How To Build A Home Network

1
How To Build A Home Network

• Houliang Li
• December 4, 1999

2
I. Review of Home LANs

• History of home LANs
• Why do we need home LANs?
• The best model for your home LAN

FOR MORE INFO...

• Contact houliang_li_at_yahoo.com

3
History of home LANs

• Phase I Single computer in a home
• Phase II Two machines in a home
• Phase III Home LANs inspired by the

  Internet
• Phase IV The future of home LANs

4
Why do we need home LANs?

• File sharing
• Resource sharing
• Equipment revival
• Cost cutting

FOR MORE INFO...

• Contact houliang_li_at_yahoo.com

5
The best model for your home LAN

• Peer-to-peer network
• Client/server network
• Hybrid network

6
II. The Physical Network for Your Home LAN

• Comparing different topologies
• Network interface cards
• Alternative approaches to Home LAN

7
Comparing different topologies

• The bus topology
• The star topology
• The token ring

FOR MORE INFO...
Contact houliang_li_at_yahoo.com
8
Network interface cards

• Internal NIC
• BNC type NIC
• RJ-45 type NIC
• BNC/RJ-45 combo card

9
Network interface cards (cont.)

• External NIC
• PCMCIA type II combo card
• USB Ethernet converter

10
Alternative methods of building your home
network

• Phoneline network
• Wireless network
• Fast Ethernet network

11
III. Communication Protocols for Your Home LAN

• Networking protocol stacks
• Choosing your best protocols

FOR MORE INFO...
Contact houliang_li_at_yahoo.com
12
Networking protocol stacks

• NetBEUI
• IPX/SPX
• TCP/IP

FOR MORE INFO...
Contact houliang_li_at_yahoo.com
13
Choosing your best protocols

• If you do not plan to share Internet access...
• If you need to share your only phone line and
  ISP account...
• If you are a multi-player gaming enthusiast...

FOR MORE INFO...
Contact houliang_li_at_yahoo.com
14
IV. Configuring Your Machines on the LAN

• Checking and adding network components
• Software configuration
• Sharing resources
• Mapping shared resources

FOR MORE INFO...
Contact houliang_li_at_yahoo.com
15
Checking and adding network components

• Client for Microsoft Networks
• Look for the newly installed NIC
• File and printer sharing for Microsoft Networks
• Add missing components

FOR MORE INFO...
Contact houliang_li_at_yahoo.com
16
Software configuration

• Configure TCP/IP stack
• File and Print Sharing
• Primary Network Logon
• Removing useless network components
• Setting up Identification and Access Control tabs

17
Sharing resources
FOR MORE INFO...
18
Mapping shared resources
19
V. Using and Maintaining Your Home LAN

• Welcome to the networked world of the new
  millennium
