Lecture 8: CoreConnect and The PLB Bus

1
ECE 412 Microcomputer Laboratory

• Lecture 8 CoreConnect and The PLB Bus

2
Outline

• Bus protocol
• IBM CoreConnect
• PLB bus overview
• PLB timing

3
Review Question 1

• What interfaces do the Virtex-II Pros PowerPC
  cores provide to communicate with user logic?

4
Review Question 1

• What interfaces do the Virtex-II Pros PowerPC
  cores provide to communicate with user logic?
• PLB (Processor Local Bus)
• OPB (On-Chip Peripheral Bus)
• OCM (On-Chip Memory) Controller
• Interrupt Controller
• Device Control Register
• Clock, Power Management
• JTAG Port

5
Review Questions 2

• How does ADC work?

6
Review Questions 2

• How does ADC work?
• It contains a DAC
• ADC guesses an encoding d and evaluates its guess
  by inputting d into the DAC
• Compare the generated analog output e from DAC
  with e using an analog comparator
• Use a binary-search method and do this until a
  match is found

7
An Example (as promised)
Given an analog input signal with voltage range
from 0 to 15 volts, and an 8-bit digital
encoding, calculate the correct encoding for 5
volts. Then trace the binary search approach to
find the correct encoding. 5/15 d/(28-1) d 85
Encoding as calculated 01010101
Successive-approximation (binary search) method
½(Vmax Vmin) 7.5 volts Vmax 7.5 volts.
½(5.63 4.69) 5.16 volts Vmax 5.16 volts.
½(7.5 0) 3.75 volts Vmin 3.75 volts.
½(5.16 4.69) 4.93 volts Vmin 4.93 volts.
½(7.5 3.75) 5.63 volts Vmax 5.63 volts
½(5.16 4.93) 5.05 volts Vmax 5.05 volts.
½(5.63 3.75) 4.69 volts Vmin 4.69 volts.
½(5.05 4.93) 4.99 volts
8
A simple bus

• Wires
• Uni-directional or bi-directional
• One line may represent multiple wires
• Bus
• Set of wires with a single function
• Address bus, data bus
• Or, entire collection of wires
• Address, data and control
• Associated protocol rules for communication

9
Ports
bus

• Conducting device on periphery
• Connects bus to processor or memory
• Often referred to as a pin
• Actual pins on periphery of IC package that plug
  into socket on printed-circuit board
• Sometimes metallic balls instead of pins
• Today, metal pads connecting processors and
  memories within single IC
• Single wire or set of wires with single function
• E.g., 12-wire address port

10
Timing Diagrams

• Most common method for describing a communication
  protocol
• Protocol may have subprotocols
• Called bus cycle, e.g., read and write
• Each may be several clock cycles
• Read example
• rd/wr set low, address placed on addr for at
  least tsetup time before enable asserted, enable
  triggers memory to place data on data wires by
  time tread

rd'/wr
enable
addr
data
tsetup
tread
read protocol
rd'/wr
enable
addr
data
tsetup
twrite
write protocol
11
Basic protocol concepts

• Actor master initiates, servant (slave) respond
• Master device that can start transactions on the
  bus
• Slave device that can only respond to
  transactions
• Direction sender, receiver
• Addresses special kind of data
• Specifies a location in memory, a peripheral, or
  a register within a peripheral
• Time multiplexing
• Share a single set of wires for multiple pieces
  of data
• Saves wires at expense of time

Time-multiplexed data transfer
Master
Servant
Master
Servant
req
req
data(150)
data(150)
addr
data
addr
data
mux
demux
mux
demux
data(8)
addr/data
req
req
addr/data
data
data serializing
address/data muxing
12
Basic protocol concepts control methods
13
A strobe/handshake compromise
Master
Servant
req
wait
data
req
1
3
req
1
4
wait
wait
3
2
data
4
2
data
5
taccess
taccess
1. Master asserts req to receive data
1. Master asserts req to receive data
2. Servant puts data on bus within time taccess
2. Servant can't put data within taccess, asserts
wait ack
3. Servant puts data on bus and deasserts wait
(wait line is unused)
3. Master receives data and deasserts req
4. Master receives data and deasserts req
4. Servant ready for next request
5. Servant ready for next request
Fast-response case
Slow-response case
14
Three Different Buses in CoreConnect

• The PLB on-chip bus is used in highly integrated
  systems. It supports read and write data
  transfers between master and slave devices
  equipped with a PLB interface and connected
  through PLB signals.
• Lower-performance peripherals are attached on the
  on-chip peripheral bus (OPB). A bridge is
  provided between the PLB and OPB to enable data
  transfer by PLB masters to and from OPB slaves.
• The device control register (DCR) bus is used
  primarily for accessing status and control
  registers within the various PLB and OPB masters
  and slaves. It is meant to off-load the PLB from
  the lower-performance status and control read and
  write transfers

15
IBM CoreConnect
16
CoreConnect Main Features

• CoreConnect, the IBM PowerPC processor bus, has
  been licensed at no cost to more than 1500 IP
  developers in the past decade.
• In addition, IBM provides a bridge to the I/O
  core solutions of IP supplier ARM. This enables
  ARM solutions to be used in Power
  Architecture-based designs.
• Peripheral options include memory controllers,
  direct memory access (DMA) controllers, PCI
  interface bridges and interrupt controllers, etc.

• When combined with SystemC models, available
  peripherals and design services, a complete
  PowerPC solution from system-level design to
  implementation can be realized.

17
Another View
Supporting ARM I/O cores (AHB) Advanced
Microcontroller Bus Architecture (AMBA) advanced
high-performance bus
18
PLB Overview

• PLB is a 64-bit bus format that supports multiple
  master and slave devices
• Also supports 32-bit devices
• Each master device is assigned a priority so that
  the bus can arbitrate when multiple masters want
  to use the bus
• Slave devices are assigned one or more regions of
  addresses that they are responsible for handling
  requests
• Our designs will use both the PowerPC and your
  logic as bus masters
• PowerPC 405 supports two PLB interfaces
• Instruction-side PLB for loading instructions
  into cache
• IPLB is read-only
• Data-side PLB (read-write) for data
• Can tie both buses together if desired

19
Instruction-Side PLB

• Read-only bus
• Allows PowerPC to request instructions from
  off-chip devices
• Supports four-word and eight-word transfers into
  instruction unit

20
Data-Side PLB

• Supports reads and writes
• One- and eight-word transfers
• Uncacheable data typically one-word transfer
• Can configure PowerPC to fetch multiple-word
  uncacheable blocks

21
Data-Side PLB Signals

• Signaling convention
• C405PLB at the beginning of a signal name
  indicates an output from the PowerPC to the PLB
• PLBC405 at the beginning of a signal name
  indicates an input to the PowerPC from the PLB
• Signal names are of the form PLBC405
  C405PLBDCUltnamegt
• Well use the ltnamegt portion of each signal to
  avoid wasting half of each slide on signal names

22
Data-Side PLB Signals

• REQUEST Indicates that the PowerPC is initiating
  a request over the PLB bus
• RNW, ABUS031, SIZE2, CACHEABLE, WRITETHRU,
  U0ATTR, GUARDED, CUBE07 must be valid when
  REQUEST is asserted and remain valid until the
  end of the cycle when the request is acknowledged
• RNW Indicates whether the request is a read or
  write
• Asserted read, De-asserted write
• ABUS031 Address bus
• Byte-addressed
• Single-word transfers may fetch only portions of
  a word, controlled by the DCUBE signal

23
Data-Side PLB Signals

• SIZE2 Specifies size of the request
• Asserted eight-word, De-asserted one-word
• CACHEABLE Is data at this address cacheable?
• Asserted cacheable, de-asserted un-cacheable
• Un-cacheable data typically accessed using
  one-word requests
• Can set a configuration bit in the PowerPC to
  request eight-word uncacheable data blocks
• WRITETHRU Indicates whether data at the address
  is in write-through or write-back cacheable
  memory
• Asserted write-through, De-asserted
  write-back
• Mostly used in systems with cache coherence

24
Data-Side PLB Signals

• U0ATTR Gives the value of the U0 (user 0)
  attribute bit for this address
• Flag that can be set in processor register
• GUARDED Indicates whether address is in guarded
  storage
• CUBE07 Indicates which bytes of a single-word
  transaction are being transferred
• Restrictions exist on which combinations can be
  transferred
• PRIORITY01 Priority of the request
• Used to arbitrate between multiple bus masters
• ABORT Abort current transaction
• Requirements about how PowerPC and device handle
  aborts at different times

25
Data-Side PLB Signals

• WRDBUS063 Output data bus from PowerPC to PLB
• ADDRACK Indicates that PLB bus device has seen
  the request and latched the appropriate control
  signals
• May be asserted as early as the same cycle as
  REQUEST
• SIZE1 Indicates whether the device handling a
  request supports 32- or 64-bit transfers
• Asserted 64-bit, De-asserted 32-bit
• Valid during same cycle as ADDRACK
• RDDBUS063 Data bus from PLB to PowerPC

26
Data-Side PLB Signals

• DWDADDR13 Indicates which word of an
  eight-word transfer is present on the data bus
• Device can return words in any order
• WRDACK Indicates that device has latched the
  data being written on the WRDBUS
• PowerPC must hold data on the bus until
  acknowledged
• BUSY Indicates that the PLB bus device is
  processing a request
• Doesnt always prevent PowerPC from starting
  another request
• PowerPC checks signal during SYNC operations
• ERR Device detected an error in processing
  request
• Slave still completes request, processor decides
  how to handle

27
Timing of PLB Transactions

• PLB device can acknowledge a request as early as
  the cycle when the request is asserted
• PowerPC required to assert request and control
  signals continuously until device acks.
• PowerPC drives write data in the same cycle as
  request, holds until getting write ack.
• Device can return read data as early as the cycle
  after it acknowledges read request
• PowerPC can pipeline up to two line read requests
• Pipeline means to start a second request before
  first completes
• Device is required to complete requests in order

28
PLB Timing Consecutive Word Reads
29
PLB Timing Pipelined Block Reads
30
PLB Timing Consecutive Line Writes
31
Documentation

• PowerPC 405 Processor Block Reference Guide
• PLB IPIF v2.01a Document
• Describes Xilinx customizable cores that
  interface to PLB
• Platform Specification Format Reference Manual
• Describes the different files used to build a SoC
  system
• Shows you whats going on under the hood of the
  GUI

32
Next Time

• OPB bus
• Using IFIP Cores to connect to the PLB and OPB
  busses
