• Lecture 23

2
Previous Lecture

• Source of deterministic errors and random noises
• Basics of signal spectrum
• Nyquist sampling
• Fourier transform
• Basic filters
• What you can do and when you should ask for help

3
Overview of Todays Lecture

• What is middleware?
• CORBA
• Java (EJB)
• DCOM
• Comparing different middleware
• Get to know one middleware (CORBA) in depth
• Middleware in embedded systems
• What are the criteria?

4
Moving Beyond A Single Processor

• So far, weve only dealt with the issues of a
  single embedded processor
• What if we want to get embedded processors to run
  applications that communicate across the network?
• Networked/distributed programs
• Processes that communicate over the network (or
  on the same machine)
• Client piece of code that requests services
• Server piece of code that provides the services

5
Writing Distributed Programs

• Common ways of writing distributed client-server
  programs
• Sockets
• Low-level interface to the operating system for
  TCP and UDP
• STREAMS
• Even lower-level interface within the kernel
  (almost device-driver level)
• Shared memory
• Low-level interface for clients and servers on
  the same machine to communicate using a chunk of
  memory that they share
• Shared files
• Clients and servers exchange information through
  a shared file system
• RPC (Remote Procedure Call)
• Clients communicate with long-lived server
  processes (daemons) over the network

6
Socket Programming

• Servers role
• Binds to an Internet (IP) address
• Listens for clients on the network
• Provides services to clients that connect to it
• Clients role
• Knows the servers IP address
• Connects to the server
• Sends service requests
• Client and server exchange messages over TCP or
  UDP
• Socket/networking code mixed with real client
  and server logic

Server
Client
Listens for more clients
TCP or UDP
TCP or UDP
Exchange of messages over an established
connection
7
Low-level Network Programming

• Very efficient mechanism
• Available on almost every operating system
• Standardized application programming interface
  (API)
• Can be used for clients and servers to
  communicate on the same machine and across the
  network
• But ..
• Exposes too many low-level details
• Application writer must be able to debug
  network-level issues and problems
• Mixes application logic with networking logic
• Clients must know where servers live
• If client and server run on different
  byte-ordered machines, they must be aware of
  these differences in talking to each other

8
.. And Middleware was Born

• Layer between the operating system and the
  application
• Hides the operating systems details from the
  application developer
• CORBA, EJB, DCOM
• Why do we need/have middleware?
• It makes it easier to write distributed
  applications
• Takes care of all the networking code and the
  messaging
• Leaves you free to focus on writing the
  application

9
High-Level Overview of Middleware
10
CORBA (Common Object Request Broker Architecture)

• Middleware for interoperability from

  the Object Management
  Group
• CMU is a member of the OMG, along

  with 800 other
  companies/universities
• The key component is the broker (ORB)
• Shields the client and the server from

  each
  others differences
• Whats the CORBA client-server model?
• Language transparency Clients and servers can be
  written in different programming languages
• Location transparency Client and server dont
  care about each others locations
• Interoperability Clients and servers can run on
  different hardware, operating systems and still
  be able to talk to each other using a protocol
  called IIOP
• No support for distributed garbage collection
• Real-Time CORBA standard available

11
CORBA - Putting All The Pieces Together
12
J2EE (Java 2 Enterprise Edition)

• Sun Microsystems Java-based middleware
• Implicitly has all of Javas portability
  advantages
• Component application-level software unit
• Container runtime support/services for a
  component
• On the client side
• Applets, application clients executing in their
  own JVM
• On the server side
• Web components
• Servlets and Java Server Pages (JSP)
• Enterprise Java Beans (EJB) components can
  contain two kinds of objects
• Session beans valid for the duration of a
  client-server session
• Entity beans valid for the lifetime of the
  persistent data that it manages
• What makes J2EE powerful?
• Can interface to multiple existing back-end
  systems and technologies
• Power of Javas intrinsic portability, graphical,
  web garbage collection capabilities
• Real-Time Java standard available

13
J2EE - Putting All The Pieces Together
14
DCOM (Distributed Component Object Model)

• Microsofts middleware
• DCOM server
• Body of code containing multiple objects
• Each object can support multiple interfaces
• Can be written in Java, C, Pascal
• DCOM client
• Gets a pointer to one of the interfaces
• Talks to the server over that interface
• Doesnt care if the server is local or remote
• Client-server communication
• Occurs over the Object Remote Procedure Call
  (ORPC)
• Originates from DCEs RPC (where Distributed
  Computing Environment, or DCE, was one of the
  earliest middleware platforms)
• The broker is called the Service Control Manager
  (SCM)
• Some support for distributed garbage collection

15
DCOM - Putting All The Pieces Together
16
Critical Thinking

• What are the differences between DCOM, EJB and
  CORBA?

17
Overview of CORBA
18
Interface Definition Language (IDL)

• Used to define
• Interfaces methods or behavior (but not
  attributes or state) of a server object
• Modules packages of related interfaces and types
• IDL is not a programming language
• No conditional constructs such as if, else, then,
  while, do, etc.
• IDL compiler
• Provided with every ORB
• Input Servers interface in IDL
• Output Skeleton and stub in a programming
  language (Java, C, etc.)
• What are the IDL types?
• Basic types octet, char, short, long, double
• Structured types string, sequence,
  union, struct
• Arbitrary types any
• User-defined types e.g., interfaces

19
Example of an IDL Interface
module Bank exception ZeroBalance
typedef sequence DepositHistory
interface Account
string getBalance(in string accountNumber)
void depositMoney(in double amount,

out double balance,
inout
DepositHistory latest) double
withdrawMoney (in double amount)
raises (ZeroBalance)
20
Stubs and Skeletons

• What is a stub, anyway?
• Automatically generated by the IDL compiler
• Client-side glue in Java/C
• Marshals (packages) parameters from the client
  into a message to be sent to the server
• Unmarshals results from the response message
• What is a skeleton, anyway?
• Automatically generated by the IDL compiler
• Server-side glue in Java/C
• Unmarshals (unpackages) messages into the
  parameters that the client
  intended to send
• Marshals results into a response message

21
Portable Object Adapter (POA)

• Exists only within CORBA servers
• Dispatches incoming requests to the right target
  servants
• Also acts as a namespace for the collection of
  servants it manages
• Additional policies that you can use to customize
  a POA
• Multithreading
• Activation on demand
• Persistent references (lifespan of objects)
• Unique object identifiers
• A server process can have multiple POAs, each
  configured differently, and each responsible for
  a certain set of servants

22
CORBAs Protocols

• General Inter-ORB Protocol (GIOP)
• Specification of a protocol, and not the
  implementation
• Eight message formats Request, Reply,
  LocateRequest, LocateReply, CancelRequest,
  MessageError, CloseConnection, Fragment
• Well-defined headers for every message
• Carries the senders byte ordering
• Can be mapped onto any real protocol that is
  connection-oriented
• Internet Inter-ORB Protocol (IIOP)
• Concrete implementation of GIOP specification
  onto TCP/IP
• Must be supported by every ORB
• Allows objects to communicate without caring
  about their operating systems, hardware
  architectures, etc.

23
Other CORBA Components

• Implementation Repository
• Stores location of the executables in your file
  system
• Run-time registry of servers and clients
• Very specific to the vendor
• Interface Repository
• Stores the type information of all CORBA objects
  in your application
• Dynamic invocation interface implies that you
  dont know your types ahead of time, and you can
  look these up at run-time
• Naming Service
• Registry of user-friendly names associated with
  object references
• Servants can bind references by a name
• Clients can look up references by that name

24
Interoperable Object References (IORs)

• Stringified format of a reference
• Can be stored in a file, sent across the network,
  etc.
• Contains servers hostname, port number, object
  key, etc.
• Sample IOR looks like this
• IOR010000001000000049444c3a4163636f756e743a312e
  30000200000000000000300000000101000013000000752d6d
  61792e7468696e6b6f6e652e636f6d00007b0900000c000000
  424f410a20b053000005503010000002400000001000000010
  00000010000001400000001000000010001000000000009010
  10000000000

25
System and User Exceptions

• Exception Something bad/illegal/undesirable
  occurred
• System Exceptions
• Defined within the CORBA standard
• Can alert the application of communication
  errors, resource exhaustion, invalid
  object references, host crashes
• Usually raised by the ORB before the request gets
  to the servant
• Format of a System Exception
• Minor code Identifies the source of the problem
  (e.g., COMM_FAILURE)
• Completion status COMPLETED_YES, COMPLETED_NO,
  COMPLETED_MAYBE
• Make sure that your CORBA clients catch system
  exceptions!
• User Exceptions
• Can be defined within IDL interfaces
• Each method of an interface can raise exceptions

26
(No Transcript)
27
Inside Your Netscape Browser
28
Middleware in Embedded Systems

• Requirements
• Limited resources Smaller footprint (requires
  less code-bloat)
• Real-time support (available in Real-Time CORBA
  specification)
• Full CORBA implementation 150 Kbytes 5 Mbytes!
• What are your options?
• Minimal CORBA Throw out some of the heavyweight
  CORBA mechanisms ( 30-60 Kbytes)
• IIOP Engine Use a library that keeps only the
  IIOP protocol part ( 15 Kbytes)
• CORBA Gateways TCP bridge from the embedded
  processors to a CORBA gateway that talks to the
  rest of the world

29
Using CORBA Gateways
30
Summary of Lecture

• What is middleware?
• CORBA
• Java (EJB)
• DCOM
• Compare the different middleware
• Get to know one middleware (CORBA) really well
• Middleware in embedded systems
• What are the criteria?
