Beyond Web Parts: Rapid Web Application Development Using Windows SharePoint Services 3'0

1
Beyond Web Parts Rapid Web Application
Development using Windows SharePoint Services 3.0
Nadeem Mitha, MCTS (WSS App Dev) Infusion
Development nmitha_at_infusiondev.com http//home.inf
usionblogs.com/nmitha
2
Overview

• The advantages of leveraging SharePoint lists
• The approach at a high level
• The basics (no code required)
• Rolling up sleeves (some code required)
• Common reusable customizations
• Application-specific custom tailoring
• Options for reporting

3
Why Build Your Web Application on Windows
SharePoint Services?
4
Why Build Your Web App on WSS?

• Common answer WSS lets you integrate document
  libraries, discussions and other SharePoint
  entities into your web application
• In other words, applications built on SharePoint
  are for collaboration.

5
Why Build Your Web App on WSS?

• We can leverage more from WSS. Think Lists
• User-manageable content types
• Provide Create, Retrieve, Update and Delete
  (CRUD) functionality and search w/o code
• Security model and auditing w/o code
• Inheritance, item-level ACLs, security groups
  with ability to designate owners, draft item
  security, limit user to modifying only items they
  create

6
Why Build Your Web App on WSS?

• Lists offer even more
• Web services and RSS w/o code
• Recovery support via recycle bin w/o code
• Content approval, version history, alert
  notifications and workflow w/o code
• Support for creating and saving personal views
  w/o code
• Integration with Excel w/o code

7
Common Developer Myths about Customizing
SharePoint
8
Myths

• Myth 1 Customizing SharePoint amounts to writing
  custom web parts
• Myth 2 Its hard to force SharePoint do anything
  differently, or do something it cant do OOTB

9
The Approach
10
The Approach

• Define entities as content types
• Entity properties site columns
• Relate entities via lookup columns
• Attach content types to lists, enable and
  leverage desired list features
• Write or reuse customizations that provide base
  functionality and glue

11
The Approach

• Use event receivers, workflows, custom context
  menu actions or web parts as a means to kick off
  custom code for business logic
• Use the Object Model to make things happen in
  SharePoint

12
SharePoint 2003? forget about it
13
WSS 2.0 Wont Work

• WSS 2.0 event receiver framework is too
  inadequate
• WSS 2.0 has no OOTB workflow support
• WSS 2.0 does not employ content types
• WSS 2.0 does not support multi-valued lookup
  columns

14
The BasicsWhat You Can Do Before You Need
Custom Code
15
The Basics

• Use OOTB content type and list functionality
• Define an entity definition as a content type
• Use OOTB field types to create columns for each
  attribute/property of the entity
• Wide selection for basic column types
• Add any calculated columns you might need
• Use inheritance, have a base content type

16
Defining an entity using a content type and OOTB
field types
17
The Basics

• Introduce lookup columns to relate entities
• Real world data has relationships with other data
• WSS 3.0 (SharePoint 2007) now allows multiple
  values to be assigned to a single lookup field
• Allows many-to-many relationships
• Myth Lookup columns only work for lists on the
  same site (SPWeb)
• Not true create the lookup column on the site
  containing the list, then use the column in any
  sub-site of that site

18
Relating entities using lookup columns
19
The Basics

• Count Related feature of the lookup column
• Column value will display the number of items in
  another list that link to the current item
• Example
• List of Status Reports
• Each Status Report linked to a Project using
  lookup
• Each Project can show of associated Status
  Reports when you define a lookup column on
  Projects (into Status Reports) has a display
  field with the text (Count Related) selected

20
The Basics

• Content types can be packaged for reuse and
  deployment by using the feature framework
• Well-documented
• Can define your content type in the UI and
  extract the XML markup (CAML) for creating the
  feature

21
Time to go beyond OOTB
22
Advanced Columns and Custom Field Types

• Computed columns
• Render HTML based on CAML markup
• Three deployment options Object Model
  (AddFieldAsXml), web services or feature
  framework
• Good for generating hyperlinks to actions or
  related content
• Tip Computed field can use count related field
  to create link to view showing related entities

23
Computed column
24
Advanced Columns and Custom Field Types

• Custom field types
• Well-documented
• Validation is straightforward (override
  GetValidatedString method and throw
  SPFieldValidationException when value is invalid)
• Facilitated by Visual Studio template
• Can override controls for editing, rendering
  field and defining column
• Last is free if you have only simple custom
  properties

25
Common Reusable Customizations
26
Cross-Listing DataImplementing Two-Way
Bidirectional Lookups

• Scenario
• Several Technologies are associated with any
  given Project
• Each Technology item should list all associated
  Projects that use (are associated with) that
  Technology
• This makes it easy to filter the Technologies
  list to show only those Technologies associated
  with a particular Project (similar to a simple
  join)

27
Cross-Listing DataImplementing Two-Way
Bidirectional Lookups

• Implementation
• Use the event receiver framework to capture
  ItemAdding and ItemUpdating events on the
  Projects list
• Procedure for creating and registering event
  receivers is well-documented
• Can use a tool such as SharePoint Inspector to
  bind your event receivers (find using Google)

28
Cross-Listing DataImplementing Two-Way
Bidirectional Lookups

• Implementation (continued)
• The back reference column on the Technology
  content type can be hidden on just the new and
  edit forms and still visible on the display form
• Method 1 Edit fields CAML (OM, web services or
  in feature definition)
• Method 2 Use tool such as SharePoint Tips
  Utility Pack (find on Google)

29
Cross-listing data (bidirectional lookup)
30
Site ProvisioningCreating SharePoint Sites
Linked to New List Items

• Scenario
• New Project item is created
• Each Project can (or must) have its own
  associated SharePoint site
• Think Document Workspace, but for list items
• Implementation
• Kick off OM code to create site using event
  receiver, or using context menu action on list
  item

31
Site ProvisioningCreating SharePoint Sites
Linked to New List Items

• Implementation (continued)
• Site can carry reference to the associated list
  item by storing list item ID or title in site
  property bag
• Can allow unpriveleged users to create these
  sites using SPSecurity.RunWithElevatedPriveleges
• Note must use context URLs to instantiate new
  SPWeb object in the elevated code method since
  any existing SPWeb (e.g., from context) will
  carry over users restricted permissions

32
Creating site linked to new list item
33
List View Filtered by ContextDisplaying View of
List in a Sub-Site, Specific to the Sites
Associated List Item

• Scenario
• Homepage of Project site must show list of all
  Technologies associated with the project
• The related Technologies list should show
  additional properties of each Technology
• Method 1 Page Viewer
• Page Viewer to show list, querystring to filter
• Custom aspx to show list without chrome (Google
  PrintList.aspx

34
List View Filtered by ContextDisplaying View of
List in a Sub-Site, Specific to the Sites
Associated List Item

• Method 2 Remote List View Web Part
• Custom or third party web part
• Free implementation at KWizCom.com
• Can code connections support, or build filtering
  into web part
• List viewer looks at property bag for filtering
  data
• Method 3 Data View Web Part
• Well-documented
• No need to unghost (can export/import web part)

35
List View Filtered by Context
36
Populating Form Values by ContextPre-Selecting
Values in New Forms Based on Where New was
Clicked

• Scenario
• List of Technologies on your Project homepage has
  an Add New Technology link at the bottom
• User expects added technology to be associated
  with current project
• Implementation
• Add querystring parameter to the Add New
  hyperlink
• AssociatedProjectltThe Project Namegt

37
Populating Form Values by ContextPre-Selecting
Values in New Forms Based on Where New was
Clicked

• Implementation (continued)
• Use JavaScript on NewForm.aspx to select the
  appropriate project based on the querystring
  parameter
• One option for adding JavaScript is to add custom
  web part to NewForm.aspx (or content editor web
  part)
• Append ToolPaneView2 querystring parameter
• Other options for adding JavaScript master page,
  custom.js

38
Pre-selected value in New Form based on context
39
Application-Specific Custom Tailoring
40
Customizing the List Item Context Menu

• Appears when the drop-down arrow in the Title
  field is clicked
• Easiest use is to redirect user to an aspx page
  while passing the list item ID as a parameter
• Example CreateSite.aspx?AssociatedItemId3
• JavaScript-based. Google CAMOpt and look at
  CORE.js for examples.
• Local or global change possible

41
Customizing the OOTB New/Edit Forms

• Create and use custom field types
• Edit or replace NewForm.aspx and/or EditForm.aspx
• Change on a per list basis using ToolPaneView2
• Can use OM to switch these pages at a content
  type level
• Fields can be modified to be hidden from New or
  Edit forms as necessary

42
Reporting
43
Customizing the OOTB New/Edit Forms

• Could be a lengthy presentation on its own
• For now, just know that you have several options
• Option 1 OOTB Access or Excel integration (pivot
  tables, etc)
• Option 2 Create usable views of list data in
  SQL, then use with SQL Reporting Services,
  Crystal Reports, etc (contact me for C script)
• Option 3 Third-party solution

44
Questions?
Nadeem Mitha, MCTS (WSS App Dev) Infusion
Development nmitha_at_infusiondev.com http//home.inf
usionblogs.com/nmitha
