An Array of FDA Efforts in Pharmacogenomics

1
An Array of FDA Efforts in Pharmacogenomics

• Weida Tong
• Director, Center for Toxicoinformatics, NCTR/FDA
• Weida.tong_at_fda.hhs.gov

CAMDA 08, Boku University, Vienna, Austria, Dec
4-6, 2008
2
Pipeline Problem Spending More, Getting Less
While research spending (Pharma and NIH) has
increased, fewer NMEs and BLAs have been
submitted to FDA
3
The FDA Critical Path to New Medical Products

• Pharmacogenomics and toxicogenomics have been
  identified as crucial in advancing
• Medical product development
• Personalized medicine

4
Guidance for Industry Pharmacogenomic Data
Submissions
www.fda.gov/cder/genomics
www.fda.gov/cder/genomics/regulatory.htm
5
A Novel Data Submission Path - Voluntary
Genomics Data Submission (VGDS)

• Defined in Guidance for Industry on
  Pharmacogenomics (PGx) Data Submission (draft
  document released in 2003 final publication,
  2005)
• To encourage the sponsor interacting with FDA
  through submission of PGx data at the voluntary
  basis
• To provide a forum for scientific discussions
  with the FDA outside of the application review
  process.
• To establish regulatory environment (both the
  tools and expertise) within the FDA for
  receiving, analyzing and interpreting PGx data

6
VGDS Status

• Total of gt40 submissions have been received
• The submissions contain PGx data from
• DNA Microarrays
• Proteomics
• Metabolomics
• Genotyping including Genome wide association
  study (GWAS)
• Others
• Bioinformatics has played an essential role to
  accomplish
• Objective 1 Data repository
• Objective 2 Reproduce the sponsors results
• Objective 3 Conduct alternative analysis

7
FDA Genomic Tool ArrayTrack Support FDA
regulatory research and review

• Developed by NCTR/FDA
• Develop 1 An integrated solution for microarray
  data management, analysis and interpretation
• Develop 2 Support meta data analysis across
  various omics platforms and study data
• Develop 3 SNPTrack, a sister product in
  collaboration with Rosetta
• FDA agency wide application
• Review tool for the FDA VGDS data submission
• gt100 FDA reviewers and scientists have
  participated the training
• Integrating with Janus for e-Submission

8
ArrayTrack An Integrated Solution for omics
research
Clinical and non-clinical data
Chemical data
ArrayTrack
9
(No Transcript)
10
Specific Functionality Related to VGDS

• Phenotypic anchoring
• Systems Approach

Gene
Gene name is hidden
Clinical pathology data
CLinChem name is hidden
11
ArrayTrack-Freely Available to Public
Web-access
Local installation
of unique users calculated quarterly

• To be consistent with the common practice in the
  research community
• Over 10 training courses have been offered,
  including two in Europe
• Education Part of bioinformatics course in UCLA,
  UMDNJ and UALR
• Eli Lilly choose ArrayTrack to support its
  clinical gene-expression studies after rigorously
  assessing the architectural structure,
  functionality, security assessments and custom
  support

12
ArrayTrack Website
http//www.fda.gov/nctr/science/centers/toxicoinfo
rmatics/ArrayTrack/
13
MicroArray Quality Control (MAQC) - An FDA-Led
Community Wide Effort to Address the Challenges
and Issues Identified in VGDS

• QC issue How good is good enough?
• Assessing the best achievable technical
  performance of microarray platforms (QC metrics
  and thresholds)
• Analysis issue Can we reach a consensus on
  analysis methods?
• Assessing the advantages and disadvantages of
  various data analysis methods
• Cross-platform issue Do different platforms
  generate different results?
• Assessing cross-platform consistency

14
MAQC Way of Working
Participants Everyone was welcome however,
cutoff dates had to be imposed. Cost-sharing Ever
y participant contributed, e.g., arrays, RNA
samples, reagents, time and resources in
generating and analyzing the MAQC
data Decision-making Face-to-face meetings
(1st, 2nd, 3rd, and 4th) Biweekly, regular MAQC
teleconferences (gt20 times) Smaller-scale
teleconferences on specific issues
(many) Outcome Peer-reviewed publication Followe
d the normal journal-defined publication
process 9 papers submitted to Nature
Biotechnology 6 accepted and 3 rejected Transpare
ncy MAQC Data is freely available at GEO,
ArrayExpress, and ArrayTrack RNA samples are
available from commercial vendors
15
MicroArray Quality Control (MAQC) project Phase
I
Feb 2005

• MAQC-I Technical Performance
• Reliability of microarray technology
• Cross-platform consistency
• Reproducibility of microarray results
• MAQC-II Practical Application
• Molecular signatures (or classifiers) for risk
  assessment and clinical application
• Reliability, cross-platform consistency and
  reproducibility
• Develop guidance and recommendations

137 scientists from 51 ORG
MAQC-I
Sept 2006
MAQC-II
gt400 scientists from gt150 ORG
Dec 2008
16
Results from the MAQC-I Study Published in Nature
Biotechnology on Sept/Oct 2006

• Six research papers
• MAQC Main Paper
• Validation of Microarray Results
• RNA Sample Titrations
• One-color vs. Two-color Microarrays
• External RNA Controls
• Rat Toxicogenomics Validation

Nat. Biotechnol. 24(9) and 24(10s), 2006
Plus Editorial Nature Biotechnology Forewo
rd Casciano DA and Woodcock J Stanford
Commentary Ji H and Davis RW FDA Commentary
Frueh FW EPA Commentary Dix DJ et al.
17
Key Findings from the MAQC-I Study

• When standard operating procedures (SOPs) are
  followed and the data is analyzed properly, the
  following is demonstrated
• High within-lab and cross-lab reproducibility
• High cross-platform comparability, including one-
  vs two-color platforms
• High correlation between quantitative gene
  expression (e.g. TaqMan) and microarray platforms
• The few discordant measurements were found,
  mainly, due to probe sequence and thus target
  location

18
How to determine DEGs - Do we really know what
we know

• A circular path for DEGs
• Fold Change biologist initiated (frugal
  approach)
• Magnitude difference
• Biological significance
• P-value statistician joined in (expensive
  approach)
• Specificity and sensitivity
• Statistical significance
• FC (p) A MAQC findings (statistics got to know
  its limitation)
• The FC ranking with a nonstringent P-value
  cutoff, FC (P), should be considered for class
  comparison study
• Reproducibility

19
Nature
Science
Nature Method
Cell
Analytical Chemistry
20
Post-MAQC-I Study on Reproducibility of DEGs - A
Statistical Simulation Study
Lab 1
Lab 2
P vs FC
POG
Reproducibility
21
How to determine DEGs- Do we really know what we
dont know

• A struggle between reproducibility and
  specificity/sensitivity
• A monotonic relationship between specificity and
  sensitivity
• A ??? relationship between reproducibility and
  specificity/sensitivity

22
More on Reproducibility

• General impressions (conclusions)
• Reproducibility is a complicated phenomena
• No straightforward way to assess the
  reproducibility of DEGs
• Reproducibility and statistical power
• More samples ? higher reproducibility
• Reproducibility and statistical significance
• Inverse relationship but not a simple trade-off
• Reproducibility and the gene length
• A complex relationship with the DEG length
• Irreproducible not equal to biological irrelevant
• If two DEGs from two replicated studies are not
  reproducible, both could be true discovery

23
MicroArray Quality Control (MAQC) project Phase
II
Feb 2005

• MAQC-I Technical Performance
• Reliability of microarray technology
• Cross-platform consistency
• Reproducibility of microarray results
• MAQC-II Practical Application
• Molecular signatures (or classifiers) for risk
  assessment and clinical application
• Reliability, cross-platform consistency and
  reproducibility
• Develop guidance and recommendations

137 scientists from 51 ORG
MAQC-I
Sept 2006
MAQC-II
gt400 scientists from gt150 ORG
Dec 2008
24
Application of Predictive Signature
Treatment
Long term effect
Clinical application (Pharmacogenomics)
Treatment outcome
Prognosis
Diagnosis
Short term exposure
Long term effect
Safety Assessment (Toxicogenomics)
Prediction
Phenotypic anchoring
25
Challenge 1
Batch effect
Data Set
QC
Which QC methods
Normalization
e.g. Raw data, MAS5, RMA, dChip, Plier
Preprocessing
How to generate an initial gene pool for modeling
Feature Selection
P, FC, p(FC), FC(p)
Classifier
Which methods KNN, NC, SVM, DT, PLS

• How to assess the success
• Chemical based prediction
• Animal based prediction

Validation
26
Challenge 2 Assessing the Performance of a
Classifier
Prediction Accuracy Sensitivity, Specificity
1
Robustness Reproducibility of signatures
3
2
Mechanistic Relevance Biological understanding
27
Dataset Set
QC
A consensus approach (12 teams)
Normalization
Preprocessing
Freedom of choice (35 analysis teams)
Feature Selection
Classifier
Validation, validation and Validation!
Validation
28
What We Are Looking For

• Which factors (or parameters) critical to the
  performance of a classifier
• A standard procedure to determine these factors
• The procedure should be the dataset independent
• A best practice - Could be used as a guidance to
  develop microarray based classifiers

29
Three-Step Approach
Step1 Training set
Step 2 Blind test set
Step 3 Future sets
New exp for selected endpoints
Prediction

1. Classifiers
2. Sig. genes
3. DAPs

Assessment
Validate the Best Practice
Frozen
Best Practice
30
MAQC-II Data Sets
Providers Datasets Size Size
Providers Datasets Step 1 - Training Step 2 - Test
MDACC Breast cancer 130 100
UAMS Multiple myeloma 350 209
Univ. of Cologne Neuroblastoma 251 300
Hamner The lung tumor 70 (18 cmpds) 40 (5 cmpds)
Iconix Non-genotoxic hepatocarcinogenicity 216 201
NIEHS Liver injury (Necrosis) 214 204
Clinical data
Toxicogenomics data
31
Where We Are
Step1 Training set
Step 2 Blind test set
Step 3 Future sets
New exp for selected endpoints
Prediction

1. Classifiers
2. Sig. genes
3. DAPs

Assessment
Validate the Best Practice
Frozen
Best Practice
32
18 Proposed Manuscripts

• Main manuscript - Study design and main findings
• Assessing Modeling Factors (4 proposals)
• Prediction Confidence (5 proposals)
• Robustness (3 proposals)
• Mechanistic Relevance (2 proposals)
• Consensus Document (3 proposals)

33
Consensus Document (3 proposals)
Modeling

1. Principles of classifier development Standard
   Operating Procedures (SOPs)
2. Good Clinical Practice (GCP) in using microarray
   gene expression data
3. MAQC, VXDS and FDA guidance on genomics

Assessing
Consensus
Guidance
34
Best Practice Document

• One of the VGDS and MAQC objectives is to
  communicate with the private industry/research
  community to reach consensus on
• How to exchange genomic data (data submission)
• How to analyze genomic data
• How to interpret genomic data
• Lessons Learned from VGDS and MAQC have led to
  development of Best Practice Document (Led by
  Federico Goodsaid)
• Companion to Guidance for Industry on
  Pharmacogenomic Data Submission (Docket No.
  2007D-0310). (http//www.fda.gov/cder/genomics/con
  ceptpaper_20061107.pdf)
• Over 10 pharmas have provided comments

35
An Array of FDA Endeavors- Integrated Nature of
VGDS, ArrayTrack, MAQC and Best Practice Document
36
Member Of Center for Toxicoinformatics
