A Research Program in Reliable Adaptive Distributed Systems RADS

1
A Research Program inReliable AdaptiveDistribute
d Systems (RADS)

• Armando FoxStanford University
• Michael Jordan, Randy Katz, George Necula, David
  Patterson, Doug Tygar
• University of California, Berkeley

2
Presentation Outline

• A New Vision for Networked Systems
• Enabling Technology Statistical Learning Theory
• Approaches for Dependability
• Approaches for Security
• Elements of an Experimental Prototype
• Summary and Conclusions

3
Presentation Outline

• A New Vision for Networked Systems
• Enabling Technology Statistical Learning Theory
• Approaches for Dependability
• Approaches for Security
• Elements of an Experimental Prototype
• Summary and Conclusions

4
Networked SystemsCurrent State-of-the-Art

• Todays systems fragile, easily broken, yielding
  poor reliability and security
• Complexity of configurations by humans is
  overwhelming, infrequently correct, yielding lack
  of dependability and introducing vulnerabilities
• 50 outages, 90 security break-ins attributed
  to configuration
• Attackers exploit known problems faster than
  system managers apply known fixes
• Overly focused on performance, performance, and
  cost-performance
• Systems based on fundamentally incorrect
  assumptions
• Humans are perfect
• Software will eventually be bug free
• Hardware MTBF is already very large, and will
  continue to increase
• Maintenance costs irrelevant vs. purchase price

5
Networked SystemsCost of Failure and its
Inevitability

• Outage Costs
• Amazon Revenue 3.1B, 7744 employees
• Revenue (24x7) 350k per hour
• Employee productivity costs 250k per hour
• Total Downtime Costs 600,000 per hour
• Employee cost/hour comparable to revenue, even
  for an Internet company
• People/HW/SW failures are facts, not problems
• If a problem has no solution, it may not be a
  problem, but a fact--not to be solved, but to be
  coped with over time Shimon Peres (Peress
  Law)
• Recovery/repair is how we cope with them

6
Principles for Reliable Adaptive Distributed
Systems

• Given errors occur, design to recover rapidly
• Partial Restart
• Crash only software (1 way to start, stop)
• Given humans make (most of the) errors, build
  tools to help operator find and repair problems
• Pinpoint the error
• Undo of human error
• Note Errors often associated with configuration
• Recovery benchmarks to measure progress
• What you cant measure, you cant improve
• Collect real failure data to drive benchmarks

7
Networked SystemsComponents of New Approach

• Statistical learning algorithms that observe and
  predict future behaviors
• Verification techniques that check for correct
  behavior, reveal vulnerabilities, harness
  techniques for the rapid generation of behaviors
  with desirable properties
• Programmable network elements allowing active
  code to be inserted into the network, to provide
  observation and enforcement points without the
  need for access to user end systems

8
Interdisciplinary Expertise

• SLT (Jordan), Network Services/Protocols (Fox,
  Katz, Patterson, Stoica), and Verification
  Methods applied to network and security behaviors
  (Stoica, Tygar)
• Comprehensive distributed architecture embedding
  SLT as building block for critical components for
  system observation, coordination, inference,
  correction, and evolution of behaviors
• Components suitable for embedding in distributed
  systems
• Network behaviors that reveal correct or
  incorrect operation of higher-level network
  applications
• Embedding observational and inference means at
  strategic points in the network, obviating need
  to modify end hosts or applications
• System level heterogeneity and ability to
  generate new behaviors on demand in response to a
  dynamic system threat environment to achieve
  enhanced dependability and resilience to attack
• Enabling applications for investigation will
  include web services, intrusion detection,
  storage access

9
Presentation Outline

• A New Vision for Networked Systems
• Enabling Technology Statistical Learning Theory
• Approaches for Dependability
• Approaches for Security
• Elements of an Experimental Prototype
• Summary and Conclusions

10
Statistical Learning Theory

• Toolbox for design/analysis of adaptive systems
• Algorithms for classification, diagnosis,
  prediction, novelty detection, outlier detection,
  quantile estimation, density estimation, feature
  selection, variable selection, response surface
  optimization, sequential decision-making
• Classification algorithms
• Recent scaling breakthroughs 10K features,
  millions of data points
• Kernel machines functional analysis and convex
  optimization
• Generalized inner productsimilarities among data
  point pairs
• Defined for many data types
• Classical linear statistical algorithms
  kernelized for state-of-the-art nonlinear SLT
  algorithms in many areas

11
Statistical Learning Theory

• Novelty Detection Problem
• Unlimited observations reflecting normal
  activityYet few (or no) instances that reflect
  an attack or a bug
• Second-order cone program a convex optimization
  problem with an efficient solution method
• Given cloud of data in a high-dimensional feature
  space, place a boundary around these to guarantee
  that only a small fraction falls outside
• Needed on-line variants of SLT algorithms that
  update the learning systems state based on small
  sets of data
• Available for some kernelized problems
• On-line versions of the best algorithms have yet
  to be developed!

12
Statistical Learning Theory

• Super kernels combine heterogeneous data via
  multiple kernels
• Semidefinite programs, convex optimization
  problems with efficient solutions involving
  efficient decomposition techniques
• Useful in fusing evidence at distributed nodes
• Problems of interest require combined parameter
  estimation and optimization
• Response surface methodology building local
  mappings from configurations to performance, and
  suggesting gradient directions in configuration
  space leading to performance improvements
• Policy-gradient methods SLT algorithms that make
  sequences of decisions, yielding a behavior or
  policy successfully developed policies for
  nonlinear control problems involving high degrees
  of freedom

13
Statistical Machine Learning

• Kernel methods
• neural network heritage
• convex optimization algorithms
• kernels available for strings, trees, graphs,
  vectors, etc.
• state-of-the-art performance in many problem
  domains
• frequentist theoretical foundations
• Graphical models
• marriage of graph theory and probability theory
• recursive algorithms on graphs
• modular design
• state-of-the-art performance in many problem
  domains
• Bayesian theoretical foundations

14
Vision

• First 50 years of computer science
• manually-engineered systems
• lack of adaptability, robustness, and security
• no concern with closing the loop with the
  environment
• Next 50 years of computer science
• statistical learning systems throughout the
  infrastructure
• self-configuring, adaptive, sentient systems
• perception, reasoning, decision-making cycle

15
Example I Statistical Bug-finding

• Programs are buggy, yet people use them
• Exploit this use user trials to debug programs
• Outline of system
• Instrument programs to take samples at runtime of
  program state
• Collect information over the Internet
• Learn a statistical classifier based on
  successful and failed runs, using feature
  selection methods to pinpoint the bugs

16
Case Study BC

• Array overrun bug in re-allocation routine
  more?arrays() leads to memory corruption and
  sometimes an eventual crash 2908 features
• All top feature indicate indx being unusually
  large
• storage.c176 more?arrays() indx ? optopt
• storage.c176 more?arrays() indx ? opterr
• storage.c176 more?arrays() indx ? use?math
• storage.c176 more?arrays() indx ? quiet
• storage.c176 more?arrays() indx ? f?count
• And this indeed pinpoints the bug

17
Example II Novelty Detection

• The goal is binary classification
• but all of the training data come from one class
• Many practical applications
• intrusion detection
• machine diagnostics
• Basic problem---find a boundary that encloses a
  desired fraction of the data, and is as tight as
  possible
• can be done using the generalized Chebyshev
  inequality
• using kernels, this is a convex problem

18
Case Study Analog Circuit Design

• case study---a Low Noise Amplifier (LNA) for
  wireless applications
• 7 design parameters (transistor size, bias
  currents, etc)
• 50,000 positive samples
• visualize the projection of feasible solutions in
  a plane representing second-order harmonic
  distortion (HD_2) and third-order (HD_3) harmonic
  distortion

19
Case Study Analog Circuit Design
20
Example III Diagnosis

• A probabilistic graphical model with 600 disease
  nodes, 4000 finding nodes
• Node probabilities p(f_i d) were assessed from
  an expert (Shwe, et al., 1991)
• Want to compute posteriors p(d_j f)
• Is this tractable?

21
Case Study Medical Diagnosis

• Symbolic complexity
• symbolic expressions fill dozens of pages
• would take years to compute
• Numerical simplicity
• Jaakkola and Jordan (1999) describe a variational
  method based on convexity that computes
  approximate posteriors in less than a second

22
Presentation Outline

• A New Vision for Networked Systems
• Enabling Technology Statistical Learning Theory
• Approaches for Dependability
• Approaches for Security
• Elements of an Experimental Prototype
• Summary and Conclusions

23
Crash-Only SoftwareDramatically Simplifying
Recovery

• Robust systems must be crash-safe
• Restart-curable bugs cause outages
• Rebooting eliminates many corruptions
• Why support any other kind of shutdown/restart??
• Crash-only software,
• Shutdown crash recover restart
• Software components provide external PWR switch
  independent of component behavior
• Recovery is inexpensive/safe to try
• Crash-only power switch infrastructure is
  simpler than apps, common to all of them
• Higher confidence that it will work
• Like transaction invariants yet focused on
  recovery
• Can machine learning and statistical monitoring
  approaches be applied during online operations?

24
Crash-Only Software Simplified Recovery
Management

• Failure detection and recovery management are
  hard
• How to detect that somethings wrong?
• How do you know when recovery is really
  necessary?
• Will a particular recovery technique work?
• What is the effect on online performance?
• What if you needlessly over-recover?
• Predictable, fast recovery simplifies failure
  detection and recovery management
• Something doesnt look the way it used to
  anomaly
• Not all anomalies are failures... but
  over-recovering is OK
• If rebooting suspected-bad component doesnt
  work reboot its larger containing group,
  recursively
• Leverage for applying statistical monitoring
  machine learning

25
Crash-Only SoftwarePractical to Build

• Case studies two crash-only state-storage
  subsystems (for session state and durable state)
• OK to crash any node at any time for any reason
• Recovery is highly predictable, doesnt impact
  online performance
• Replication provides probabilistic durability
  capacity during recovery
• Access pattern exploited for consistency
  guarantees
• Nine activity state statistics monitored
  per storage brick
• Metrics compared against those of peer bricks
• Basic idea Changes in workload tend to affect
  all bricks equally
• Underlying (weak) assumption Most bricks are
  doing mostly the right thing most of the time
• Anomaly in 6 or more (out of 9) metrics reboot
  brick
• Simple thresholding and substring-frequency used
  to determine anomalous

26
Crash-Only Statistical Monitoring Resilience
to Real-World Transients

• Simple fault model observed anomalies coerced
  into crash faults
• Surprise! Statisticalmonitoring catches
  manyreal-world faults, withouta pre-established
  baseline
• Memory bitflips in code, data, checksums (
  crash)
• hang/timeout/freeze
• Network loss (drop up to 70 of packets
  randomly)
• Hiccup (eg from garbage collection)
• Persistent slowdown (one node lags the others)
• Overload (TCP-like mechanism used to generate
  backpressure)

27
Generalizing Crash-Only Micro-reboots

• Add micro-reboot (uRB) support to middleware
• Enhance open-source JBoss J2EE application server
  with fault injection, code path tracing,
  micro-reboots
• Use automated fault injection observation to
  infer propagation of exceptions
• During operation, micro-reboot components or
  component groups suspected of being correlated to
  an observed failure
• uRBs improve performability
• 2-3 orders of magnitude faster than full
  reboots or application reload
• Minimizes disruption to users of other
  (non-faulty) parts of system
• Goal is fast recovery, not causal analysis

Fast, cheap uRBs statistical monitoring
provide a degree of application-generic failure
detection recovery
28
Crash-Oriented SoftwareSystematic Approach

• Some design lessons already learned
• OK to say no, OK to make mistakes,
  interchangeable parts
• Systematic approach for generic componentized
  apps ...
• Compiler and languages technology to understand
  what makes app amenable to microreboots or c/o
  generally
• E.g., racking state management across app
  components
• E.g., establishing observational equivalence
  between executions with and without
  micro-recovery
• Goal
• Static and dynamic analysis of when safe to use
  generic recovery
• Aggressive application of machine learning
  statistical monitoring to trigger generic
  recovery mechanisms
• High confidence in mechanisms due to simplicity
  and orthogonality

29
Presentation Outline

• A New Vision for Networked Systems
• Enabling Technology Statistical Learning Theory
• Approaches for Dependability
• Approaches for Security
• Elements of an Experimental Prototype
• Summary and Conclusions

30
Self-Verifiable ProtocolsStatement of the
Problem

• Problem Detect and contain network effects of
  misconfigurations and faulty/malicious components

• Approach design network protocols so each
  component verifies correct behavior of the
  protocol
• Examples
• e2e protocols
• routing (BGP) protocols

31
Self-Verifiable ProtocolsCase Study BGP

• Propagating invalid BGP routes can bring the
  Internet down
• Multiple causes
• Router misconfigurations happen daily, yielding
  outages lasting hours
• Malicious routers huge potential threat
• Routers with default passwords
• Possible to buy routers passwords on darknets
• Existing solutions
• Hard to deploy (e.g., Secure-BGP), or
  insufficient security
• Our solution
• Whisper verify the correctness of router
  advertisements
• Listen verify the reachability on the data plane

32
Self-Verifiable ProtocolsBGP Whisper

• Use redundancy to check consistency of peers
  information
• Whisper game
• Group sits in a circle., person whispers secret
  phrase to neighbors
• Person at other end concludes
• Phrase is correct if same phrase from both
  neighbors
• Otherwise, at least one phrase is incorrect

33
Self-Verifiable ProtocolsBGP Whisper

• AS1 advertises its address prefix
• Chooses a secrete key x, and sends y h(x)
• h() well-known one-way hash function
• Every router forwards y h(y)
• AS4 performs consistency check (y1)3 (y2)3 ?
• If yes, assume both routes are correct
• If no, at least one rout is incorrect (but dont
  know which) ?rise a flag

(AS1,AS2,y1h2(x))
(AS1,AS2,AS3,y1h3(x))
AS3
AS2
(AS1, y1h(x))
AS4
Chose secret key x
AS1
(AS1,AS3,y2h2(x))
(AS1, y2h(x))
AS3
34
Self-Verifiable ProtocolsBGP Listen

• Monitor progress of TCP flows
• If TCP flow doesnt make progress, might be
  because route is incorrect
• Use heuristics to reduce number of false
  positives and negatives
• Still difficult to handle traffic patterns like
  port scanners
• Use SLT techniques to improve the detection
  accuracy?

35
Self-Verifiable ProtocolsStatus and Future Plans

• Two examples
• BGP verifications (Listen Whisper)
• Can trigger alarms and contain malicious routers
• Minimal changes to BGP incrementally deployable
  (Listen)
• Self-verifiable CSFQ
• Per-flow isolation without maintaining per flow
  state
• Detect and contain malicious flows
• Ultimate goal develop distributed system able to
  self diagnose and self-repair
• Eliminate faulty components
• Minimum raise a flag in case of configurations
  and attackers
• Develop set of principles and techniques for
  robust protocols

36
Enabling TechnologyEdge Services by Network
Appliances

• In-the-Network Processing the Computer IS THE
  Network

37
Generic PNE Architecture
Tag Mem
Rules Programs
38
Enabling TechnologyProgrammable Networks

• Problem
• Common programming/control environment for
  diverse network elements to realize full power of
  inside the network services and applications
• Approach
• Software toolkit and VM architecture for PNEs,
  with retargetable optimized backend for diverse
  appliance-specific architectures
• Current Focus
• Network health monitoring, protocol interworking
  and packet translation services, iSCSI processing
  and performance enhancement, intrusion and worm
  detection and quarantining
• Potential Impact
• Open framework for multi-platform appliances,
  enabling third party service development
• Provable application properties and invariants
  avoidance of configuration and latest patch not
  installed errors

39
Enabling TechnologyProgrammable Networks

• Generalized PNE programming and control model
• Generalized virtual machine model for this
  class of devices
• Retargetable for different underlying
  implementations
• Edge services of interest
• Network measurement and monitoring supporting
  model formation and statistical anomaly detection
• Framework for inside-the-network protocol
  listening
• Selective blocking/filtering/quarantining of
  traffic
• Application-specific routing
• Faster detection and recovery from routing
  failures than is possible from existing Internet
  protocols
• Implementation of self-verifiable protocols

40
Security of Networked SystemsLearning Systems
Opportunity

• New focus on network-wide attacks
• E.g., worms, denial of service
• Arise suddenly, spread quickly
• No time to deploy patches or filters to protect
  machines
• SLT offers promises for improvements
• Distributed, so information across machines are
  shared
• Handles changes in user behavior, preventing
  false positives
• Truly distributed SLT systems are possible that
  can detect and protect against very large-scale
  security attacks

41
Security of Networked SystemsTechnical Approach

• Mechanisms to learn, share, repair against
  potential threats to dependability
• Strengthen assurance of shared information via
  lightweight authentication and encryption
• TESLA authentication system replaces public-key
  crypto with lightweight symmetric encryption
  uses time asymmetry to provide assurance
• Messages initially encrypted, verification keys
  revealed laterprevents attacker from using a
  received key to forge messages
• Variations provide instant authentication.
• Athena system generate random instances of
  secure protocols
• Ultra-fast checking softwaremodel-checking
  proof-theoretic techniques to verify protocols
  against stated requirements
• Intelligently generate most efficient secure
  protocol satisfying requirements or a random
  instance of a secure protocol satisfying a given
  set of requirements
• Apply for SLT systems to more quickly exchange
  information

42
Presentation Outline

• A New Vision for Networked Systems
• Enabling Technology Statistical Learning Theory
• Approaches for Dependability
• Approaches for Security
• Elements of an Experimental Prototype
• Summary and Conclusions

43
System Prototype

• Comprehensive system architecture
• Reduction of SLT to practical software components
  embedded within a distributed systems context
• Exhibition of an architecture for dramatically
  improving the reliability and security of
  important systems through observation-coordination
  -adaptation mechanisms.

44
RADS Prototype Applications

• E-mail Systems/Messaging
• Scale
• Distribution, heterogeneity
• Non-stop
• Reactive Systems
• E.g., Distributed worm detection
• Network/Web Services
• Financial Applicatioms
• Collective Decision Making/Electronic Voting
• Security, privacy
• Non-stop

45
RADS Conceptual Architecture
Operator
User
Prototype Applications E-voting,
Messaging, E-Mail, etc.
Programming Abstractions For Roll-back
SLT Services
Crash-Oriented Svrcs Observation Infrastructure
forSystem SLT
Application- Specific Overlay Network
Verifiable Protocols Fast Detection Route
Recovery ObservationInfrastructure for network
SLT
PNE
PNE
Edge Network
Edge Network
Commodity Internet
46
Presentation Outline

• A New Vision for Networked Systems
• Enabling Technology Statistical Learning Theory
• Approaches for Dependability
• Approaches for Security
• Elements of an Experimental Prototype
• Summary and Conclusions

47
Summary and Conclusions
