Post-Placement Rewiring and Rebuffering by
Exhaustive Search for Functional Symmetries

• Kai-hui Chang, Igor L. Markov and Valeria Bertacco

University of Michigan at Ann Arbor
Nov. 7, 2005
2
Improving Deep Submicron Layouts

• Technology trends
• Wire delay becomes dominant
• Routability is exacerbated
• Manufacturing defects in vias become significant
• Making wires short and uncrossing them
• Decreases delay, power consumption
• Improves routability and yield

Rewiring
Permutational Symmetry
3
Optimization for Long Wires Buffering

• Buffering add buffers to drive long nets
• 70 gates will be buffers at 32nm Saxena04
• A buffer ? 2 inverters
• A single inverter is often enough

Phase-shift Symmetry
4
Post-Placement Rewiring and Rebuffering
Rewiring
Rebuffering
5
Post-Placement Rewiring and Rebuffering
Unified optimization is more powerful
g1
g1
Rewiring and Rebuffering
g2
g2
g5
g5
g3
g3
Composite Symmetry
g4
g4
6
Our Contributions

• A comprehensive symmetry detector
• Detects more symmetries more optimization
  opportunities
• Scalable enough for rewiring applications
• Applications of symmetries to rewiring
• Wirelength reduction comparable to detailed
  placement and is orthogonal to it
• Long-range rewiring
• Find equivalent wires that are further apart
• Innovative algorithm for rebuffering

7
Outline

• Symmetry detection
• Layout improvement
• Permutative rewiring
• Rebuffering
• Long-range rewiring
• Experimental results
• Conclusions

8
Symmetries in Boolean Functions

• Functional (semantic) symmetry
• Preserves functional relationshipbetween
  inputs/outputs
• Syntactic symmetry
• Preserves a specific representationof the
  function like circuit, BDD, etc.
• Syntactic symmetries ? semantic symmetries
• Detecting all semantic symmetries is more
  difficult

9
Previous Work Symmetry Detection

• BDD
• Limited to input symmetries
• Circuit
• Syntactic symmetries only
• Also used in rewiring C. W. Chang04
• Graph
• A permutation of vertices that maps edges to
  edges and preserves vertex colors

D. Moller93 A. Mishchenko03
C. W. Chang04 G. Wang03
P. T. Darga04
1
2
Symmetries detected (3, 4) (4, 5)
3
4
5
10
Symmetry Detection for Boolean Functions Using
Graphs
z x XOR y

• Two vertices for an input andits complement
• Two vertices for an output and its complement
• One vertex for each minterm/maxterm
• Edges from term to inputs
• Edges from term to outputs
• Feed the graph to Saucy for symmetry detection

Saucy is the graph symmetry detector used in
this work Darga, DAC 04
11
Two Symmetries Returned by Saucy
z x XOR y
z(8)
z(8)
z(9)
z(9)
t0(4)
t1(5)
t2(6)
t3(7)
t0(4)
t1(5)
t2(6)
t3(7)
x(0)
y(2)
x(0)
y(2)
x(1)
y(3)
x(1)
y(3)
x ? y
x ? x, z? z
12
1. Permutative Rewiring Concept and Algorithm

• If swapping/negating some pins can improve a
  certain objective accept the change
• Algorithm

• Extract sub-circuits iterativelyfrom the circuit
• Detect symmetries in thesub-circuit

circuit
13
1. Permutative Rewiring Concept and Algorithm

• If swapping/negating some pins can improve a
  certain objective accept the change
• Algorithm

• Extract sub-circuits iterativelyfrom the circuit
• Detect symmetries in thesub-circuit
• Try rewiring and see if wirelength(delay, power)
  is improved
• (a) Improved ?
• rewire
• (b) No improvement ?
• ignore the symmetry

circuit
sub-circuit
symmetric
14
1. Permutative Rewiring Sub-circuit Extraction

• Symmetries in sub-circuits represent rewiring
  opportunities
• Windowing is used
• To ensure efficiencyof symmetry detection
• It is a trade-off between coverage, runtime and
  rewiring quality
• Equivalent pins are more likely to be on
• Gates that are connected to each other
• Gates that connect to other common gates

15
1. Permutative Rewiring Sub-circuit Extraction
Techniques

• Depth first search (DFS) 1-4 gates
• Breadth first search (BFS) 3-4 gates
• Recursive bisection 4-8 gates
• Min-cut placer
• Bins contain cells that are tightly connected

16
2. Rebuffering

• Goal
• Reduce area and power by removing unnecessary
  inverters
• Improve circuit timing by moving inverters to
  more/less critical nets
• Logic equivalence is preserved
• Our algorithm

• Given a buffer to be inserted
• Extract a sub-circuit involving the wire
• Search for phase-shift symmetry involving the
  wire

17
2. Rebuffering

• Goal
• Reduce area and power by removing unnecessary
  inverters
• Improve circuit timing by moving inverters to
  more/less critical nets
• Logic equivalence is preserved
• Our algorithm

• Given a buffer to be inserted
• Extract a sub-circuit involving the wire
• Search for phase-shift symmetry involving the
  wire
• Rebuffer according to the symmetry

or
18
3. Long-Range Rewiring

• Idea F. Lu04A. Mischenko05(FRAIG)
• Find equivalent wires that are further apart
• Further reduce wirelength by reconnecting
  equivalent wires
• Algorithm
• Use simulation to identify potentially
  equivalent wires
• Check for wirelength improvement
• CNF-SAT is used to prove the equivalence
• Equivalence checking can be pruned if no
  wirelength reduction can be gained

Equivalent
19
3. Long-Range Rewiring Algorithm

• Simulate using random patterns
• Generate a signature for each wire (simulated
  values)
• For wires with identical signatures
• Try to reconnect them
• If wire is not shortened, abandon the
  reconnection
• If wire is shortened, use CNF-SAT solver to check
  equivalence, abandon the reconnection if not
  equivalent

010
010
110
1. Random simulation
3. Try to reconnect 4. Equivalence Checking
2. Possibly equivalent
011
010
111
20
Experimental Setup

• Placer Capo. Symmetry detector Saucy
• Nodes and nets generated by blif2book.exe
  provided in the GSRC bookshelf
• The converter was enhanced to generate standard
  cells of different sizes
• e.g., NAND and BUF are 2x larger than INV
• Benchmarks

21
Our Experiments
Globalplacer
Detailed placer
Nodes,nets
Global placement
Detailed placement
All netlist transformations were verified by
equivalence checking
22
Experimental Results 1Number of Symmetries Found

• Symmetries represent potential for improvement
• Most previous works focus on input symmetries
• Phase-shift and output symmetries should also be
  exploited for better optimization

23
Experimental Results 2 Performance of
Permutative Rewiring
Comparison between Rewiring and Detailed Placement
24
Experimental Results 3 Performance of
Permutative Rewiring
Performance Comparison Before and After Detailed
Placement
25
Experimental Results 4Performance of Long-Range
Rewiring
Long-Range Rewiring Before and After Permutative
Rewiring

• Long-range rewiring can further reduce wirelength
  and should be applied after permutative rewiring
• Cumulative wirelength reduction becomes 5.17
• 5 improvement is significant
• It is independent of other optimizations
• It does not require any changes in existing tools
• It leads to a comparable reduction in via counts
• For example, in b10, 5.7 reduction in number of
  vias is observed

26
Summary of Experimental Results
Globalplacer
Detailed placer
Nodes,nets
Global placement
Detailed placement
Wirelength reductions from permutative rewiring
and detailed placement are similar
Long-range rewiring and permutative rewiring are
independent optimizations
Phase-shift and output symmetries should also be
utilized
Permutative rewiring and detailed placement are
independent optimizations
All netlist transformations were verified by
equivalence checking
27
Discussion

• Advantages
• It does not change any placement
• It is safe and can be applied with every flow
• It can optimize a broad variety of objectives
• It considers both input and output symmetries
• E. g., in multi-bit adders order of inputs and
  outputs can be permuted, but only simultaneously
• Greater benefits when gates are larger and pins
  are further apart
• Limitations
• Performance depends on the benchmark
• Reduction ratio decreases when design gets larger
  similar to detailed placement

28
Conclusions and Future Work

• Comprehensive detection of functional symmetries
  in small circuits
• Suitable for rewiring
• The more symmetries, the more optimization
  opportunities
• Permutative rewiring is effective and appears
  orthogonal to detailed placement
• Long-range rewiring can further reduce wirelength
• Overall wirelength reduction is 5.17
• Symmetry-based rebuffering proposed
• Better use of phase-shift symmetry
