Fault Tolerant Computing

1
Fault Tolerant Computing
2
Acknowledgements

• The following lectures are based on materials
  from the following sources
• S. Kulkarni
• J. Rushby
• J. Knight

3
Objectives

• Exposure to area of Critical Systems
• What it means to have a fault-tolerant system
• Specification techniques for representing
  critical properties
• How to Design Fault tolerance into a system

4
Reliability and Recovery

• Reliability
• Probability that a system will not fail at time t
  if it was operating properly at time 0.
• Recovery
• Process of restoring consistency after a failure

5
Dependability

• Dependability
• How much one may rely on the quality of services
  delivered
• Quality of service depends on
• Correctness
• Continuity of service

6
Terms

• Failure malfunction
• Fault condition that might lead to failure
• Error an incorrect response indicates a fault
  is present
• Faults may be
• permanent
• intermittent
• transient

7
Terms (contd)

• Graceful Degradation
• system is operational, but degraded, after faults
• Fail-safe
• system execution is safe after the fault
• Stabilizing
• system recovers to a consistent state after the
  fault
• Masking
• the user of the system does not see any
  unintended behavior due to faults

8
Terms (contd)

• Mean Time to Failure (MTTF)
• expected value of system failure time
• Mean Time to Repair (MTTR)
• expected value of system repair time
• Mean Time Between Failure
• expected time between successive failures MTBF
  MTTF MTTR
• Fault Tolerance
• ability to continue operation after occurrence of
  faults
• A system is faulty, once its behavior is no
  longer consistent with its specification.

9
Design Decisions

• Fault detection
• Fault confinement
• Fault diagnosis
• Repair and/or reconfigure
• Redundancy
• Hardware extra hardware
• Information redundancy bits
• Software diagnosis software, extra software
• Temporal re-execute software to recover from
  intermittent faults

10
Safety vs Reliability

• Reliability
• concerns occurrence of failures
• System failures defined in terms of system
  services
• Safety concerns occurrence of accidents
• Unplanned events that result in death, inury,
  illness, damage, loss of property or evironmental
  harm
• Defined in terms of external consequences

11
Types of Faults

• Omission failure
• server omits to respond to an input (fail-silent
  failure)
• Timing failure
• response is functionally correct, but untimely
• can be early timing failure or late timing
  failure
• (performance failure)
• Response failure
• incorrect response
• if output value incorrect (value failure)
• state transition incorrect (state transition
  failure)

12
Types of Faults (contd)

• Crash failure
• if after a first omission, a server omits to
  produce output until it restarts
• Amnesia crash
• server restarts in a predefined initial state
  that does not depend on the inputs seen before
  crash
• Partial amnesia crash
• some part of the state is the same before the
  crash rest is in predefined initial state
• Pause crash
• server restarts in the state it had before the
  crash
• Halting crash
• crashed server never restarts

13
Types of Faults (contd)

• Byzantine failure
• Component exhibits arbitrary and malicious
  behavior,
• Perhaps in cooperation with other faulty
  components.
• Fail-stop failure
• In response to a failure,
• Component changes to a state that permits other
  components to detect that a failure has occurred
  and then stops.

14
Examples

• OS crashed followed by reboots in initial state
  (amnesia failure)
• Database server crash followed by recovery of a
  database state that reflects all transactions
  before the crash (pause failure)
• Communication server occasionally loses messages
  but does not delay messages (omission failure)
• Excessive message transmission or message
  processing delay (communication performance
  failure)
• Alteration of a message due to random noise
  during transmission (response failure)

15
Hierarchical Failure Masking

• A failure of a certain type at a lower level can
  propagate as a different kind of failure at a
  higher level abstraction.
• Value Error at the physical layer (e.g., 2 bits
  corrupted) propagates as omission error at data
  link layer

16
Group Failure Masking

• To ensure a service remains available to clients
  despite server failure,
• one can implement a group of redundant,
  physically independent servers.
• The group masks the failure of a member.
• Hierarchical masking requires
• users to implement resource failure-masking
  attempts as exception handling code.
• In group masking,
• individual members failures are entirely hidden
  from users by group management mechanisms.

17
Group Failure Masking (contd)

• Group output is a function of outputs of
  individual group members.
• fastest member
• distinguished member
• result of majority vote
• A server able to mask any k-1concurrent member
  failures will be termed k-fault tolerant
• e.g., a primary/standby group of k servers with
  members ranked as primary, 1st backup, 2nd
  backup, ..., can mask k-1 failures.

18
Some Formalism

• Programs
• A Program consists of
• a finite set of variables
• a finite set of actions
• where
• guard is a boolean expression over program
  variables, and
• statement updates program variables
• Modifications
• guards may contain receive from channels
• statements may contain sends/receive

19
Computation

• A program computation is a fair'' sequence of
  steps, where in each step an action whose guard
  is true has its statement executed
• In one step, multiple guards may be true.
• If guard of some action is true continuously,
  then that action would eventually be chosen for
  execution.
• Notes
• A program computation is a sequence of states

20
Specification

• A specification is a set of sequences of states.
• What does it mean for a program, p to satisfy a
  specification sp from a set of states S?
• every computation of p that starts from a state
  in S is in sp .

21
Examples of specifications

• Let S be a predicate.
• invariant
• Invariant(S) seq S is true in each state of
  seq
• A sequence seq is in invariant(S) iff S is true
  in each state in seq.
• Closure
• Closed(S)
• seq "i i gt 0
• S is true in the ith state of seq
• S is true in the (i1)th state of seq
• If S ever becomes true, it continues to be true.

22
Examples of specifications (contd)

• Let R and S be predicates.
• leads-to
• R leads-to S
• seq ("i i gt 0
• R is true in ith state of seq
• gt
• ( k k gti
• S is true in kth state of seq)
• )

23
Examples of specifications (contd)

• Mutual Exclusion
• invariant( (j ltgt k) (cs.j /\ cs.k) )
• ("j (req.j leads-to cs.j)) // request for
  cs
• Leader Election
• invariant ( ( jltgtk) (leader.j s /\ leader.k)
  )
• true leads-to ( j leader.j)
• Load Balancing
• true leads-to
• ("j,k load.j - load.k bound)

24
Safety Specification

• Safety specification
• A sequence does nothing bad''
• No sequence has a bad prefix
• Let sp be a specification.
• sp is a safety specification
• iff
• ("s s Ï sp
• ( a a is a prefix of s ("b ab Ï sp)))

25
Liveness Specification

• Liveness specification
• A sequence does something good
• Every finite prefix has a good extension
• Let sp be a specification
• sp is a liveness specification
• iff
• (" a ( b ab Î sp)) // a could be
  bad prefix

26
Faults

• A fault is an action that can change the program
  state
• All faults
• (be they crash, fail-stop, omission,
  corruption, timing, Byzantine, intruders, or
  ...)
• can be thus viewed as perturbations on the
  system

27
Faults (contd)

• A program computation in the presence of faults
  is a sequence of steps where
• in each step either program action executes or
  fault action executes
• the program actions are fairly executed
• the fault occurrences are finite

28
Representation of Faults

• Communication faults
• Let c denote the sequence of messages on a
  channel.
• Let m1 and m2 be messages, and let seqm be a
  sequence of messages.
• Message Loss c lt seqm, m1gt c lt seqmgt
• Message Duplication c lt seqm ,m1gt c lt
  seqm,m1,m1gt
• Message Reorder c lt seqm,m1,m2gt c lt
  seqm,m2,m1gt

29
Representation of Faults (contd)

• Amnesia/Transient faults.
• Let c denote all the variables of a process.
• True c?? // ?? arbitrary value

30
Representation of Permanent Faults

• Fail-stop fault
• Upon fail-stop, a process does nothing
• it does not execute any action and
• it does not send any messages.
• Introduce an auxiliary variable up.j at process j

• Add up.j to the guard of each action of j
• If processes can detect failure of other
  processes, then they can do so using variable up.

31
Representation of Permanent Faults

• Byzantine Faults
• Introduce an auxiliary variable b.j at process j
• Add these actions as faults b.j b.j true
• b.j state.j??

32
Goal of Fault-tolerance Design

• Starting from some initial states, S,
• If the program executes alone then the original
  specification, sp, is satisfied
• If the program executes in the presence of faults
  then the fault-tolerant specification, sp', is
  satisfied.
• The fault-tolerance specification depends upon
  the type of the desired fault-tolerance, e.g.,
• for masking sp' sp
• for fail-safe sp' safety specification of sp'

33
Representation of Permanent Faults

• Fault-tolerant systems are rarely designed from
  scratch!!!
• One needs to modify a fault-intolerant system to
  add fault-tolerance
• Need for reuse of the fault-intolerant program.
• Fault-tolerant systems need to be modified to
  deal with new faults.
• Need for incremental design
• Need to perform several activities while
  developing fault-tolerant systems.
• manual or automated design, testing,
  verification, synthesis, ...
• desirable to have a unified framework that allows
  to perform these activities.

34
Overall Design
35
Overall Design (contd)

• Should separate concerns of functionality and
  fault-tolerance.
• Should use components that are responsible for
  fault-tolerance alone.
• Should provide structural continuity while
  performing these tasks.
• Should be able to use the same components while
  performing the above tasks.

36
A Specific Approach

• We explore the following thesis (Kulkarni)
• fault-tolerant system
• fault-intolerant system
• in composition with
• fault-tolerance components

37
Validation

• Two components, detectors and correctors form a
  basis of fault-tolerance design
• Detectors and correctors are necessary and
  sufficient for designing fault-tolerant systems
  that satisfy the reuse criterion
• Reuse criterion
• In the absence of faults, the fault-tolerant
  system behaves like the fault-intolerant system
• In the presence of faults, the fault-tolerant
  system recovers to the computations of the
  fault-intolerant system

38
Validation (contd)

• Existing methods satisfy the reuse criterion
• Replication
• Schneider's state machine approach
• Checkpointing and recovery
• Programs designed with these methods can be
  (alternatively) designed by using detectors and
  correctors
• The use of detectors and correctors offers the
  potential for improved design

39
Outline of Approach

• Identifying the components
• Their applications in design
• Their applications in verification

40
Components for Fail-safe Tolerance

• How to preserve the safety specification ?
• Existence of safe predicate
• follows from the definition of safety
• Hence, we need to detect whether execution of an
  action in the given state is safe
• The added component is called a detector

Assume that safety is not violated here
Check whether safety would be violated
41
Detectors

• Specification of a detector ( detection
  predicate, X, witness predicate, Z)
• Z Þ X
• X leads to (ØZ Ú X)
• Z next (Z Ú ØX)
• Examples error detection codes, acceptance
  tests, comparators snapshot procedures,
  exception conditions

42
Designing Fail-safe Fault-Tolerance

• For each program action
• Add a detector d such that
• detection predicate equals a safe predicate of
• g st
• witness predicate equals Z
• New action is
• Z Ù g st

43
Hierarchical Construction of Detectors
44
Components for Nonmasking Fault-Tolerance

• How to eventually satisfy the specification ?
• Restore the program to a state from where its
  safety and liveness specification are satisfied
• The added component is called a corrector

45
Correctors

• Specification of a corrector ( correction
  predicate, X, witness predicate, Z)
• Z Þ X
• true leads to (X Ù Z)
• X next X
• Z next Z
• Large' correctors in distributed programs are
  built out of parallel' or sequential'
  composition of smaller' ones
• Examples error correction codes, reset
  procedures, voters, rollback recovery,
  constraint satisfaction

46
Components for Masking Fault-Tolerance

• Ensure that in the presence of faults the safety
  specification is always satisfied
• use detectors
• Ensure that eventually the program reaches a
  state from where the specification is satisfied
• use correctors

47
An example Input-Output Problem

• in constant // either 0 or 1
• out 0,1, // either 0 or 1 or //
  some specific value (currently // unknown)
• Safety specification
• always ( )
• (out ) Ú (out in)
• Ù (out ¹ ) next (out ¹ )
• Liveness specification eventually (u) (out
  in)

48
Example contd

• in constant // either 0 or 1
• x 0, 1 // initialized to in
• out 0,1,
• out out x
• Faults
• true x ?

49
Example contd

• y,z 0, 1 // initialized to in
• (x y Ú x z) Ù //detector
• More Faults
• true y ?
• true z ?

50
Triple Modular Redundancy

• (y x Ú y z) Ù out out y
• (z x Ú z y) Ù out out z

51
Distributed Reset An Example in Design

• The problem Reset the state of a distributed
  system to a given global state
• Applicable in the design of various
  fault-tolerant systems
• Need for a fault-tolerant, bounded memory
  protocol (Lamport and Lynch, in Handbook of TCS
  1990)
• Previous solutions are merely stabilizing
  tolerant
•   Allows resets to be incorrect during recovery
• Our solution is the first to provide masking
  tolerance in addition to stabilizing tolerance

52
Specification of Distributed Reset
Masking Tolerant Program
Fail-safe tolerant program
Nonmasking tolerant program
detectors and correctors
detectors
correctors
Intolerant program
53
Specification of Distributed Reset

• A process initiates a reset operation to reset
  the system to a given global state.
• For each reset operation initiated, the following
  two conditions should be satisfied
•  non-prematurity
• when the initiating process completes the reset
  operation, the program state is reachable from
  the given global state
• eventual completion
•   the initiating process eventually completes the
  reset operation

54
Faults and Fault-tolerance Requirements

• CJTSS'98
• Fault-classes considered in our solution
• Network faults
• Failure and repair of processes and
  communication channels
• Memory faults
•  Transient faults, undetectable message
  corruption
• Fault-tolerance requirements
• Masking tolerance to network faults
• Stabilizing tolerance to network faults and
  memory faults
• Other requirements
• Bounded memory at each process

55
Use a diffusing computation
56
Fault-intolerant Distributed Reset

• Embed a tree
• Use a diffusing computation
• Root of the tree initiates a diffusing
  computation
• Each process propagates the diffusing computation
  to its children
• A process completes the diffusing computation
  only after its descendents have completed the
  diffusing computation
• Each process resets its state when it propagates
  the diffusing computation
• Two processes communicate only if either both
  have reset their states or none have reset their
  states in the current reset computation
• When the root of the tree completes the diffusing
  computation, the state of the system is reachable
  from the given global state

57
 Designing components for masking tolerance

• Add a detector that
• lets the root detect if all processes
  participated in the current diffusing computation

• Add a corrector that
• reconstructs the tree
• corrects the variables used in a diffusing
  computation
• ensures that the diffusing computation never
  blocks
• when if the diffusing computation completes, if
  the check performed by the detector fails then
  performs another diffusing computation
• These components must be multitolerant !!

58
Designing multitolerant detector

• Problem Detect whether all processes
  participated in the diffusing computation
• Subproblem Let each process detect if all its
  neighbors participated in that diffusing
  computation
• Easy if each diffusing computation is associated
  with a distinct sequence number
• requires that the sequence numbers are unbounded

• Difficult if the sequence numbers are bounded
• sequence numbers from old diffusing computations
  may confuse the detection

59
Problem with Bounded Sequence Numbers
60
Problem with Bounded Sequence Numbers (contd)
61
Problem with Bounded Sequence Numbers (contd)

• Theorem. Let j and l be neighboring processes and
  let ROOT be an ancestor of j.
• If j and l have completed at least two diffusing
  computations since they changed tree or they
  observed a network fault, and the sequence
  numbers of j and l are identical,
• Then l has propagated the same diffusing
  computation as j

62
Multitolerant Detector (continued)

• Our detector guarantees that
• In the presence of network faults only, the root
  can always detect whether all processes
  participated in the current diffusing
  computation
• In the presence of network faults and memory
  faults, the root can eventually detect whether
  all processes participated in the current
  diffusing computation

63
Multitolerant Distributed Reset

• Properties of our program
• Masking tolerance to network faults
• Stabilizing tolerance to memory faults and
  network faults bounded memory
• Contains a multitolerant detector for
  non-prematurity
• Useful in various other applications
• termination detection
• network management
