Web Service Discovery

1
Web Service Discovery

• Swapna Oundhakar
• LSDIS, University of Georgia

2
Outline

• Motivation
• Web Service Discovery
• Why ?
• How ?
• Current Practices
• Problems
• A Solution - Semantics
• Our Approach

3
Motivation

• The Web is evolving from a provider of documents
  images

4
Motivation (Contd.)

• to a provider of services

5
What is a Web Service?

• A programmable application component that is
  accessible via standard Internet protocols
• Web page with functions
• Available for a variety of clients
• Examples stock quotes, traffic conditions,
  calculators, news, weather, et cetera

6
Technical Definition

• Def 1. Web Services as a Software Architecture

• Web services are a new breed of Web
  application. They are self-contained,
  self-describing, modular applications that can be
  published, located, and invoked across the Web.
  Web services perform functions, which can be
  anything from simple requests to complicated
  business processes.
• Once a Web service is deployed, other
  applications (and other Web services) can
  discover and invoke the deployed service.

• IBM web service tutorial

7
State of the Art
8
State of the Art

• The web is organized around URIs, HTML, and HTTP.
• URIs provide defined ids to refer to elements on
  the web,
• HTML provides a standardized way to describe
  document structures (allowing browsers to render
  information for the human reader), and
• HTTP defines a protocol to retrieve information
  from the web.
• Not surprisingly, web services require a similar
  infrastructure around UDDI, WSDL, and SOAP.

WSMF
9
What is Web Service Discovery?

• Service discovery
• Many web services available over the net.
• Problem of web service discovery is to find the
  web service that suits our requirements.
• How can I find a service that meets my
  requirements
• For example,
• I want to buy the CHEAPEST airline ticket from
  Atlanta to New York.
• There are hundreds of services on the web to buy
  airline tickets ?
• How do I find one to give me CHEAPEST tickets

10
Approaches to Discovery (General)

• Focused discovery
• A result of an active search either on a specific
  target, for a specific piece of information, or
  as a combination of both
• Example Directories like yahoo
• Unfocused Discovery
• As a result of receiving unsolicited information,
  or through traversing a potentially open-ended
  space in order to retrieve any available data
  which may be present
• Example Search engines like google

11
Approaches to Discovery (General)

• Direct Communication (Voice)
• Supports some focused and unfocused discovery
  pattern
• Dissemination is direct from the
  source/originator
• No overhead
• Simple aggregate token (Business Card)
• Supports some focused and unfocused discovery
  pattern
• Dissemination is direct from the
  source/originator
• Moderate overhead
• Directory Assistance (Operator)
• Supports a significant number of focused
  discovery patterns and some unfocused one
• Dissemination is via a third-party
• High overhead

12
Approaches to discover a Web Service

• Direct Communication
• User knows what he wants, goes to a known service
  provider and invokes the required service
  directly
• Simple aggregate token (WSIL)
• User searches over the web for a service provider
  or knows one
• Service provider provides a file which lists his
  services like a business card
• User checks it selects one and invokes it
• Directory Assistance (UDDI)
• User knows about a directory or can find one
  through search
• Many different businesses and services are
  registered at a centralized place
• User goes through them and selects one of them

13
How WSIL works

• WSIL Web Service Inspection Language
• With WS-Inspection, I know the host I want to
  work with.
• I go to that host and get a list of services it
  provides, then I choose one.
• Typically I get the file inspection.wsil this is
  the index.html of Web services.

14
WSIL discovery step 1 The client requests
inspection.wsil from the server.
Client
Service Provider
WSIL requestover HTTP?
WSIL file
WSDL file
service
15
WSIL discovery step 2 The client gets
inspection.wsil from the server.
Client
Service Provider
WSIL file over HTTP?
WSIL file
WSDL file
service
16
WSIL discovery step 3 The client requests a
particular WSDL file.
Client
Service Provider
WSIL file
WSDL requestover HTTP?
WSDL file
service
17
WSIL discovery step 4 The provider returns the
WSDL service description.
Client
Service Provider
WSIL file
WSDL file
WSDL file over HTTP?
service
18
WSIL discovery step 5 The client invokes the
service with the WSDL info.
Client
Service Provider
WSIL file
WSDL file
service
SOAP request HTTP?
19
WSIL discovery step 6 The service delivers the
requested data to the client.
Client
Service Provider
WSIL file
WSDL file
service
Service results HTTP?
20
How UDDI works
1. Service Registration SOAP
Web Services
3. Service InvocationSOAP, ebXML, BizTalk,
RosettaNet, COM, EJB/RMI, CORBA, ...
2. Service Discovery SOAP
21
Wide-spread usage
22
How UDDI works
4.
SW companies, standards bodies, and programmers
populate the registry with descriptions of
different types of services
1.
Marketplaces, search engines, and business apps
query the registry to discover services at other
companies
2.
UDDI Business Registry
5.
Service Type Registrations
BusinessRegistrations
Businesses populate the registry
with descriptions of the services they support
Business uses this data to facilitate easier
integration with each other over the Web
23
Public Registry Operation

• Peer nodes (websites)
• Companies registerwith any node
• Registrations replicatedon a daily basis
• Complete set ofregistered recordsavailable at
  all nodes
• Compliance enforced by business contract

Queries
IBM
Ariba
other
other
Microsoft
24
Registry Data
WhitePages

• Businesses register public information about
  themselves
• Standards bodies, Programmers, Businesses
  register information about their Service Types

YellowPages
GreenPages
Service Type Registrations
25
White Pages

• Business Name
• Text Description
• list of multi-language text strings
• Contact info
• names, phone numbers, fax numbers, web sites
• Known Identifiers
• list of identifiers that a business may be known
  by

26
Yellow Pages

• Business categories
• 3 standard taxonomies in V1
• Industry
• Product/Services
• Location Geographical taxonomy
• Searches can be performed to locate businesses
  who service a particular industry or product
  category, or who are located within a specific
  geographic region.

27
Green Pages

• New set of information businesses use to describe
  how to do e-commerce with them
• Nested model
• Business processes
• Descriptive container that is used to group a
  series of related Web services related to either
  a business process or category of services.
• Purchasing services, shipping services, and other
  high-level business processes
• Service descriptions
• Binding template
• Information required to actually invoke a service
• Services can also be categorized

28
Service Type Registration tModel

• Pointer to the namespace where service type is
  described
• What programmers read to understand how to use
  the service
• Identifier for who published the service
• Identifier for the service type registration
• called a tModelKey
• Used as a signature by web sites that implement
  those services

29
tModel

• Each tModel consists of a name, an explanatory
  description, and a Universal Unique Identifier
  (UUID).
• The tModel name identifies the service, such as,
  for example, online order placement.
• The description supplies more information, which
  in this case might be place an order online.
• The unique identifier, called a tModelKey, is a
  series of alphanumeric characters, such as, for
  example, uuid4CD7E4BC-648B-426D-9936-443EAAC8AI.

• Another example the tModel uddi-orghttp has the
  description An http or web browser based web
  service, and the tModelKey uuid68DE9E80-AD09-469D
  -8A37-088422BFBC36.

30
Business Registration

• XML document Created by end-user company (or on
  their behalf)
• Can have multiple service listings
• Can have multiple taxonomy listings

businessEntity
businessKey name URL description contacts business
Services identifierBag categoryBag
businessService
businessService
serviceKey tModelKey Name Description BindingTempl
ates
Key Name Description BindingTemplates
31
Example of a Registration
32
UDDI discovery step 1 The client queries the
UDDI registry for a service.
UDDI query Over SOAP
UDDI registry
Client
WSDL file
Schema file
Service Provider
WSDL file
service
33
UDDI discovery step 2 The UDDI registry sends
the query results back to the client.
UDDI resultsover SOAP
UDDI registry
Client
WSDL file
Schema file
Service Provider
WSDL file
service
34
UDDI discovery step 3 The client uses the UDDI
results to contact the provider.
UDDI registry
Client
WSDL file
Schema file
WSDL requestover HTTP?
Service Provider
WSDL file
service
35
UDDI discovery step 4 The provider returns the
WSDL service description.
UDDI registry
Client
WSDL file
Schema file
Service Provider
WSDL file
WSDL file over HTTP?
service
36
UDDI discovery step 5 The client invokes the
service with the WSDL info.
UDDI registry
Client
WSDL file
Schema file
Service Provider
WSDL file
service
SOAP request HTTP?
37
UDDI discovery step 6 The service delivers the
requested data to the client.
UDDI registry
Client
WSDL file
Schema file
Service Provider
WSDL file
service
Service results HTTP?
38
Basic Web Services Architecture

• The basic architecture includes technologies
  capable of
• Exchanging messages
• Describing Web services
• Publishing and discovering Web service
  descriptions
• The basic Web service architecture models the
  interactions between three roles
• the service provider, service discovery agency,
  and service requestor.

39
Web Service Discovery - Problems

• How can I find a service that meet my
  requirements
• For example,
• I want to buy the CHEAPEST RELIABLE airline
  ticket from Atlanta to New York.
• Someone advertises that its Service can buy the
  CHEAPEST airline ticket for me.
• But how do I know if the airline would be
  RELIABLE enough for me ?
• Can search program understand what do I mean by
  RELIABLE

40
Problems

• All the approaches so far mentioned are not
  semantic.
• They have their limitations.
• UDDI, WSIL
• By itself does not support semantic description
  of services and depends on the functionality of
  the content language
• Web Service Descriptions - WSDL
• Is the content language used but it also does not
  support semantic description of web services

41
Service description with DAML-S

• DAML-S is DAMLOIL based web service ontology
• Supplies web service providers with a core set of
  markup language constructs for describing
  properties capabilities of their web services
• DAML-S can be regarded as semantics-based
  approach for describing Web services
• Service profile (describes what the service does)

• Service model (describe how the service works)
• Service grounding (specifies details on how an
  agent can access a service) Latest Version
• Input/Output parameters of web services are
  associated with some ontological concepts

42
Semantic Service Discovery

• Service discovery based on DAML-S
• Create a service template
• User can specify what inputs he might want to
  give and what outputs he expects
• This service template is then matched with
  service descriptions using some algorithm
• Research work at LSDIS by Jorge Cardoso
• DAML-S approach
• Algorithm uses semantic information provided by
  service description

43
Current Semantic Service Discovery - Problems

• Web service for Buying book
• Inputs
• AuthorName
• BookName
• ISBN
• Output
• Cost of the book
• Operations
• buyBook

• Web service for Bibliography
• Inputs
• AuthorName
• BookName
• ISBN
• Output
• List of the books
• Operations
• getBooksByAuthor
• getBooksByName
• getBooksByISBN

If a user searches for Book Buying service, based
on current approach search will list the
bibliographical service also.
44
A proposed approach

• Match services based on operations and not
  input/output parameters
• Services in turn would be matched based on
  input/outputs

45
References

• Supporting Web services with HR-XML standards -
  Doug Tidwell, IBM Developerworks
• UDDI Technical White Paper
• Web Services and UDDI IBM
• Web Service Modeling Framework Dieter Fensel
  et.al.
• DAML-S Web Service Description for the Semantic
  Web Ankolekar et.al.
• Semantic e-Workflow Composition Cardoso, Sheth
• METEOR-S WSDI Verma et.al.
