Cell Phone with Sensor

1
Cell Phone with Sensor

• ICS 280
• 1/10/2005
• Kyoungwoo Lee

2
Contents

• Cellular Phone
• Architecture
• BREW
• Power Consumption
• Cellular Phone with Sensors
• Sensor
• Roles of Cellular Phone

3
Mobile Handset
Cellular Phone Convergent Mobile Device
4
Cellular Phone

• Key Features of Motorola V710
• MSM6100 chipset with ARM926EJ-S up to 150 MHz
• 1.2 Megapixel Camera w/ Zoom
• MP4 Video Capture Playback
• Integrated MP3 Player
• Bluetooth
• BREW 2.1
• MMS (Multimedia Messaging Service)
• TransFlash Memory Expansion Slot up to 128 MB

5
QUALCOMM Chipset Solution
6
BREW

• Binary Runtime Environment for Wireless
• End-to-end solution for
• Wireless application development
• Device configuration
• Application distribution
• Billing Payment
• BREW includes
• BREW SDK for application developers
• BREW client software porting tools for device
  manufacturers
• BDS(BREW Distribution System) for operator

7
BREW Device Architecture
8
Power Consumption

• Power Measurement
• Power Consumption
• 3 hours talking and 165 hours standby with 750
  mAh battery
• Application level power measurement
• Idle
• Video Application
• Talking
• Define each status

9
Experimental Results

• 1 IDLE_Nothing
• 2 IDLE_Light
• 3 IDLE_Browsing
• 4 ACT_VideoCapture
• 5 ACT_VideoPlay
• 6 ACT_Talk
• Output Video File
• 170180 KB
• MP4
• 15 Seconds
• 96kbps

Energy Overhead on Video Application(5060) and
Backlight(81)
10
Contents

• Cellular Phone
• Architecture
• BREW
• Power Consumption
• Cellular Phone with Sensors
• Sensor
• Roles of Cellular Phone

11
Sensor

• What it senses
• Home Monitoring
• Health Monitoring
• Environment Monitoring
• Habitat Monitoring
• Earthquake Monitoring
• Battlefield Monitoring
• ?Sensors exist everywhere
• ?Monitoring of physical world its phenomena
• Additional Features
• Data Processing
• Communication
• within Low-Power Constraints

12
Cellular Phone

• Main Function
• Mobile Phone to connect people
• Additional Features
• Message Service
• Camera and Camcorder
• Multimedia Playback
• with powerful computing and infrastructure-based
  network
• Battery-operated
• Roles for Sensors
• A bunch of sensor nodes
• A central node or a proxy server for sensor
  network
• A terminal to human for sensing data

13
A. Cell Phone as a Sensor

• To collect, to process, and to distribute data
  around people
• Home Care
• scan environmental data and forward it to care
  center
• e.g.) check the gas leakage or poisonous material

• Health Care
• sense users health status and update/keep it.
• e.g.) keep the heart rate or blood sugar rate for
  diabetics
• Emergency Care
• catch the emergent situation around people and
  scan/send data
• e.g.) send rescue calls and captured data like

14
A-2. Health Care

• People want to check their health simply
• LG KP8400 Diabetics Phone
• Blood Sugar Testing Phone
• place a strip of testing paper located near
  battery
• place a drop of blood on the end of the strip
• get a reading from the phone
• upload to an online database for later retrieval
• ? Mobile Handset provides tools to check our
  health status and to keep or accumulate it

15
A-2. Health Care (cont)

• What else for heath care?
• Very basic but important health care services
• NONIN Onyx 9500 Digital Finger Pulse Oximeter
• Read data over fingertip
• Real-time information on Heart-Rate and Blood
  Oxygen Saturation Level
• ? Simple devices for health care can be converged
  into mobile phones to check the health by user

16
A-3. Emergency Care

• Cellular phone carries rescue button call for
  safe
• Curitel PG-L5000 SOS Phone
• Emergency Button Call
• Call at three saved numbers
• Take two pictures and send them
• Inform others of the position using GPS
• ? Mobile Handset senses emergent data

17
B. Cell Phone as a Proxy

• To use computing power and communication ability
  of cell phones for sensor network like a Proxy or
  a central node
• Offloading technology
• CPU1s MHz in Sensor VS 100s MHz in Cell Phone
• e.g.) sensor captures images and cell phone
  encodes/encrypts them and transmits them.

18
C. Cell Phone as a Terminal

• A terminal to human for sensing data
• User can get information from sensor network
  immediately after requesting
• An interface to human for information
• User can collect preferred data through cellular
  phone

19
C1. Security

• Cellular phone scans users fingerprint
• LG LP-3800 with Fingerprint Scanner
• AuthenTech sensor for fingerprint recognition
• Locked for unwanted user to use the phone
• ? Mobile Handset recognizes unique data for
  personal security

20
C-2. Code Interface
1
2

• Colorzip.com "ColorCode" - an interface
  connecting you to online contents
• Media provides ColorCode
• User camera on phone recognizes it
• Server provides contents to client
• User enjoys the contents
• ? Mobile Handset provides an interface like
  camera to read and process data

3
4
21
Wrap-up

• Cellular Network might be a huge-covering and
  very potential Sensor Network.
• More Friendly and Closer to Human Being
• Mobile Handset has an interface for sensing data
  and functionalities of computing and
  communication

22
References

• BREW2004Conf http//brew.qualcomm.com/brew/brew_
  2004/
• BREW http//brew.qualcomm.com/brew/en/
• Healthpia www.healthpia.com
• Diabetic http//www.mobileburn.com/news.jsp?Id8
  96sourceSIDEBAR
• SOS http//www.curitel.com/html/product/lineup/f
  eature.asp?serial_no50
• FingerPrint http//www.3g.co.uk/PR/Sept2004/8318
  .htm
• Nonin http//www.nonin.com/products/9500.asp
• ColorCode http//www.colorzip.com
• Howard Andrew Howard, Maja J Mataric, and
  Gaurav S Sukhatme, Mobile Sensor Network
  Deployment using Potential Fields A Distributed,
  Scalable Solution to the Area Coverage Problem
  the 6th International Symposium on Distributed
  Autonomous Robotics Systems (DARS02)
• AdHoc http//www.acticom.de/fileadmin/data/publi
  cations/WWRF9_White_Slides.pdf
• Joseph Anthony Joseph, B.R. Badrinath, and
  Randy Katz, "A Case for Services over Cascaded
  Networks", First ACM/IEEE International
  Conference on Wireless and Mobile Multimedia
  (WoWMoM'98), October 30, 1998.
• Rutgers http//www.research.rutgers.edu/mini/se
  nsornetworks.html
• CENS http//www.cens.ucla.edu
• Crossbow http//www.xbow.com/
