Congestive Heart Failure: Update 2002

1
Congestive Heart Failure Update 2002

• Bruce D. Hettleman, MD
• DHMC
• December 2, 2002

2
CASE PRESENTATION

• 71 yo retired submarine captain is admitted with
  pulmonary edema and an elevated troponin. His PMH
  is notable for advanced CAD and previous MI. He
  had CABGX3 in 1990.
• Echo demonstrated a severely dilated LV with an
  EF of 20 and 3/4 mitral regurgitation.
• EKG showed sinus rhythm at 52 with first degree
  AV block and LBBB.
• Cardiac Cath revealed a patent IMA to the LAD,
  patent SVG to the RCA and a severely diseased SVG
  to the circumflex.

3
What should be done once the patient is initially
stabilized?

• 1. Perform urgent repeat bypass surgery and
  mitral valve replacement.
• 2.Perform percutaneous intervention (stent) on
  the SVG to the circumflex.
• 3. Put in a dual chamber pacemaker
• 4.Maximize medical therapy because he is too high
  a risk for revascularization.

4
Case Presentation--Continued

• After stenting the SVG to the circumflex his
  pulmonary edema subsequently responded to medical
  therapy and he was able to ambulate but remained
  Class III CHF.
• Discharge medications consisted of a
  diuretic,digoxin, beta blocker, ace inhibitor,
  aspirin, plavix and spironolactone.
• He was given dietary and weight-based diuretic
  adjustment guidelines.
• Follow-up in CHF Clinic was scheduled for 1 month.

5
What is the most likely adverse event after
adding aldactone in the treatment of CHF?

• 1. Hypotension
• 2. Breast enlargement
• 3. Yellow vision
• 4. Hyperkalemia
• 5. Worsening CHF

6
After starting aldactone in Class IV CHF, when
should electrolytes be rechecked?

• 1. No worries, mate
• 2. One week ( big worries, mate)
• 3. Four weeks
• 4. Three months

7
Potassium Level
8
Drugs that have shown to prolong life in CHF are

• 1. ACE inhibitors
• 2. Beta Blockers
• 3. Digoxin
• 4. Aldactone
• 5. 1,2 and 4

9
DIG Trial Effect of Digoxin on Survival in CHF

• NHLBI sponsored study of 7,788 patients with
  class II and III CHF and LVEFs
  45
• Randomized, controlled, double-blinded
• 93 of patients on ACEIs
• Superimposable survival curves
• 25 reduction with Dig on first CHF
  hospitalization

10
Weight of Evidence ACE Inhibitors
Approximately 7000 patients evaluated in
long-term placebo-controlled clinical
trials Improvement in cardiac function,
symptoms, and clinical status equivocal effects
on exercise tolerance Decrease in all-cause
mortality by 20-25 (Pcombined risk of death and hospitalization by
30-35 (PTreatment, CONSENSUS, and V-HeFT II trials
Garg and Yusuf, 1995.
11
Weight of Evidence ?-Blockade
Traditionally contraindicated in heart failure,
due to impaired inotropy, early lack of
tolerability, and worsening heart failure Over
10,000 patients have now been evaluated in
long-term placebo-controlled clinical trials
Improvement in cardiac function and NYHA class
and decrease in mortality and morbidity shown in
multiple clinical trials Effects shown in
patients already receiving ACE inhibitors
12
Improved survival with aldactone in advanced
CHF--Rales Trial
13
Will a permanent pacemaker help this man?

• 1. No, he has no indication for a pacemaker and
  if you put one in medicare will send you the
  bill.
• 2. Yes, he should have a VVI back up pacemaker
  prior to discharge because he has LBBB and may
  unpredictably develop complete heart block and
  die.
• 3. Yes, the placement of a routine DDD pacemaker
  will reliably improve his hemodynamics
• 4.Yes, he ought to have a brand-spankin new
  biventricular resynchronization device because he
  has LBBB.

14
Cardiac Resynchronization Therapy for Heart
FailureMechanisms, Clinical Outcomes,Patient
Selection, and Implant
15
Ventricular Dysynchrony and Cardiac
Resynchronization

• Ventricular Dysynchrony1
• Electrical Inter- or Intraventricular
  conduction delays typically manifested as left
  bundle branch block
• Structural disruption of myocardial collagen
  matrix impairing electrical conduction and
  mechanical efficiency
• Mechanical Regional wall motion abnormalities
  with increased workload and stresscompromising
  ventricular mechanics
• Cardiac Resynchronization
• Therapeutic intent of atrial synchronized
  biventricular pacing
• Modification of interventricular,
  intraventricular, and atrial-ventricular
  activation sequences in patients with ventricular
  dysynchrony
• Complement to optimal medical therapy

1 Tavazzi L. Eur Heart J 2000211211-1214
16
Animation Ventricular Dysynchrony
Click to Start/Stop
17
Cardiac Resynchronization
Click to Start/Stop
18
Clinical Consequences of Ventricular Dysynchrony

• Abnormal interventricular septal wall motion1
• Reduced dP/dt3,4
• Reduced pulse pressure4
• Reduced EF and CO4
• Reduced diastolic filling time1,2,4
• Prolonged MR duration1,2,4

1 Grines CL, Bashore TM, Boudoulas H, et al.
Circulation 198979845-853. 2 Xiao, HB, Lee CH,
Gibson DG. Br Heart J 199166443-447. 3 Xiao
HB, Brecker SJD, Gibson DG. Br Heart J
199268403-407. 4 Yu C-M, Chau E, Sanderson JE,
et al. Circulation. 2002105438-445.
19
Proposed Mechanisms Improved Intraventricular
Synchrony
Improved Intraventricular Synchrony1,2
? dP/dt 1,3,4 ?EF1,5 ? Pulse Pressure 3,4
? SVCO1, 2
? MR1
? LVESV1
? LA Pressure1
1 Yu C-M, Chau E, Sanderson J, et al.
Circulation 2002105438-445 2 Søgaard P, Kim W,
Jensen H, et al. Cardiology 200195173-182 3
Kass D Chen-Huan C, Curry C, et al. Circulation
1999991567-73 4 Auricchio A, Ding J, Spinelli
J, et al. J Am Coll Cardiol 2002391163-1169 5
Stellbrink C, Breithardt O, Franke A, et al. J Am
Coll Cardiol 2001381957- 65
20
Prevalence of Inter- or Intraventricular
Conduction Delay
Moderate to Severe HF Population3,4,5
General HF Population1,2
IVCD 30
IVCD 15
1 Havranek E, Masoudi F, Westfall K, et al. Am
Heart J 2002143412-417 2 Shenkman H, McKinnon
J, Khandelwal A, et al. Circulation 2000102(18
Suppl II) abstract 2293 3 Schoeller R, Andresen
D, Buttner P, et al. Am J Cardiol.
199371720-726 4 Aaronson K, Schwartz J, Chen T,
et al. Circulation 1997952660-2667 5 Farwell D,
Patel N, Hall A, et al. Eur Heart J
2000211246-1250
21
Increased Mortality Rate with LBBB

• Increased 1-year mortality with presence of
  complete LBBB (QRS 140 ms)
• Risk remains significant even after adjusting for
  age, underlying cardiac disease, indicators of
  HF severity, and HF medications

All patients N5517
20
LBBB N1391
HR 1.70 (1.41-2.05)
16.1
15
11.9
HR 1.58 (1.21-2.06)
1-Year Mortality ()
10
7.3
5
5.5
HR Hazard Ratio
0
All Cause
Sudden Cardiac
Cause of Death
Baldasseroni S, Opasich C, Gorini M, et al. Am
Heart J 2002143398-405
22
Proposed Mechanisms of Cardiac Resynchronization
Yu C-M, Chau E, Sanderson J, et al. Circulation
2002105438-445
23
Summary of Proposed Mechanisms
Yu C-M, Chau E, Sanderson J, et al. Circulation
2002105438-445
24
Achieving Cardiac ResynchronizationMechanical
Goal Atrial-synchronized bi-ventricular pacing

• Transvenous Approach
• Standard pacing lead in RA
• Standard pacing or defibrillation lead in RV
• Specially designed left heart lead placed in a
  left ventricular cardiac vein via the coronary
  sinus

Right AtrialLead
Left VentricularLead
Right VentricularLead
25
CRT Improves Quality of Life Score and NYHA
Functional Class
QoL NYHA PATH-CHF1 (n41) InSync
(Europe)2 (n103) InSync ICD (Europe)3
(n84) MUSTIC4 (n67) MIRACLE5
(n453) MIRACLE ICD6 (n364)
Statistically significant improvement with
CRT (p ? 0.05) ? Not statistically
significant or No statistical analysis performed
on dataBlank Indicates
test neither performed nor reported
26
CRT Improves Exercise Capacity
27
CRT Improves Cardiac Function/Structure
28
Cardiac Resynchronization OutcomesSustained for
at least 12 months
Statistically significant
improvement with CRT (p ? 0.05)?
No statistically significant improvement
with CRTBlank Indicates
test neither performed nor reported
1 Gras D, Leclercq C, Tang A, et al. Eur J Heart
Fail 20024311-320 2 Auricchio A. Stellbrink C,
Sack S., et al. J Am Coll Cardiol
2002392026-2033 3 Linde C, Leclercq C, Rex S,
et al. J Am Coll Cardiol 200240111-118
29
Step 1 Cannulate CSAttain LDS Model 6216A

• Use extreme care when passing the guide catheter
  through vessels
• Due to the relative stiffness of the catheter,
  damage to the walls of the vessels may include
  dissections or perforations

30
Step 2 Perform Venograms
Varying Patient Anatomy 1,2,3
1. Potkin et al. Am J Cardiol 1987601418-1421
2. Neri et al. Europace 2000I D95 Abstract 88/2
3. Hill et al. Europace 2000ID238 Abstract
167/2
Photos Courtesy of Dr. Daniel Gras
31
Cardiac Venous Anatomy
Step 2 Perform Venograms
Great
Postero-lateral
CS Os
Antero- lateral
Lateral
Middle
Anterior
Posterior
32
Lead in Lateral Cardiac Vein
Step 2 Perform Venograms
33
Step 4 Place LeadAttain OTW Model 4193
Click to Start/Stop
34
Step 4 Place LeadAttain OTW Model 4193
Courtesy ofDr. Daniel Gras
Click to Start/Stop
35
LAO View Tracking Over the Wire
Courtesy ofDr. Daniel Gras
Click to Start/Stop
36
Step 4 Place Leads Attain LV Model 2187
Video compliments of Dr. Vince Paul
Click to Start/Stop
37
Biventricular Pacing is indicated for the
reduction of CHF symptoms in patients with

• 1. Stable Class III-IV CHF
• 2. QRS 130 ms
• 3.EF
• 4. Optimal medical therapy
