1
Put your company on the Cutting Edge of concrete
floor technology!
2
Introduction
The CopperHead has helped thousand of
contractors deliver floors faster and flatter on
millions of square feet worldwide. Now Somero
has taken this walk-behind Laser Screed
innovation a step further with the introduction
of the Mini Screed C a smaller, lighter machine
that meets the needs of many of our customers
customers who look to Somero for innovation,
technology, leadership, and a competitive
advantage in the constantly changing concrete
flooring industry.
3
Introduction

• The Mini Screed C delivers the same results as
  our other
  walk-behind Laser Screeds and gives your crews
  the ability to
• Laser Screed projects that were previously to
  small
• Laser Screed on lightweight metal decks
• Screed small jobs with laser accuracy
• Screed at a lower cost than any other
  conventional method or product on the market
  today
• The Mini Screed C is a small, yet powerful,
  self-propelled, walk-behind Laser Screed thats
  small enough to fit in the bed of a pickup, but
  large enough to tackle a wide range of jobs.
• The Mini Screed C delivers outstanding
  performance slab-on-grade,
  below-grade, or on virtually
  any type of deck.

4
Yesterdays method of hand-screeding floors
5
Todays leading-edge technology of a Laser
Screed floor
Each model has its own unique applications
6
Applications

• Slab-on-Grade or Slab-on-Deck Projects
• - Fibers
• - Pulled Mesh
• - Chaired Mesh
• - Chaired Rebar
• - Double Mat Rebar
• - Post Tension
• - Precast Topping
• - Fluted Metal Deck
• - Radiant Floor Heating

7
Quality difference between todays screeding
methods

8
Maneuverability
9
LIGHTWEIGHT, COMPACT DESIGN

• Weight 470 lbs
• Width 32 outside of tires
• Head Width 68
• Height 41 without masts
• Length 72 ½

10
Screeding with the Mini Screed C
No Wet-pads or Rails needed
11
Mini Screed C Features
SSR Laser Receivers with internal 1/16 inch grade
adjustment
Adjustable Weight Distribution
Weight 470 lbs. Height 41 without
masts Length 72 ½ Width 32 outside
tires 30 ½ handle bars 83 ½ head
Automatic Operator Controls
2 Lift Points
Automatic Self Level
Robin America 6 hp Gas Engine
Quick Disconnect Head
Headlights
Adjusts 6 times per second to maintain grade
High Float Tires (standard) Skinny Tires
(optional)
Pivoting 6 8 Vibrating Screed Head
12
Easy Operation
QUICK PASS CONTROL
MANUAL RECIEVER OVERRIDE
HEADLIGHT SWITCH
VIBRATOR SWITCH
FORWARD / REVERSE SWITCH
HEADLIFT SWITCH
TIME RAISE / LOWER SWITCH
Operator Friendly - Fast Learning Curve
13
Man vs. Machine
Mini C weight 470 lbs Ground Pressure
3.9 psi
Average weight 190 lbs Ground Pressure
size 11 boot 2.2 psi
Exerts less pressure on the surface then 2 men
14
Performs on Various Applications
15
Why consider purchasing a Mini Screed C
Faster
Improve hourly productivity. Faster finishing
times. Reduce overtime expenses. Improve floor
quality. Improve concrete yields. Notice
immediate labor savings. Reduce fatigue. Retain
key personnel. Reduce workers compensation
claims. Costs less per month than one
laborer. Improve your competitive edge, win more
bids. Improve the image of your company.
Flatter
Fewer
Profitability
16
PRICING
Monthly Payments Start At 547

• Mini Screed C 27,950
• Spare Parts Kit Manuals included
• Initial On-Site Training
  included
• Destination 800
•
  28,750
• Options
• Emergency Support Kit 1,918
• Start-up Kit 3,171
• Includes tripod, column clamp, lift harnesses,
  skinny tire assy, L-500 laser transmitter
• All pricing is in US Funds and subject to change
• 800 Destination is valid for the continental US
  only
• Note additional training trips 1,500 each if
  needed

with first last down, 60 months, 10 buy out
17
Standard and Optional Equipment
OPTIONAL START-UP KIT LL-500 non-sloping
Laser Transmitter Tripod Column Clamp Skinny
Tires Wheel Assy. Lift Harness
STANDARD SPARE PARTS KIT Owners
Manual Actuator cord Emergency Cord Rocker
Switches Spare Pins (turnbuckle/removable
head) Cotter Pins Ring- Split Isolators 8mm Hex
bit, T handle Element, Air filter Carrying
case Gauge- Air Pressure Digital Fitting Grease
M10 straight
OPTIONAL SUPPORT KIT Control Box SSR
Receiver Cord Linear Actuator Assy. 2 Plow
Wings 4 Plow Linkages 8 Vibrator
Isolators Hydraulic Filter Air Filter Clamp
Assembly Misc Hardware Carrying case
18
Typical Manpower Conventional vs. Mini Screed C
15,000 sq. ft. Placement 1 Finisher setting
wet pads 2 Finishers using a straight edge 3
Laborers leveling concrete while screeding 6 -
Total manpower for the screeding process Average
2,500 sq. ft. per hour
15,000 sq. ft. Placement 1 - Finisher using a
Somero Mini Screed C 2 - Laborers leveling
concrete while screeding 3 -Total manpower for
the screeding process Average 3,000 sq. ft. per
hour
3 Man Savings with a Mini Screed C
19
Average Non-Union Labor Cost Conventional vs.
Mini Screed C
15,000 sq. ft. Placement 1 - Finisher _at_ 40 per
hr x 5 hr 200 2 - Laborers _at_ 30 per hr
x 5 hr 300 Mini Screed C Labor Cost
500
15,000 sq. ft. Placement 3 - Finishers _at_ 40 per
hr x 6 hr 720 3 - Laborers _at_ 30 per hr x
6 hr 540 Conventional Labor Cost
1,360

Average Non-Union Labor Savings 860 per day
Yields a 460 Return On Investment
Assuming 30 uses per year with an average labor
rate of 35/hr, 604 per month in payments and
operating expenses
20
Average Union Labor Cost Conventional vs. Mini
Screed C
15,000 sq. ft. Placement 1 - Finisher _at_ 54 per
hr x 5 hr 270 2 - Laborers _at_ 45 per hr
x 5 hr 450 Mini Screed C Labor Cost
720
15,000 sq. ft. Placement 3 - Finishers _at_ 54 per
hr x 6 hr 972 3 - Laborers _at_ 45 per hr x
6hr 810 Conventional Labor Cost
1,782

Average Union Labor Savings 1,062 per day
Yields a 679 Return On Investment
Assuming 30 uses per year with an average labor
rate of 51/hr, 604 per month in payments and
operating expenses
21
Extremely Productive Package!
Combine the Mini-Rake with a Mini Screed C and
you will significantly increase your labor
savings and floor quality even more.
22
Sustainability and Profitability
The Economic RealityWhat Contractors Should Be
Doing Now to Prepare for Whats Nextby Scott
Humrickhouse, Director of FMI
The Labor Productivity Opportunity
4 Keys To Survival
1. Aggressively expand your revenue
opportunities 2. Labor productivity
improvements 3. Lower self-performed cost
of work in place efficiencies 4.
Find and implement improved equipment
efficiencies
Improvement 8-Hour Day Increase in Profitability
2 9.6 minutes 20
5 24 minutes 50
10 48 minutes 100
22
23
Somero Mini Screed C
Increase Your Competitive Advantage in 2010!

• Greater Efficiency
• - Less money spent per square foot screeded
• - Operator and crew friendly
• Increases Productivity
• - Screed more square feet per hour
• Improves Quality
• - Improved FL numbers
• Safer
• - Fewer injuries
• Lowers Operating Costs
• Fewer work comp claims
• Less lost time
• Lower insurance rates
• Yields Greater Profitability

23
