MD240 Transaction Processing Systems, Functional Systems, and Systems Integration

1
MD240Transaction Processing Systems, Functional
Systems, and Systems Integration
2
Overview

• Background
• Integration of Systems
• Transaction Processing Systems
• Innovative Functional Information Systems

3
BackgroundFunctions in Porters Value Chain
Typical functional areas mapped on the value
chain of a manufacturing company
4
BackgroundHistorical Functional Systems
3 weeks later Okay, here it is! All 500
pages on crisp white
paper!
Accounting info. systems
Finance info. systems
TPS
TPS
Manufacturing info. systems
Hey, could you generate a report for
me detailing how much this part typically costs?
TPS
5
Integration of Systems
6
Integration of SystemsModern Integrated
Functional Systems
To Suppliers
Finance
Accounting
TPS
SCM
TPS
To Customer Touchpoints
Operations
data
TPS
HR
data
ERP
Marketing
CRM
TPS
TPS
Executive IS
7
Integration of SystemsReasons for Integration

• Helps to reduce cost
• Helps to increase employees productivity
• Helps to facilitate faster information sharing
• Helps to facilitate collaboration between
  functional areas

8
Integration of SystemsIntegration Approaches

• Various Integration Approaches
• Buy (or build) a fully integrated set of software
  components
• Link together two applications via software that
  sends data between the two
• EDI
• TCP/IP
• Application Connectors that connect specific
  applications (e.g. Oracle to Peoplesoft)
• Middleware
• Web Services (XMLSOAP)

9
Transaction Processing Systems
10
Computerization ofRoutine Transaction Processes

• Transaction Processing System (TPS)
• supports transaction processes
• monitors, collects, stores, processes, and
  disseminates information for all routine core
  business transactions
• includes accounting and finance transactions and
  some sales, personnel, and production activities

11
Transaction Processing SystemsObjectives of TPS

• Primary Objectives
• To quickly store data
• To quickly retrieve data
• To provide the necessary data for tactical and
  strategic systems such as DSS applications
• To assure accuracy and integrity of data and
  information

12
Transaction Processing SystemsTypical Tasks
13
Transaction Processing SystemsObjectives of TPS

• Organizational Objectives Fulfilled by TPS
• To provide all the information needed by law
  and/or by organizational policies to keep the
  business running properly and efficiently
• To allow for efficient and effective operation of
  the organization
• To provide timely documents and reports
• To increase the competitive advantage of the
  corporation
• To safeguard assets and security of information

14
Transaction Processing SystemsMajor
Characteristics of TPS

• Large amount of data are processed
• The sources of data are mostly internal, and the
  output is intended mainly for an internal
  audience
• The TPS processes information on a regular basis
• Large storage (database) capacity is required
• High processing speed is needed due to the high
  volume
• TPS basically monitors and collects past data
• Input and output data are structured
• High level of detail is usually observed
• Low computation complexity
• High level of accuracy, data integrity, and
  security is needed
• High reliability is required
• Inquiry processing is a must

15
Transaction Processing SystemsVarious TPS
Technologies

• Some TPS Technologies
• Online Transaction Processing (OLTP)
• Allows managers to run client-server transactions
  to obtain some information of interest
• Web-based Transaction Processing
• Similar to OLTP
• Allows managers to run transactions via the web
• Object-Oriented Transaction Monitors (OTM)
• Objects that monitor transactions in web-based
  applications
• When an activity happens within a web site, the
  object sends a query to the data warehouse to
  record information about what happened (e.g.,
  customer checked out)

16
Transaction Processing SystemsBenefits of
Internet-based OLTP

• Flexibility to accommodate unpredictable growth
  in processing demands
• Cost effectiveness even for small dollar amounts
• Interactive, automatic billing, enabling
  companies to offer services to anyone, not just
  subscribers
• Timely search and analysis of large databases
• Multimedia data such as pictures and sound are
  handled effectively and efficiently
• High data throughput to support inquiries
  requiring massive file size
• Fast response time
• Effective storage of huge graphics and video
  databases

17
Transaction Processing SystemsTPS Hardware

• Traditional TPSs were centralized and run on a
  mainframe
• Today
• mainframes
• client/server systems
• clusters of servers, each server running multiple
  processors

18
Management Decision MakingHow to Choose a TPS?

• Transaction Processing Performance Council
  (tpc.org)
• Industry forum for fighting over who is fastest
• Provides benchmarking results for different TPS
  computer systems, based on bundle of
• Hardware
• Operating system
• Database
• Several performance metrics
• TPC-C OLTP performance
• TPC-H decision support for ad hoc queries
  performance
• TPC-R decision support for business reporting
  performance
• TPC-W web based transaction performance

19
Management Decision MakingHow to Choose a TPS?

• ECperf (ecperf.theserverside.com)
• Industry benchmark for fighting over who has the
  fastest Java-based TPSs
• Provides benchmarking results for different TPS
  computer systems, based on bundle of
• Hardware J2EE Server DBMS
• ECperf takes into account several transaction
  processing scenarios
• Customer
• Manufacturing
• Supplier
• Corporate

20
Functional Information Systems
21
Functional Information Systems Major
Characteristics

• A functional information system comprises several
  smaller information systems that support specific
  activities performed by each functional area
• The specific IS applications in any functional
  area can be integrated to form a coherent
  functional system, or they can be completely
  independent
• Functional information systems interface with
  each other to form the organization-wide
  information system
• Some organizational information systems interface
  with the business environment
• Information systems applications support the
  three levels of an organizations activities
  operational, managerial, and strategic

22
Innovative Functional Applications of IT
23
Innovative IT in Operations
24
Innovative IT Applicationsin Operations

• Managing Production/Operations and Logistics
• transform inputs into useful outputs
• very diversified, and so its supporting
  information systems
• related to finance and sales, engineering and
  design, and purchasing and logistics

25
OperationsTypical TPS of a Manufacturer
26
Operations

• Supply-Chain Management
• objective is to support the flow of goods and
  materials from the original supplier through
  multiple production and logistic operations to
  the ultimate consumer
• extensive integrated software is available for
  managing portions of the supply chain as well as
  the entire process

27
OperationsSupply-Chain Management
Supply Chain Organization
28
OperationsIn-House Logistics and Material
Management

• Inventory Management
• Used to estimate inventory levels
• Now try to keep an accurate count through
  barcodes, scanners, GPS systems to locate
  specific inventory
• Quality Control
• Used to sample quality of items at fixed
  intervals
• Now, can examine quality of every single item

29
OperationsPlanning Production/Operations

• Material Requirements Planning (MRP)
• Manufacturing Resource Planning (MRP II)
• Just-in-Time Systems
• Project Management
• Short-Term Schedules

30
OperationsAutomated Design and Manufacturing

• Computer-aided Design (CAD)
• Computer-aided Engineering (CAE)
• Computer-aided Manufacturing (CAM)

31
OperationsComputer-Integrated Manufacturing (CIM)

• Factory of the Future
• Three basic goals
• simplification
• automation
• integration and coordination
• The CIM model
• made up by general business management, product
  and process definition, manufacturing planning
  and control, factory automation, and information
  resource management

32
Innovative IT in Marketing
33
MarketingChannel Systems/Customer Touchpoints

• The customer is king (queen)
• Customer profiles and preference analysis
• Prospective customer lists and marketing
  databases
• Mass customization
• Targeted Advertisement on the Web
• Customer inquiry systems and Automated Help Desk
  (EC application)

34
MarketingChannel Systems/Customer Touchpoints

• Telemarketing
• Capabilities
• personalized contact with the customers
• allows customers to buy at their convenience
• effective in informing customers about a
  companys products and services
• Limitations
• cost can be high
• difficult to find good telemarketers
• may be seen by many as a nuisance
• challenges in reaching people

35
MarketingDistribution Channels

• Distribution channels management
• DSS models are frequently used to support the
  decision of accomplishing by a company, or by a
  subcontractor
• Improving sales at retail stores
• using IT, it is possible to improve the situation
  by reengineering the checkout process

36
MarketingMarketing Management

• Pricing of products or services
• Salesperson productivity
• Productivity software
• Products and customers profitability analysis
• Sales analysis and trends
• New products, services, and market planning

37
Innovative IT in Finance Accounting
38
Accounting Finance Systems
39
Managing the Accounting and Finance Systems
40
Accounting FinanceFinancial Planning and
Budgeting

• Financial and economic forecasting
• Planning for incoming funds
• Budgeting preparation and operation
• Capital budgeting decision

41
Accounting Finance Investment Management

• Access to financial and economical reports
• Internet meta-search engines for finding
  financial data
• Internet directories and yellow pages
• Software for monitoring, interpreting, analyzing
  financial data, and alerting management
• Financial analysis
• Treasury risk management systems (TRMS)

42
Accounting Finance Control and Auditing

• Budgetary control
• Auditing
• Financial health analysis
• Profitability analysis and cost control
• Product pricing

43
Innovative IT in HR
44
Human ResourcesRecruitment

• Position inventory
• Employee selection
• Using the Internet

45
Human ResourcesMaintenance and Development

• Performance evaluation
• Training and human resources development
• Turnover, tardiness, and absenteeism analyses

46
Human ResourcesPlanning and Management

• Personnel planning
• Succession planning
• Labor-management negotiations
• Benefits administration
