Thames Valley ARES Red Cross Presentation

1
Thames Valley ARESRed Cross Presentation
June 18, 2008
Presented byDoug Elliott  VA3DAE Amateur
Radio Emergency Service (ARES) Emergency
Coordinator (EC) for the City of London
2
Agenda
What is Ham Radio? What is ARES? ARES and the Red
Cross The ARES Callout Process The National
Traffic System (NTS) The Stratford / Kashechawan
Experience Questions and Answers
3
What is Ham Radio?

• Amateur radio is both a hobby and a service in
  which participants ("hams") use various types of
  radio equipment to communicate with other radio
  amateurs for recreation, self-training and public
  service

4
Its a hobby

• The main reason most hams are involved in Ham
  radio is because its fun.
• making brief contacts or lasting friendships with
  people around the city and the world
• taking part in contests, field day, clubs
• building your own antennas and radio gear
• trying unusual radio operations talking to
  astronauts, moonbounce, microwave

5
Do it yourselfAntennas
2 Meter Ham Antenna(No trombones were harmed in
the making of this antenna)
6
and its a Service

• Providing communications support for public
  events marathons, air shows, parades

Providing emergency communications in times of
disaster, assisting Red Cross, Police, Municipal
emergency plans
When all else fails, theres Amateur Radio
7
Chinese Earthquake May 12

• Chinese government officials and the news media
  have recognized that when communications failed
  after the earthquake, Amateur Radio operators
  stepped in to provide vital links
• right after the earthquake, "Two ham radio
  operators drove to the center of the earthquake
  area and had a repeater set up by the morning of
  May 13. This repeater enabled the transmission of
  rescue instructions and status reports, and was a
  main communication channel for public use

8
..various types of radio communications

• Portable (fits in your hand)
• Mobile (fits in your vehicle)
• Base Station (fits on your desk)
• Usually, a bigger the radio has more capabilities
  (and a bigger price tag)

9
Antennas

• Bigger antennas
• longer wavelength
• further distance
• HEIGHT is MIGHT

10
Antenna Sizes

• Portables ----------? inches
• Mobile Several feet
• Base Station 20 to 200 feet

11
Mobile Antennas
12
Base Stations

• Every ham dreams
• of having a big tall
• tower some day

13
..various types of radio communications

• Voice simplest, and most popular
• Morse Code workable when voice isnt
• Computer data messaging, higher speed

Repeaters central rebroadcasters that amplify
and re-send transmissions Internet Linking
radio internet radio
14
to communicate with other amateurs

• Hams must pass an exam to be licensed by Industry
  Canada
• There are selected radio frequencies set aside
  for hams
• Hams can only talk to hams, only on ham bands
• Ham transmissions must be non-commercial, and
  hams can never accept money for use of radio

15
for recreation and self-training

• contests, long distance friendships, challenge
• way to learn about electronics, radio career
• endless number of different aspects of ham radio
  to explore
• more advanced licenses recognize training and
  grant more privileges

16
and for Public Service

• In return for use of frequencies, hams provide
  their skills for public service when needed
• emergency communications is a natural, since
• have our own equipment, training licenses
• have a variety of gear and frequencies available
• can still operate when infrastructure fails
• in many cases have special training and practice
  for emergency situations ARES

17
Agenda
What is Ham Radio? What is ARES? ARES and the Red
Cross The ARES Callout Process The National
Traffic System (NTS) The Stratford / Kashechawan
Experience Questions and Answers
18
What is ARES?

• Amateur Radio Emergency Service
• hams who volunteer for emergency service
• an International organization, sponsored by RAC
  in Canada, and ARRL in USA.
• National leadership structure
• regular meetings, training and practice

19
Ontario ARES Top Officials

• Vice-President Field Services
• Robert Cooke, VE3BDB
• Ontario Section Manager
• Allan Boyd, VE3AJB
• Ontario Section Emergency Coordinator
• Bob Gammon, VA3RX

20
ARES Structure

• Ontario is divided into Districts or Sectors,
  each with a District Emergency Coordinator (DEC).
• Districts have Emergency Coordinators (ECs) at
  the county or municipal level.
• There can also be Assistant ECs.

21
(No Transcript)
22
Tecumseh District

• Tecumseh District covers London, Huron,
  Middlesex, Oxford and Perth Counties.
• District Emergency Coordinator (DEC) isBrett
  Gilbank, VE3ZBG
• The DEC works with the Emergency Coordinators in
  their District and assists with coordination when
  multiple ARES groups are responding to an
  incident.

23
St. Clair District

• St. Clair District covers the south-west corner
  of Ontario, plus the Elgin County panhandle.
• This arrangement is due to the alignment of ARES
  Sectors with EMO districts.
• Scott Carter, VE3CGN, is DEC for the Elgin County
  portion of St. Clair district.
• Mike Ciacelli, VE3UCY is DEC for the remaining
  parts of St. Clair district.

24
New ARES Group Name

• To simplify reporting, and to prevent isolating
  smaller communities and radio clubs, the name
  Thames Valley ARES Group was selected by ARES
  leadership.
• TVAG currently provides service to Oxford,
  Middlesex and Elgin counties.
• One Group of Leaders working together to provide
  encouragement, support and prevent duplication of
  efforts.

25
District Emergency Coordinators

• DECs provide all of the tasks and duties of the
  EC in areas that do not have a dedicated EC.
• DECs provide support to the EC and ARES Groups
  and lead by example.
• DECs work with the ECs to assist with
  coordination when two or more ARES areas are
  affected by an incident.

26
Emergency Coordinators

• ECs create Emergency Communications Plans for
  their area.
• They create training materials, hold training
  sessions and organize radio nets.
• They provide leadership for the ARES group by way
  of example.
• They attend municipal and agency meetings and
  bring updates to the team.

27
Local ARES Leaders

• Thames Valley ARES Group

28
Brett Gilbank, VE3ZBGDistrict Emergency
Coordinator forTecumseh
29
Doug Elliott, VA3DAEEmergency Coordinator for
London
30
Scott Carter, VE3CGNDistrict Emergency
Coordinator for Elgin
31
Dave Young, VE3EAYEmergency Coordinator for
Middlesex East and Oxford South
32
Steve Struthers, VA3TDZEmergency Coordinator
for Middlesex North and Central
33
Assistant Emergency Coordinators

• AECs are appointed by the Emergency Coordinator.
• There is no limit to the number of AECs an EC can
  assign in their area.
• AECs are active in their local community, and are
  key responders during a disaster.
• AECs work with the DEC to assist with EC duties
  if the EC is unavailable.
• AECs are often assigned special roles.

34
Assistant Emergency Coordinators

• Thames Valley ARES Group

35
Local ARES Member Categories

• Steering Committee Composed of the five area
  Emergency Coordinators.
• Core Team Committed, Active Volunteers who are
  eager to participate as often as their schedule
  allows.
• First Wave Volunteers who are willing to assist
  the Core Team during emergencies, but who are
  unable to participate in many scheduled ARES
  activities.

36
Who is in the ARES Core Team?

• The members that will be contacted first when an
  emergencies arises.
• The members who are eager to participate in ARES
  events and volunteer frequently.
• The members willing to participate in training
  sessions to improve their skills.
• The members who will get clearance to operate in
  the Emergency Operations Centre (EOC), Canadian
  Red Cross and other key locations.

37
Who is in the ARES First Wave?

• The members that will assist trained members of
  the Core Team.
• The members who are willing to help in an
  emergency but are unable to commit to training
  and events.
• The members who make an effort to attend annual
  ARES training events for Basic Training. (ARES
  Boot Camp)
• The members who will not be assigned to key
  locations during a disaster.

38
Agenda
What is Ham Radio? What is ARES? ARES and the Red
Cross The ARES Callout Process The National
Traffic System (NTS) The Stratford / Kashechawan
Experience Questions and Answers
39
Memorandum of Understanding

• Between Red Cross and RAC/ARES at the national
  level
• Is in the process of being revised

Excerpts In an emergencyRadio Amateurs of
Canada Inc. agrees to provide, whenever and
wherever possible 2. The establishment and
maintenance of fixed, mobile and portable
emergency communications facilities for local
radio coverage and point-to-point contact between
Red Cross and various locations, as required
40
MOU

• 3. Adequate provision of service for the duration
  of the emergency or until substantial regular
  communications are restored and stand down is
  ordered by Red Cross
• Red Cross..Branches are encouraged to invite one
  or more members of the amateur radio community to
  serve as Red Cross volunteers for emergency
  preparedness and relief
• plans forutilization of communications
  facilities of ARES should be developed by the
  local Red Cross in cooperation with RACs local
  emergency coordinator

41
What Can ARES Do?

• We are communicators, pure and simple
• We can quickly create communications paths
• We can accommodate unusual circumstances, by
  being flexible and creative
• We can call on other ARES teams to assist
• We can provide relevant training and practice for
  our volunteers if we know what we may be called
  for

42
What Cant ARES Do?

• We do not work with or interfere with radio
  systems of first responders
• We are not trained for search and rescue, or to
  provide medical services
• We cant ask our volunteers to put their own
  safety and well being at risk
• We cant be responsible for all the factors that
  affect radio signal propagation but we will
  always do our best to provide good service

43
Callout Logistics Variations

• Topics
• Callout Timeline
• What Agencies?
• Agency Ham Gear
• Variations

44
Callout Timeline

• Established Relationship with Agency
• Agency contacts one of 5 ECs
• Agency EC exchange contact event info
• EC selects resource net frequency, finds NCS
• NCS goes on air with current info, logging
• EC pages out frequency, starts phone tree
• Once ECs are on-air, ICS roles are assigned
• Do whats needed possible tactical net(s)

45
Established Relationship with Agency

• Discussions with agency long before callout
• go over possible activities, and what training,
  gear, practice goes with it
• insurance coverage and ID card needs
• callout method, info to be exchanged
• admin person for updating callout details
• technical details on any Agency ham gear

46
Agency contacts one of 5 ECs

• may use agreed text pager message
• telephone number list
• email to Blackberrys or Cell phones
• In a severe communications outage, Police vehicle
  sent to ECs home addresses
• limited Agency staff can do a callout

47
Agency EC exchange info

• ARES activated, or on standby?
• summary of nature, location of emergency
• what services ARES is asked to provide
• main and backup contacts on both sides
• time, place, contact for any initial meeting
• roles frequencies for Agency Ham gear
• frequency for status updates, if any

48
EC selects frequency, finds NCS

• usually use local repeater with big footprint
• depends on location of emergency
• avoid possible conflicts with CANWARN net
• calls list of net controllers to get net on air
• if none available, EC starts as NCS
• if phones down, EC starts as NCS

49
NCS goes on air, starts logging

• NCS was briefed by EC when contacted
• NCS starts by giving out status summary, and key
  information every 10-15 min
• may or may not call for checkins if ARES has been
  put on standby
• NCS has initial responsibility for logging all
  events on the resource net, but may delegate

50
EC sends page, starts phone tree

• after getting (or becoming) NCS, EC sends net
  frequency out as a message to ARES pagers
• EC then starts phone tree with 3 topics
• one sentence summary of emergency
• recorded check to if called persons available
• if you cant reach em, call their contacts

51
ICS roles are assigned

• once bulk of ECs are on air, assign the standard
  ICS roles
• Incident Command always needed, NCS if no one
  else
• Liaison Officer contact point for Agency
• Operations Chief NCS for tactical net
• Resource NCS is likely Logistics Chief

52
Possible tactical net(s)

• Incident Commander decides if one (or more)
  tactical nets is needed
• NCS for tactical net selected by resource net NCS
  and Incident Commander
• operators for tactical net assigned by resource
  net NCS
• may need monitors to pass traffic between nets
  when needed.

53
What Agencies?

• The Canadian Red Cross MOA
• London Police Services
• City of London Emergency Plan
• Community Emergency Management Coordinators
  (CEMCs) in Middlesex, Oxford, Elgin and Perth
  counties.

54
Agency Ham Gear We Use

• Varies from area to area..
• -Amateur Gear in Agency buildings(St Thomas Red
  Cross, London EOC)
• -provide operators for EMOs Mobile Emergency
  Operations Center

55
Agency Ham Gear We Hear

• ( or might work with in an emergency)
• -all the equipment in the previous slide
• -London Police Community Oriented Response (COR)
  vehicle
• -OPP mobile command post

56
Variations

• Do we come forward and volunteer our services
  when an emergency occurs?-never at the disaster
  scene-our preference pre-existing
  relationship-we might come forward in unusual
  cases
• What if I hear about a disaster via media?-best
  thing to do is to monitor repeaters-if youre
  really anxious, contact an EC, start charging
  batteries, grab go kit

57
Agenda
What is Ham Radio? What is ARES? ARES and the Red
Cross The ARES Callout Process The National
Traffic System (NTS) The Stratford / Kashechawan
Experience Questions and Answers
58
NTS Message Handling

• The National Traffic System (NTS) isan
  internationally standardized formal message
  handling system based on a common written format
  that is designed to be highly reliable,
  prioritized, trackable, and accurate despite
  unfamiliar content and recipients.

59
NTS Message Flow
Hierarchical Relay
Vancouver
Parkhill
RADIO
RADIO
Surrey
London
RADIO
PAPER
PAPER
60
NTS Message Flow
Multiple message streams
Seattle
PHONE
Moscow
PHONE
New Orleans
Atlanta
PAPER
PAPER
61
When would you use NTS?

• When precision is important (medical, logistics)
• When you need an audit trail for message
• When special handling is needed to get message to
  its final destination
• When you need confirmation of receipt
• When prioritization is needed
• For Health and Welfare traffic

62
The Radiogram

• has standardized pieces of information and
  associated procedures
• lots of different form layouts exist, but basic
  information is always the same
• NTS radiogram is used all over the world
• Were going to go over the form, and the basic
  procedures there are additional procedures that
  we wont cover today

63
Sample Radiogram
64
Preamble
65
Address
66
Text
67
Signature
68
Rx From / Tx To
69
Preamble

• The most complicated part. Includes
• - message number
• - precedence (i.e. priority)
• - handling instructions HX
• - station of origin originators callsign
• - check a count of words in the message
• - place of origin location of 3rd party sender
• - time filed when the 3rd party sent message
• - date when the 3rd party sent message

70
Address
Address should contain -full name-complete
address with postal code-telephone number with
area codeMessages from one ham to another need
only a callsign and a telephone number
71
Text

• Most forms have 5 lines each with spaces for 5
  words, which makes it easy to count for the check
  field in the preamble.
• The X that takes the place of a period at the end
  of a sentence counts as a word by itself

72
Signature

• Form of the signature is up to 3rd party
  originator of traffic, but must be sendable, not
  a scribble.
• May be a name, and/or callsign and/or a title or
  rank.
• Words in the signature are not counted in the
  check count

73
Received from / Sent To

• These parts are filled out by the radio operator
  sending the message
• These are different for every transmission hop
  that the message takes towards its destination.

74
Agenda
What is Ham Radio? What is ARES? ARES and the Red
Cross The ARES Callout Process The National
Traffic System (NTS) The Stratford / Kashechawan
Experience Questions and Answers
75
Summary of the Callout

• (Read the Thames Valley ARES summary document.)

76
Thanks for giving us the chanceto make this
presentation.Wed be glad to answer any
questions you may have
The End
