Fatigue Testing: The Effects of Different Surface Treatments on Nitinol

1
Fatigue Testing The Effects of Different Surface
Treatments on Nitinol

• Presented by
• Lucy Zhu
• Senior Project MatE 198B
• Advisor Dr. Stacy Gleixner
• Instructor Dr. Richard Chung
• May 11, 2001

2
Overview

• Motivation
• What are Stents?
• What is Nitinol?
• Purpose
• Experimental Procedure
• Results and Discussion
• Conclusions
• Future Work

3
Motivation

• Cardiovascular disease is the leading cause of
  death in America
• Biomaterials and biomedical devices are in demand

4
What are Stents?

• Permanent implant used to open coronary arteries
  and provide support
• Made from laser cut tubing
• Most commonly made from stainless steel or nitinol

Multilink stent by Guidant Ref Handbook of
Coronary Stents
Crossflex stent Ref Handbook of Coronary Stents
5
What is Nitinol?

• Metal alloy which consists of about 50 Ni atoms
  and 50 Ti atoms
• Advantageous properties
• Shape memory alloy
• Superelastic alloy
• Biocompatible
• Mechanical properties

Stent by Cordis NDC
6
Surface Treatments

• Electropolished nitinol produces a biocompatible
  TiO2 surface
• Surface preparation is crucial before
  electropolishing
• Natural oxide
• Sandblast
• Chemical etch
• Electropolish

7
Purpose

• Distinguish the effects of different surfaces
  treatments on nitinol
• Fatigue test
• Explain the effect of surface treatment on
  fatigue life

8
Literature Review

• Rotary bend fatigue testing of wire
• Strain-controlled
• Fatigue life is highly dependent
• Test temperature
• Aging
• Strain

Jianhua Yang. Fatigue Characterization of
Superelastic Nitinol, 1997
9
Experimental Procedure

• Prepare nitinol wire with different surface
  treatments
• Natural black oxide
• Sandblasted
• Chemical etch
• Electropolished

10
Experimental Procedure

• Tensile test wire to observe mechanical
  properties
• Fatigue test wire
• Strain controlled bend test
• 1, 2, 3 strain, 20 oC, in air
• Cycle to failure
• Analyze surface features
• Surface roughness
• Surface defects

11
Bend Fatigue Test Setup
Lever cycles up and down
Nitinol wire
Weight
Machine designed and built by SMA, Inc.
12
Surface Treatments
Natural Oxide (200X)
Sandblasted (200X)
Etched (200X)
Images obtained from an optical microscope
Electropolished (200X)
13
Results of Fatigue Data
14
Fatigue Data Summary
Values based on an average of 10 samples
15
Results

• Decrease strain, increase life
• Cycles to failure dependent on surface conditions
• Electropolished wire failed first, sandblasted
  wire failed last

16
Discussion

• Sandblasted
• Etched
• Natural oxide
• Electropolished

0.0220
0.0218
0.0221
0.0206
(200X)
17
Conclusions

• Fatigue life is affected by strain and surface
  treatment
• Surface defects can lead to premature failure

18
Future Work

• Cycle at lower strains
• Perform test in an environment which simulates
  the human body
• Use SEM to analyze surface features

19
Acknowledgements

• Advisor Dr. Stacy Gleixner
• Instructor Dr. Richard Chung
• Sponsor Shape Memory Applications, Inc.
• Dr. Darel Hodgson
• Carolyn Rice
• Elgin Bravo

20
Thank You
21
Tensile Test Results
