Introduction to SMV

1
Introduction to SMV
2
Symbolic Model Verifier

• Ken McMillan, Symbolic Model Checking An
  Approach to the State Explosion Problem, 1993.
• Finite-state Systems described in a specialized
  language
• Specifications given as CTL formulas
• Internal representation using OBDDs
• Automatically verifies specification or produces
  a counterexample

3
Overview of SMV
SMV Input Language
Backend
Finite State Kripke Structure
OBDD based Symbolic Model Checking
Yes
Specification CTL Formula
No
CounterExample
4
Language Characteristics

• Allows description of completely synchronous to
  asynchronous systems, detailed to abstract
  systems
• Modularized and hierarchical descriptions
• Finite data types Boolean and enumerated

5
Language Characteristics (cont..)

• Parallel-assignment syntax
• Non-determinism

6
A Sample SMV Program

• MODULE main
• VAR
• request boolean
• state ready, busy
• ASSIGN
• init(state) ready
• next(state) case
• stateready request busy
• 1 ready, busy
• esac
• SPEC AG(request -gt AF (state busy))

7
SMV Syntax - Expressions

• Expr
• atom symbolic
  constant
• number numeric
  constant
• id variable
  identifier
• ! expr logical not
• expr1 ltopgt expr2
• next ( id ) next value
• case_expr
• set_expr

8
The Case Expression

• Case_expr case
• expr_a1 expr_b2
• expr_an expr_bn
• esac
• Guards are evaluated sequentially.
• The first one that is true determines the
  resulting value
• If none of the guards are true, result is numeric
  value 1

9
State Variables

• Decl VAR
• atom1 type1
• atom2 type2
• State is an assignment of values to a set of
  state variables
• Type of a variable boolean, scalar, user
  defined module, or array.

10
ASSIGN declaration

• Decl ASSIGN
• dest1 expr1
• dest2 expr2
• Dest atom
• init ( atom )
• next ( atom )

11
Variable Assignments

• Assignment to initial state init(value) 0
• Assignment to next state (transition
  relation)next(value) value carry_in mod 2
• Assignment to current state (invariant)carry_out
  value carry_in
• Either init-next or invar should be used, but not
  both
• SMV is a parallel assignment language

12
Circular definitions

• are not allowed!
• This is illegal
• a next(b)next(b) cc a
• This is o.k.
• init(a) 0next(a) !binit(b)
  1next(b) !a

13
Nondeterminism

• Completely unassigned variable can model
  unconstrained input.
• val_1, , val_n is an expression taking on any
  of the given values nondeterministically.
• Nondeterministic choice can be used to
• Model an implementation that has not been refined
  yet
• Abstract behavior

14
ASSIGN and DEFINE

• VAR a booleanASSIGN a b c
• declares a new state variable a
• becomes part of invariant relation
• DEFINE d b c
• is effectively a macro definition, each
  occurrence of d is replaced by b c
• no extra BDD variable is generated for d
• the BDD for b c becomes part of each expression
  using d

15
SPEC declaration

• Decl SPEC ctlform
• Ctlform expr bool expression
• ! ctlform
• ctlform1 ltopgt ctlform2
• E pathform
• A pathform
• Pathform X ctlform
• F ctlform
• G ctlform
• ctlform1 U ctlform2

16
Modules and Hierarchy

• Modules can be instantiated many times, each
  instantiation creates a copy of the local
  variables
• Each program has a module main
• Scoping
• Variables declared outside a module can be passed
  as parameters
• Parameters are passed by reference.

17
Pass by reference

• DEFINE
• a 0
• VAR
• b bar(a)
• MODULE bar(x)
• DEFINE
• a 1
• y x

18
Pass by reference

• VAR
• a boolean
• b foo(a)
• MODULE foo(x)
• ASSIGN
• x1

19

• MODULE main
• VAR bit0 counter_cell(1)
• bit1 counter_cell(bit0.carry_out)
• bit2 counter_cell(bit1.carry_out)
• SPEC AG AF bit2.carry_out
• MODULE counter_cell(carry_in)
• VAR value boolean
• ASSIGN
• init(value) 0
• next(value) value carry_in mod 2
• DEFINE carry_out value carry_in

20
Module Composition

• Synchronous composition
• All assignments are executed in parallel and
  synchronously.
• A single step of the resulting model corresponds
  to a step in each of the components.
• Asynchronous composition
• A step of the composition is a step by exactly
  one process.
• Variables, not assigned in that process, are left
  unchanged.

21
Asynchronous Composition

• MODULE main
• VAR gate1 process inverter(gate3.output)
• gate2 process inverter(gate1.output)
• gate3 process inverter(gate2.output)
• SPEC
• (AG AF gate1.output) (AG AF !gate1.output)
• MODULE inverter(input)
• VAR output boolean
• ASSIGN
• init(output) 0
• next(output) !input

22
Fairness

• FAIRNESS ctl_formulae
• Assumed to be true infinitely often
• Model checker only explores paths satisfying
  fairness constraint
• Each fairness constraint must be true infinitely
  often
• If there are no fair paths
• All existential formulas are false
• All universal formulas are true
• FAIRNESS running

23
With Fairness..

• MODULE main
• VAR gate1 process inverter(gate3.output)
• gate2 process inverter(gate1.output)
• gate3 process inverter(gate2.output)
• SPEC
• (AG AF gate1.output) (AG AF !gate1.output)
• MODULE inverter(input)
• VAR output boolean
• ASSIGN
• init(output) 0
• next(output) !input
• FAIRNESS
• running

24
Counter revisited

• MODULE main
• VAR
• count_enable boolean
• bit0 counter_cell(count_enable)
• bit1 counter_cell(bit0.carr_out)
• bit2 counter_cell(bit1.carry_out)
• SPEC AG AF bit2.carry_out
• FAIRNESS count_enable

25
Synchronous vs Asynchronous

• In Asynchronous process, need not combine
  transition relation of each process
• Complexity of representing set of states
  reachable in n steps higher in asynchronous
  processes occassionally due to higher number of
  interleavings

26
Implicit Modelling

• TRANS - boolean valued expr restricting
  transition relation of system
• INIT - boolean valued expression giving initial
  states
• INVAR - boolean valued expression restricting set
  of all states of model

27
Implicit Modelling Example

• MODULE main
• VAR
• gate1 inverter(gate3.output)
• gate2 inverter(gate1.output)
• gate3 inverter(gate2.output)
• SPEC
• (AG AF gate1.out) (AG AF !gate1.out)
• MODULE inverter(input)
• VAR
• Output boolean
• INIT
• output 0
• TRANS
• next(output) !input next(output) output

28
TRANS

• Advantages
• Group assignments to different variables
• Good for modelling guarded commands
• Disadvantages
• Logical absurdities can lead to unimplementable
  descriptions

29
Shared Data Example

• Two Users assign pid to shared data in turn
• MODULE main
• VAR
• data boolean
• turn boolean
• user0 user(0, data, turn)
• user1 user(1, data, turn)
• ASSIGN
• next(turn) !turn
• SPEC
• AG (AF data AF (!data))

30
Shared data example (cont..)

• Using ASSIGN and CASE statement wont
  work(constraining sema all the time)
• MODULE user(pid, data, turn)
• ASSIGN
• next(data) case
• turn pid
• 1 data
• esac
• Line 3 multiple assignment next(data)

31
Using TRANS

• TRANS useful for changing shared data in
  synchronous system between modules.
• MODULE user(pid, turn, data)
• TRANS
• turn -gt next(data) pid

32
Guarded Commands

• Guard1 action1
• Guard2 action2
• ..
• Otherwise nop
• TRANS
• (guard1 action1)
• (guard2 action2)
• (!guard1 !guard2 nop)

33
TRANS Pitfall

• True -gt next(b) 0
• True -gt next(b) 1
• Results in an empty transition relation

34
TRANS Guidelines

• Try using ASSIGN instead
• Write in a disjunction of conjunction format
• Try covering all cases
• Try make guards disjoint

35
SMV Steps

• Read_Model read model from input smv file
• Flatten_hierarchy instantiate modules and
  processes
• Build_model compile the model into BDDs
  (initial state, invar, transition relation)
• Check_spec checking specification bottom up

36
Run SMV

• smv options inputfile
• -c cache-size for BDD operations
• -k key-table-size for BDD nodes
• -v verbose
• -int interactive mode
• -r
• prints out statistics about reachable state space


37
SMV Options

• f
• computes set of reachable states first
• Model checking algorithm traverses only the set
  of reachable states instead of complete state
  space.
• useful if reachable state space is a small
  fraction of total state space

38
SMV Options Reordering vars

• Variable reordering is crucial for small BDD
  sizes and speed.
• Generally, variables which are related need to be
  close in the ordering.
• i filename o filename
• Input, output BDD variable ordering to given
  file.
• -reorder
• Invokes automatic variable reordering

39
SMV Options Transition relation

• smv -cp part_limit
• Conjunctive Partitioning Transition relation not
  evaluated as a whole, instead individual next()
  assignments are grouped into partitions that do
  not exceed part_limit
• Uses less memory and benefits from early
  quantification

40
SMV options -inc

• Perform incremental evaluation of the transition
  relation
• At each step in forward search, transition
  relation restriced to reached state set
• Cuts down on size of transition relation with
  overhead of extra computation

41
Example Client Server

• MODULE client (ack)
• VAR
• state idle, requesting
• req boolean
• ASSIGN
• init(state) idle
• next(state)
• case
• stateidle idle, requesting
• staterequesting ack idle, requesting
• 1 state
• esac
• req (staterequesting)

42

• MODULE server (req)
• VAR
• state idle, pending, acking
• ack boolean
• ASSIGN
• next(state)
• case
• stateidle req pending
• statepending pending, acking
• stateacking req pending
• stateacking !req idle
• 1 state
• esac
• ack (state acking)

43
Is the specification true?

• MODULE main
• VAR
• c client(s.ack)
• s server(c.req)
• SPEC AG (c.req -gt AF s.ack)
• Need fairness constraint
• SuggestionFAIRNESS s.ack
• Why is this bad?
• SolutionFAIRNESS (c.req -gt s.ack)

44
NuSMV

• Specifications expressible in CTL, LTL and Real
  time CTL logics
• Provides both BDD and SAT based model checking.
• Uses a number of heuristics for achieving
  efficiency and control state explosion
• Higher number of features in interactive mode

45
Cadence SMV

• Provides compositional techniques to verify
  large complex systems by decomposition to smaller
  problems.
• Provides a variety of techniques for refinement
  verification, symmetry reductions, uninterpreted
  functions, data type reductions.

46
Useful Links

• SMV sources, binaries and manualshttp//www.cs.cm
  u.edu/modelcheck/smv.html
• SMV man page
• http//www.cs.cmu.edu/dongw/smv.txt
• SMV manualhttp//www.cs.cmu.edu/modelcheck/smv/s
  mvmanual.ps
• Tutorial on verification techniques using Cadence
  SMVhttp//www-cad.eecs.berkeley.edu/kenmcmil/tut
  orial.ps
• SMV Input Language documentationhttp//www-cad.ee
  cs.berkeley.edu/kenmcmil/psdoc.html

47
Downloads

• SMV
• www.cs.cmu.edu/modelcheck/smv.html
• NuSMV
• http//nusmv.irst.itc.it/
• Cadence SMV
• http//wwwcad.eecs.berkeley.edu/kenmcmil/smv
