Analysis for Speech Translation Using GrammarBased Parsing and Automatic Classification

1
Analysis for Speech Translation Using
Grammar-Based Parsing and Automatic Classification

• Chad Langley
• Language Technologies Institute
• Carnegie Mellon University

2
NESPOLE! System Overview

• Human-to-human spoken language translation for
  e-commerce application (e.g. travel tourism)
  (Lavie et al., 2002)
• English, German, Italian, and French
• Translation via interlingua
• Translation servers for each language exchange
  interlingua to perform translation
• Speech recognition (Speech ? Text)
• Analysis (Text ? Interlingua)
• Generation (Interlingua ? Text)
• Synthesis (Text ? Speech)

3
Interchange Format

• Interchange Format (IF) is a shallow semantic
  interlingua for task-oriented domains
• Utterances represented as sequences of semantic
  dialog units (SDUs)
• IF representation consists of four parts
• Speaker
• Speech Act
• Concepts
• Arguments
• speaker speech act concept arguments

Domain Action
4
Example

• Hello. I would like to take a vacation in Val di
  Fiemme.

hello i would like to take a vacation in val di
fiemme
cgreeting (greetinghello) cgive-informationdis
positiontrip (disposition(whoi, desire),
visit-spec(identifiabilityno, vacation),
location(place-nameval_di_fiemme))
ENG Hello! I want to travel for a vacation at
Val di Fiemme. ITA Salve. Io vorrei una vacanza
in Val di Fiemme.
5
Why Hybrid Analysis?

• Goal A portable and robust analyzer for
  task-oriented human-to-human speech-to-speech MT
• Earlier MT systems used full semantic grammars to
  parse complete DAs
• Useful for parsing spoken language in restricted
  domains
• Difficult to port to new domains
• Continue to use semantic grammars to parse
  domain-independent phrase-level arguments and
  train classifiers to identify DAs

6
Hybrid Analysis Approach
Use a combination of grammar-based phrase-level
parsing and machine learning to produce
interlingua (IF) representations
7
Hybrid Analysis Approach
Hello. I would like to take a vacation in Val di
Fiemme. cgreeting (greetinghello) cgive-informa
tiondispositiontrip (disposition(whoi,
desire), visit-spec(identifiabilityno,
vacation), location(place-nameval_di_fiemme))
8
Argument Parsing

• Goal Parse IF arguments and domain-independent
  DAs using phrase-level grammars
• SOUP Parser (Gavaldà, 2000) Stochastic,
  chart-based, top-down robust parser designed for
  real-time analysis of spoken language
• Result of argument parsing is a ranked list of
  phrase-level parses
• Prototype analyzer uses only the best-ranked
  argument parse

9
Segmentation

• Goal Identify SDU boundaries in input utterances
• No punctuation or case information since input
  comes from automatic speech recognizer
• Argument parse provides useful information for
  segmentation
• Argument parses may contain cross-domain trees
• SDU boundaries not allowed within a parse tree
• Parse tree labels may be used in segmentation
  models in addition to words in the input utterance

10
Segmentation

• Drop unparsed words
• Consider SDU boundary between each pair of parse
  trees
• Insert boundary if either tree is from
  cross-domain grammar
• Otherwise use statistical model

11
Domain Action Classification

• Goal Identify the domain action for each SDU in
  an input utterance
• Use trainable classifiers to identify the domain
  action for each (non-cross-domain) SDU
• Use IF specification to aid classification and to
  ensure that the DA and arguments combine to
  produce a well-formed IF representation

12
Domain Action Classification

• Use two memory-based classifers (TiMBL, Daelemans
  et al., 2000) to identify the DA
• First classifier identifies the speech act
• Second classifier identifies the complete concept
  sequence
• Classifier features
• Binary features indicate presence or absence of
  particular arguments from the argument parse
• Concept sequence classifier also uses speech act
  as feature

13
Domain Action Classification

• Using IF specification constraints
• Check if best speech act, concept sequence, and
  arguments form a legal DA
• Fallback strategy Find the best DA that licenses
  the most arguments
• Trust the argument parser to produce reliable
  argument labels
• Better to select an alternative DA than to remove
  arguments and lose detailed information from an
  utterance

14
End-to-End Translation Evaluation

• English-to-English and English-to-Italian
• Training set 3350 SDUs from NESPOLE!
• Test set 151 utterances (4 dialogs), 332 SDUs
• 40 SDUs from test set could not be assigned a
  valid IF under the current IF definition
• Uses IF specification fallback strategy
• Each SDU graded as perfect, ok, or bad

15
End-to-End Translation Evaluation
16
Future Work

• Alternative segmentation models
• Richer feature sets for classifiers
• Alternative classification methods
• Multiple argument parses
• Evaluation of portability to a new domain

17
(No Transcript)
18
Research Context

• Spoken language translation systems
• NESPOLE!
• C-STAR
• LingWear
• Translation via a task-oriented interlingua
  (Interchange Format)
• Speech recognition
• Analysis
• Generation
• Synthesis

19
Interchange Format

• IF specification encodes how speech acts,
  concepts, and arguments are allowed to combine to
  form legal IF representations
• IF specification contains
• 62 speech acts
• 103 concepts
• 147 argument names

20
Interchange Format

• I would like to take a vacation in Val di Fiemme.
• cgive-informationdispositiontrip
• (disposition(whoi, desire),
  visit-spec(identifiabilityno, vacation),
  location(place-nameval_di_fiemme))
• Hello.
• cgreeting (greetinghello)
• Thank you very much.
• athank

21
The SOUP Parser

• Stochastic, chart-based, top-down parser designed
  for real-time analysis of spoken language
• Context-free grammars encoded as probabilistic
  recursive transition networks
• Useful features
• Allows configurable word skipping
• Returns sequence of parse trees
• Supports modular grammar development and parsing
  with multiple grammars
• Can provide a ranked list of interpretations

22
Grammars

• Argument grammar
• Phrase-level rules for parsing top-level IF
  arguments
• currency, time, location, etc.
• Pseudo-argument grammar
• Phrase-level rules for parsing common phrases
  that can grouped into classes
• all booked up, full, sold out, etc.

23
Grammars

• Cross-domain grammar
• Rules for parsing complete domain-independent
  domain actions
• Greetings Hello, Good bye, Nice to meet you,
  etc.
• Thanks Thanks, Thank you very much, Youve been
  a big help, etc.
• Shared grammar
• Library of common rules for use by any other
  grammar

24
Data Ablation Experiment

• 16-fold cross validation setup
• Test set size ( SDUs) 400
• Training set sizes ( SDUs) 500, 1000, 2000,
  3000, 4000, 5000, 6009 (all data)
• Data from previous C-STAR system
• No use of IF specification

25
Data Ablation Experiment
26
Prototype System

• Argument Parsing
• Four basic grammars
• No word skipping within parse trees
• Default SOUP disambiguation weights and
  heuristics
• Only best-ranked parse used

27
Hybrid Analysis Approach
Hello. I would like to take a vacation in Val di
Fiemme. cgreeting (greetinghello) cgive-informa
tiondispositiontrip (disposition(whoi,
desire), visit-spec(identifiabilityno,
vacation), location(place-nameval_di_fiemme))
SDU1 SDU2 greeting
disposition visit-spec location hello
i would like to take a vacation in val di
fiemme
greeting give-informationdispositiontrip gr
eeting disposition visit-spec
location hello i would like to take a
vacation in val di fiemme
greeting disposition visit-spec
location hello i would like to take a
vacation in val di fiemme
hello i would like to take a vacation in
val di fiemme
28
Objective

• Provide fast, accurate, and portable analysis for
  task-oriented speech-to-speech machine
  translation
• Must be robust to speech recognition errors,
  spoken language disfluencies, and ungrammatical
  input
• Must produce analyses in (near) real time
• Must produce interlingua representations
• Should be easily portable to new domains and
  languages

29
Hybrid Analysis Approach
