Steep Slope Landfill Closure

1
Steep Slope Landfill Closure

• Presented by
• Mark A. Swyka, P.E.
• Cornerstone Environmental Group, LLC
• May 2007

2
Definition of a Steep Slope

• Steep is relative
• Different systems have varied tolerance to slopes

3
(No Transcript)
4
(No Transcript)
5
Definition of a Steep Slope

• Challenge to traverse perpendicular to slope
  approx. 10H1V
• Challenge to traverse parallel to slope approx.
  4H1V
• Challenge to maintain approx. 3H1V
• Part 360-2.13(q) 3H1V max slope
• Difficult to work with tracked equipment
  approx. 2H1V

6
Existing 1.5H1V Slope
7
Existing 1.25H1V Slope
8
Existing Unstable Slope Steeper Than 1H1V
9
6 NYCRR Part 360-2.15(l)

• Landfills may be closed with slopes exceeding 33
  percent providing
• No Department Approved Closure Plan
• Slopes exceeded 33 percent before 12-31-88
• Stability Analysis Performed
• Final grades do not exceed 50 percent for more
  than 20 feet vertical rise
• Run-off diversion terraces must be constructed at
  vertical intervals not exceeding 20 feet

10
2H1V Slopes w/ Drainage Terrace
11
Design Requirements

• Under cap landfill gas venting
• Barrier layer Textured Geomembrane
• Barrier Protection Drainage Layer
• Topsoil
• Turf Reinforcement Mat (TRM)
• Vegetation

12
Causes of Slope Failure

• Moisture
• Surfacewater
• Head build-up on Geomembrane
• Assumption
• Material Strengths
• Material Permeabilities

13
Needs of Steep Slopes

• Site Specific Assessment
• Material Specific Testing
• Erosion Control
• Short-term TRM
• Long-term Vegetation
• Stormwater Management
• On the ground surface
• Below the ground surface
• Accessibility for Maintenance

14
TYPICAL FINAL COVERWITH INTERNAL DRAINAGE PIPES
TOPSOIL
PROTECTIVE SOIL
FML
DRAINAGE PIPE
1
DRAINAGE LAYER
3 (MAX)
15
TYPICAL FINAL COVERWITH GEOCOMPOSITE DRAIN
TOPSOIL
PROTECTIVE SOIL
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
FML
1
GEOCOMPOSITE DRAIN
3 (MAX)
16
Landfill Z New York
17
Rainfall History
RAINFALL (INCHES)
18
Landfill Z New York
19
Landfill X New Jersey
20
Landfill X New Jersey
21
Landfill X New Jersey
22
Rainfall History
RAINFALL (INCHES)
23
Shear Strength Requirements
24
Interface Friction

• Textured Geomembrane to Soil
• Reliable to about 34 degrees
• Range can extend to more than 40 degrees
• Textured Geomembrane to Geotextile
• Reliable to about 22 degrees
• Range can be higher, but highly variable
• Product specific testing is mandatory

25
STEEP SLOPE COVER WITH TENSILE ELEMENT
EMBEDMENT LENGTH
TOPSOIL
TENSILE ELEMENT
FML
DRAINAGE LAYER
1
2
26
STEEP SLOPE FINAL COVERWITH INTERNAL DRAINAGE
PIPES
TOPSOIL
BARRIER PROTECTION LAYER
FML
DRAINAGE PIPE
DRAINAGE LAYER
1
2
27
SIDESLOPE DIVERSION CHANNEL
DRAINAGE CHANNEL
2
1
TOPSOIL
DRAINAGE LAYER
FML
1
3
BARRIER PROTECTION LAYER
28
SIDESLOPE HALF-PIPE CHANNEL
TOPSOIL
HALF-PIPE CHANNEL
BARRIER PROTECTION LAYER
1.5
1.0
DRAINAGE LAYER
FML
1
2
29
(No Transcript)
30
Click to add title
The Sagamore

• Click to add presenters name

Landfill Site
31
Click to edit Master title style
Croton Watershed

• Click to edit Master text styles
• Second level
• Third level
• Fourth level
• Fifth level

Approximate Landfill Boundary
West Branch Reservoir
Shaft 10 - NYC Delaware Aqueduct
32
Town of Carmel Landfill

• Inactive Former MSW Landfill
• Footprint
• 8 Acres
• Waste Inventory
• Approximately 500,000CY
• Existing Slopes
• As Steep As 1H1V
• Inadequate Footprint to Contain Waste

33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
Summary

• Landfills can be closed with final slopes as
  steep as 2H1V using available materials
• Site specific and material specific testing is
  mandatory
• Erosion control is essential
• Moisture control is essential

55
THANK YOU
