Clinical correlation of inflammatory skin lesions

1
Clinical correlation of inflammatory skin lesions

• Mary Jo Robinson, D.O.
• UMDNJ-SOM
• Oct.3, 2007

2
5 clinical keys to diagnosis

• Type of lesions-very very important
• Region of body affected- also important
• Distribution of lesions-not that important
• Color-somewhat important
• Configuration/shape-less important
• Summary- pertinent history and complete skin
  examination is best key.

3
8 clinical diagnostic groups

• Pustular-pustule
• Vesicular bullous-vesicles or bullae
• Papular mini-vesicular- vesicles less than 2 mm
• Papulosquamous-scales
• Papulonodular-non red nodule, no scale or crust
• Vascular dominant-red macule, papule or nodule
  w/o epidermal changes
• Pigmentary-brown, black, white or yellow lesions
• Tumor large papules or nodules

4
gt2000 clinical dermatologic diseases

• Many with variety of presentations and tendency
  to change during the chronology of disorder
• Thus one disease can have a myriad of radically
  different presentations, ie. Lupus

5
100 most common dermatologic dzs

• Represent 85 of problems seen by practicing
  dermatologist
• But most do not need bx-acne, rosacea, seborrheic
  dermatitis , psoriasis, tinea corporis.diagnosed
  clinically w/o bx
• But atypical presentations of above and a
  subgroup of patients called GOK tend to get
  biopsies

6
So how does the pathologist correlate these
clinical impressions?

• Given the clinical impression (macroscopic)try to
  subclassify into microscopic appearance
• Such as clinician describes scales, slide shows
  alternating parakeratosis and orthokeratosis PRP
• Clinician describes pustules, slide shows
  collections of neutrophils in stratum corneum
  pustular psoriasis

7
Pustular

• Macroscopic
• Pustular dermatosis - impetigo -
  folliculitis - acne
• - Rosacea
• - candidiasis
• - Pustular psoriasis
• - Sweets

• Microscopic
• Collections of neutrophils, eosinophils or
  lymphocytes in epidermis, follicle, sebaceous
  glands, etc

8
Generalized and intense erythematous rash with
pustules
9
Palmoplantar pustules
10
Macropustule
11
Pustular psoriasis

• Biopsy to exclude fungus, pustular drug,
  impetigo, superficial pemphigus, impetigo
  herpetiformis
• Should culture

12
Histology not specific, CC necessary

• Pustular psoriasis cannot be distinguished on
  histology from - acrodermatitis
  continua(pustular eruption on one of more
  fingers) - Reiters disease(arthritis,
  conjunctivitis, balanitis, pustular
  dermatosis) - impetigo herpetiformis(
  pustular dermatosis of pregnancy assoc w/
  hypocalcemia)

13
Papular minivesicular

• Macroscopic
• Papular minivesicular dermatitis - contact
  dermatitis - atopic dermatitis - scabies -
  dermatophytosis
• - stasis dermatitis
• - Grovers
• - Hailey Hailey
• - Mucha-Habermann - Dermatitis herpetiformis

• Microscopic
• Epidermal spongiosis w/ scale crust

14
Intensely pruritic rash of elbows, knees, back
15
Early
Late
16
Floor of blister
17
DIF granular IgA in dermal papillae
18
D/Dx DH via DIF

• DIF DH- granular IgA
• Linear IgA dermatosis-linear IgA also lack of
  gluten sensitive enteropathy, no association
  w/HLA-B8 DR-3 antigens, less response to dapsone
  tx
• Bullous pemphigoid-linear IgG

19
Dermatitis herpetiformis

• clinically Grovers, atopic dermatitis, scabies
  Pityriasis lichenoides are always part of
  differential.
• Commonly due to intense pruritus of DH, a bx will
  come in as r/o scabies or atopic dermatitis
• Biopsy may often show only erosions or scale
  crusts

20

• Clinician should biopsy nonexcoriated,
  non-vesicular erythematous plaque or papule for
  best diagnosis
• d/dx of neutrophils in papillary dermis includes
  Bullous eruption of LE, mucous membrane
  pemphigoid, flea bites, leukocytoclastic
  vasculitis, linear IgA dermatosis.
• Clinical response to dapsone can be used as
  confirmatory test
• 2/3 pts have asymptomatic celiac like disease on
  jejunal bx endomysial antibodies

21
Vesiculobullous

• Macroscopic
• Burn
• Erythema multiforme
• Pemphigus vulgaris
• Dermatitis herpetiformis
• Herpes simplex
• Bullous pemphigoid
• Contact dermatitis
• Fixed drug eruptions

• Microscopic
• Epidermal or subepidermal vesicle(lt10mm)
• Bullae(gt10 mm)

22
Firm bullae w/ erosions, crusts, papules and
wheals

• groin, axillae, forearms, oral
• Intertriginous to generalized
• Pink to red

23
Histopathology
24
(No Transcript)
25
DIF Salt split skin IgG
DIF linear IgG
26
Type IV collagen present along base of blister
EBA - collagen along roof of blister
27
Bullous pemphigoid

• Histology- epidermal spongiosis
• Rete ridge pattern preserved
• Subepidermal blister
• Early bullae will have many eosinophils

• Clinician should biopsy erythematous skin with
  early bullae
• Perilesional skin should be biopsied for DIF

28
Histologic d/dx

• Spongiotic arthropod assault
• Herpes gestationis
• Porphyria cutanea tarda
• Erythema multiforme
• Dermatitis herpetiformis

• Linear IgA bullous dermatosis
• Epidermolysis bullosa
• Bullous lichen planus
• Bullous drug eruption
• Bullous LE

29
Pruritic vesiculopustular disease of trunk and
proximal extremities
Note the vesicles start clear and then fill with
white creamy pus, then erosions form
30
Histology

• Subcorneal pustules to bullae with neutrophilic
  infiltrate w/ sparse to moderate numbers of
  eosinophils

31
IgA pemphigus

• Presented case is SPD type (subcorneal pustular
  dermatosis)
• Resemble SPD/Sneddon- Wilkinson, pemphigus
  foliaceous

• Second clinical type is IEN type (interepidermal
  neutrophilic bullae)
• Annular erythema with peripheral vesicular
  eruption

32
IEN type
Intraepidermal pustules of neutrophils and some
eosinophils
33
IgA DIF

• Intercellular IgA deposits
• SPD form shows antibodies to desmocollin-1
• Some cases of IEN form antibodies to desmoglein1
• Both have serum antibodies to IgA epithelial cell
  surfaces by IFA
• Differentiates from Pemphigus foliaceus which
  has IgG epithelial cell surface

34
Papulosquamous

• Macroscopic
• Lichen planus
• Psoriasis
• Lupus erythematosus
• Pityriasis rosea
• Seborrheic dermatitis
• Solar keratosis
• Scaly dermatophytosis
• Ichthyosis
• Mycosis fungoides
• Pityriasis rubra pilaris

• Microscopic
• Confluent orthokeratosis, parakeratosis or
  alternating OK/PK sometimes with minimal serum

35
Clinical

• Scaly
• Large scale(flakes) gt 1mm size large scale
  dz (psoriasiform)

• Small scales lt 1 mm size small scale
  dz (pityriasis)
• Shiny compact scales compact scale dz (lichenoid)

36
Histopathology

• Large scale usually psoriasiform may be
  spongiotic, interface vacuolar or interface
• Small scale usually spongiotic, but may be
  interface vacuolar or interface

• Compact scale usually interface but spongiotic
  or interface vacuolar may be seen

37
Plaques with overlying scale and erythematous
borders
38
(No Transcript)
39
IgG, complement band at base of epidermis on IF
40
Lupus erythematosus

• Annular to plaques
• Photosensitive distribution
• Scales
• Atrophy/scarring(late)
• Follicular plugging(late)
• Dermal edema /or mucin deposits
• Telangiectases
• Lichenoid to sup deep pv lymph infiltrate

41
Follicular plugging
42
Polymorphous autoimmune disease

• primary changes at epidermal dermal interface
  including hair follicle
• Vacuolar change
• BM thickening chronic cases PAS
• Compact Orthokeratosis
• Loss of rete ridges late
• Necrotic keratinocytes occasionally

43
Stage of disease affects histology

• Early maculopapular more superficial sparse
  inflammation, lichenoid and may be neutrophilic
• Later smudging subtle to progress to more obvious
  vacuolar
• Then plaque stage shows dermal mucin and adnexal
  inflammation
• Late- scarring, atrophy, melanophages

44
Histologic D/DX

• Seborrheic dermatitis- early forms w/ pyknotic
  neutrophils _at_ follicular ostia, later chronic
  forms more spongiosis
• Actinic keratosis- interface changes due to solar
  damage, check the follicular ostia, no interface
  change there? It is not DLE
• Lichen planus
• PMLE- no atrophy, no foll. plugging, no fibrosis
• Rosacea central face especially, but more
  vascular than LE assoc clinically w/ flushing,
  perifollicular infl, no mucin

45
Flat topped violaceous papules w/ shiny scale
46
Histology
47
(No Transcript)
48
(No Transcript)
49
Lichen planus

• Compact orthokeratosis
• If rubbed, parakeratosis /or hypertrophic
• Acanthosis with jagged sawtoothed rete ridges
• Focal wedge-shaped hypergranulosis that is more
  prominent next to acrosyringium
• Colloid bodies- more prominent in lower epidermis

50
Dermis in LP

• lichenoid lymphohistiocytic infiltrate fills
  papillary dermis, is dense and close to base of
  epidermis
• Coarse collagen bundles
• No mucin, no edema

51
D/Dx of lichenoid lesions

• Lichenoid photodermatitis-sup deep w/
  spongiosis
• Lichenoid solar keratosis-atypical budding w/
  alternating ok/pk
• Lichenoid LE-vacuolar change prominent, dermal
  mucin, may be tough call
• Lichen aureus-pigmented purpuric dermatosis,
  hemosiderin macrophages
• MF- epidermotropism, lamellar fibrosis
• LPLK- usually solitary, peripheral SK/SL

52
Papulonodular

• Macroscopic
• Prurigo nodularis
• Granuloma annulare
• Amyloidosis
• Sarcoid
• Acne
• Follicular cysts
• Arthropod assaults
• Lymphocytoma cutis
• Polyarteritis nodosa

• Microscopic
• Scale crust and spongiosis are ABSENT
• Acanthosis, dermal deposits or inflammation are
  PRESENT

53
Grouped 1-2 mm flesh colored to pink papules in
arcuate distribution on extremities
54
(No Transcript)
55
Clinical d/dx

• Sarcoid
• Lichen planus
• Urticaria pigmentosa
• Papular mucinosis
• Tinea corporis
• Necrobiosis lipoidica
• Rheumatoid nodule
• Foreign body
• Granulomatous rosacea

56
Granuloma annulare Histology
57
(No Transcript)
58
D/Dx palisading granuloma

• Granuloma annulare
• Rheumatoid nodules
• Necrobiosis lipoidica
• Churg-Strauss granulomatosis
• Lupus miliaris disseminatus facei

• Bovine collagen injections
• Actinic granuloma
• Foreign body granuloma
• Infectious granuloma

59
Vascular dominant

• Microscopic
• Proliferations of blood vessels
• Or perivascular inflammatory infiltrate w/ no
  epidermal changes
• Redness, macular or papular erythema
• Wheals
• purpura

• Macroscopic
• Urticarial vasculitis
• Macular papular erythema
• Vasculitis
• Gyrate erythema
• Schambergs
• telangiectasia Hemangiomas
• Kaposis

60
Purpura as a clinical clue

• Purpuric residual erythema persists with
  pressure ecchymosis and petechiae
• Leukocytoclastic vasculitis, septic vasculitis,
  pigmented purpura, dysproteinemic purpura,
  thrombocytopenic purpura

• Non-purpuric complete blanching with
  application of pressure, no extravasated rbcs in
  dermis
• Sunburn, urticaria, macular papular erythema,
  erythema nodosum, fixed drug, gyrate erythemas

61
Bright red to brown red purpuric papules lower
extremities
62
Histology
Endothelial cell swelling, angiocentric
neutrophilic inflammation with nuclear dust,
fibrin in vessel walls, extravasated erythrocytes
63
Henoch-Schoenlein purpura-IgA mediated in
kids(beta strept)
64
Pigmentary

• Microscopic
• Pigment containing macrophages in upper dermis
• decreased or increased number of melanocytes in
  epidermis
• Of dermis with collections of histiocytic foams
  cells in dermis fibrosis

• Macroscopic
• Lichen sclerosus
• Vitiligo
• Lentigo
• Xanthelasma
• Lupus erythematosus
• Morphea
• Tinea versicolor
• Melanocytic nevus
• Basal cell carcinoma, pigmented
• Seborrheic keratosis
• Dermatofibroma

65
White to yellow linear plaques with violaceus to
erythematous halo
66
Histology linear morphea
67
Tumor

• Macroscopic
• Mycosis fungoides
• Kaposi sarcoma
• Melanoma
• Basal cell carcinoma
• Seborrheic keratosis
• Sebaceous hyperplasia
• Etc.

• Microscopic
• neoplastic proliferation of cells
• epidermal
• Dermal
• Melanocytic
• other

68
15 top inflammatory skin lesions submitted to
pathology

• Arthropod assault
• Erythema multiforme
• Fixed drug
• Granuloma annulare
• Jessners/ lymphocytoma cutis
• Lesion
• Lichen planus
• Leukocytoclasitc vasculitis

• Mycosis fungoides/ parapsoriasis
• Polymorphous light eruption
• Psoriasis
• Scleroderma/morphea
• Urticaria
• vasculitis

69
References

• Bolognia, Jorizzo Rapini, Dermatology,
  2003Elsevier, www.dermtext.com
• McKee, et.al. ,Pathology of the Skin with
  Clinical Correlations, 3rd ed. 2005Elsevier.
• Bozzo P Miller RC Clinical Dermatology and
  Dermatopathology A Dynamic Interface series of
  ASCP lectures.
