Databases

1
Databases

• Practical Informatics Course
• APIII 2008

2
What is a database?

• Technically, a database is any collection of
  data, usually in some sort of structure, but this
  definition includes essentially everything, and
  therefore is not very useful
• More practically, a database
• is a non-volatile repository for data with some
  inherent meaning
• is designed, built, and populated for a specific
  purpose
• stores multiple instances of some type of
  information
• stores similar details about each instance of
  the information
• Databases can be as simple as a list of CDs or as
  complex as a medical record

3
A Sample, Simple Database

• Address Book
• Last Name
• First Name
• Street Address
• City
• State
• Zip Code
• Phone Number

Last Name
First Name
Street
City
State
Zip
Phone
4
Database Terminology
Records
The things about which information is stored.
Each record is indepen-dent of each other record.
Last Name
First Name
Sinard
John
Street
310 Cedar Street
City
New Haven
State
Zip
CT
06510
Phone
[phone]
Fields
Values/Data
The informational elements which are stored for
each record.
The actual information which is stored for each
field.
5
Database Conceptualization

• It is convenient to think of simple databases as
  tables (more complex databases as groups of
  tables), and set aside the details of the data
  storage and manipulation
• In practice, these details are generally
  relegated to a Database Management System (more
  later), so it turns out that this abstraction
  process is not only theoretical but also the
  usual practice

Columns (fields, attributes)
Rows (instances, records, tuples)
Element (data, value)
6
Single Table Databases

• Advantages
• Simple to conceptualize
• Many options for implementation, including simply
  a spreadsheet
• Disadvantages
• Only simple databases can be accommodated
• The real world is more complex than a single
  entity with attributes
• Repeating Fields
• Attributes which can occur multiple times for a
  single instance of an entity
• Redundant Fields
• Groups of attributes which have the same values
  over multiple instances of an entity
• Difficult to expand or modify as needs change

7
Shortcomings of Single-Table Databases
Repeating Fields

• Some attributes (fields) may occur multiple times
  for a single instance of an entity
• A person can have more than one phone number
• How many repeats does one leave room for?
• Must allocate space in each row for the maximum
  number of repeats needed for any one row
• Are all repetitions equivalent or does the
  position of the repeat carry some meaning?
• If one repeat is deleted, do the others shift
  down or stay where they are?
• Problem increases when there are multiple fields
  which repeat as a group

8
Shortcomings of Single-Table Databases
Redundant Fields

• Values of groups of fields can repeat over
  multiple instances (rows) of an entity
• e.g, Two people can live at the same address
• Lots of database space can be used storing the
  same data over and over again
• Modification or incorrect entry of the data in
  any one row can lead to inconsistencies in the
  data across rows
• Real changes to the data require the changes to
  be made in multiple rows
• e.g, A family moves to a new address

9
Complex Database Architecture

• A number of different approaches have been
  developed to address the one-to-many problem
• Each approach has its own advantages and
  disadvantages
• The best choice depends on the particular
  application
• Complex Database Architectures
• Hierarchical
• Network
• Relational
• Object Oriented

10
Relational Databases

• All data is stored in tables
• Each table represents an entity and corresponds
  to some real-life concept
• eg. person, address, phone number
• Each entity has attributes (columns) which
  further define that entity
• eg. Person first name, last name, date of birth,
  gender
• Address street, city, state, zip code
• Within a table, each instance (row) is defined
  uniquely by the values of its attributes the
  order of the rows can be changed/swapped/sorted
  without consequence
• Data in different tables is related to each other
  by common data, column elements which are shared
  by two or more tables

11
Relational Database Terminology
Entity (Table, Relation)
Attributes (Columns, Fields)
Specimens
Accession
Date
Patient
Clinical History
Instances (Rows, Tuples)
1-1-97
Smith, John
Upper GI Bleed
Ovarian Tumor
1-1-97
Jones, Mary
1-1-97
Jones, Mary
Ovarian Tumor
1-1-97
Black, Frank
Gunshot Wound
Cardinality ( of Rows)
1-1-97
Simpson, Homer
Radiation Exposure
1-1-97
T
aylor, Tim
Hip Fracture
1-1-97
Skywalker
, Luke
s/p
T
raumatic
Amputation
1-1-97
Janeway
, Katherine
Viral Infection
Degree ( of Columns)
Element
12
Relational Database Terminology
Entities
Patients
Specimens
Parts
- Each Patient may have 0, 1 or many specimens -
Each Specimen must belong to one and only one
patient
- Each Specimen must have at least 1 part, but
may have many parts - Each Part must belong to
one and only one Specimen
Relationships
13
Relational Databases
Primary Key

• The Primary Key for a table is an attribute
  (column, field) or combination of attributes for
  which every instance (row) of the table has a
  unique value
• When a combination of attributes is used, it is
  referred to as a composite key
• Most tables in a relational database will have a
  primary key defined
• In general, the value of the primary key should
  not change once assigned, since it will often be
  pointed to by a foreign key in another table
• Therefore, data which might change (name, phone
  number) makes a bad key
• Selection of an appropriate primary key requires
  an understanding of the data which is stored
  cannot be done by simply looking at the data in
  the database
• Depending upon the entity, it is often necessary
  to create an artificial field such as a
  sequential identifier to serve as the primary
  key
• eg for a person table, one cannot guarantee that
  the last name, first name, or even the
  combination of both will always be unique for
  each person

14
Relational Databases
Foreign Key

• A Foreign Key in a table is an attribute
  (column, field) which defines a relationship
  between two entities (tables)
• The related rows are identified by the value in
  the foreign key column of one table matching the
  value in another column (usually the primary key)
  of another table
• This allows one-to-one, one-to-many, many-to-one,
  and even many-to-many relationships
• In a one-to-many relationship, the table with the
  many rows contains the foreign key and points
  to the primary key in the table with the one
  rows
• The foreign key can be identified as such to
  the database management system within the
  definition of the table, or simply supplied
  on-the-fly during a query

15
Relational Databases
Keys
Primary Key
Foreign Key
One-to-One
Many-to-One
Putting a foreign key in the person table allows
multiple people to be related to a single
address.
Primary Key
Foreign Key
Foreign Key
The Phone_Numbers table has two foreign keys,
allowing phone numbers to be associated with
either a person or an address, or both.
Last name would not work as a primary key because
two people can have the same last name.
Primary Key
Since the phone number is unique, it can serve as
the primary key for this table.
16
Entity-Relationship Diagrams

• A tool for designing relational databases
• Does not contain actual data but rather names of
  the tables (entities) and columns (attributes) as
  well as a symbolic representation of the
  relationships between these
• Many different formats exist

17
Entity-Relationship Diagram
Data View
Entity-Relationship View
18
Entity - Attribute - Value Data Model
Attributes
Entities
Values
19
Entity - Attribute - Value Data Model

• EAV Model Advantages
• When many of the possible attributes remain
  unvalued, takes less space in database
• Each instance of the entity can have different
  attributes stored
• Can accommodate attributes which one did not know
  about at the time the database was created
• EAV Model Disadvantages
• If most of the instances of an entity have values
  for a particular attribute, it is less efficient
  to use the EAV model since one must repeatedly
  store the entity instance identifiers and the
  attribute name
• Data retrieval is less efficient
• The attributes for a given entity instance will
  be scattered in the table
• For aggregate data analysis, first have to find
  the desired attributes

20
Direct Program Access to Databases
Application Program
Application Program
Database
21
Disadvantage of Direct Program Access to Databases

• Any modification to the type of data stored
  (e.g., number of fields) requires a complete
  rebuild of the entire database
• Each application which accesses the data needs to
  know the details of the physical storage of the
  data
• Applications need to be substantially modified if
  the structure of the data stored is altered
• Applications need to manually build and
  maintain any desired indices

22
Database Management System
Application Program
Application Program
Program Routine
Program Routine
Program Routine
Program Routine
Database Management System (DBMS)
Database
23
Database Management Systems
DBMS

• A DBMS is a type of middle-ware which sits
  between the applications and the database
• All access to the database must go through the
  DBMS
• Only the DBMS needs to know the details of the
  physical storage of the data
• Application routines can treat the database in an
  abstract fashion, funneling all requests for
  data through the DBMS using a database language
• If a common language is used by different DBMSs,
  a completely different database system can be
  substituted without requiring any modifications
  to the application routines

24
Client-Server Architecture
Client Computer
Client Computer
Client Computer
Application Program
Application Program
Application Program
Program Routine
Program Routine
Program Routine
Program Routine
Program Routine
Program Routine
DBMS Front End
DBMS Front End
DBMS Front End
Network
DBMS Back End
Database
Database Server
25
Multi-user Access to Large Databases
Most large databases need to be accessible to
multiple users at the same time

• The DBMS is split into two components
• The Front-end or Client resides on each
  users machine
• Program routines submit requests to the DBMS
  front-end
• The DBMS front-end communicates over the network
  with the DBMS back-end

Program
Program
Routine
Routine
Routine
Routine
Routine
Routine
DBMS Front-end
Server
DBMS Back-end

• The Back-end sits on a separate database
  server, communicates with the database, and
  processes the requests of the front-end(s)
• Multi-user access requires a more sophisticated
  DBMS

26
Database Abstraction
Concerns of the DBMS
Concerns of the Database Designer and the
Application

• What type of data is stored in the database?
• How are the fields in the database related to
  each other?
• What data needs to be retrieved?
• What data should be indexed, based upon how the
  data is routinely requested?

• How and where is the data stored on disk?
• How is free space in the database maintained?
• What changes need to be made to an index to
  accommodate a change in the data?
• What is the best way to find the data requested?

Physical Data Model
Conceptual Data Model
27
Functions of a Full Featured DBMS

• Handle all the details of the physical storage of
  the data
• Data Types
• Maintain indices and keys
• Support data addition, updating and deleting
• Support changes in conceptual database design /
  definition
• Client/Server distribution
• Authorization / User Privileges / Security
• Data Integrity
• Referential Integrity
• Data Concurrency
• Data Recovery
• Database Backup
• Transaction Logs
• Data Locking and Deadlocks
• Support for a Query Language

28
Preserving Data Integrity in a Database
Referential Integrity

• Making sure that the rows in a child table
  related to a row in a parent table are not
  orphaned by deletion of the row in the parent
  table

?
29
Preserving Data Integrity in a Database
Referential Integrity

• Declarative Referential Integrity
• Define Foreign Keys as such, indicating what
  table/primary key they reference
• The DBMS will make sure that any row referenced
  by a foreign key in another table is not deleted
  attempts to do so generates an error
• Advantage Developer does not need to do anything
  other than define the relationship (and check for
  errors)
• Disadvantage Deleting a parent requires
  specifically deleting all the child rows first
• Procedural Referential Integrity
• Create Procedures which are executed whenever
  the contents of a table are changed (called
  Triggers can be defined for inserts, updates,
  and/or deletes)
• Advantage Greater flexibility for developer to
  handle references
• Disadvantage Developer has to make sure triggers
  properly address referential integrity issues
• Example A delete trigger on the Address
  table automatically deletes any rows in the
  Person table which points to the row deleted
  from the Address table

30
Database Language

• Applications need a language with which to
  communicate with databases
• The database language must support
• Data definition
• Data retrieval
• Data manipulation
• Data integrity maintenance
• Access control
• Data sharing

31
SQL
(A Language for communicating with relational
databases)

• SQL is not a complete programming language
• Not as structured as C or Pascal
• No IF, GOTO, DO, or FOR statements no variable
  declaration
• Not procedural statements specify what, but
  not how
• Statements resemble English sentences
• Includes the use of optional noise words
• Improves readability but does not alter
  functionality
• Not a stand-alone product
• SQL is a standard which is incorporated, to
  varying degrees, into commercially available
  products
• eg DB2, Access, Oracle, Sybase, Informix, dBASE,
  SQL Server

32
Sample SQL Statement
Address add_id Street City State Zip a1 310 Cedar
St. New Haven CT 06510 a2 Disney
World Orlando FL 32300 a3 4 Privet Drive Little
Whinging Surrey a4 Overlook Hotel Sidewinder CO 8
0200
SELECT Person.Last, Person.First, Address.City,
Address.State FROM Person, Address WHERE
Person.add_id Address.add_id AND
Address.State "FL"
33
Features of SQL

• Vendor independence (widespread vendor support)
• Hardware/System independence
• Relational basis
• Dynamic data definition
• Client/Server architecture
• Direct interactive access without having to write
  programs to get at the data
• Program level access

34
Data Mining

• Data Mining is the process of trying to find
  new relationships in data not previously known or
  perhaps even suspected
• Requires lots of data from multiple sources
• Numerous approaches, often based predominantly on
  hit or miss queries
• Uses neural networks, case-based reasoning,
  statistical analyses
• Two approaches for aggregating data from multiple
  systems into a single database
• Data Repository
• Data Federation

35
Users
Users
Laboratory Medicine
Diagnostic Radiology
Diagnostic Radiology
Anatomic Pathology
Anatomic Pathology
Laboratory Medicine
36
Data Repository vs Data Federation

• Data Repository
• Data physically collected in one location
• Structure can be optimized for data mining
• Queries do not affect production/transactional
  environments
• Data Federation
• Data is always up-to-date
• Fewer data ownership / political issues
• Any given data source can withdraw from the
  federation at any time
• Data inconsistencies can occur
• More complex to set up and maintain
