Application of fast CCD drift scanning to speckle imaging of Binary stars

1
Application of fast CCD drift scanning to speckle
imaging of Binary stars
A A Preprint Astro-ph/0403107 4 Mar 2004
2

• Drift scanning --- taking the image by scanning
  over the target
• e.g., turning off the RA tracking
• e.g., stellar image remains fixed but read out
  the CCD photoelectrons in a controlled way

3
Application 1 Lunar occultation
4
Instruments C14 with an ST-8 (TC211 chip,
192x164 pixels ? T lt 4 mas with R filter bandwidth
5
Application 2 speckle imaging

• Speckle imaging --- fast imaging to freeze the
  atmospheric turbulence tens cycles per second
  (a poor mans space telescope)

6
Instruments 1.5 m at Calar Alto (Spain) with the
same LO SBIG ST-8 camera with a TI TC-211 chip,
readout through a parallel port, f12280 mm R
filter (?641 /- 100 nm) ? diffr. spot 108
mas Four binary systems observed in
2001 Seeing1.3 ? atm. Coherence time 4 ms
7

• Fourier analysis and self-calibration
• subtracting bias, streaks - autocorrelation
  low-order bispectral subplanes- FT ? phase map
  modulus ? FT-1

8
(No Transcript)
9
Effects of calibration by different point sources
10
Results of double star speckle imaging
11
Comparing/combining with other results
12
Further CCD improvements

• Readout noise
• multiple outputs
• new data transfer interfaces

13
Something relevant, aka. why would I care to
read/report this paper anyway?
TAOS observations of a stellar occultation by an
asteroid
14
http//www.astro.ncu.edu.tw/contents/faculty/wp_ch
en/wp_chen/nemausa20040221.pdf
15
LOT results, observed by A. Chen, processed by C.
W. Chen
