Dirk A. D. Smith

1

• Dirk A. D. Smith
• Alexander LAN, Inc.
• David L. Powell
• KIS Computer Center

2
Agenda

• Introduction
• Overview
• Deployment
• Features
• Configuration
• Demo, QA, and Raffle

3
Introduction
4
Introduction

• Alexander LAN, Inc. Nashua, New Hampshire
• Developer of IT Software since 1991
• Introduced worlds only automated crash
  management utilitiesnot that systems ever
  crash

• Alexander SPK for NetWare (1993)
• Alexander SPK for Windows (2000)
• Introduced
• Alexander SMK for Windows (2004)
• Alexander SMK for Linux (2005)
• Partner with Cyber SPK, LLC USAF Research
  Laboratory

5
Introduction

• Keep IT Simple Computer Center (KIS)
  Fremont, California and Kansas City, Missouri

• Network solutions and consulting since 1988
• Microsoft Gold
• Novell Platinum
• West Coast center for Alexander SMK Sales,
  Training Support

• Exclusive classroom training for Laura Chappell
  Presents

6
Overview
7
Overview

• Alexander SMK
• SMK System Management Kit
• Supports Windows and Linux
• Pro-active Monitoring to Prevents Unplanned
  Downtime

• Know when conditions begin to degrade
• Know when software has been added or removed
• Know when a case has been opened or a processor
  removed

8
Overview

• SMK Provides Data Other Management Utilities
  Cant

• Most management utilities report system state
  only (Configuration info on hardware and OS)

• SMK provides system state as well as real-time
  variable data(Operating metrics including CPU or
  memory overload, fan spin rates, is drive
  failing, etc.)

9
Overview

• Single Interface Simplifies Management Across
  Systems

• IE or Mozilla
• Screens auto-adjust for high end server or simple
  desktop/notebook

• Simple Installation
• Auto-discovers system sensors
• Auto-defines alert levels
• Typical install 4 min.
• Provide alert address and SMK begins reporting
  1 min.

10
Overview

• Manage Systems Remotely
• Take over KVM for remote systems
• Start/Stop systems or services
• Update drivers
• Multi-Vendor Support
• Most utilities are hard coded to support
  particular vendors hardware

• SMK supports all tier-one hardware vendors and
  many domestic and international independent
  hardware vendors (IHV)

• Change-Event Monitoring Warns of Asset
  Alterations

• At reboot or 24 hrs.
• Checks all hardware and software assets for
  discrepancies

11
Overview

• Event Log Provides Complete History
• Stores all hardware and software events
• Export to CSV, Excel, or XML
• Generate complete asset reports instantly
• Full International Support
• Supports all languages supported by Microsoft
• Auto-detects language in use on target system
• Defaults UI to that language (can select
  others)

• Alert Notification
• Dynamically discovers environment and applies
  default settings

• User can change all alerts in seconds from a
  single screen

• Send alerts to different admins based upon their
  category

12
Deployment
13
Quick Start Guides

• Quick Start Guides simplify installation
• Central Manager
• Local Agent

14
Deployment Sequence

• Install Central Manager
• Validate License Key
• Deploy Local Agents

15
Components

• Central Manager
• Management Console
• Web Server
• Local Agent (Automatically installed with
  manager)

Central Mgmt
Web Server
Monitoring Agent
16
Components

• Local Agents
• Server, Desktop, or Notebook Agent

Monitoring Agent
17
Central ManagerInstall on 1 System

• Intel Architecture platform x86/x64
• Compatible Operating System
• 160MB disk space
• Typically uses 40MB
• SMK installs all required software
• Each manager supports up to 500 Agents
• Only additional requirement is Java run-time for
  the web browser to utilize Remote Console

18
Local AgentsInstall on each system to be managed

• Intel Architecture platform x86/x64
• Compatible Operating System
• 60MB disk space
• Typically uses 20MB RAM
• SMK installs all required software for operation
• Only additional requirement is Java run-time for
  the web browser to utilize Remote Console

19
Installation Notes

• Path name for software installation can not
  contain a SPACE

• Only change RMI Port Number from default 1099 if
  another RMI application is using it

• SSL encryption is used for the encryption between
  the browser and web server

• The communication between the central manager and
  the agents is a secure proprietary protocol that
  stops replay attacks

20
Central System Management
21
Features
22
Features

• A single user interface
• Manage all systems Servers, Desktops, Notebooks,
  Windows, Linux

• Reporting
• Report on your system assets, from location,
  owner, function down to the hardware
  configuration and the software and versions
  installed
• Event Logging
• Filter events to identify trends across your
  systems

• Centralized Hierarchal Alerting
• Send different categories of alerts to different
  administrators

23
Features

• Remote Power Management
• Power on and off systems
• Out of Band Management
• Control non-responding IPMI based systems
• Remote Console
• Control keyboard, video and mouse through your
  browser

24
Features

• Configurable monitoring
• Thresholds, Sample periods, Reset periods
• Enterprise Integration
• Alerting and remote resolution (Openview,
  Unicenter, Netview, and other SNMP MIB compliant
  applications)

• Microsoft Operations Manager integration (MOM)
• System Event Logging

25
Features

• RAID Controller configuration
• Single UI configures RAID controllers from 3ware,
  Adaptec, Intel, LSI, and others

• Power Policy management
• Configure system power policies and schedule
  system restarts and shutdowns to conserve power
  costs

• Remote service and process management
• Start / stop a service or process remotely

26
Features

• Real-time Management of Assets
• Be alerted when someone removes hardware
  components or installs software

• Centralized Management Simplifies Asset
  Management

• Precise, automated reporting reduces time and
  increases accuracy

• Extend Useful Life of Systems
• Monitor for repair or optimization instead of
  replacing before needed

• Simplify Planning and Budgeting
• Reduce effort needed to plan for technology
  refreshes


27
Configuration
28
Configuring Local Alerts
Alert configuration
Notification information
29
Configuring Central Alerts
Alert configuration
Notification information
30
Adding Systems to the Tree
IP Address Range
Used for the Central Tree
31
Generating a License Key
Evaluation end date
Generates License Key
32
Uploading a License Key
Support Information
License Key Management Limits
Upload License Key
Choose Key file to upload
33

• Demo, QA and Raffle
