Simon Stewart

1
IP Convergence The Future of Satellite
Communications
Simon Stewart Satellite Gateway Technician
2
What is IP Convergence?

• The transmission of different types of traffic
  over a single converged network
• Voice
• Video
• Data

3
The Benefits of IP Convergence

• A converged IP network
• IP is an open standard
• Easily scalable
• Capable of CoS and QoS-based routing
• Fewer components in the network
• Elimination of multiple networks operating in
  parallel.

4
IP Modem Architecture

• IP Modems Provide Efficient Bandwidth Utilization
• Differs From Basic Satellite Modems in Their
  Ability to Efficiently Transport IP Data Over the
  Satellite Link
• Uses Time Division Multiple Access (TDMA) Framing
  Structure Bandwidth on a Single Carrier

5
Timeline for DevelopmentTransformational
Communications Architecture (TCA)

• Legacy Design 2004 - 2005
• Phase One Limited IP 2006
• Phase Two Expanded IP 2007 - 2008
• Phase Three Full IP 2008 - 2012

6
Phase One Limited IP System Overview

• Net-centric Router
• Voice Gateways
• HAIPE
• Intrusion detection devices
• The Performance Enhancing Proxy

7
Phase Two Expanded IP System Overview

• IP Modems are installed (iDirect, Linkway)
• Support 4 Wideband RF Interfaces
• Support Hub/spoke and Mesh Topology
• Utilize Dynamic Bandwidth Resource Allocation
• Upgraded Converged IP Suites
• Ensure Compatibility With various terminals
• Enhances Bandwidth availability

8
Expanded IP Architecture
9
Phase Two Linkway

Equipment Shelter
Terminal 6 Modem Linkway Services Voice,
Video, Data
2.25 MSPS x 4
Pre-Positioned Services


2.25 MSPS
Terminal 7 Modem Linkway Services Voice,
Video, Data
2.25 MSPS
Central Network
2.25 MSPS

2.25 MSPS
Linkway
Terminal 8 Modem Linkway IP Services Voice,
Video, Data


Terminal 9 Modem Linkway IP Services Voice,
Video, Data

Network Manager
Network Controller


10
Phase Two iDirect
Equipment Shelter
Terminal 1 Modem iDirect 7350 Services Voice,
Video, Data
512 Kbps

Pre-Positioned Services
Central Network
Terminal 2 Modem iDirect 7350 Services Voice,
Video, Data
2048 Kbps
iDirect
512 Kbps
Terminal 3 Modem iDirect 7350 Services Voice,
Video, Data
Network Manager
Network Controller
11

• Phase Three
• Full IP Implementation

• Net-Centric Enterprise Service integrated
• Future IP modem with Embedded TRANSEC
• Enhances bandwidth capability further
• Other future requirements yet to be determined

12
Summary

• Taking Steps Toward Realizing the
  Transformational Communications Architecture
  (TCA)
• IP Transition Will be Incremental
• Benefits of IP Convergence
• Limited IP
• Expanded IP
• Fully Implemented IP
• Keys to Success Requirement Solidification,
  Program Synchronization, and Funding

13
Questions?
