The Comfort System

1
The Comfort System

• Product Presentation

The Intelligent Home System
2
What is Comfort?

• Comfort - an Intelligent Home System which
  integrates Alarm, Home Automation, Answering
  Machine, and Intercom.

3
Operating Comfort
4
Scene Control Switch

• Each Scene switch has 4 buttons and indicator
  LEDs
• Buttons can be programmed to control lights,
  appliances, or set scenes
• LED indicators indicate status of items
• Optional IR receivers allow handheld remote
  control to control the house

5
Comfort Keypad

• One-touch keys to Arm to Away, Night, Day modes
• Short Cut Function Keys
• Voice Menu to guide user through
• all operations

6
Operating Comfort by Telephone

• Use your PIN code to gain access

• Call in to Comfort from any mobile phone wherever
  you are.

• This is the most convenient method as no special
  equipment is needed, only a phone.

• A Voice menu guides you through all operations.

7
Using A Handheld Remote Control

• A handheld Touchscreen remote controller can be
  used to control Comfort
• Hundreds of levels of screens for lighting
  scenes, Air-conditioning, Home Entertainment,
  security and many more.

Philips Pronto
Next Page
8
RC01 Handheld Remote Control

• New Low cost RC01 handheld remote control
• Just point the remote control at any Keypad or
  Scene switch

9
RC01 Handheld Remote Control
Operation Keys function depending on the Room Key
Room Keys select a Room or appliance
Scene Buttons 1 to 12
Pressing both buttons causes a PANIC alarm
4 additional Scenes A to D
Remote Keypad works as a keypad when pointed at
a KP02 keypad
10
Controlling Comfort from the Internet

• Comfort Network Interface Unit to connect to a
  LAN or via dial-up to the Internet
• Use any browser to access Comfort from anywhere!

11
Comfort on a Home Network
12
Home Automation
13
Comfort Automation

• Lighting
• TWS Lighting Control Modules work with 2-way
  switches for on-off relay control of lighting,.
  2-way switches work even when Comfort is switched
  off.
• For high-end lighting, Comfort is able to
  integrate with EIB (European Installation
• Bus) and C-BUS systems using bus-wiring, or
  Lutron using infrared signals.

14
Comfort Automation- X10-Compatible

• Comfort can send and receive X10 commands, ie
• it has 2-way X10 communications (using X10
  TW7223).
• Comfort can send the new Extended commands e.g.
  preset dim.
• Comfort can receive X10 commands from X10
  switches and controllers to activate Responses to
  trigger non-x10 devices or scenes
• The new Comfort Scene Switches and RIO Modules
  can send X10 signals from IR remote control

15
Comfort Automation

• Integration
• is the key

16
Comfort Automation
Voice Menu

• Voice menu over the phone gives list of
  appliances - no need to remember activation codes
• It is not necessary to wait for the voice menu to
  finish once you are familiar.

17
Comfort Automation

• 16 Time Programs available
• Each Time Program can be activated for any
  combination of Days of Week or holiday, and at
  any programmed time.
• Time Programs can arm or disarm the security
  system, or control one or more appliances

18
(No Transcript)
19

• Security Off - system is not armed, but 24 hour
  zones are active
• Away Mode - when everyone is out - all zones are
  protected, phone cannot answer calls or dial.
• Vacation Programs - cause lights, TV, radio can
  turn on and off semi-randomly giving impression
  the house is occupied

20

• Day Mode to protect the perimeter doors and
  windows. Internal zones are inactive - arm to day
  if people are in the house, but awake, e.g.
  watching TV
• Night Mode to protect all zones except designated
  zones - arm to Night when occupants go to bed.

21

• can dial up to 8 numbers which may be cellular
  phones, pagers, or Alarm Monitoring Centers or
  SMS (with GSM Module).
• Dial to Voice phone - announces Alarm Type and
  allows the user to track theintruder, or listen
  to sounds inthe home through the keypad.

22

• The Security System may be linked to Lights
  and appliances in the home, for example
• Fire alarm can light up exit path
• Intruder alarm in Away mode (no one at home) can
  cause house lights to flash on/off
• Lights turn on in the area where intruder was
  detected, and zone is announced on keypad.

23

• Opening door at night can turn on hall light
• Arming to Away can turn off all lights and
  airconditioners.
• Activation of outside PIR can trigger a
  user-recorded warning message

24
(No Transcript)
25

• Press a key to record a message when going out
• Users enter their PIN code to hear their recorded
  messages
• MSG led turns on when there are new messages

26

• Up to 8 personal mailboxes for members of the
  family
• Each mailbox is accessed by User code
• User-recorded greeting Message (OGM)

27

• 10 minutes of messages saved in nonvolatile
  memory
• Message memory is maintained even after total
  power shutdown and removal of battery.

28
User can choose to have Comfort call a pager to
notify that a new message has been received. The
user can call back to hear the message.

• Or forward new messages to their cellphone, to
  hear the new message as soon as it is received.

29
(No Transcript)
30

• Home LED - steady when not armed, flash for
  trouble (line cut, AC fail, battery low)
• ARM LED - steady for armed, flash for alert or
  alarm state
• AC - Off if AC OK, steady for power failure,
  flash for low battery
• MSG - steady for new message from user, flash for
  new message from incoming call.
• MIC - Steady if Mic is on (recording or listen)

31

• One-touch keys to arm to Away, Day, and Night
  Modes
• 2 key combinations for Fire and Panic

32

• Short-cut keys for common operations

33

• Any keypad can intercom to any other keypad
• Broadcast or individual keypad select modes
• Keypad can act as a Baby Monitor

34

• Any telephone in the house can be used to talk to
  the Door Station
• When armed to Away Mode, Comfort dials to a
  programmed phone so user can talk to the visitor
• User can open the door or gate to let the visitor
  in (2 doors can be controlled)

35

• Built-in Resettable Fuse for Lightning surge
  protection on the telephone line
• Individual surge protection for ALL inputs and
  outputs
• Rugged Power supply with surge protection
