Title: Considerations: Spinal


1
Considerations Spinal Epidural Anesthesia
  • Joseph E Pellegrini, CRNA, PhD

2
Spinal Column Anatomy
  • Vertebra
  • Vertebral Body
  • Pedicles Anterior (2) Laminae Posterior (2)
  • Transverse Process Junction of the Pedicles and
    Laminae
  • Spinous Processes Joining of the Laminae
  • Intervertebral Disks

3
Advantages of Spinal/Epidural Anesthesia
  • Avoids Hazards of General Anesthesia
  • Patient is Alert earlier postoperative
  • Lower incidence of Nausea/Vomiting
  • Better Pain Control/Less Narcotics

4
Spinal Anesthesia
  • Indications
  • Best reserved for operations below the level of
    the umbilicus
  • R/LIH, GYN, Peroneal, Anal, LEs
  • C-sections
  • Preferable to Epidural GA
  • Risk/Benefit Ratio
  • Contraindications
  • Refusal
  • Infection
  • Severe Neurological Disease
  • Hypovolemia
  • Coagulopathy
  • LMWH use?

5
LMWH Neuraxial Blockade
  • Overall incidence of Spinal Hematoma
  • Estimated
  • Estimated
  • Benefit/Risk Ratio
  • Recommendations

6
LMWH Neuraxial Blockade
7
Recommendations

8
Spinal Anesthesia
  • A single injection of a local anesthetic solution
    into the subarachnoid space usually at the lumbar
    level
  • Intrathecal Narcotics
  • Commonly at L3-L4
  • Largest Interspace
  • L5-S1

9
Spinal Needle Considerations
  • Small needles ? PDPH
  • Large needles improve tactile sensations
  • Pencil-point needles ? PDPH risk
  • Further reduction with addition of ITN
  • Side injection needles with large holes ? CSF but
    careful to have entire hole subarachnoid

10
Most Important Factors Affecting Block Height -
SAB
  • Baricity of anesthetic solution
  • Position of the patient
  • During injection
  • Immediately after injection
  • Drug Dosage (mg)
  • Concentration times volume
  • Addition of Opioids
  • Site of Injection

11
Additional Factors to Consider with SAB Height
  • Patient Age
  • Elderly patients 80 yrs
  • Patient Height
  • Intra-abdominal Pressure
  • Pregnancy Obesity
  • Drug Volume

12
Factors Unrelated to SAB Height
  • Added Vasoconstrictor
  • Rate of Injection
  • Except for Hypobaric
  • Gender
  • Females
  • Pregnant versus Non-pregnant
  • Weight
  • Increased Weight
  • Lesser concentration needed?

13
Differential Block with SAB
Sympathetic
  • Sympathetic Block
  • 2-6 dermatomes higher than the sensory block
  • Motor Block
  • 2 dermatomes lower than sensory block

T5
Sensory
Motor
14
Baricity of Local Anesthetics
  • Isobaric Stays where you put it
  • LA has the same density or specific gravity as
    CSF (1.003-1.008) Normal Saline
  • Hypobaric Floats up Lighter than CSF
  • LA has a density or specific gravity that is less
    than CSF (
  • Hyperbaric Settles to Dependent aspect of the
    subarachnoid space Heavier than CSF
  • LA has a density or specific gravity that is
    greater than CSF (1.008) - Dextrose

15
Positioning the Patient
  • Sitting
  • With Legs hanging over side of bed
  • Have the patient hug a pillow
  • Put Feet up on a Stool (no wheels)
  • Assistant MUST keep the patient from Swaying
  • Curve her back like a C, Halloween Cat, Shrimp,
    Cannon ball
  • Up in the Bed (quicker but not optimal)
  • Baricity?
  • Lateral Decubitus (Left or Right?)
  • Needs to be Parallel to the Edge of the Bed
  • Legs Flexed up to Abdomen
  • Forehead Flexed down towards Knees
  • Jack-knife Position
  • Chosen for ano-rectal surgery
  • CSF will not drip from hub of needle
  • Use hypobaric solution
  • Bupivacaine less run-off than lidocaine

16
Preparation for SAB
  • Identify Suitable Patients
  • Equipment Required
  • Single-shot or Catheter Placement
  • Continuous spinal with epidural catheter
  • Know your Spinal/Epidural Kit
  • Determine Insertion Approach
  • Midline
  • Paramedian

17
Midline Insertion Approach
  • Midline
  • Most commonly used
  • As needle passes thru the dura mater a pop is
    often appreciated
  • CSF flows thru once stylet is used
  • For small gauge needles (26-29 g) this may take
    5-10 seconds
  • May take even longer in dehydrated or elderly
    patients
  • If no CSF flow, needle can be obstructed by a
    nerve root (rotate 90 degrees)

18
Paramedian (Lateral) Approach
  • After identifying the proper interspace palpate
    the spinous process
  • Insert needle 1 cm lateral and 1 cm inferior to
    this point and direct needle towards interspace
  • May need to walk medially off of transverse
    process
  • Ligamentum flavum is usually the first resistance
    indentified
  • Bypasses supraspinous and intraspinous ligaments

Traditional
Taylor (L5-S1)
19
Preparation continued
  • GIVE INTRAVENOUS FLUID BOLUS OF 500 CC PRIOR TO
    SAB/EPIDURAL DOSE.
  • If it is not a labor epidural/c-section, give
    versed, fentanyl and oxygen prior to neuraxial
    anesthesia.
  • Local Anesthetics to the skin, deep tissues?
  • Skin wheal should be performed at vertebral
    interspace (1-2 ml) and to adjacent sides (.5ml)
    with 1 Lidocaine

20
MOST COMMON CAUSES OF INADEQUATE SPINAL ANESTHESIA
  • Unable to locate CSF
  • Inability to enter SA space
  • If bone (os) encountered superficially
  • redirect needle cephalad
  • If bone (os) encountered deep
  • redirect needle caudally
  • Inability to aspirate CSF before injection
  • Ensure that you have CSF in all 4 planes
  • Surgery outlasting the drug selected
  • Short, intermediate long term local anesthetics
  • Can increase duration efficacy with opioids/LA
    admixture
  • 5-10 mcg fentanyl or 1-2 mcg sufentanil

21
Intrathecal Analgesia
22
METHODS OF DETERMINING SPINAL LEVEL
  • Definition of determining level analgesia
    versus anesthesia
  • Alcohol skin wipe
  • Pinch
  • toothpick skin test
  • Nerve stimulator
  • Etc., etc., etc.
  • Beware break no skin, use no needles

23
STRATEGIES TO INCREASE THE LEVEL OF SPINAL
ANESTHSIA IN THE PERI-BLOCK FRAME
  • Work fast after local anesthetic injected
  • Assess early and frequently
  • Augment position changes to maximize spread hyper
    / hypo baric solutions early
  • Co-administration of IT Opioids
  • ? Make patient cough several times
  • More effective with lidocaine

24
ACTIONS TO DEAL WITH INADEQUATE LEVEL
  • Use previously discussed strategies
  • Re-do spinal anesthetic
  • Supplementation with local anesthetic per surgeon
  • Analgesic intravenous supplements
  • Dissociative intravenous supplements
  • General Anesthesia

25
Lidocaine Group 10 mg hyperbaric lidocaine via
SAB Fentanyl/Propofol Group 1 mcg/kg fentanyl
followed by 1 mg/kg bolus 90 mg/kg infusion
26
A Comparison of Three anesthetic Techniques for
Outpatient Knee Arthroscopy General Anesthesia,
Spinal Anesthesia and Intraarticular Infiltration
of Local Anesthetic (2008)LT Riley Williams,
SRNA, LT Robert Haag, SRNA, LT Rodrigo Lopez,
SRNA, LT William Baker, SRNA, CDR Lisa Osborne,
CRNA, PhD and CAPT (ret) Joseph Pellegrini, CRNA,
PhD
  • Spinal Anesthesia Group
  • 10-12 mg Hyperbaric Bupivacaine
  • Supplemental Anxiolysis fentanyl
  • Intraarticular Group
  • IA Injection 15 min before incision by anesthesia
    in holding
  • Followed customized format
  • 2-injection technique
  • 20 ml Bupivacaine 0.5 with epinephrine
    (1200,000)
  • Propofol Infusion
  • 50-100 mg/kg/hr
  • Fentanyl supplementation
  • 50-100 mcg during injection with 2 mg midazolam
  • General Anesthesia Group
  • Standardized Induction
  • Desflurane or Sevoflurane

27
Epidural Anesthesia
  • Placement of Local Anesthetic into epidural space

Dural Rent
28
Epidural Anesthesia
  • Indications
  • Contraindications
  • Same as SAB (
  • ? Tattoos
  • Epidural blocks can be placed 4 hrs after last
    dose of SQ Heparin, 12 hrs after last dose of
    LMWH
  • NSAIDS (including ASA) not contraindicated
  • Placement relatively safe with INR

29
Epidural Placement
  • Typically use Loss of Resistance Technique
  • Routinely placed in Lumbar region
  • Use the needle for skin infiltration to identify
    midline structures
  • Insert the needle in a slightly cephalad
    direction
  • Dorsum of non-injecting hand rests on patients
    back
  • Thumb and index finger grasp hub of needle
  • Seat needle into intraspinous ligament and
    advance in slightly cephalad direction with
    continuous pressure on plunger of syringe and
    when the needle exits ligamentum flavum feel
    sudden loss of resistance
  • The distance from skin to epidural space is 4-6
    cm in 90 of the population
  • Never change the direction of the needle tip
    after it passes through the ligamentum flavum
  • Do not advance the needle
  • Air versus Normal Saline
  • Missed dermatomes
  • Presence of parasthesias?

30
Epidural Placement
  • Thread catheter 3-5 cm
  • Check position
  • Presence of parasthesias?
  • Remove needle while keeping positive pressure on
    catheter (thread concurrently)
  • Check position
  • Secure catheter
  • Check position
  • Test dose
  • Aspirate for Blood or CSF
  • Off midline insertion usually results in higher
    blood vessel puncture
  • A change of 20 or greater in HR after test dose
    indicates intravascular injection (replace
    catheter)
  • A dense motor block within 5 minutes after test
    dose indicates spinal block (if positive either
    replace catheter or convert to continuous spinal
    technique)
  • Only give test dose after contraction is over in
    pregnant women
  • If patient on beta blocker a change in systolic
    pressure 20 mm Hg indicates intravascular
    injection
  • 1.5 Lidocaine with epinephrine vs 2 Lidocaine

31
Problem Solving with Epidural Placement
32
Local Anesthetics for Epidural Blockade
33
Epidural Dosing
  • Volume is the key factor in determining height of
    blockade
  • Typical loading dose is 10-20 ml given in 5 ml
    increments
  • Wait about 2-3 minutes between increments
  • Use of epinephrine and bicarbonate will speed up
    onset on anesthesia
  • If block incomplete after bolus replace catheter
    rather than wasting time giving larger dose or
    re-positioning catheter
  • Inject one-quarter to one-third of initial dose
    about 15 minutes after initial bolus to enhance
    sensory blockade
  • Cookbook guideline
  • To determine volume you can use the 5-foot rule
  • Example For an individual who is 5 feet in
    height you administer 1 ml of local anesthetic
    solution for each segment requiring blockade and
    increase the volume by 0.1 ml for every 2 inches
    above 5 feet.
  • Example For someone 510 in height and you
    enter at L3-L4 Interspace and want a to block up
    to T-6.
  • 8 ml for L3-S5 and 7 ml for L2-T6 15 ml (base
    amount)
  • Additional amount is 0.1 ml times 5 (10 inches/2)
    0.5 times 15 segments 7.5 (supplemental
    amount)
  • Overall add the 15 ml plus the 7.5 ml to get a
    dose of 22.5 ml
  • Need a total of 22.5 ml to achieve a T-6 level on
    a 70 person

34
Epidural Additives
  • Opioids
  • Morphine, Fentanyl, Sufentanil, Depo-Dur
  • Depo-Dur Considerations
  • Clonidine
  • Hemodynamic Considerations
  • Sodium Bicarbonate
  • Speeds onset Prolongs duration

35
Combined-Spinal Epidural (CSE) Technique
  • CSE technique
  • Allows for immediate relief of pain (from SAB)
    subsequent administration of medications via CLE
    for prolonged anesthesia
  • Advantages
  • Reported to decrease failure rates of CLE
    (confirmation of epidural placement)
  • Clinical uses
  • General Surgery
  • Laboring analgesia Cesarean Section
  • High risk patients
  • Slower onset of sympathetic blockade
  • Careful positioning during SAB with subsequent
    titration of CLE
  • Administration of intrathecal opioids with small
    amount of bupivacaine (2.5-5 mg) decreases
    epidural dosing requirements and decreases degree
    of sympathectomy

36
CSE Technique
37
CSE Technique
  • CSE offers the advantages of both spinal and
    epidural anesthesia
  • CSE provides rapid onset and careful titration
  • Can use doses as low as 40 mg lidocaine or 7.5 mg
    bupivacaine
  • Additional Opioids
  • Sufentanil
  • Fentanyl
  • Morphine
  • Potential disadvantages
  • PDPHA
  • Catheter migration into SA space
  • Test Dose
  • Transient parasthesias
  • Ideal length of spinal needle beyond epidural
    needle is 12-13 mm
  • Longer spinal needles associated with higher
    incidence

38
Joseph.pellegrini_at_med.navy.mil
Write a Comment
User Comments (0)
About PowerShow.com
