You are well advised with Xaloy
2
What is bi-metal

• Bimetallic means two metals
• Nitrated is one metal
• Strong metal outside for the screw
• Strong metal inside for the barrel

3
Bimetallic Cylinders

• Cross section of a bimetallic barrel
• The dark inner ring is the strong bimetallic
  alloy
• Depending on the application, different alloys
  are recommended

4
Bimetallic Screws

• The finished screw has 3/10 to 5/10 mm left on
  each side
• Depending on the hardfacing the welding method is
  different
• After welding the edges are finished to
  specifications

5
Benefits

• Longer protection
• Stable protection
• calculable risk
• anticipatory maintenance

6
Xaloy - Added Value

• 1. Reduced manufacturing costs - longer service
  life
• 2. Higher productivity- higher constant
  throughput - less down time
• 3. More Flexibility - Various plastics on one
  machine

7
Xaloy - Your Added Value
8
Cylinders
9
New development for cylinders

• Next frontier is higher pressures at higher
  temperatures
• Xaloy Solution X340
• Design parameters are 3000 bar (4350 PSI) at
  400 C (750 F)
• Nickel based alloy with high abrasive wear
• Now in field tests
• Patent pending for Europe

10
Barrel Inlays

• X102 /A110 Moderate abrasion resistance
• X200 /AC330) Moderate abrasion and corrosion
  resistant
• X306 /C242 Moderate corrosion resistant
• X309 Highest corrosion resistance with High
  abrasion resistance
• X800 High abrasion and high corrosion resistant
• X802 Highest abrasion resistant

11
Bimetallic alloys

• Type Abrasion Corrosion
• X102/ A110
• X306 / C242
• X309
• X200 / AC333
• X800
• X802 ( Warranty)

12
Bimetallic cylinders
A barrel with complete wear protection consists
of - Base material- Bi-metallic inlay
13
Combination of cylinders/screws
14
Combination of cylinders/screws
15
Structure

• Hard phases (carbide, boride)? light areas
• Matrix ? dark areas
• FE-Basis
• Ni-, Co-Basis

16
X102 / A110

• Fe based alloy
• Anti-abrasiv
• Hardness 58-65 HRc
• Generally applied for applications of standard
  plastic processing.

17
X306 / C242

• Ni based alloy
• Anti-corrosiv
• Hardness 48-56 HRc
• Used for applications with medium corrosion,
  especially for compounding

18
X800

• Ni based alloy
• Highest Level of wear and corrosion resistance
• Hardness 58-66 HRc

19
X 802 - with wear warranty for Injection

• Ni based alloy with tungsten carbide
• Predictable maintance and spare part costs
• Highest level of wear and corrosion resistance
• Hardness 60-66 HRc

20
Warranty conditions for X802

• 18 mm lt ID lt 100 mm Cylinders will be replaced
  free of charge, if the wear is higher than 0.254
  mm within 4 years.
• ID gt 100 mm Cylinders will be replaced free of
  charge, if the wear is higher than 0.381 mm
  within 4 years.
• The warranty starts with the delivery.
• No-hassle guarantee - no questions asked

21
Relative abrasive wear
22
Relative corrosive wear
Relative corrosion rate in 50 Sulfuric acid at
70C
70
X306 / C242 1
60
50
40
Relative corrosion rate
30
20
10
0
X102 / A110
X200 / AC333
X800 / X802
X306 / C242
Standard Xaloy Alloy
23
Backing Material

• BM 37 Steel with medium mechanical strength
  (equ. 1.1221) Use Extrusion
• BM 63 Steel with high mechanical strength
  (equ. 1.8159) Use Injection Molding
• BMC 11,13,28 Stainless Steel with increasing
  strengthBMC 30 Inconell 625 highest
  mechanical strength

24
Screws
25
Xaloy Screw Design Solutions

• Xaloy is well known for its metallurgical
  solutions to processor problems
• Xaloy also offers screw design solutions through
  its Plastification Technical Center
• Our engineering staff offers both standard
  solutions to problems or custom designs specific
  screws to meet our customers needs

26
Design portfolio - Injection Molding

• High Performance
• Guaranteed Output

Fillers Glass or MineralsX Xaloy Standard
Design Portfolioo Customer Specific Designs
possible
27
Design portfolio - Extrusion

• High Performance
• Guaranteed Output

Fillers Glass or Minerals
X Xaloy Standard Design Portfolioo Customer
Specific Designs possible
28
Extrusion Designs - Any Application
29
Screwflight - hardfacing

• Type Abrasion Corrosion
• Stellite 1 / 6 / 12
• X 183 (NiBSi)
• X 830 (WC)

30
X183 (Superceeds Colmonoy 56)

• NiBSi based alloy
• Hardness 50-55 HRc
• Antia-brasive
• Anti-corrosive
• Best combination properties to X800 and
  X200/AC333 cylinders

31
X183 (Colmonoy 56-Type)

• NiBSi based alloy
• Hardness 56-58 HRc
• Antia-brasive
• Anti-corrosive
• Best combination properties to X800 and X102/A110
  cylinders

32
X830

• Ni based alloy with tungsten carbide
• Hardness 56-60 HRc
• Anti-abrasive
• Anti-corrosive
• Highest wear protection in combination with X800
  or X802

33
Stellite

• Co based alloys
• Hardness
• Stellite 1 48-54 HRc
• Stellite 6 37-42 HRc
• Stellite 12 45-50 HRc
• Anti-abrasive

34
X8000 - Encapsulation Technique

• Screw (root) is encapsulated with Ni-based
  Alloy/WC
• Spray and Fusion

35
Details for X8000
36
Welding Methods

• Welding Methods
• PTA- Plasma transfer arc (hardfacings)
• MIG- Metallized Inert Gas (refurbishment)

37
Hardfacing methods
38
Screw Refurbishment
Welded hardfacing
Finished, refurbished screw
39
Screw Base Materials

• Nitriding Steels
• Quenched and Tempered Steels
• Stainless Steels
• Tool Steel
• Powder Metallurgical Tool Steels

40
Screw Coatings and Heat Treatments

• Nitriding
• Through Hardening
• Chrome Plating
• Nickel Plating
• PVD-Coatings
• X 8000 (Encapsulation Technique)

41
Your global partner
