Weaponizing Noam Chomsky: Symbols and Grammars Are Fun

1
Weaponizing Noam ChomskySymbols and Grammars
Are Fun

• Dan Kaminsky
• Director Of Penetration Testing

2
Introduction

• Many physicists would agree that, had it not been
  for congestion control, the evaluation of web
  browsers might never have occurred. In fact, few
  hackers worldwide would disagree with the
  essential unification of voice-over-IP and public
  private key pair. In order to solve this riddle,
  we confirm that SMPs can be made stochastic,
  cacheable, and interposable.
• Rooter A Methodology for the Typical Unification
  of Access Points and Redundancy

3
That was BS.

• That also got accepted into a con.
• Automatically generated from a context free
  grammar

• Ive been working too hard all these years ?
• Be quiet, or I will replace you with a very
  small shell script

• This talk is a bit of a remix
• Patterns and symbols are interesting me as of
  late

• Automatic determination of both is difficult,
  interesting, and unsolved

• Integration into human symbolic systems promises
  particularly interesting results

• So were going to explore a bit.

4
Language Is Cool

• Language A protocol for the transmission of
  concepts and intentions between humans

• Documentation is not available
• Documentation does not really work
• Learned through exposure and use
• Significant amount of internal structure,
  redundancy, and consistency

• Who makes language?
• Kids.
• Adults coin words here and there, but when
  theyre forced to invent a common language to get
  things done, its called a Pidgin, and its
  terrible
• The kids hear it, and invent a Creole a merged
  language of significantly greater accuracy and
  depth

• Children make languages
• Adults make working languages
• Programmers make barely working languages

5
Programmers Talk Funny

• Fundamentally two languages that programmers must
  use

• Code to Human User Interface Design
• Code to Code File and Network Protocol
• UI is a protocol.
• This is obvious in retrospect.
• There are two things this talk hopes to do
• Correct some of the Code-Human protocols that
  are out there

• Use human strategies to analyze Code to Code
  communications

• Learning a protocol is learning a language.
  Humans do not learn languages quickly, and thus
  were resource bound on fuzzer development

• Its 2007 most parsers remain unfuzzed (and
  thus just waiting to be exploited)

6
Weaponizing Noam?

• An early inference procedure was described by
  Chomsky and Miller (1957a), as reported in
  Solomonoff (1959). Chomsky proposed a method for
  detecting loops in finite state languages. The
  approach requires a set of valid sentences, and
  an oracle that determines whether a sentence is
  in the language.The algorithm proceeds by
  deleting part of a valid sentence and asking the
  oracle whether the sentence is still valid. If it
  is, the deleted part is reinserted into the
  sequence and repeated, so that it appears twice.
  If the sentence is still in the language, a cycle
  has been detected.
• Inferring Sequential Structure, Craig Neville
  Manning, 1996

• This couldnt POSSIBLY be useful for building a
  structure for a dumb fuzzer to operate against.

• Instead of seeing if the parser crashes, just see
  if it considers the input valid

7
Topics Of Discussion

• Further Explorations in Cryptomnemonics
• Using Names and Syllables for password
  representation

• Sequitur-XML Merging automated structure
  discovery with the standard architecture for
  structure representation

• which turned out to be quite nice for controlled
  structure destruction ?

• Exploring Dotplots
• Building a GUI
• Exploring other domains

8
Intro To Symbol Sets

• Machine Symbols
• Data (AA, BB, CC)
• Code (a(), b(), c())
• Formats (All, Bad, Code) ?
• Human Symbols
• Letters (A, B, C)
• Glyphs (A, B, C)
• Syllables (Ah, Bee, See)
• Words (Amazing, Bear, Clear)
• Native Names (Alice, Bob, Charlie)
• Things (Axe, Bone, Chimpanzee)
• Actions (Ask, Buy, Compute)
• Colors (Aquamarine, Blue, Chartreuse)
• Machines can use formats, but their native format
  is raw bits

• Humans have no concept of raw bits everything
  must be contextual

• Long history in mnemonics of mapping arbitrary
  data to a context

9
Different Domains Have Different Strengths See
Visual Processing
10
Cryptomnemonics

• Definition The study of human memory, as it
  applies to cryptographic systems

• Developing in response to this
• ssh dan_at_blahThe authenticity of host 'blah
  (1.2.3.4)' can't be established.RSA key
  fingerprint is 09a9b19984177dbac655465a
  17f88301.Are you sure you want to continue
  connecting (yes/no)?
• The machine is acting like its integrating with
  another machine. Its not, and that matters.

• Humans can handle hexadecimal characters but
  not that many.

11
Hex Confusion

• After somewhere between 2 and 5 characters, most
  of you will fail to see a difference

• Positional Bias Expect to see certain things at
  the beginning or end

• Value Confusion Letter vs. Number is remembered
  before the actual value of letter or number

• Glyph confusion
• Despair Effect
• Nobody could possibly detect a change, so its
  not rational to even try

12
Classes of Memory

• There are three classes of memory, at least to
  the degree as is useful in cryptography

• Rejection Ive never seen that before
• Recognition Its that one, not that other
  one

• Recollection Let me describe it to you.
• SSH just requires rejection
• Hex is not rejectable
• Can we try another domain?

13
Exploring The Nymic Domain

• ssh dan_at_blahKey Data julio and epifania
  dezzutti luther and rolande doornbos manual
  and twyla imbesi dirk and cuc kolopajlo
  omar and jeana hymelThe authenticity of host
  'blah (1.2.3.4)' can't be established.Are you
  sure you want to continue connecting (yes/no)?
• Alternate mapping for 09a9b19984177dbac65
  5465a17f88301.

• Proposed last year as a potential solution
• There is nothing more contextual than a story,
  and there is nothing more stable in a story than
  the names of its participants

• Stories retold are stories remembered we need
  to be exposed to the above group time and time
  again to be able to reject any deviation from it


14
How To Derive Names?

• Original Model
• Take US Census Data
• Remove any names that may be easily confused with
  one another

• Easy Bob v. Bobby
• Hard Bob v. Robert
• Celebrity Naming
• Marge Godwin
• Archaic Naming
• Use constructs from various ancient languages
• Mechanistic Constructs
• Bubble Babble 64 bits xegoz-tosys-vusik-masar
• Koremutake 64 bits darujifahe stygrifrejy

15
How Many Names?

• Unclear what the crossover point is between hard
  from more names, and benefit from more entropy
  per name

• Present system is 512 male name, 512 female name,
  1024 last names from US Census

• 256/256/256 would provide 24 bits per couple
  instead of 40, and the names would be more
  recognizable. Better? How much better?

• The more names, the more a problem position
  becomes

• Were sensitive to names, but without a story
  context, theres no roles locking people to being
  the first or the second or the third. So the
  more names, the more bits we lose to reader
  confusion.
• How many bits are necessary? Depends on what for.

16
Flipping The Bits

• SSH Key Representation is not the only thing we
  can do with this technique

• In fact, its not even the most pressing problem
• Passwords are in crisis right now
• PKI failed, deal with it
• Theres an entire alternate history where XSS
  enjoys the benefits of your legal credentials
  being available and shared

• People are being asked to generate, frequently,
  high entropy non repeated passwords

• Theyre repeating them
• Theyve exhausted personal entropy, and have
  moved to geometric progressions to evade lameness
  checks

• (uoiJKL798
• Fixed prefix

17
A Fundamental Shift

• Generate passwords for your users.
• But theyre hideous, nobody will remember what
  we automatically generate

• Youre theoretically forcing them to generate
  those hideous passwords, off the top of their
  head

• Use alternate symbolic domains to coat the
  password entropy you require in a form users can
  accept

• Why yes, this is exactly like a tunnel. Were
  tunneling entropy over a baby name book ?


18
Change Your Ways

• Modify your validation logic to accept long
  passwords without weird character sets

• Punctuation and case sensitivity are weak
  symbols

• It is easier to chain together common symbols in
  a common way, than it is to link together
  arbitrary bytes out of context

• This is a fundamental difference between human
  symbol manipulation and the operations of
  computers

19
How Many Bits Do We Really Need?

• Hash Validation 80-100 bits
• We dont have a birthday paradox problem with
  hashes, since one of them is fixed.

• 280-2100 work efforts are outside the range of
  feasibility at this time

• Password Entry 24 bits for low security, 36-48
  bits for high security

• Need enough to make brute force enumeration
  across all users infeasible

• For each username, try one possible password
• 48 bit is what were at with punctuation/case/numb
  er/8 character.

20
Limits to alternate symbol domains

• We lose the ability to measure nextness
• 0x10 is one less than 0x11
• Bob ishow much less than Charlie?
• Data may become variable length Bob is three
  characters, Charlie is seven

• Harder to see patterns
• Has trouble scaling to any large number of bits.
• We cant analyze even mildly large systems using
  this translation layer

21
What Weve Been Using(Warning Sucks.)
22
Nestce pas Non Sequitur

• Sequitur Linear Time Pattern Finder
• Creates hierarchal Context Free Grammars from
  arbitrary input

• Compression Algorithm in which you can look
  under the covers to see whats going on

• Created by Craig Neville-Manning as his PhD
  thesis a decade ago

• Hes now Chief Research Scientist at Google

23
Whats New Sequitur-XML

• echo aabbabc ./sequitur_simple.exe
• Why translate Gives us much easier to
  manipulate output

• C is very good for generating the tree
• Other languages are very good for analyzing /
  modifying the tree

• XML is a (shockingly) good machine format for
  representing structure

24
Early Work Syntax Highlighting Using
Compression Depth
25
Whats Actually Going On?

• (0) - (73),b4,(73),ca,(73),e6,(73),02,(74),18,(
  74),2c,(74),4a,(74),5c,(74),6e,(74),80,(74),98,(74
  ),b0,(74),c8,(74),e8,(74),fc,(74),10,(75),20,(75),
  30,(75),40,(75),50,(75),64,(75),82,(75),90,(75),9e
  ,(75)(84),d6,(84),ee,(84),0c,(85),28,(85),3c,(8
  5),4e,(85),66,(85),7e,(85),8c,(85),9e,(85),ac,(85)
  ,be,(85),ca,(85),ea,(85),08,(86),26,(86),44,(86),5
  6,(86),6a,(86),7c,(86),8a,(86),a6,(86),b6,(86),cc,
  (86),de,(86),02,(87)
• Repeated sequence, single byte literal. Repeated
  sequence, single byte literal. Rinse, lather,
  repeat.

26
Where Things Get Most InterestingLive Symbol
Browsing!
27
Browsing HOWTO

• For each entry in the root node,
• If its a literal, color it white
• If its part of a reference, color it red
• If its clicked, color it and every other
  instance of that reference blue

• A little buggy
• Present implementation DOES NOT SCALE
• But effective!

28
Symbol Links Where To Go From Here

• Turns code on left intosymbolic set on
  rightits easy then to linkthe symbols
  togetheras per the graph.

• This works for non-textual data
• Sequitur imputes meaningfulsymbols from
  arbitrary inputdata

29
Context Free Grammar FuzzerTHE CFG9000

• Reduce input data to a stream of symbols
• Fuzz data at the symbol level, rather than at
  pure bytes

• Shuffle
• Drop
• Repeat
• Uniform Corrupt
• Consistently corrupt all instances of a given
  symbol

• -
• Partially ported to the new XML framework

30
Sample CFG9000 Output

• calculate_rule_usage(p-rulep-rulep-rulep-rule
  p-rulep-rulep-rulep-rulep-rulep-rulep-rulep
  -rulep-rulep-rule()

• calculate_rule_usage(calculate_rule_usage(calculat
  e_rule_usage(calculate_rule_usage(calculate_rule_u
  sage(calculate_rule_usage(calculate_rule_usage(cal
  culate_rule_usage(calculate_rule_usage(calculate_r
  ule_usage(calculate_rule_usage(calculate_rule_usag
  e(calculate_rule_usage(calculate_rule_usage(calcul
  ate_rule_usage(calculate_rule_usage(calculate_rule
  _usage(calculate_rule_usage(p-rule())

31
Slashdot Fuzzed
32
Slashdot Fuzzed (2)
33
Why We Moved To XML In The First Place

• XML is a (potentially) validating format
• Has the concept of schemas
• NOT THAT THEYRE ALWAYS OR EVEN OFTEN CHECKED
• Schema validation is expensive
• We should be able to use XML Schemas to guide
  fuzzers

• WS-Bang
• Excellent tool for bashing Web Services
  frameworks

• Given a WSDL file (Web Services Description
  Language), fuzz it

• Untidy Mostly just attacks XML parsers, doesnt
  hit the structure

34
Automatically Generating Schemas?

• We can autogenerate Schemas from XML (to some
  degree)

• Relaxer
• Trang
• Tends to capture structure better than content
• Doesnt appear to automatically determine what
  values are valid for each field

• Does provide framework for automatically
  extracting all instances of what can go where

35
Wireshark DemoFrom

• pos"126" value"ff002700ff000000080000004e0054004
  6005300"

• - size"4" pos"126" value"ff002700"

•   .... .... .... .... .... .... ...1 Case
  Sensitive Search This FS supports CASE SENSITIVE
  SEARCHes" size"4" pos"126" show"1" value"1"
  unmaskedvalue"ff002700" /
•   .... .... .... .... .... .... ..1. Case
  Preserving This FS supports CASE PRESERVED
  NAMES" size"4" pos"126" show"1" value"1"
  unmaskedvalue"ff002700" /
•   .... .... .... .... .... .... .1.. Unicode On
  Disk This FS supports UNICODE NAMES" size"4"
  pos"126" show"1" value"1" unmaskedvalue"ff0027
  00" /

36
Wireshark DemoTo

• -
• -
•   minOccurs"1" name"field" type"field" /

•
•


•
•   tring" /

•   type"xsdnormalizedString" /

•
•


•


•   type"xsdtoken" /

•

37
Could we automatically extract structure from
Sequitur-XML?

• This sequence of bytes can be reconstructed with
  these other sequences of bytes

• No tree relationship anything can link in
  anything

• Need to have the content awareness Relaxer lacks
  to get anything useful

• Where might we get this content awareness?

38
What Might We Borrow From Linguistics?

• Can we use linguistic approaches?
• Common Elements
• Humans Subjects, Verbs, etc.
• Machines Delimiters, Length Fields,
  ASCII/Unicode, x86, Padding to Four Byte
  Boundries

• Symbol Interrelationships
• Humans We take word boundries for granted
• Until were listening to a foreign language, and
  wonder why there arent spaces between words ?

• Machines File formats rarely make it easy to
  see where one symbol starts and another begins

• Does one symbol always appear before another?
  Does one symbol always found itself surrounded by
  two others?

39
How To Think Of Sequitur

• Any time youre manipulating data as bytes, think
  of manipulating it as symbols

• N-gram histograms on bytes - N-gram histograms
  on symbols

• Bayesian probabilities on characters - Bayesian
  probabilities on symbols

• Sequitur is not necessarily the best way to
  determine a grammar

• Suffix Trees may be more accurate
• Keiffer-Yang (redundant symbol extraction) a very
  good post-processing step to add

• Ray removes In-Memory Grammar Requirement
• Not all other solutions are linear time, though
• Kind of cool to have a grammar that covers a
  750GB hard drive undergoing forensics ?s

40
Fuzzy Wuzzy Wuz A Symbol

• Symbol analysis systems (language translators,
  etc) have issues w/ TMTOWTDI (Theres More Than
  One Way To Do It)

• Very similar messages can be encapsulated in very
  different ways

• Very similar messages can be encapsulated in very
  similar, but not identical ways

• Sequitur only handles exact matches fuzzy
  grammar imputation doesnt appear to exist yet

• We must develop this fuzziness to create
  byte-sourced XML schemas ?

• It is a pretty wild concept, so ?
• Are there any systems for analyzing complex,
  inequal but somewhat related sets of symbols?

41
Another Approach Dotplots
42
What Exactly Are We Doing

• Jonathan HelmansDotPlot Patterns ALiteral
  Look at PatternLanguages offers
  anintroduction

• Instead of to, be, not etc, we use chunks of
  data from arbitrary files

• Instead of demanding perfect equality, we measure
  how similar the chunks are

• If most of the bytes are in most of the same
  places, its pretty similar, if most are
  different, pretty dissimilar


43
New Video Analysis!(Nine Inch Nails, Closer)
44
More Video AnalysisCibo Matto / Michel Gondrys
Palindromatic Sugar Water
45
Weve figured out what some of these patterns
mean
46
But some code just comes out strange.
47
So How Might This Be Useful?

• A) Format Identification
• 1) Do different files appear different, and does
  the appearance reflect the existence of internal
  structure?

• 2) Do different instances of the same file
  format appear similar?

• 3) Does one format embedded in another make
  itself apparent?

• B) Fuzzer Guidance
• 1) Can we locate the actual byte offsets where
  one section ends and another begins?

• 2) Can we visualize and compare fuzzer
  operations via Dotplots?

48
Format Identification

• 1) Do different files appear different, and does
  the appearance reflect the existence of internal
  structure?

• 2) Do different instances of the same file
  format appear similar?

• 3) Does one format embedded in another make
  itself apparent?


49
Java Class Files
50
.NET Assemblies
51
CNNs Home Page
52
SMBTorture Traffic(Packets Note, Stop/Start Is
Visible)
53
Kernel32.dll
54
Chromosome 22(This is, after all, a genomics
hack)
55
The Legend Of Zelda
56
Format Identification

• 1) Do different files appear different, and does
  the appearance reflect the existence of internal
  structure?

• Answer Yes. They do.
• 2) Do different instances of the same file
  format appear similar?

• 3) Does one format embedded in another make
  itself apparent?


57
Books from Project GutenbergConsistent
Despite Englishs low information content, lack
of even mildly related strings causes little
self-similarity across symbol clusters
58
US CodeModerately Consistent
Legalese is a massively structured dialect.
Symbols appear in very distinct patterns that are
more reminiscent of machine code than text.
59
HTMLConsistent
HTML repeats smaller symbols (tags) and larger
symbol clusters (via template engines) regularly.
This shows up visually as a tightly repeating
pattern.
60
Java Class Files (Compared)Mildly Consistent

• Binary code (be it bytecode or x86) tends to be
  very structured. Still, we are dependent on both
  the content and the compiler to generate distinct
  patterns.

61
x86Consistent (In Sections)
x86 tends not to be handwritten as such complex
instructions are emitted in a highly structured
form.
62
Exception?

• 64 kilobyte graphical demonstration
• Run through a packer ?
• Compression removes patterns

63
NES Games
6502 Assembly Tends To Show Consistent Patterns,
But
64
Mario Games Look Rather Different.

• Output is highly dependent on the compiler
• Output is highly dependent upon the actual
  content

• File formats are merely shells for actual
  content. You are analyzing the content the
  format is just syntactic sugar.

65
Format Identification

• 1) Do different files appear different, and does
  the appearance reflect the existence of internal
  structure?

• Answer Yes. They do.
• 2) Do different instances of the same file
  format appear similar?

• Answer Somewhat. Similar content looks like
  itself, but youre measuring the fundamental
  entropy of the underlying content, not the format
  of the content itself.
• 3) Does one format embedded in another make
  itself apparent?

66
File Formats Contain Multiple SubformatsAnother
Look At Kernel32.DLL
These are all different parts of Kernel32.
67
Quickly Browsing Large FilesTilt-Shift View

• Instead of measuring absolute Y against absolute
  X, make X relative

• Advance through the file going down, look back a
  number of bytes going right


68
Complain All You Want.Hex Still Sucks.
69
Format Identification

• 1) Do different files appear different, and does
  the appearance reflect the existence of internal
  structure?

• Answer Yes. They do.
• 2) Do different instances of the same file
  format appear similar?

• Answer Somewhat. Similar content looks like
  itself, but youre measuring the fundamental
  entropy of the underlying content, not the format
  of the content itself.
• 3) Does one format embedded in another make
  itself apparent?

• Answer Yes. Multiple, distinct sections are
  clearly visible in a way that hex cannot show.

70
Fuzzer Guidance

• 1) Can we locate the actual byte offsets where
  one section ends and another begins?

• Why would we want to?
• Fuzzers break parsers.
• Many subformats to a format, many subparsers to a
  parser

• To a rough level of approximation, fuzzing a
  single subformat lets you stress a single
  subparser

• So once we split a file up, we can selectively
  attack one subparser at a time.

• 2) Can we visualize and compare fuzzer
  operations via Dotplots?


71
Simple Math
We select an interesting blob from kernel32.dll.
The blob is at pixel offset 507x507, and is a
square around 570 pixels wide.
Window size on viz was 32. 50732 The interesti
ng section starts 16224 bytes into the file.
57032 The interesting section is 18240 bytes
long.
72
Whats The Actual Data?dd ifkernel32.dll bs1
skip16100 hexdump - more
73
Using Hardcorr as a first knife to locate
interesting-to-fuzz regions
74
Fuzzer Guidance

• 1) Can we locate the actual byte offsets where
  one section ends and another begins?

• Answer Yes. We can quickly route from the
  image to the byte offset, through basic
  arithmetic.

• 2) Can we visualize and compare fuzzer
  operations via Dotplots?


75
Differentials

• Major use of dotplots in bioinformatics is to
  compare one genome against another

• Autocorrelation Compare A to A
• Cross-Correlation Compare A to B
• Most files are sufficiently dissimilar that not
  very interesting structure shows up

• Notable exception Different versions of the
  same binary


76
Visual Bindiff!
77
MSVCR70.DLL v. MSVCR71.DLL
78
FuzzersVery Broken Patchers ?
Mangle.C Single Bit Differences
CFG9000 Large Scale Reordering
79
Fuzzer Guidance

• 1) Can we locate the actual byte offsets where
  one section ends and another begins?

• Answer Yes. We can quickly route from the
  image to the byte offset, through basic
  arithmetic.

• 2) Can we visualize and compare fuzzer
  operations via Dotplots?

• Answer Yes visual diffing effectively shows
  differences between files, including differences
  introduced by various flavors of fuzzers.


80
Conclusions

• Lots of interesting work left to do
• Unification of local presence of symbols, and
  global view of file format

• Possible to do dotplots themselves in the
  symbolic domain

• Use of dotplots to segment formats, which thus
  provides the tree we want for an XML schema

• More colorful pretty pictures!

81
The Ancient TongueTCP/IP

• Cant all be about pretty pictures ?
• A new problem has popped up Network oligopolies
  are threatening to install firewalls that limit
  or eliminate bandwidth on a per-company basis

• Their own media services might be fast, others
  will be slow

• Their own VPN services might be fast, others will
  be slow

• Question Is it possible to detect and locate
  devices violating network neutrality?

82
Whats The Closest Tool We Have?

• Firewalk
• Mike Schiffmans Firewall Analysis Tool
• Packets elicit a ICMP Time Exceeded error if they
  reach a router with TTL0

• TTL decremented by one for each hop, so you start
  low, you can trace the route to a host

• A firewalled packet wont live long enough to
  reach TTL0

• So you can locate the firewall, and divine things
  about its ruleset, based on when your packets
  stop getting ICMP Time Exceeded

83
Limitations of Firewalking

• But Firewalk tells us what, not who is
  blockedand it tells us nothing about who is
  allowed to go fast, and who is made to go slow

• Suddenly, we devolve to a much older question
  Is it possible to find out that a target firewall
  is, or is not, blocking against or accepting
  traffic from an arbitrary IP address?

84
TCP Does Speed Measurement

• TCP speed analysis done blindly
• Endpoints do not negotiate with one another
• Everyone sends their packets, routers route what
  they will. Endpoints need to adjust to what the
  routers are willing to pass.

• Routers communicate with endpoints by dropping
  their packets

• Can we combine this router backchannel w/
  Firewalk?

85
In From The Side

• What causes packets to drop?
• Too many packets
• What are we going to do?
• Send too many packets
• Two channels are set up
• A primary channel, which drops packets at some
  known rate

• A secondary channel, whose purpose it is to
  interfere (or not) with the primary channel

• When the secondary interferes with the primary,
  we get feedback via the primary channel

• The traffic composing the secondary channel can
  come from anywhere, be composed of anything, and
  can be TTLd just like in a normal firewalk.

86
The TTL Channel

• Normally, you dont know which router along a
  path is dropping your packets

• ?
• If you are the source of the drop-inducing
  packets, you can control how far your noise goes
  out thus, you can discover which router is
  hitting its limit / censoring your net
  connection
• ?

87
Scorchmarking

• Why Scorchmarking?
• Routers are burning packetsthose that get
  through might have a scorch mark or two ?

• Basic Model
• Client downloads a file from a site, at some
  given speed negotiated via TCP.

• At the same time, traffic is injected from
  different IP addresses. This should cause
  drops.

• If it doesnt, the network is either penalizing
  the primary channel (easy to drop against) or
  rewarding the secondary channel (resilient to
  drops)

88
Advanced Scorchmarking 0

• Having to depend on a client is lame
• Wouldnt it be nice if we could scan the Internet
  for these servers?

• What fundamental service is a receiving client
  providing?

• It is acknowledging our traffic letting us know
  how much it received, and how many milliseconds
  it took to receive it

• Arent there other ways we could extract the same
  data from hosts?

89
Advanced Scorchmarking 1

• What else will acknowledge receiving traffic from
  us?

• TCP Servers
• Sting, from Stefan Savage, used this to great
  effect

• DNS Servers ?
• Routers.
• Supposedly, routers wont send more than a
  certain number of ICMP Time Exceeded packets per
  second

• In reality, they seem to ICMP Time Exceeded ACK
  however much you throw at them

• Even if they didnt, you could use the difference
  in ICMP Time Exceeded rates between Primary and
  Secondary channel, to determine whether
  interference was showing up.
• Everyones got a NAT so you can query everyone
  for whether certain sorts of traffic are being
  blocked to them

90
Advanced Scorchmarking 2

• So, yes.
• You can scan for violations of Network
  Neutrality

• You can find networks that are blocking or
  passing particular IP ranges

• Its not exactly efficient though
• Neutrality violations are easier to find than the
  standard FW case

• Firewalls are normally between the WAN and the
  LAN (Slow Net - FW - Fast Net)

• Neutrality violators are mid-WAN (Slow Net - Fw
  - Slow Net - Fast Net)

• Easier to overload the slow net after the
  firewall

• Boxes with max TTL rates override this

91
Speed Limits

• Fundamental Problem Have to max out bandwidth
  on the link to trigger the backchannel

• No packets dropping, no data
• Means you have to DoS a link not
  scalable/legal

• Potential Solution Find capped acknowledgers
• The mythical ICMP Time Exceeded rate limit works
  well

• Primary and Secondary channel both eliciting
  ITEs

• When secondary channel gets a packet through, it
  takes up a slot on the primary channels

• ITE is perfect, since you can TTL limit any
  packet

• Depends on the firewall passing the primarys
  ITEs

• Maybe Linux / NATs actually implement rate
  limits?

• Another option What if we have code on the
  client?

92
Windows Media PlayerMore Than Just DRM. Really!

• Bulk Transfer RTP
• Runs over Unicast UDP
• Yes, the same Unicast UDP that penetrates NAT so
  well!

• Flow Control / Quality Monitoring RTCP
• No technical reason RTCP needs to go back to the
  same address that RTP stream is coming from

• So We pretend to provide media streams from all
  sorts of sites, and use WMP to collect traffic
  stats for us ?

• It might work
