Transaction Processing Systems and System Development Life Cycle

1
Transaction Processing Systems andSystem
Development Life Cycle
2
An organization's transaction processing systems
(TPSs) must support the routine, day-to-day
activities that occur in the normal course of
business and help a company add value to its
products and services
3
TPSTransaction Processing Systems

• Process detailed data for fundamental business
  operations
• Provides data for the MIS/DSS/AI/ES systems
• On-line Transaction Processing (OLTP)
  transaction is processed immediately
• Batch Processing transactions are accumulated
  and processed at one time

4
TPS vs. MIS/DSS and AI/ES
5
Transaction Processing Cycle

• Basic data processing activities
• Data Collection capture all necessary data
• Data Editing check for validity of data
• Data Correction prompt for reentry of data
• Data Manipulation perform any necessary
  calculations on data
• Data Storage update database with data

6
SDLC

• Systems Development Life Cycle
• Careers are made and taken away based on the
  outcome of system development.

7
Who are the players in SDLC?

• Business
• Stakeholders employees who should benefit from
  the system
• Users employees using the system
• Business Owners employees playing an active role
  in developing the system

8
Who are the players in SDLC?

• IT
• Manager Ultimately responsible for system.
  Handles
• Funding
• Communication with upper level management
• Resolves major issues
• Can manage several systems at any point in time
• Project Lead Head systems analyst
• Reports to manager
• Manages all day to day activity for system
• Determines schedule (could be determined by
  outside forces)
• Main contact for stakeholders and users

9
Who are the players in SDLC?

• IT (cont)
• Systems Analyst
• Specializes in analyzing business problems and
  designing a system to resolve problems.
• Programmer
• Builds and modifies programs based on direction
  of systems analyst and project lead.

10
Traditional SDLC

• Investigation
• Analysis
• Design
• Implementation
• Maintenance and Review

11
SDLC Step 1 Investigation

• What is the problem and is it worth solving?
• Feasibility study may be created by IT
• Short, Inexpensive study
• Objective Define scope of problem, cost vs.
  benefits
• technical, operational, schedule, economic, legal
  feasibility
• End Result Systems Investigation report
• Continue on with project?
• Modify project?
• Drop it?
• Methods IT interviews business employees and
  observes current system and processes

12
SDLC Step 2 Analysis

• Most critical step
• What must the system do to solve the problem?
• Objectives Detailed business/functional
  requirements
• End Results Logical requirements (Data Model,
  Flowcharts, expected volume, etc.)
• Methods Interviews, Data Collection and
  Analysis, Data-flow diagrams
• Everyone must spend the necessary time here,
  planning is everything. All parties should
  review results (IT and Business). NO CHANGES
  SHOULD BE MADE TO THE SPECS AFTER THIS!!!

13
SDLC Step 3 Design

• How will the system solve the problem?
• Objective Develop detailed technical
  specifications for hardware, software, database,
  etc.
• End result
• Make or buy?
• RFP (Request for Proposal)
• Program, interface and response time specs
• Methods IT uses technical knowledge to create
  requirements. Small amount of input from
  business organization. Freeze is placed on
  Design.

14
SDLC Step 4 Implementation

• Objective A system delivered to the business
  users
• End result System works correctly, users are
  trained
• IT will provide status updates to Business
• Any changes made to the system during this phase
  will need more time/money.
• Given time and money, anything is possible

15
Phases of Implementation

• Purchase of Hardware/Software
• Programming
• Testing (Initially by IT and then by Business
  users)
• Training (Done by IT and Business users)
• Conversion from old to new system
• Direct Cutover (manual work may also be done as a
  fail-safe)
• Phased In (most critical components first)
• Pilot (released to one area at a time)
• Parallel (old and new run together for a short
  time)

16
SDLC Step 5 Maintenance/Review

• Objective Fix Bugs, add enhanced functions
• End Result Fully functional system
• User acceptance document
• Need to watch for changing business environment.
  Any enhanced functions should follow through the
  SDLC.

17
Other things to consider

• Prototyping
• Portions of the system are developed
• May not be fully functional
• Feedback from users provides future direction
• Rapid Application Development (RAD)
• Uses tools and techniques designed to speed
  development
• JAD (Joint application development) involves
  heavy interaction of users and analysts.

18
CASE Tools

• CASE Computer-Aided Software Engineering
• Tools that automate tasks in SDLC
• Upper-CASE tools
• Aid in early stages of SDLC (investigation,
  analysis and design)
• Lower-CASE tools
• Aid in later stages of SDLC (development,
  maintenance). Can generate code
• Integrated-Case tools
• Provide links between upper and lower. Can
  generate code based on data from analysis and
  design.
