random process
Arbitrary sequence? RNA behavior?
folding dynamics
Rapidly converges on a unique, specific fold
Never converges on a unique, specific fold
23
RNA NKS
What do we mean by
generated by random process
Arbitrary sequence? RNA behavior?
folding dynamics
Rapidly converges on a unique, specific fold
Never converges on a unique, specific fold
Ordered
Disordered
Poly(U)
Helix
24
RNA NKS
What do we mean by
generated by random process
Arbitrary sequence? RNA behavior?
folding dynamics
Rapidly converges on a unique, specific fold
Complex
Never converges on a unique, specific fold
Evolved
Ordered
Disordered
Poly(U)
Helix
25
RNA NKS
What do we mean by
generated by random process
Arbitrary sequence? RNA behavior?
folding dynamics
Classes I II
Class IV
Class III
Rapidly converges on a unique, specific fold
Complex
Evolved
Ordered
Helix
26
RNA NKS
Analyzing RNA Behavior
1. Lead II chemical probing secondary
structure uniqueness of folding 2. Native gel
electrophoresis uniqueness of folding size of
fold 3. Analytical centrifugation size shape
of fold
27
RNA NKS
Choosing Arbitrary Sequences
Control Sequences tRNAPHE (76nt) HDV
(85nt) Ligase (87nt) Reference Sequence Poly(U)

28
RNA NKS
Choosing Arbitrary Sequences
Control Sequences tRNAPHE (76nt) HDV
(85nt) Ligase (87nt) Reference
Sequence Poly(U)85 Arbitrary Sequences 10
Permuted HDV (85nt) 10 Isoheteropolymer (85nt)
29
Automated DNA Synthesis
30
Structure Probing with Pb
31
Structure Probing with Pb
32
Structure Probing with Pb
33
Structure Probing with Pb
OH ladder
Time
T1 ladder
HDV
34
Structure Probing with Pb
OH ladder
Time
T1 ladder
HDV
35
Arbitrary sequences acquire sequence-specific
folds
36
Native Gel Electrophoresis
8 (291) 100mM THE, pH7.5 30mM KCl 0, 1, 10mM
MgCl2 3W, 2000Vhr XC 100mm T 23-24 ºC
-

37
Arbitrary sequences acquire compact folds
38
Sedimentation Velocity Experiments

Inferring molecular size and shape from the
concentration distribution of pure sample under
a centrifugal filed.
39
Sedimentation Velocity Experiments
Reference
Sample
40
Sedimentation Velocity Experiments
Meniscus
RNA
41
Sedimentation Velocity Experiments
40,000 RPM 100,000 Xg
A260
r (cm)
42
Sedimentation Velocity Experiments
S4.072 S D8.45 Ficks M25.2 kDa Rs26.2 Å
tRNA
A260
r (cm)
43
Arbitrary sequences acquire compact folds
44
The behavior of arbitrary RNA
Arbitrary sequences frequently have compact,
sequence specific folding - properties that have
always been assumed to be evolutionarily
derived.
So far 20 seq, 2 compositions (1/2 postdoc)
45
The behavior of arbitrary RNA
Arbitrary sequences frequently have compact,
sequence specific folding - properties that have
always been assumed to be evolutionarily
derived.
So far 20 seq, 2 compositions (1/2
postdoc) Next step 35,000 seq, 1700
compositions (100M)
46
The behavior of arbitrary RNA
Arbitrary sequences frequently have compact,
sequence specific folding - properties that have
always been assumed to be evolutionarily
derived.
Principle of Computational Equivalence weak RNA
PCE complex, biologically relevant folds are
abundant in seq space
47
The behavior of arbitrary RNA
Arbitrary sequences frequently have compact,
sequence specific folding - properties that have
always been assumed to be evolutionarily
derived.
Principle of Computational Equivalence weak RNA
PCE complex, biologically relevant folds are
abundant in seq space strong RNA PCE specific
folds may be abundant in seq space
48
Distribution of Folds in RNA Sequence Space
49
Prototype Ribozymes
50
Intersection Sequence
51
Testing for Ligation Cleavage
52
Connecting the Prototypes by Neutral Paths
53
Connecting the Prototypes by Neutral Paths
Prototype Ligase
42 mutations
54
Connecting the Prototypes by Neutral Paths
Prototype Ligase
42 mutations
44 mutations
Prototype HDV
55
Intersection of Fitness Landscapes
56
Conclusion

• RNA NN exist -
• seq space is highly redundant in folds

2. Different NN are proximal
Biological Implications
1. New folds from existing folds
2. RNAs with different sequences and folds
could still share ancestry
57
NKS and Neutral Networks
1. Are INT sequences typical or rare?
2. Are sequences on NN typical or evolved?
58
NKS and Neutral Networks
1. Are INT sequences typical or rare?
2. Are sequences on NN typical or evolved?
3. Does CA rule space have NN? 4. If so, are
there INT rules?
59
Acknowledgments
David P. Bartel Whitehead Institute NSF/Alfred
P. Sloan Fellowship TMF/Charles A. King Trust
Fellowship
