Timed I/O Automata: A Mathematical Framework for Modeling and Analyzing Real-Time Systems

1
Timed I/O Automata A Mathematical Framework for
Modeling and Analyzing Real-Time Systems

• Frits Vaandrager, University of Nijmegen
• joint work with
• Dilsun Kaynar and Nancy Lynch, MIT
• Roberto Segala, University of Verona

FV supported by EU IST project AMETIST
2
Objectives

• A mathematical framework for modeling and
  analyzing real-time systems
• Focus on expressiveness rather than on automatic
  verification
• System designers can use this framework for
• Decomposition of complex system descriptions into
  manageable pieces
• Description at multiple levels of abstraction
• Statement and proof of safety, liveness and
  performance properties

3
Contributions

• Improved formal model for real-time systems
• Interesting special case of hybrid I/O automata
• Simplified treatment of receptivity
• The problem with timed automata is that if you
  compose them you get deadlocks (George
  Logothetis, RTSS03)

4
Evolution of the Framework
Previous timed I/O automaton models Merritt,
Modugno, Tuttle (91) tasks, upper and lower
bounds Lynch, Vaandrager (91) generalizes MMT
model
Hybrid I/O automata framework Lynch, Segala,
Vaandrager (96,03)
Timed I/O automata framework Kaynar, Lynch,
Segala, Vaandrager
5
Describing Timed Behavior

• Variable v
• Static type, type(v)
• Dynamic type, dtype(v) allowed trajectories
  for v
• Functions from time intervals to type(v)
• Valuation for V assigns value in type(v) to
  each v in V
• Trajectory
• Models evolution of variables over time interval
  I
• I-trajectory for V maps I to valuations for V
  restriction to
  each v is in dtype(v)
• Hybrid sequence
• Models a series of discrete and continuous
  changes
• ?0 a1 ?1 a2 ?2 , alternating sequence of
  trajectories and actions

6
Timed Automaton (TA)

• X internal variables
• Q states, a set of valuations of X
• T start states, a non-empty subset of Q
• E, H external, internal actions
• D ? Q ? (E ? U) ? Q discrete transitions
• T a set of trajectories for X such that ?(t) ? Q
  for all t in domain(?)

7
Automaton Channel(b, M) where b ? R
Variables X discrete queue ? (M ? R) initially
empty analog now ? R
initially 0 States Q val(X) Actions
A external send(m), receive(m) where m ? M
Transitions D external send(m)
effect add (m, nowb) to queue

external receive(m, local u)
precondition
(m,u) is the first element
of queue
urgency u now
effect remove first element of queue
Trajectories T satisfies
constant(queue)
d(now)1
8
Automaton Synch(u,?)i where u ? R, 0 ? ? lt 1, i
? I Variables X discrete nextsend, maxother
? R initially 0
analog physclock ? R initially 0 Derived
Variables logclock max(maxother, physclock)
States Q val(X) Actions A external
send(m)i,receive(m)j,i where m ? R, j ? I, j ?
i Transitions D external send(m)i

precondition mphysclock ? physclocknextsend

urgency true
effect nextsend nextsend u

external receive(m)j,i
effect maxother max(maxother,m)
Trajectories T satisfies
constant(nextsend), constant(maxother)
1- ? ?
d(physclock) ? 1 ?
9
Executions and Traces

• Execution fragment
• Hybrid sequence ?0 a1 ?1 a2 ?2 , where
• Each ?i is a trajectory of the automaton and
• Each (?i.lstate, ai1 , ?i1.fstate) is a
  discrete transition
• Execution
• Execution fragment beginning in a start state
• Trace
• Restrict to external actions and trajectories
  over empty set of variables

10
Implementation Relationships

• A implements B if they have the same external
  interface and traces(A) ? traces(B)
• Simulation relations provide sufficient
  conditions for showing that one automaton
  implements another
• Several types of simulation relations (forward,
  backward, history, prophecy) have been defined
  for timed automata

11
Forward Simulation from A to B

• Relation R from QA to QB satisfying
• Every start state of A related to some start
  state of B
• If x R y and ? is a step of A starting with x,
  then there is an execution fragment ? starting
  with y such that trace(?) trace(?), and
  ?.lstate R ?.lstate
• y ?
  ?.lstate
• R
  R
• x ?
  ?.lstate
• If x R y and ? is a closed trajectory of A
  starting with x, then there is

12
Simulation Theorems

• Theorem If there is a simulation relation from
  A to B then A implements B.

13
Example Simulation

• Automaton SendVal(u,?)i where u ? R, 0 ? ? lt 1,
  i ? I
• Variables X discrete counter ? N initially 0
• analog now? R initially
  0
• States Q val(X)
• Actions A external send(m)i, receive(m)j,i
  where m ? M, j ? I, j ? i
• Transitions D external send(m)i
• precondition
  m counter ? u ? counter ? u / (1 ?) ? now
• urgency now
  counter ? u / (1- ?)
• effect counter
  counter 1
• external
  receive(m)j,i
• Trajectories T satisfies
•
  constant(counter)
• d(now)1

14
Forward Simulation Relation R

• Suppose that
• x is a state of Synch(u,?)i ,
• y is a state of SendVal(u,?)i
• Then x R y provided that the following conditions
  hold
• y(now) (1 - ?) ? x(physclock) ? y(now)(1 ?)
• y(counter) x(nextsend)/u

15
Composition

• Assume A1 and A2 are compatible (internal actions
  are private). Then, A A1 A2 is the following
  automaton
• X X1 ? X2
• States Q Projections in Q1, Q2
• E (E1 ? E2 ) H(H1 ? H2 )
• Start states, discrete steps, trajectories
  Projections
• Projection/pasting theorem
• If A A1 A2 then traces(A) is the set of
  hybrid sequences (of the right type) whose
  restrictions to A1 and A2 are traces of A1 and
  A2, resp.
• Substitutivity theorem
• If A1 implements A2 and both are compatible with
  B, then A1 B implements A2 B.

16
Example Clock Synchronization Network
C2,1
send(m)
receive(m)
S1
S2
send(m)
receive(m)
C1,2
send(m)
send(m)
C1,3
receive(m)
C2,3
receive(m)
receive(m)
C3,1
receive(m)
C3,2
S3
send(m)
17
Invariants for Clock Synchronization Network

• The difference between any physical clock and the
  real time at time t is at most t?
• The difference between any two physical clock
  values is at most 2t?
• (Validity) The logical clock values of all the
  processes are always between the minimum and the
  maximum physical clock values in the system
• All the logical clocks differ from real time at
  time t by at most t?
• (Agreement) The difference between two logical
  clocks is always bounded by u b(1?)

18
Timed I/O Automata (TIOA)

• A TIOA is a TA where the set of external actions
  is partitioned into inputs and outputs
• Inputs model actions of the environment
• Outputs model external actions under the
  systems control
• Two additional axioms are required to hold
• (Input enabling) A TIOA is able to accommodate
  an input action whenever it arrives
• (Time-passage enabling) A TIOA either allows
  time to advance forever, or it allows time to
  advance for a while, up to a point where it is
  prepared to react with some locally controlled
  action

19
Example From TA to TIOA

• Channel(b, M) can be turned into a TIOA
• Classify send actions as inputs
• Classify receive actions as outputs
• Synch(u, ?)i , can be turned into a TIOA
• Classify send actions as outputs
• Classify receive actions as inputs

20
I/O Feasibility

• An automaton is I/O feasible if it is capable of
  providing some response from any state, for any
  sequence of input actions and any amount of
  intervening time-passage.
• A basic requirement for a reasonable TIOA
• I/O feasibility is not preserved by composition
  of TIOAs
• Search for a condition that implies I/O
  feasibility and is preserved by composition

21
Progressive TIOAs

• A TIOA is progressive if it never generates
  infinitely many locally controlled actions in
  finite time
• Theorem Every progressive TIOA is I/O feasible
• Theorem Composition of progressive TIOAs is
  progressive

22
Receptive TIOAs

• But progressiveness is not enough
• TIOAs involving only upper bounds on timing are
  not progressive
• A strategy for a TIOA A is a TIOA that is the
  same as A except that it restricts the sets of
  discrete steps and trajectories
• TIOA is receptive if it has a progressive
  strategy
• Theorem Every receptive TIOA is I/O feasible
• Theorem If A1 and A2 are compatible receptive
  TIOAs with progressive strategies B1 and B2, then
  A1 A2 is receptive with progressive strategy
  B1 B2

23
Example Receptiveness

• Channel(b, M) is not progressive
• Allows an infinite execution in which send and
  receive actions alternate without any time
  passage in between
• Channel(b, M) is receptive
• Has a progressive strategy add condition unow
  to precondition of receive so that messages are
  delivered exactly at their delivery deadline
• Synch(u,?)i is receptive
• The clock synchronization network is receptive

24
Related Work

• Alur-Dill timed automata
• Uppaal/Kronos/IF/...
• Linear hybrid automata
• Hytech
• Work of Sifakis et al on TAs with deadlines
• Previous I/O automaton based models

25
Conclusions and Future Work

• The TIOA framework is a new modeling framework
  for timed systems
• Special case of new HIOA model
• General enough to collect and summarize previous
  timed I/O automata work
• Establishes formal relationships with other
  models
• Tool development project in progress
• Extension of the IOA language
• Automatic translation to UPPAAL
• More details in monograph
• The Theory of Timed I/O Automata. Available at
  http//theory.lcs.mit.edu/tds/reflist.html
