Last Smallpox Victim on Earth

1
Last Smallpox Victim on Earth
2
Little Nasty Things
Prions
Protozoa
Viruses
Bacteria
Amebae (dysentary) Plasmodium (malaria)
Mad Cow Disease Variant CJD
3
Little Nasty Things
Prions
Protozoa
Viruses
Bacteria
E. coli B. anthracis (Anthrax) Y. pestis
(Plague)
Influenza Varicella (Chickenpox) Variola
(Smallpox)
Amebae (dysentary) Plasmodium (malaria)
Mad Cow Disease Variant CJD
4
Little Nasty Things
Prions
Protozoa
Viruses
Bacteria
RNA Viruses
DNA Viruses
5
Little Nasty Things
Prions
Protozoa
Viruses
Bacteria
RNA Viruses
DNA Viruses
(ortho)Pox Viruses
Other Pox Viruses
Many Other Viruses

• Variola (smallpox)
• Major Minor
• Vaccinia/Cowpox
• Monkeypox

• Molluscum
• ORF (parapox)
• Milkers nodules
• Tanapox, others

6
An Orthopox Virus

• Variola (smallpox)
• major
• minor
• Vaccinia

7
Variola minor, early 1900s
8
Variola minor, early 1900s
9
Variola minor, early 1900s
10
Epidemiology

• Winter Early spring
• Like measles and chickenpox
• Virus killed by heat and humidity
• Age Distribution
• Historically affected younger children and
  unvaccinated persons
• Outbreak now would match age distribution of
  population since there is little immunity

11
Transmission

• Person ? Person
• Primarily droplet, or aerosol
• No animal reservoir or vector
• Very contagious, but less than measles or
  chickenpox
• Less transmissible (lower 2 attack rates)
• Persons are very sick before contagious

12
18th Century Native American Blankets
13
Time Course of Infection

• Entry through Oropharynx or Lungs
• Virus Multiplies in Lymph Nodes
• Spreads through Bloodstream (1 viremia)
• Multiplies again in Lymph nodes, Spleen, Bone
  Marrow
• Spreads through Bloodstream (2 viremia)
• Prodrome Fever, Headache, Backache, SICK!
• Multiplies in mouth and Dermis (deep layer of
  skin) ? Rash

NOT Infectious (12-14 d )
NOT Infectious (2-4 d)
VERY Infectious
14
Fever Curve of Typical Smallpox Case
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Last case of smallpox in Bengledesh (now
healthy)
20
Early Chickenpox
21
Chickenpox Varicella-Zoster Virus (VZV)
22
Chickenpox Superficial Vesicles
23
Chickenpox
24
Smallpox 1 week into rash
25
Chickenpox
26
ChickenpoxDifferent sizes stages
27
Smallpox
28
Coxsackie A16Virus
29
Smallpox
30
Molluscum Contagiosum
31
Molluscum Contagiosum
32
Man Severely Ill with Smallpox
33

• Smallpox Lesions
• Start on Face, (fore)Arms, Mouth
• Palms and Soles
• Deeply Embedded into Skin
• Similar Stage of Development
• Occur in Very Sick Persons

34
Smallpox Complications

• Hemorrhagic-type Smallpox 1 in 20 cases
• More common in pregnant women
• Flat-type Smallpox 1 in 20 cases
• Encephalitis
• Variola major 1 in 500 cases
• Variola minor 1 in 2000 cases
• Ocular Infection
• Blindness in 1 of cases
• Infection transmitted to child in late pregnancy

35
Case Presentation

• 20 y/o woman with Fever, Misery X 2 days
• Today, rash appeared on face arms
• Temp 103oF Blood Pressure106/78

• Pulse 116/minute Breathing Rate 18/minute
• Mentally sound, Lungs clear
• Scattered macules (spots) and vesicles noted
• Diagnosis Chicken pox (Varicella Zoster virus)
• Treatment oral Acyclovir, recheck in 2 days

36
What if this wasnt Chickenpox?

• Patient had history of chickenpox as a child
• Unusually severe for atypical or second infection
• Need to Diagnose Smallpox ASAP
• Needle in a haystack

37
What if this wasnt Chickenpox?

• Patient had history of chickenpox as a child
• Unusually severe for atypical or second infection
• Need to Diagnose Smallpox ASAP
• Match in a haystack

38
Infection Control Nightmare(Yugoslavia 1972)

• 1 case ? Vaccination of 20,000,000

39
Hospital Infection Control

• Respiratory Isolation Critical
• NOTIFY IMMEDIATELY
• Hospital Infection Control
• Local Health Department

40
CDCs Interim Smallpox Response Plan

• Self-declared Work in Progress

41
Smallpox Response Plan

• Surveillance
• Outbreak Investigation
• Outbreak Containment
• Vaccination
• Quarantine/Isolation
• Public/Media Communication

42
Smallpox Response Plan

• Surveillance
• Outbreak Investigation
• Outbreak Containment
• Vaccination
• Quarantine/Isolation
• Public/Media Communication

43
Smallpox Response Plan

• Surveillance
• Outbreak Investigation
• Outbreak Containment
• Vaccination
• Quarantine/Isolation
• Public/Media Communication

44
Smallpox Response Plan

• Surveillance
• Outbreak Investigation
• Outbreak Containment
• Vaccination
• Isolation/Quarantine
• Public/Media Communication

45
Smallpox Response Plan

• Surveillance
• Outbreak Investigation
• Outbreak Containment
• Vaccination
• Quarantine/Isolation
• Public/Media Communication

46
Surveillance

• Pre-event (baseline) Rash Surveillance
• Notification for suspected smallpox case,
  outbreak, contamination or distribution
• Local Health Department
• State Health Department ? CDC
• Emergency Preparedness and Response Branch
• Bioterrorism Preparedness and Response Program
• Poxvirus Section, Division of Viral and
  Rickettsial Diseases
• Case Definitions and Clinical Appearance

47
Surveillance Case Definition

• Major Criteria
• Fever 102F before rash onset
• Classical smallpox lesions
• Lesions at same stage of development
• Minor Criteria
• Patient is toxic or moribund
• Rash began on forarms, face, or mouth
• Rash includes palms and soles
• Centrifugal distribution (extremities trunk)
• Slow evolution of rash

48
SurveillanceSmallpox Case Categories

• Low Probability
• No Fever
• Fever and no other major and
• Moderate Probability Fever
• 1 other major, or
• 4minor criteria
• High Probability all 3 major criteria

49
Outbreak Investigation

• Active Surveillance for Smallpox
• Local, state, national, international
• Surveillance for Adverse Vaccine Reactions
• Epi Investigation of Cases
• Contact Tracing
• Specimen Collection Transportation
• Laboratory Confirmation (at CDC )
• Detecting Smallpox Directly in Tissues
• Viral Culture
• Molecular Fingerprinting using PCR

50
Outbreak ContainmentVaccination Activities

• CDC vaccine deployment strategy
• Set up vaccination clinics
• Educate a pool of vaccinators
• Recognize vaccine take
• Recognize and treat adverse events
• Safe handling of vaccine
• MASS VS. TARGETED VACCINATION?

51
Outbreak ContainmentRing Vaccination

• Strategy used for smallpox elimination
• Avoids recurring cost of mass vaccination
• Avoids unacceptably high, recurring risk of mass
  vaccination
• Strengthen public health surveillance
  infrastructure for ALL infectious diseases
• Smallpox vaccine prevents only smallpox

52
Isolation of Smallpox Victim in Australia
53
Outbreak ContainmentIsolation Categories

• Isolation Units (smallpox hospitals) contagious
  persons
• Observation Units (for persons with fever but no
  rash after smallpox contact) possibly contagious
  persons awaiting triage
• Home Fever Surveillance with travel restriction
  for exposed or vaccinated persons

54
Outbreak ContainmentLevels of Quarantine

• Education/Notification
• Suspension of Gatherings
• Restriction on Travel
• Blockade (cordon sanitaire) and community-wide
  interventions

55
Communication

• Training for Local/State Health Departments
• Webcasts
• Workshops
• Direct public education
• During an Event
• Contact Information
• Education of General Public
• Media Relations

56
Other Critical Issues

• Infrastructure Development
• Inter-Agency Coordination

57
Final Thoughts

• Smallpox can be recognized early in the course of
  an outbreak, incumbent on
• Provider and public awareness
• Public health surveillance capacity
• Outbreaks probably not avoidable, but could
  (theoretically) be contained
• Prodromal symptoms
• Rash identifiable
• Contagious persons unlikely to travel extensively

58
Final Thoughts II

• Public health agencies will play a critical role
  in incident command (i.e., what do we do now?)
• Important but political
• Uncomfortable decisions
• Unprecedented (not yet available) public health
  surge capacity is crucial to early outbreak
  containment
• Dual-use infrastructure may become important
  method of efficiently using smallpox resources

59
Questions Answers Smallpox plan available
athttp//www.bt.cdc.gov/DocumentsApp/Smallpox/
RPG/index.asp
60
Summary III
Cancer
AIDS
61
Summary IV
Cancer
AIDS
62
Summary V
Bioterrorism
63
Summary VI
Cancer
BT
AIDS
64
Summary VII
Cancer
AIDS
BT
65
Smallpox Vaccination Complications(a live virus
vaccine)

• Disseminated vaccinia
• Eczema vaccinatum

Pre-AIDS!

• Points
• For each 1 million vaccinated, there were 250
  complications
• Vaccine immune globulin (VIG) Rx is needed -
  short supply

66
(No Transcript)
