IDS

1
IDS Intrusion Detection Systems
2
Overview

• Concept An Intrusion Detection System is
  required to detect all types of malicious network
  traffic and computer usage that can't be detected
  by a conventional firewall. This includes network
  attacks against vulnerable services, data driven
  attacks on applications, host based attacks such
  as privilege escalation, unauthorized logins and
  access to sensitive files, and malware (viruses,
  trojan horses, and worms).
• Components
• Sensors which generate security events
• Console to monitor events and alerts and control
  the sensors
• Engine that records events logged by the sensors
  in a database and uses a system of rules to
  generate alerts from security events received.
• Types
• Anomaly-Based Intrusion Detection System
• Signature-Based Intrusion Detection System
• Network-Based Intrusion Detection System
• Host-based Intrusion Detection System

3
IDS mechanisms work together
Source ComputerWorld
4
Basic tools

• Enterprise systems Cisco Safe and IDS, Symantec
  Intrusion Protection, CA Host-based IPS, Network
  Intrusion- Prevention Systems, Others.
• Honeypots Honeyd Virtual Honeypot and Deception
  ToolKit
• Snort open source, from PCs to large networks
  for Linux/UNIX, Windows, Macs.
• References
• Infosyssec IDS FAQ
• SANS IDS FAQ
• SANS InfoSec Reading Room Intrusion Detection
• WindowsSecurity.com Intrusion Detection Systems
  (IDS) Classification methods techniques

5
Snort

• What is Snort?
• What can it do detect and respond
• Open source and business.
• The main Web site for Snort.
• Downloading
• Download WinPcap 3.1 (do not use newer WinPcap
  versions.)
• Download Snort for Windows or Linux
• Install and setup
• Install WinCap, then Snort, by double-clicking in
  the downloaded files. Snort is installed in
  c\snort and snort.exe is in the c\snort\bin
  directory.
• Create a login in the Snort Web account signup
  page and login.
• Go to the Download rules page and download under
  Sourcefire VRT Certified Rules - The Official
  Snort Ruleset (registered user release) the
  CURRENT file. It will look like
  snortrules-snapshot-CURRENT.tar.gz
• Extract this file to the directory c\snort and
  both signatures (under doc) and rules (under
  rules) will be created.

6
Snort

• Using snort
• at the command prompt start in c\snort\bin
  (options)
• checking available interfaces c\snort\bin
  snort -W example
• capturing and viewing packets c\snort\bin
  snort -dev (press Control-C to stop the
  capture) example
• capturing and saving in log file c\snort\bin
  snort -de -K ascii -l c\snort\log examples tcp
  arp
• log the Snort alert messages to the Windows Even
  Viewer, Applications c\snort\bin snort -E - l
  c\snort\log -c c\snort\etc\snort.confsee
  example of running in IDS mode and events in
  Event viewer.
• Modifying and creating rules
• creating rules experts only, download updates
  and read them.
• modifying not a problem typically many false
  positives are eliminated
• example I got many false positives as MISC UPnP
  malformed advertisement Classification Misc
  Attack I looked for misc.rules and edited rule
  as follows alert udp EXTERNAL_NET any -gt
  HOME_NET 1900 (msg"MISC UPnP malformed
  advertisement" content"NOTIFY " nocase In
  the example I just commented out the rule added
  in front of the line.

7
Snort

• Additional references
• Snort documentation
• a Snort Reporting Tool
• Snort IDS Policy Manager For Windows 2000/XP
• Snort-Wireless
• Securing your system with Snort in Linux
• Snort install in Win 2000/XP with Acid and MySQL
• Snort install in Linux with Acid and MySQL
• ACID - Analysis Console for Intrusion Databases
• ACID Installation and Configuration in Linux
• MySQL A free DB client and server
