HIghResolution TRANsmission molecular absorption database HITRAN

1
HIgh-Resolution TRANsmission molecular absorption
database (HITRAN)
http//www.cfa.harvard.edu/hitran/
2
Why HITRAN?

• There is a need for a database of spectroscopic
  parameters for atmospheric molecules, CFCs, NOx,
  organics, aerosols, etc.
• HITRAN is indispensable as input to atmospheric
  transmission and radiance simulation codes
• HITRAN is the internationally recognized
  standard
• Users have faith that the data is validated
• Contributors have faith that the data will get
  to a large user community

3
Schematic of Fundamental Spectroscopic Parameters
of a Line Transition in HITRAN(the Dotted Line
Refers to a Perturbed Transition)
4
Molecular Absorption
Partition Sum
5
(No Transcript)
6
HITRAN Line-by-line Parameters
(39 molecules)
160-character total
7
M I
8
(No Transcript)
9
(No Transcript)
10
Diatomics in HITRAN
11
Triatomics in HITRAN
12
More Molecules in HITRAN
13
Impact of HITRAN (Examples)

• Global Climate Modeling
• Support for NASA Earth Orbiting System (EOS)
• Integral part of the DOE ARM program
• Ozone Depletion Studies
• NASA Upper Atmosphere Research Satellite (UARS)
• Atmospheric Trace Molecule Spectroscopy (ATMOS)
• Greenhouse Effect
• Enables balloon-borne, aircraft, and satellite
  systems to make remote sensing retrievals
• Industrial Processes
• Monitoring of production processes, temperature
  in furnaces
• Monitoring of stack emissions
• Oil exploration techniques
• Surveillance
• Target acquisition
• Fence-line monitoring

14
(No Transcript)
15
C2F6 (CFC-116)
CCl4
CCl3F (CFC-11)
16
Pressure and temperature pairs example
17
File Structure of HITRAN Compilation
18
JavaHAWKS
Java version of HITRAN Atmospheric WorKStation

• Functions to manipulate and filter the HITRAN
  and
• associated molecular spectroscopic databases

• Plotting of line-by-line files and
  cross-section files

• Internet access to HITRAN and other related
  databases

• Links to abstracts that are the sources for
• HITRAN parameters

• Access to archival HITRAN documentation

19
Development and Improvementof the HITRAN Database
Laboratory MEASUREMENTS
Atmospheric Planetary
MOLECULAR MODELS (Theory)
HITRAN Database
SIMULATED Spectra
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Original preference order for adding
air-broadened half-width data into HITRAN2004

• Intercomparison database (averaging of 2-8
  experimental data)
• Database of the single measurements

R. Gamache and J.-M. Hartmann, Can. J. Chem., 82
(2004) 1013

• Smoothed values from R. Toth

• Database of complex Robert-Bonamy (CRB)
  calculations
• (http//faculty.uml.edu/Robert_Gamache/)

• Semi-empirical calculations that employ all
  available experimental and theoretical data, D.
  Jacquemart, R.R. Gamache, and L.S. Rothman, JQSRT
  96, 205-239 (2005).

• Default estimate

26
Sources of errors

• No available data is flawless
• Experiments are plagued by impurities and line
  overlaps, which are especially difficult for weak
  lines
• Smoothed values are dependant on the quality of
  experimental information
• CRB calculations are not perfectly applied to all
  types of transitions
• Semi-empirical calculations inherit uncertainties
  from the above sources (except smoothed values)
• Approach Each transition have its own
  metabolism and it has own dietsource
  preference

27
Intercomparison of experimental data
28
Intercomparison of experimental data
29
Gordon et al, JQSRT 108 (2007) 389402
30
Validation (AER)
31
Validation (ACE)
