NPP Mission Overview November 4, 2003

1
NPP Mission Overview November 4, 2003

• Dan DeVito
• NPP System Manager
• NASA / GSFC

2
Agenda

• Program Overview
• Requirements Summary
• NPP Mission System Requirements Specification
• NPOESS System Requirements Specification
• System Architecture
• Issues/Risks/Schedule

3
Agenda

• Program Overview
• Requirements Summary
• NPP Mission System Requirements Specification
• NPOESS System Requirements Specification
• System Architecture
• Issues/Risks/Schedule

4
NPP Origins

• NPP is a joint partnership between NASAs Office
  of Earth Sciences (OES) and the NPOESS Integrated
  Program Office (IPO) initiated in 1998
• Feasibility study began in November 1998
• Formulation began in November 1999
• The partnership provides both organizations with
  considerable cost savings while achieving their
  key program objectives
• To provide NASA with continuation of a group of
  global change observations initiated by the Earth
  Observing System (EOS) TERRA, AQUA, and Aura
  missions.
• To provide the NPOESS operational community with
  pre-operational risk reduction demonstration and
  validation for selected NPOESS instruments, and
  algorithms, as well as ground processing.

5
NPP Roles/Responsibilities

• IPO
• Joint Program Management
• VIIRS Instrument
• CrIS Instrument
• OMPS Instrument
• Command, Communications, Control Segment (C3S)
• Interface Data Processing Segment (IDPS)
• Mission Operations

• NASA
• Joint Program Management
• Mission systems engineering, integration, and
  test
• ATMS Instrument
• Spacecraft and integration
• Launch vehicle and associated activities
• Science Data Segment (SDS)

• NOAA/NESDIS
• Archive Distribution Segment (ADS)

6
NPOESS Command Authority
Executive Committee
Joint Agency Requirements Council
Under Secretary for Oceans Atmosphere
Deputy Administrator
Under Secretary of Defense, Acquisitions and
Technology
Senior Users Advisory Group
System Program Director
Joint Agency Requirements Group
Associate Director for Acquisition
Associate Director for Operations
Associate Director for Technology
Transition Integrated Program Office
Users
First successful effort to converge operational
environmental satellites
7
NPP Organization
Project Manager J. Watzin Deputy Project
Manager B. Fafaul Deputy Project Manager
Resources G. Barth
Project Scientist R. Murphy Deputy Project
Scientist J. Privette Deputy Project Scientist
Data S. Wharton
Integrated Program Office NPP Program Manager P.
Wilczynski
Chief Engineer J. Schaeffer Deputy Chief
Engineer D. Spencer
Project Support Manager H. Sullivan Configuration
Management C. Blank Scheduling D. Bearchell
Project Support K. Latham Project Support K.
Yoder
Chief Engineer T. Trenkle
Financial Manager J. Chan Resource Analyst R.
McCaskill Resource Analyst V. Briton
Mission Systems Manager D. DeVito Deputy Mission
Systems Manager J. Smith Information Architect J.
Henegar Electrical Systems Engineer D.
Charleson Operations Systems Engineer R. Saylor
Software Systems Engineer L. Shears
System Assurance Manager L. Kleppin Safety
Manager C. Hamilton Parts Engineer T. Duffy
Materials Engineer S. Le
Procurement Manager T. Seidel Contracting
Officer L. Levine
C3S J. Valenti
IDPS J. Mulligan
In-Situ Manager P. Coronado
CrIS Sensor Capt. C. Muth VIIRS Sensor Capt. T.
Scalione OMPS Sensor 1Lt. C. Stutz
CrIS Sensor R. Welsh VIIRS Sensor A. Bartels OMPS
Sensor R. Welsh ATMS Instrument S. Krimchansky
Observatory Manager W. Anselm Deputy Observatory
Manager L. Shears
SDS Manager TBD
Mission Operations Manager J. Valenti
Launch Vehicle Manager T. Jones
ATMS Sensor Dr. A. Webb
IPO Blue Code 200 Violet Code 300 Red
Code 400 Black Code 500 Green Code 900
Brown
Contractor IPO Internal
8
Unique Nature of Mission

• Peer-to-Peer Partnership (i.e. blending of
  cultures)
• NASA / IPO / NOAA
• Shared Risk
• Agency-centric vulnerabilities
• Shared Control
• Joint Project Management
• Joint award fee representation
• Joint Oversight
• Tri-Agency (NOAA, NASA and DoD) Steering
  Committee
• Executive Committee (EXCOM)
• No Exchange of Funds
• Each partner will contribute mission components
  in-kind

9
NPP Mission Segments
Space Segment
Space Segment

• Spacecraft
• ATMS

• VIIRS
• CrIS
• OMPS

10
NPP Developers
11
Agenda

• Program Overview
• Requirements Summary
• NPP Mission System Requirements Specification
• NPOESS System Requirements Specification
• System Architecture
• Issues/Risks/Schedule

12
Requirements Hierarchy
NOAA
NASA / ESE
DoD
NPOESS IORD
Level 1 Requirements
Level 1
NPP Mission Requirements
NPOESS System Spec
IRDs
Level 2
Satellite Req Specs
ICDs
SDS Specs
C3S Specs
VIIRS Specs
IDPS Specs
ADS Specs
LSS Specs
CrIS Specs
OMPS Specs
ATMS Specs
Level 3/4
IPO
Joint
NASA
NOAA
Key
13
Agenda

• Program Overview
• Requirements Summary
• NPP Mission System Requirements Specification
• NPOESS System Requirements Specification
• System Architecture
• Issues/Risks/Schedule

14
NPP Mission Requirements Highlights

• Provide accommodations for 4 Instruments (TBR) -
  VIIRS, CrIS, ATMS and OMPS
• Establish and maintain the Satellite in the
  following orbit
• Normal Orbit Altitude 824 km
• Descending Node 1030am /- 10 min. (Local Mean
  Sun Time)
• Ground Track Repeatability /- 20 km, all
  latitudes, cross track
• Repeat Cycle 16 Days
• Be designed using right-hand, orthogonal,
  body-fixed XYZ coordinate system
• Mission Lifetime of at least five years
• Maintain a Mission Success (Ps) of 0.500 (TBR) or
  better at five years
• Conform to national asset security guidelines

15
NPP Mission Requirements Highlights

• Make Raw Data Records (RDRs), Sensor Data Records
  (SDRs), and Environmental Data Records (EDRs)
  available within 180 minutes of observation,
  minimally 95 of the time over an annual basis
• Make RDRs, SDRs, and EDRs available for at least
  98 of all observations over an annual basis
• Maintain an operational availability (Ao) of 95
  throughout the life of the mission
• Provide a High Rate Direct-broadcast (HRD) link
  for in-situ users
• Design Spacecraft for a minimum lifetime of 5
  years in orbit, with a minimum Ps of 0.86 at 5
  years
• CCSDS compatibility for all Spacecraft commands
  and telemetry
• Be capable of performing deep space calibration
  maneuvers

16
NPP Mission Requirements Highlights

• Allow no single point of failure to preclude
  supporting the mission
• Store at least two and a half orbits of mission
  data on the Satellite
• Provide mission management, satellite operations,
  space/ground communications, and data routing
• Be capable of contacting the Satellite at least
  every orbit
• Provide mission operations guidance, including
  mission configuration, maneuver planning,
  satellite activity prioritization, and data
  handling.
• Provide command and control of the Satellite at
  the initial communications contact after
  separation and thereafter for the life of the
  Satellite
• Perform orbit maintenance activities to maintain
  the orbit for the operational life of the
  Satellite

17
NPP Mission Requirements Highlights

• Be capable of receiving 3.5 orbits worth of
  Stored Mission Data (SMD) within 2 orbits
• Provide archive and distribution services in
  perpetuity
• Limit orbital debris in compliance with NPD 8710.3

18
Agenda

• Program Overview
• Requirements Summary
• NPP Mission System Requirements Specification
• NPOESS System Requirements Specification
• System Architecture
• Issues/Risks/Schedule

19
Requirements Allocations

• Requirements are allocated and flowed down
  through the spec tree from the system
  specification to the segments and below
• Key requirements that are allocated from the
  system to the segments are
• Data Availability (98 over an annualized basis)
• Operational Availability (95 over an annualized
  basis)
• Data Latency (120 minutes from observation)
• Interoperability (Drives IDPS interface design)
• EDR Performance

20
NPOESS and NPP Mission Deliverables Are Data
Products

• Raw Data Records (RDRs)
• Similar to Level 1A for CEOS/NASA
• 150 giga bytes per day (similar to Terra or
  Aqua)
• Sensor Data Records (SDRs)
• Similar to CEOS/NASA Level 1B

• Environmental Data Records (EDRs)
• Similar to CEOS/NASA Level 2
• NPP Provides 27 of 56 NPOESS EDRs

12 Mbps
3 Mbps
CrIS/ATMS
APS
VIIRS
CMIS
SES
GPSOS
ERBS
TSIS
ALT
OMPS
Flight on NPP
Flight on NPOESS
21
NPP Sensors Contribute 27 of 56
Environmental Data Records (EDRs)
Cloud Top Pressure
Atm Vert Moist Profile
Precipitable Water
Atm Vert Temp Profile
Precipitation Type/Rate
Cloud Top Temperature
Down LW Radiance (Sfc)
Imagery
Pressure (Surface/Profile)
Sea Surface Temperature
Down SW Radiance (Sfc)
Sea Ice Characterization
Electric Fields
Sea Surface Winds
Sea SFC Height/TOPO
Soil Moisture
Electron Density Profile
Snow Cover/Depth
Energetic Ions
Aerosol Optical Thickness
Solar Irradiance
Aerosol Particle Size
Geomagnetic Field
Supra-Therm-Aurora Prop
Ice Surface Temperature
Aerosol Refractive Index
Surface Type
In-situ Plasma Fluctuation
Albedo (Surface)
Active Fires
Auroral Boundary
In-situ Plasma Temp
Surface Wind Stress
Ionospheric Scintillation
Auroral Energy Deposition
Suspended Matter
Med Energy Chgd Parts
Auroral Imagery
Total Water Content
Land Surface Temp
Cloud Base Height
Vegetative Index
Net Heat Flux
Cloud Cover/Layers
LEGEND
Net Solar Radiation (TOA)
Cloud Effective Part Size
Neutral Density Profile
Cloud Ice Water Path
VIIRS (24)
GPSOS (2)
CMIS (19)
ERBS (5)
Ocean Color/Chlorophyll
Cloud Liquid Water
TSIS (1)
CrIS/ATMS (3)
Cloud Optical Thickness
Ocean Wave Character
ALT (3)
OMPS (1)
Outgoing LW Rad (TOA)
Cloud Particle Size/Distrib
SES (13)
APS (4)
Cloud Top Height
O3 Total Column Profile
- NPOESS KPPs
NPP EDRs in black font
22
NPOESS and NPP Mission Deliverables Are Data
Products

• From the System Specification, Appendix A
  Definition/Glossary of Terms
• Raw Data Records (RDRs)
• Full resolution, digital sensor data,
  time-referenced and locatable in earth
  coordinates with absolute radiometric and
  geometric calibration coefficients appended, but
  not applied, to the data. Aggregates (sums or
  weighted averages) of detector samples are
  considered to be full resolution data if the
  aggregation is normally performed to meet
  resolution and other requirements. Sensor data
  should be unprocessed with the following
  exceptions time delay and integration (TDI),
  detector array non-uniformity correction (i.e.,
  offset and responsivity equalization), and
  lossless data compression are allowed. Lossy
  data compression is allowed only if the total
  measurement error is dominated by error sources
  other than the data compression algorithm. All
  calibration data will be retained and
  communicated to the ground without lossy
  compression.
• Sensor Data Records (SDRs)
• Data record produced when an algorithm is used to
  convert Raw Data Records (RDRs) to geolocated,
  calibrated detected fluxes with associated
  ephemeris data. The existence of the SDRs
  provides an intermediate step between the EDRs
  and the raw data. Full resolution sensor data
  that are time referenced, earth (GEO) located (or
  orbit-located for in-situ measurements), and
  calibrated by applying the ancillary information
  including radiometric and geometric calibration
  coefficients and georeferencing parameters such
  as platform ephemeris. These data are processed
  to sensor units (e.g., radar backscatter cross
  section, brightness temperature, radiance, etc.).
  Calibration, ephemeris, and any other ancillary
  data necessary to convert the sensor units back
  to sensor raw data (counts) are included.
• Environmental Data Records (EDRs)
• Data records produced when an algorithm is used
  to convert Sensor Data Records (SDRs) to
  geophysical parameters (including ancillary
  parameters, e.g., cloud clear radiation, etc.).
  EDRs are generally produced by applying an
  appropriate set of algorithms to Raw Data Records
  (RDRs).
•

23
EDR Requirements are Captured in Appendix D of
the System Spec

• RDR/SDR requirements derive from EDR
  requirements, with specs based on
  modeling/analysis and heritage sensor
  performance, as well as design improvements and
  algorithm developments for NPP/NPOESS

Mission products specified through performance
attributes, associated with remote sensing of
environmental parameters

Attributes are also associated with architecture,
downlink, and processing
24
Agenda

• Program Overview
• Requirements Summary
• NPP Mission System Requirements Specification
• NPOESS System Requirements Specification
• System Architecture
• Issues/Risks/Schedule

25
System Context
NPP Mission System
Environment
Application Processing Systems (Centrals)
26
NPP System Architecture
GPS
TDRSS
WSC LEO A Backup TC
NESDIS Central
AFWA Central
I/F Data Proc Segment
Command, Cntrl CommSegment
Data Del
Data Del
Science Data Segment
GSE - Svalbard Primary TC NPP SMD
Cal/Val
Cal/Val
Process
Process
Infra
Infra
Data Mgt
Data Mgt
Ingest
Ingest
Archive Dist Segment
Ingest

• Mission Mgmt Center - Suitland
• Flight Operations Team
• Enterprise Management
• Mission Management
• Satellite Operations
• Data Monitoring Recovery

Archive Interchange
Datastore
Data Handling Node
Inventory
RoboticStorage
Archiver
Data Routing Retrieval
NPP Mission Data
Command and Telemetry
Key
Climate User Community
MSO - 26
27
Space Segment
MSO - 27
28
Space Segment Elements

• Space Segment is comprised of six elements
• Spacecraft
• VIIRS
• CrIS
• ATMS
• OMPS
• Ground Support Equipment

CERES instrument (TBR)
29
Spacecraft

• Ball BCP 2000 Bus Heritage QuickBird 1 and 2,
  QuikSCAT, CloudSat, ICESat
• Dimensions 1.3m2 base, 4.2 m tall Aluminum
  Honeycomb Structure
• 3-axis stabilized attitude control
• 5 year design life
• X-, S-Band communication

Nadir Deck
Margins
x
z
2.610m
4.028m
y
2.206m
30
NPP Spacecraft
X (Velocity)
.096m
Z (Nadir)
ST1
VIIRS OM
BCL RADIATOR
VIIRS RADIATOR
VIIRS EM
ST2
3.733m
RF ACCESS DOOR
4.028m
ATMS RADIATOR
ATMS
75
OMPS
PROPULSION MODULE
SSW2
SSW1
.140m
31
Visible/Infrared Imager/Radiometer Suite (VIIRS)

• Multispectral, cross-track-scanning, imaging
  instrument
• 22 spectral bands 0.4 12.5 mm
• Single 20 cm diameter, rotating, all-reflective
  telescope
• Day-Night Band, VisNIR, S/MWIR, LWIR Focal
  Plane Assemblies
• Solar reflective and IR emissive on-board
  calibration sources
• Heritage MODIS on EOS Terra and Aqua

z
z
85 cm
y
y
141 cm
134 cm
x
x
Margins
Colorado, March 20, 2003 MODIS - Terra
Colorado, March 13, 2003 MODIS - Terra
32
Cross-track Infrared Sounder (CrIS)

• Fourier Transform Spectrometer providing high
  resolution IR spectra
• Fields of Regard each 3 x 3 FOVs
• 14 km nadir spatial resolution
• 2200 km swath width
• On-board internal calibration target
• Heritage AIRS on EOS Aqua

z
y
72 cm
95 cm
x
80 cm
Margins
Hurricane Isabel, September 18, 2003 AIRS - Aqua
33
Advanced Technology Microwave Sounder (ATMS)
NGES

• Develop and build EDU and PFM radiometers with 22
  channels (23 to 183 GHz)
• Heritage AMSU-A1, AMSU-A2, MHS

z
60 cm
y
40 cm
x
70 cm
Margins
Hurricane Isabel, September 18, 2003 AIRS/AMSU -
Aqua
34
Ozone Mapping Profiler Suite (OMPS)

• OMPS consists of three spectrometers
• Nadir Total Column Spectrometer based on TOMS
  heritage, covers a 2800km cross-track swath
• Nadir Profile Spectrometer provides heritage
  SBUV/2 performance over (250km)2 cell
• Limb Sensor provides 1 km vertical sampling along
  3 slits enabling ozone profile retrieval
• Heritage TOMS and SBUV

z
z
x
35 cm
37 cm
x
66 cm
54 cm
y
25 cm
56 cm
y
Main Electronics Box
Nadir Sensor
Limb Sensor
Margins
35
Launch Support Segment
MSO - 35
36
Command, Control Comm Segment
MSO - 36
37
I/F Data Processing Segment
MSO - 37
38
IDPS Subsystems
Ingest
Calibration/ Validation
Data Management
Processing
Infra- structure
Data Delivery
MSO - 38
39
IDPS Infrastructure
Ingest
Calibration/ Validation
Data Management
Process Management
Process Management
Logging
To/From C3S
Infra- structure
Processing
Data Delivery
Stats/Summaries
Retransmit Coord
Process Management
S/C Config Updates, Mission Schedule
Process Management

• Provides capability to manage, schedule and
  control data processing and resources
• Monitors IDPS performance and data quality
• Generates and transfers performance reports to
  C3S
• Receives s/c configuration updates from C3S
• Receives mission schedule updates, planned
  outages, and notices from C3S

MSO - 39
40
IDPS Ingest
Ingest
Calibration/ Validation
Data Management
RDRs
TLM DB Updates
SMD EAPs
Validated Ancillary Data
From C3S
TLM Data
Ancillary Data
From Externals
SDR/EDR Cal Coeffs, Data Quality Monitoring Tables
Process Management
Infra- structure
Processing
Data Delivery

• Ingests rate-buffered, pre-processed Extended
  Application Packets from C3S
• Monitors and tracks data receipt for quality and
  quantity measurements
• Ingests ancillary data to IDPS
• Generates time-referenced Raw Data Records (RDRs)
• Generates RDR metadata
• Receives and processes retransmitted data
  Extended Application Packets from C3S
• Request common services from Infrastructure and
  provides process status information
• Ingests updated calibration coefficients and data
  quality monitoring tables

MSO - 40
41
IDPS Data Management
Ingest
Calibration/ Validation
Data Management
RDRs
Validated Ancillary Data
xDRs, Ancillary Data
Account-ability
Stored Ancillary Data
RDRs
Inv. Queries
Process Management
SDRs/ EDRs
Infra- structure
Processing
Data Delivery

• Provides capability to temporarily store TBD GBs
  of stored mission data for a period of 24 hrs.
• Provides capability to store RDRs in a compressed
  format (TBR)

MSO - 41
42
IDPS Processing
Ingest
Calibration/ Validation
Data Management
Account-ability
Stored Ancillary Data
RDRs
SDRs/ EDRs
SDRs/ EDRs
Infra- structure
Processing
Data Delivery
Process Management

• Provides capability to generate SDRs
• Provides capability to generate EDRs

MSO - 42
43
IDPS Calibration / Validation
To/From C3S
Ingest
Calibration/ Validation
Data Management
Mission Schedule
Sensor Cal Table Updates
SDR/EDR Cal Coeffs, Data Quality Monitoring Tables
Data Request
HDF Files
Infra- structure
Processing
Data Delivery
Process Management

• Evaluates satellite performance w.r.t.
  radiometry, geometry and temporal registration
• Assesses band-to-band registration
• Generates radiometric calibration
• Generates geometric calibration
• Generates/updates to application processing
  coefficients
• Determines need for instrument calibration table
  updates
• Provides instrument updates to the C3S

MSO - 43
44
IDPS Data Delivery
Ingest
Calibration/ Validation
Data Management
xDRs, Ancillary Data
To Application Processing Systems SDS ADS
Data Request
HDF Files
Inv. Queries
xDRs
Infra- structure
Processing
Data Delivery
App Proc Cal Coeff
Val Anc Data
Data Request

• Accepts data requests from user (internal and
  external)
• Forms data products based on user requests
• Transfers HDF formatted data product to the to
  SDS
• Transfers HDF formatted operational data product
  and ancillary data to the ADS
• Transfers application processing calibration
  coefficients to the ADS
• Transfers HDF formatted operational data products
  to the Centrals

MSO - 44
45
Science Data Segment
Science Data Segment
MSO - 45
46
SDS Requirements - General
SDS

• Provide limited testing of the usefulness of the
  NPP EDRs for accomplishing climate research
• Receive data records from ADS
• Prototype for future ESE distributed science
  data systems

MSO - 46
47
Archive and Distribution Segment
MSO - 47
48
ADS Requirements
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Generate Reports
Manage Archive
Billing and Accounting
MSO - 48
49
ADS Requirements Data Ingest, Validation
Archive
RDRs SDRs EDRs
Appl Proc Cal Coeffs
Formatted Level 1B Data
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Application Products
Validate Ancillary Data
Validated Data
Software Documentation
Generate Reports
Manage Archive
Billing and Accounting

• Capability to ingest
• data records, associated metadata, operational
  calibration coefficients and ancillary data from
  IDPS
• specified applications products from designated
  IDPS Centrals

MSO - 49
50
ADS Requirements Data Ingest, Validation
Archive
RDRs SDRs EDRs
Appl Proc Cal Coeffs
Formatted Level 1B Data
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Application Products
Validate Ancillary Data
Validated Data
Software Documentation
Generate Reports
Manage Archive
Billing and Accounting

• Capability to ingest
• TBD amount of data, on average, per 24 hour
  period
• IDPS data, metadata and products concurrently
• Validate data received for format, content
  completeness and metadata accuracy.
• Provide confirmation or status to the data
  providers upon completion of data validation
• Coordinate and provide (within 12 hours of data
  receipt) retransmission requests

MSO - 50
51
ADS Requirements Archive Management
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Archived Data Request
Archived Data
Validated Queries
Validated Data
User Query Responses
Generate Reports
Manage Archive
Billing and Accounting
Archive Status

• Place ingested data into the archive upon
  validation.
• Distinguish within archive data that have been
  reprocessed and received again
• Replace or remove specific versions of data
• Retrieve information about the archive holdings
  for reporting and querying purposes
• Retrieve archived data to fulfill user requests
• Backup and recover/restore the archive
• Perform periodic archive integrity validation

MSO - 51
52
ADS Requirements Service User Requests
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Product Request
Validated Order
Order Status
Queries / Query Response
Order Validation Information
Generate Reports
Manage Archive
Billing and Accounting
Validated Query
User Query Response

• Provide an electronic, interactive user metadata
  interface for query, search and order services
• Provide customer support services via human
  interaction
• Validate user queries and requests for data
  orders
• Accept and register new users
• Provide data to users within 24 hours of ingest
  at the ADS

MSO - 52
53
ADS Requirements Billing and Accounting
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Shipping Notification
Payment Notification
Order Validation Information
Order Notification
Generate Reports
Manage Archive
Billing and Accounting
Accounting Status
Billing
Payment

• Request and verify payment prior to processing
  user orders
• Maintain user registration and account
  information
• Provide user status and account information

MSO - 53
54
ADS Requirements Product Generation
Distribution
Product
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Archived Data Request
Validated Order
Order Status
Payment Notification
Order Notification
Generate Reports
Manage Archive
Billing and Accounting
Shipping Notification
Archived Data

• Generate user products based on validated user
  requests
• Ship user products via electronic or physical
  means within 7 days of user request
• Generate user products in various formats
• Generate, maintain and retrieve status
  information for each order processed
• Produce and distribute 1.5 TB of data and
  products per day on average
• Produce and distribute a minimum of 0.5 TB of
  data and products per day
• Provide account information to user for each
  request fulfilled

MSO - 54
55
ADS Requirements Report Generation
Ingest Data For Archive
Service User Requests
Generate Distribute Products
Mission Reports
Generate Reports
Manage Archive
Billing and Accounting
Accounting Status
Archive Status

• Generate mission reports for
• volume of data received, transmitted and archived
• statistical performance of system
• number of users requests received, processed,
  shipped and outstanding and turnaround times to
  fulfill
• requests

MSO - 55
56
Agenda

• Program Overview
• Requirements Summary
• NPP Mission System Requirements Specification
• NPOESS System Requirements Specification
• System Architecture
• Issues/Risks/Schedule

57
NPP Issue Summary

• IEEE 1394 High Data Rate Interface (S/C, VIIRS,
  CrIS)
• Extensive risk reduction program in place
• Recent progress has been very good
• Proof Of Design (POD) chips due end of November,
  2003
• Fight chip sets on track for late January 2004
  delivery
• SDS Requirements Approval
• Current Draft Mission Level 1 Requirements define
  the SDS as research tool (not an operational
  system)
• A study was initiated by the Project/Program for
  an independent assessment of a system
  architecture for NPP climate data needs
• Acceptance and sign-off of the Mission Level 1
  requirements is expected by November

58
NPP Issue Summary

• NOAA NESDIS CLASS (ADS) funding is not sufficient
  to support NPP mission development
• CLASS will not support any of the high volume
  data sets NPP, NPOESS, any of the EOS
  satellites, or GOES-R, at current funding levels
• Currently, CLASS will not achieve readiness to
  support the Oct 2006 NPP launch
• The Assistant Administrator for NOAA's Satellite
  and
  Information Services,
  re-affirmed NOAAs commitment to the ADS and
  promised to find the required resources

59
NPP Risk Summary
L I K E L I H O O D
5
4
1
2
3
4
3
2
5
7
9
8
6
1
10
2
3
4
5
1
CONSEQUENCES
60
Mission Review History

• Mission System Requirements Review (MSRR) 3/00
• ATMS Preliminary Design Review (PDR) 7/00
• SDS System Requirements Review (SRR) 2/01
• VIIRS Critical Design Review (CDR) 3/01
• Spacecraft Preliminary Design Review (PDR) 1/02
• ATMS Critical Design Review (CDR) 5/02
• Spacecraft Baseline Design Review (BDR) 12/02
• Mission Preliminary Design Review (MPDR) 1/03
• OMPS Critical Design Review (CDR) 3/03
• Spacecraft Critical Design Review (CDR) 6/03
• CrIS Critical Design Review (CDR) 8/03
• Mission Critical Design Review (MCDR) 10/03
• Mission Confirmation Review (MCR) 11/03
• Mission Operations Review (MOR) (L-15m) 7/05
• Mission Test Readiness Review (MTRR) (L-10m) 12/05

• Operational Readiness Review (ORR) (L-5m) 5/06
• Satellite Pre-ship Review (SPSR) (L-3m) 7/06
• Mission Readiness Review (MRR) (L-2m) 8/06
• Flight Readiness Review (FRR) (L-1/2w) 10/06

61
Mission Schedule
2000
2001
2002
2003
2004
2005
2006
Status as of 9/30/03
Calendar Year
Q4
Q2
Q3
Q4
Q1
Q2
Q3
Q4
Q1
Q2
Q3
Q4
Q1
Q2
Q3
Q4
Q1
Q2
Q3
Q4
Q1
Q2
Q3
Q4
Q1
Q2
Q3
CRITICAL MILESTONES
Launch
ATMS
MSRR
MOR
ORR
MPDR
EMD
FIA
MCR
FIA
Awd
MRR
NRA
10/06
MCDR
SPACE SEGMENT
PDR
Awd
CDR
VIIRS FU1
EDU Del.
EDU Complete
11/05
VIIRS Instrument (IPO)
PSR
VIIRS
EDU Test
CDR
EDU2
CrIS FU1
EDU Del.
Sys DDR
S/SSR
CrIS Instrument (IPO)
10/05
Complete
PSR
Detailed Design
PDR
Awd
CDR
EDU
PSR
ATMS PFM 12/04
ATMS Instrument (NASA)
PER
Implementation
EDU Test Complete
ATP
OMPS PFM
PSR
CDR
OMPS Instrument (IPO)
1/05
Bus/IRR
CDR
Launch
PER
ORR
Awd
Awd
SDR
RFO
Awd
S/C Development (NASA)
10/06
PSRR
12/04
Study 1
Study 2
Study 2
PDR
S/C
ATP
ICD
NLS
LRD
LV
LAUNCH SUPPORT SEGMENT (NASA)
Ready
Awd
Ground Ready 3/06
B1.2
B1.4
B1.3
SRR
SFR
IDR
CDA
EMD
PDR
RFP
B1.1
Ops
COMMAND, CONTROL COMM SEGMENT (IPO)
Awd
EMD
Ground Ready 3/06
SRR
SFR
IDR
B1.2
B1.3
CDA
EMD
PDR
RFP
Ops
B1.4
INTERFACE DATA PROCESSOR SEGMENT (IPO)
EMD
Awd
B1.1
SRR
SCIENCE DATA SEGMENT (NASA)
Rel.
Rel.
Rel.
Rel.
SRR
Rel.
ARCHIVE DISTRIBUTION SEGMENT (NESDIS)
Rel.
EtE
Complete
3.0
3.1
5/05
1.0
0.0
4.0
2.0
NCT1
NCT2B
NCT3
NCT4
NCT2A
MISSION SYSTEM INTEGRATION (NASA)
ORT
62
Backup Charts
63
Command, Control Comm Segment
MSO - 63
64
C3S Elements
Mission Management Center
Data Routing and Retrieval
Ground Station Element
MSO - 64
65
Mission Management Center
SIM Telemetry
Mission Reports / Mission Guidance
to IDPS, SDS, ADS
SIM CT Commands
Mission Status
Equip. Status/Control
to User Comm
Mission Management Center
Data Routing and Retrieval
TDRSS Sch Req
to SN
S/C CT Commands
Tasking Request
S/C, SIM Telemetry
from SDS, IDPS
S/C PT Commands
Cal Table Updates
from IDPS
Contact Schedule Coord
Contact Quality Summary
Ground Station Element

• Enterprise Management
• Mission Management
• Satellite Operations
• Flight Vehicle Simulator

• Orbit Operations
• Ground Operations
• Stored Telemetry Analysis

MSO - 65
66
Ground Station Element
Mission Management Center
Data Routing and Retrieval
SMD VCDUs
S/C Telem
S/C CT commands
S/C PT Commands
Contact Schedule Coord
Ground Station Element
SMD Downlink
GS Status Control
S/C Telemetry
to SS
S/C CT PT commands

• Provides communications between the NPP
  satellite and the ground through Svalbard and SN.
• Receives stored mission data via X-Band(Svalbard
  only).
• Receives satellite telemetry via S-Band(Svalbard
  SN).
• Transmits satellite commands via S-Band
  (Svalbard SN).
• Performs preprocessing (Reed-Solomon Decoding)
  of SMD telemetry.
• Provide rate buffering of SMD data.
• Provides Monitoring of HRD direct broadcast link
  at Svalbard.

MSO - 66
67
Data Routing Retrieval
SIM Telemetry
SIM CT Commands
Equip. Status/Control
Mission Management Center
Data Routing and Retrieval
SMD APs
IDPS
S/C CT Cmds
S/C, SIM Telemetry
SMD VCDUs
S/C CT Commands
Ground Station Element
S/C Telemetry

• Provides all inter-segment communications
  between C3S, IDPS, LSS, SDS, and ADS.
• Provides all connectivity between elements
  within the IDPS and C3S.
• Provides command encryption.
• Processes SMD and telemetry VCDUs to generate
  Application Packets for delivery to MMC IDPS.
• Provides data accounting and data recovery.

MSO - 67
