Class 3: Estimating Scoring Rules for Sequence Alignment

1
Class 3 Estimating Scoring Rules for Sequence
Alignment
2
Reminder

• Last class we discussed dynamic programming
  algorithms for
• global alignment
• local alignment
• All of these assumed a pre-specified scoring rule
  (substitution matrix)that determines the
  quality of perfect matches, substitutions and
  indels, independently of neighboring positions.

3
A Probabilistic Model

• But how do we derive a good substitution
  matrix?
• It should encourage pairs, that are probable to
  change in close sequences, and punish others.
• Lets examine a general probabilistic approach,
  guided by evolutionary intuitions.
• Assume that we consider only two options
• M the sequences are evolutionary related
• R the sequences are unrelated

4
Unrelated Sequences

• Our model of 2 unrelated sequences s, t is
  simple
• For each position i, both si, ti are sampled
  independently from some background distribution
  q() over the alphabet ?.
• Let q(a) be the probability of seeing letter a in
  any position.
• Then the likelihood of s, t (probability of
  seeing s, t), given they are unrelated is

5
Related Sequences

• Now lets assume that each pair of aligned
  positions (si,ti) evolved from a common
  ancestor gtsi,ti are dependent !
• We assume si,ti are sampled from some
  distribution p(,) of letters pairs.
• Let p(a,b) be a probability that some ancestral
  letter evolved into this particular pair of
  letters
• Then the likelihood of s, t, given they are
  related is

6
Decision Problem

• Given two sequences s1..n and t1..n decide
  whether they were sampled from M or from R
• This is an instance of a decision problem that is
  quite frequent in statistics hypothesis testing
• We want to construct a procedure Decide(s,t)
  D(s,t) that returns either M or R
• Intuitively, we want to compare the likelihoods
  of the data in both models

7
Types of Error

• Our procedure can make two types of errors
• I. s and t are sampled from R, but D(s,t) M
• II. s and t are sampled from M, but D(s,t) R
• Define the following error probabilities
• We want to find a procedure D(s,t) that minimizes
  both types of errors

8
Neyman-Pearson Lemma

• Suppose that D is such that for some k
• If any other D is such that ?(D) ? ?(D), then
  ?(D) ? ?(D) --gt D is optimal
• k might refer to the weights we wish to give to
  both types of errors, and on relative abundance
  of M comparing to R

9
Likelihood Ratio for Alignment

• The likelihood ratio is a quantitative measure of
  two sequences being derived from a common origin,
  compared to random.
• Lets see, that it is a natural score for their
  alignment !
• Plugging in the model, we have that

10
Likelihood Ratio for Alignment

• Taking logarithm of both sides, we get
• We can see that the (log-)likelihood score
  decomposes to sum of single position scores, each
  dependent only on the two aligned letters !

11
Probabilistic Interpretation of Scoring Rule

• Therefore, if we take our substitution matrix be
• then the score of an alignment is the log-ratio
  between the two models likelihoods, which is
  nice.
• Score gt 0 ? M is more probable (k1)
• Score lt 0 ? R is more probable

12
Modeling Assumptions

• It is important to note that this interpretation
  depends on our modeling assumption of the two
  hypotheses!!
• For example, if we assume that the letter in each
  position depends on the letter in the preceding
  position, then the likelihood ration will have a
  different form.

13
Constructing Scoring Rules

• The formula
• suggests how to construct a scoring rule
• Estimate p(,) and q() from the data
• Compute ?(a,b) based on p(,) and q()

14
Estimating Probabilities

• Suppose we are given a long string s1..n of
  letters from ?
• We want to estimate the distribution q() that
  generated the sequence
• How should we go about this?
• We build on the theory of parameter estimation in
  statistics

15
Statistical Parameter Fitting

• Consider instances x1, x2, , xM such that
• The set of values that x can take is known
• Each is sampled from the same (unknown)
  distribution of a known family (multinomial,
  Gaussian, Poisson, etc.)
• Each is sampled independently of the rest
• The task is to find a parameters set ? defining
  the most likely distribution P(x?), from which
  the instances could be sampled, I.e.
• The parameters ? depend on the given family of
  probability distributions.

16
Example Binomial Experiment
Head
Tail

• When tossed, it can land in one of two positions
  Head or Tail
• We denote by ? the (unknown) probability P(H).
• Estimation task
• Given a sequence of toss samples x1, x2, ,
  xM we want to estimate the probabilities P(H)
  ? and P(T) 1 - ?

17
Why Learning is Possible?

• Suppose we perform M independent flips of the
  thumbtack
• The number of head we see is a binomial
  distribution
• and thus
• This suggests, that we can estimate ? by

18
Expected Behavior (? 0.5)
M 10 M 100 M 1000
Probability (rescaled) over datasets of i.i.d.
samples
0
0.2
0.4
0.6
0.8
1

• From most large datasets, we get a good
  approximation to ?
• How do we derive such estimators in a principled
  way?

19
The Likelihood Function

• How good is a particular ??It depends on how
  likely it is to generate the observed data
• The likelihood for the sequence H,T, T, H, H is

20
Maximum Likelihood Estimation

• MLE Principle
• Learn parameters that maximize the likelihood
  function
• This is one of the most commonly used estimators
  in statistics
• Intuitively appealing

21
Computing the Likelihood Functions

• To compute the likelihood in the thumbtack
  example we only require NH and NT (the number of
  heads and the number of tails)
• NH and NT are sufficient statistics for the
  binomial distribution

22
Sufficient Statistics

• A sufficient statistic is a function of the data
  that summarizes the relevant information for the
  likelihood
• Formally, s(D) is a sufficient statistics if for
  any two datasets D and D
• s(D) s(D ) ? L(? D) L(? D)

23
Example MLE in Binomial Data

• Applying the MLE principle we get (after
  differentiating)
• (Which coincides with what we would expect)

24
From Binomial to Multinomial

• Suppose X can have the values 1,2,,K
• We want to learn the parameters ? 1, ? 2. , ? K
• Sufficient statistics
• N1, N2, , NK - the number of times each outcome
  is observed
• Likelihood function
• MLE (differentiation with Lagrange multipliers)

25
At last Estimating q()

• Suppose we are given a long string s1..n of
  letters from ?
• s can be the concatenation of all sequences in
  our database
• We want to estimate the distribution q()
• Likelihood function
• MLE parameters

Number of times a appears in s
26
Estimating p(,)

• Intuition
• Find pair of presumably related aligned sequences
  s1..n, t1..n
• Estimate probability of pairs in the sequence
• Again, s and t can be the concatenation of many
  aligned pairs from the database

Number of times a is aligned with b in (s,t)
27
Estimating p(,)

• Problems
• How do we find pairs of presumably related
  aligned sequences?
• Can we ensure that the two sequences are indeed
  based on a common ancestor?
• How far back should this ancestor be?
• earlier divergence ? low sequence similarity
• later divergence ? high sequence similarity
• The substitution score of each 2 letters should
  depend on the evolutionary distance of the
  compared sequences !

28
Let Evolution In

• Again, we need to make some assumptions
• Each position changes independently of the rest
• The probability of mutations is the same in each
  positions
• Evolution does not remember

Time
t
t?
t2?
t3?
t4?
29
Model of Evolution

• How do we model such a process?
• The process (for each position independently) is
  called a Markov Chain
• A chain is defined by the transition probability
• P(Xt?bXta) - the probability that the next
  state is b given that the current state is a
• We often describe these probabilities by a
  matrixT?ab P(Xt?bXta)

30
Two-Step Changes

• Based on T?, we can compute the probabilities
  of changes over two time periods
• Thus T2? T?T?
• By induction Tk? T? k

31
Longer Term Changes

• Idea
• Estimate T? from some closely related
  sequences set S
• Use T? to compute Tk?
• Derive substitution probability after time k?
• Note, that the score depends on evolutionary
  distance, as requested

32
Estimating PAM1

• Collect counts Nab of aligned pairs (a,b) in
  similar sequences in S
• Sources include phylogenetic trees and close
  related sequences (at least 85 positions have
  exact match)
• Normalize counts to get transition matrix T? ,
  such that average number of changes is 1
• that is,
• this is called 1 point accepted mutation (PAM1)
  an evolutionary time unit !

33
Using PAM

• The matrix PAM-k is defined to be the score based
  on Tk
• Historically researchers use PAM250
• Longer than 100 !
• Original PAM matrices were based on small number
  of proteins
• Later versions of PAM use more examples
• Used to be the most popular scoring rule

34
Problems with PAM

• PAM extrapolates statistics collected from
  closely related sequences onto distant ones.
• But short-time substitutions behave differently
  than long-time substitutions
• short-time substitutions are dominated by a
  single nucleotide changes that led to different
  translation (like L-gtI)
• long-time substitutions dominated do not exhibit
  such behavior, are much more random.
• Therefore, statistics would be different for
  different stages in evolution.

35
BLOSUM (blocks substitution) matrix

• Source aligned ungapped regions of protein
  families
• These are assumed to have a common ancestor
• Procedure
• Group together all sequences in a family with
  more than e.g. 62 identical residues
• Count number of substitutions within the same
  family but across different groups
• Estimate frequencies of each pair of letters
• The resulting matrix is called BLOSUM62
