Elastomeric Materials

1
Elastomeric Materials
2
Elastomeric Materials

• Common characteristics
• Large elastic elongation (i.e.200)
• Can be stretched and then immediately return to
  their original length when the load was released
• Elastomers are sometimes called rubber or rubbery
  materials
• The term elastomer is often used interchangeably
  with the term rubber
• Elastomers are usually thermosets (requiring
  vulcanization) but may also be thermoplastic (see
  thermoplastic elastomer).

3

• All materials have some elastic elongation
• elastic elongation elongation of any material
  when that material is at its yield point
• Ceramic metal- small elastic elongation 2
• PE, elastic elongation 50

4
Stress-strain diagram
5
Idealized stress-strain curves for metals,
conventional plastics and elastomer
6
Diagram showing the random, natural state of
elastomer when under no stress and when stressed
7

• A material may be elastomeric at room temp,
  however rigid at lower temp (why???)
• They are amorphous polymers existing above their
  glass transition temperature, so that
  considerable segmental motion is possible.
• At ambient temperatures rubbers are thus
  relatively soft (E3MPa) and deformable

8

• Most elastomers are crosslink. Atoms between
  crosslink can still move, uncoil and coil.
• The long polymer chains cross-link during curing
  and account for the flexible nature of the
  material.
• Without crosslink, an elastomer may be elongated
  beyond elastic limit, with crosslink, max.
  elongation is set safely within the elastic
  region
• Crosslink density- total number of crosslink in
  the system (less elongation is desired, number of
  crosslink can be increased)

9
Natural Rubber

• Rubber tree (Hevea Braziliensis)
• Natural rubber is obtained by drying a latex
  rubber (milk in which the butter fat component is
  suspended in water salution)
• High temperature stability cooking the crude
  natural rubber with sulphur (vulcanization)
• Vulcanization creates crosslinking between rubber
  molecules
• Natural rubber is highly elastomeric (elongation
  1000 for vulcanized natural rubber)
• Compared to other elastomeric materials, natural
  rubber shows higher tensile strength, high tear
  strength, high resilience, resistance to wear, etc

10
Polymer repeating groups

• Crude natural rubber was chiefly composed of
  cis-polyisoprena (a polymer chain with carbon
  carbon double bond with repeating unit)
• Cis means that two pendent group (H and CH3) that
  are attached to the two carbons in the carbon
  carbon double bond
• The alternate configuration where the two groups
  are located on the opposite side of the carbon
  carbon double bond is called trans
• The presence of methyl group interfere the
  movement in polyisoprene polymer- restricted
  bending and twisting motion (increased stiffness,
  higher strength, and higher temperature stability

11
Polyisoprene structure
Cis-poliisoprena (Hevea rubber)
Trans-poliisoprena (Gutta percha)
12

• Properties of cis and trans are quire different
• Cis is highly elastomeric sensitive to heat
  softening
• Trans materials is called gutta percha, much
  harder than cis isoprena-used for golf balls
• During vulcanization process, sulphur will react
  with carbon carbon double bond

13
Synthetic Polyisoprena or Isoprene Rubber (IR)

• Disruption of supplies of natural rubber during
  world war I and II increase needs for
  elastomeric materials- needs for synthetic rubber
• Synthetic polyisoprena made in early 1900s, used
  for tires for lightweight vehicles
• Combination of cis and trans molecular forms-
  mixture of properties
• Ziegler-Natta catalyst system was developed in
  1950s, it was found that 90 pure cis-isoprena
  could be produced by this catalyst system
• However, natural rubber is used mre extensively
  because of its low cost

14
Butadiene Rubber (BR)

• Synthetic rubber
• Repeating units of both have a backbone of four
  carbon atoms including carbon carbon double bond
• Polybutadiene has just two hidrogen attached to
  the carbon carbon double bond
• Absence of methyl group in polybutadiene results
  in porrer strength tear strength than would
  polyisoprena. Resilient is about the same.
  Polybutadiene has poor resistance to solvents

15

• Advantages of Polybutadiene low cost,
  improvement in low temp. flexibility,
  compatibility with many other polymeric
  materials, good adhesion to metal
• Butadiene monomer is added to the monomer of the
  other plastic copolymer is created
• Butadiene monomer polystyrene styrene
  butadiene rubber (SBR)
• Bulky Styrene molecules add stiffness and
  intermolecular interference to butadiene while
  butadiene adds flexibility and toughness to
  styrene

16
SBR
17
BR
18
Thermoplastic Elastomer (TPE)

• These materials are not crosslinked, have some
  distinct processing advantages over traditional
  thermoset elastomers and physical properties of
  vulcanised elastomers
• TPEs are able to be molded like thermoplastic
  (injection molding, extrusion, etc)
• Thermoplastic elastomers are more temperature
  sensitive
• Scrap and reject of these materials can be
  recycled-environmetal friendly behavior
• Normal crosslinked polymers cannot be recycled
  because they don't melt. They don't melt because
  the crosslinks tie all the polymer chains
  together, making it impossible for the material
  to flow.

19
Silicones, or polysiloxanes

• Silicones, or polysiloxanes, are
  inorganic-organic polymers with the chemical
  formula R2SiOn, where R organic groups such
  as methyl, ethyl, and phenyl.
• These materials consist of an inorganic
  silicon-oxygen backbone (...-Si-O-Si-O-Si-O-...)
  with organic side groups attached to the silicon
  atoms, which are four-coordinate.

20
Silicones, or polysiloxanes

• In some cases organic side groups can be used to
  link two or more of these -Si-O- backbones
  together. By varying the -Si-O- chain lengths,
  side groups, and crosslinking, silicones can be
  synthesized with a wide variety of properties and
  compositions.
• They can vary in consistency from liquid to gel
  to rubber to hard plastic. The most common type
  is linear polydimethylsiloxane or PDMS

21
Silicones, or polysiloxanes

• Service temperature to about 260C
• Good chemical resistance, low water absorption,
  good electrical properties, available in flame
  retardant grade
• In the plumbing and automotive fields, silicone
  grease is often used as a lubricant. In plumbing,
  the grease is typically applied to O-rings in
  faucets and valves.

22

• In the automotive field, silicone grease is
  typically used as a lubricant for brake
  components since it is stable at high
  temperatures, is not water-soluble

23
PROCESSING OF ELASTOMER

• Common machine used for rubber compounding-
• Banbury mixer
• 2-roll mill

24
APPLICATION OF ELASTOMER

• Bearings - structural joints that are installed
  between a structure and its foundation.
• The bearing is very stiff and strong in the
  vertical direction, but flexible in the
  horizontal direction.

1.0 Introduction
25
HOW THE BEARING WORKS
Figure Base-Isolated and Fixed-Base Buildings

• A base isolated structure is supported by a
  series of bearing pads which are placed between
  the building and the building's foundation

26
2.0 How The Bearing work?

• As a result of an earthquake, the ground beneath
  each building begins to move.
• Each building responds with movement which tends
  toward the right.
• The building's displacement in the direction
  opposite the ground motion is actually due to
  inertia.

27
2.0 How The Bearing work?

• In addition to displacing toward the right, the
  un-isolated building is also shown to be changing
  its shape-from a rectangle to a parallelogram.
  deforming
• The primary cause of earthquake damage to
  buildings is the deformation which the building
  undergoes as a result of the inertial forces
  acting upon it.

28
2.0 How The Bearing work?

• The base-isolated building retains its original,
  rectangular shape.
• It is the elastomeric bearings supporting the
  building that are deformed.
• It implies the inertial forces acting on the
  base-isolated building have been reduced.

29
ELASTOMERIC BEARINGS
Fig Basic structure of rubber bearing

• Consist of thin rubber sheets bonded onto thin
  steel plates and combined with an energy
  dissipation mechanism.
• The rubber sheets are vulcanized and bonded to
  the thin steel plates under pressure and heat.
• it is designed in such a way that bearing is very
  stiff and strong in vertical direction, but
  flexible in horizontal direction.
• Thick mounting steel plates are bonded to the
  bottom and top surfaces allowing the isolator to
  be firmly connected to the foundation below and
  the superstructure above.

3.0 Elastomeric Bearings
30
Processing Flow Chart - Seismic Rubber Bearings
