MS MUG Best Practices

1
MS MUG Best Practices

• The Microsoft Manufacturers Users Group

2
What is the MS MUG?

• Microsoft Manufacturing User Group
• User group devoted to addressing issues faced
  when applying Microsoft technology to industrial
  applications
• Formed in February, 1999
• 70 Members
• Users
• Software suppliers
• Microsoft

3
Best Practices

• Information to help users implement systems that
  are
• More reliable
• Cost effective
• Easier to support
• Target audience is non-IT people
• Address issues specific to manufacturing

4
Topics in the Best Practices

• Architecture
• Security
• Redundancy Reliability
• System Monitoring
• Change Management
• Support
• Backup Recovery

5
Architecture
6
Network Architecture

• Most Microsoft based applications in
  manufacturing are connected to a network
• 10MB 100MB Ethernet widely available cost
  effective
• Many control systems support Ethernet
• Utilize Ethernet switches vs. hubs for connecting
  devices to network
• Routers can be used to
• isolate mission critical portions of LAN from
  rest of LAN
• Connect LAN to WAN to provide remote support

7
Network Media

• Unshielded twisted pair most widely used
• Fiber optic good for electrical noise immunity

8
Wireless

• Wireless technology continuing to evolve
• Security is an issue that needs to be addressed
  when using wireless

9
Hardware
10
Software

• When developing software architecture consider
• Where software applications should be installed
• Where the data should be stored
• Where the OPC server should be installed

11
Security
12
Fundamentals of Global Standards

• Security is a Process not a Project
• What are standards?
• How are standards enforced?
• Uniform Accounts
• Independent Security Administrators
• Process Control Systems are different from Office
  Systems

13
Unified Global Security Standards

• Know what is on your system
• Control the Easy Stuff
• Who has physical access
• Who has connections
• Who gets information about your system
• Have good Passwords

14
Unified Global Security Standards

• Accounts
• Make sure they are well identified
• Only create when definitely needed
• Delete when done
• Process Station Accounts should change passwords
  regularly
• FTP accounts must be limited

15
Ports and Services

• Shut down unused Ports and Services
• Review all necessary services
• Turn on monitoring and alerting
• Do not install sample applications on production
  systems
• Restrict SNMP Telnet
• Restrict FTP HTTP

16
Administration and Maintenance

• Learn to audit the systems
• Keep up-to-date with updates
• Restrict non-standard practices
• Control physical access
• Make Backups, Backup Backup again
• Limit remote connections
• Avoid Network Services on Process Control Machines

17
Administration and Maintenance

• Do NOT rely on Share Protection
• File/Folder ACL (Access Control Lists) should be
  used
• Do maintenance on accounts
• Limit who is an administrator
• Service accounts are special
• Control Domain Trusts

18
Attack Response

• Remain calm
• Keep an open mind
• Take good notes
• Notify the right people and get help
• Enforce a "need to know" policy
• Use out-of-band communications
• Contain the problem
• Make backups
• Get rid of the problem
• Get back in business

19
Redundancy Reliability
20
Software

• Primary backup ID status
• Redirection of clients in event of primary or
  backup failure
• Synchronization of archives
• I/O communication switching
• Synchronization of tags
• Failover time
• Cluster awareness
• Load balancing
• Ability to interact with power management systems
• Data replication across networks

21
Data Storage

• RAID drives
• Remote archives

22
Power

• UPS
• Surge Protector
• Redundant power supplies
• Line conditioners
• Generator

23
Hardware

• Fault tolerant computers
• Clusters
• Industrial computers
• Locate hardware where environmental factors are
  controlled

24
System Monitoring
25
Background

• What is System Monitoring?
• A systematic approach to ensure that your
  computer system runs as well as the first day it
  was installed.
• Allows you to observe the health of a system in
  real-time
• Under-utilized in most manufacturing applications
• Help catch problems before a disaster occurs and
  provide a tool for proactive maintenance
• Questions you can ask
• Does anyone ever look at the event viewer?
• Does anyone monitor key system variables?
• Do you know what the normal load on the system
  is?
• Is the system load staying the same or tracking
  up or down?

26
Objectives

• High Availability
• Ideally 99.999 (i.e. 5 minutes of
  downtime per year)average is 99.964 uptime
  (i.e. 3.2 hours of downtime per year)
• Allocation of Outages
• 20 Infrastructure
• 40 Applications
• 40 People

Infrastructure Power, Network, cabling, hardware,
Operating System
Application Custom and Commercial App maintenance
People Operator error, malicious activities,
deliberate outage for maintenance
27
System Level Management Process (SLM)

• Build the team
• Define the System
• Measure relevant variables
• Set system level objectives (SLOs)
• Apply Monitoring tools
• Improve through actions
• For more information SLAs www.nextslm.org
• Microsoft also has a tech-note on SLM/SLA at
• http//www.microsoft.com/technet/prodtechnol/windo
  ws2000serv/maintain/opsguide/slmgmtog.asp

28
1. Build the team

• One process owner (or Monitoring Manager) for
  each critical component
• Implement automated monitoring if system
  component where appropriate
• An internal team is necessary even if IT is
  outsourced
• Define typical duties for monitoring managers or
  Process Owners, e.g.
• Detect management events and raise alerts across
  multiple shifts
• Execute documented operational procedures for
  event escalations
• Follow data security procedure
• Adhere to maintenance contracts
• Provide regular feedback on operational
  performance
• Ensure detection of alerts from all
  infrastructure components
• Ensure that system resources are in good working
  order
• Monitor backup, restore, recovery and
  verification procedures

29
2. Define the System

• Data flow
• Identify boundaries
• Data providers and data consumers
• Focus on availability and performance
• E.g. PLC are data provider, desktop are data
  consumers goal is to deliver timely and
  accurate process data to desktop user

30
3. Measure Relevant Variables

• Select metrics that both team and operations
  agree are meaningful
• Document baseline data on CPU, RAM, Hard disk,
  web traffic, communication and monitor these
  systems for increased burden
• Monitor configuration changes (registry, patches,
  file permission, access control, user data)

31
4. Set Service Level Objectives (SLOs)

• Place rules (e.g. thresholds, filters, trends) to
  avoid false alarms
• E.g. physical memory drops below 20
• Also, include system wide deliverables e.g. 10
  minutes response time after an emergency
  maintenance request
• Monitor and reward team performance

32
5. Apply monitoring tools

• Partly this can be achieved by tools (software
  hardware) available in market today
• Consider using Agents (software programs),
  background task that monitors variables
• E.g. Network monitoring tool, email agent

33
6. Improve through Action

• Continuous Improvements is a way of life.
• E.g. as alarms and anomalies are experienced, the
  control part of System Monitoring and Control
  now becomes important. It is at this point that a
  change in hardware or procedure takes place so
  that it prevents the problem from occurring
  again.

34
Change Management
35
Change Management Process
36
Risk Levels
37
Testing Validation
38
Emergency Change Management
39
Support
40
Major Process Management Disciplines

• Incident Management
• Problem Management
• Change Management
• Release Management
• Configuration Management

41
Support Process Model
Management Tools
Incidents
Incidents
Service Desk
Incident Management
Changes
Problem Management
Releases
Change Management
Release Management
Configuration Management
Changes
Incidents
Releases
Problems Known Errors
Change Management Database
The ITIL Support Process Model
42
Backup And Recovery
Backup and Recovery

• A critical part of any application.
• Should be included in the design and
  implementation.

43
Types Of Backup

• Image
• Normal
• Incremental
• Differential
• Copy
• Daily

44
Image Backup

• Snapshot of entire disk
• No applications can be running
• Restore requires identical hardware
• Fastest to restore
• Norton Ghost is an example

45
Normal Backup

• Selected files are copied
• Marks file as backed up
• Best when many files have changed

46
Incremental Backup

• Best when fewer files change between backups
• Marks file as backed up
• Restore from the last normal backup and then add
  all the incremental backups

47
Differential Backup

• Copies only files new or changed since last
  normal or incremental backup
• Marks file as backed up
• Restore by restoring the last normal and the
  differential backup

48
Copy Backup

• Copies all selected files
• No files marked as backed up

49
Daily

• Copies all files that changed on the day the
  backup is performed
• No files marked as backed up

50
Software License Keys

• Software keys are common in automation software
  and usually cannot be backed up.
• Procedures must be obtained from the manufacturer
  and documented

51
Document The Recovery Process

• Disasters can happen when those that created the
  backup are unavailable
• Written procedures should be available to guide
  maintenance personnel through the recovery process

52
Thanks!

• The following companies contributed to the
  development of the MS MUG Best Practices
• 3M
• ARC Advisory Group
• Boeing
• Cisco
• Lousiana Center for Manufacturing Sciences
• Microsoft
• Procter Gamble
• Siemens
• Wonderware

53
For More Information

• MS MUG Best Practices document can be downloaded
  from the MS MUG website
• http//www.omac.org/wgs/MSMUG/msmug_default.htm
