Bridging Different Data Representations

1
Bridging Different Data Representations

• Zachary G. Ives
• University of Pennsylvania
• CIS 550 Database Information Systems
• November 11, 2004

2
A Special Type of Query Conjunctive Queries

• A single Datalog rule with no Ç, , 8 can
  express select, project, and join a conjunctive
  query
• Conjunctive queries are possible to reason about
  statically
• (Note that we can write CQs in other languages,
  e.g., SQL!)
• We know how to minimize conjunctive queries
• An important simplification that cant be done
  for general SQL
• We can test whether one conjunctive querys
  answers always contain another conjunctive
  querys answers (for ANY instance)
• Why might this be useful?

3
Example of Containment

• Suppose we have two queriesq1(S,C) -
  Student(S, N), Takes(S, C), Course(C, X),
  inCIS(C), Course(C, DB Info
  Systems)q2(S,C) - Student(S, N), Takes(S, C),
  Course(C, X)
• Intuitively, q1 must contain the same or fewer
  answers vs. q2
• It has all of the same conditions, except one
  extra conjunction (i.e., its more restricted)
• Theres no union or any other way it can add more
  data
• We can say that q2 contains q1 because this holds
  for any instance of our DB Student, Takes,
  Course

4
Wrapping up Datalog

• Weve seen a new language, Datalog
• Its basically a glorified DRC with a special
  feature, recursion
• Its much cleaner than SQL for reasoning about
• But negation (as in the DRC) poses some
  challenges
• Weve seen that a particular kind of query, the
  conjunctive query, is written naturally in
  Datalog
• Conjunctive queries are possible to reason about
• We can minimize them, or check containment
• Conjunctive queries are very commonly used in our
  next problem, data integration

5
A Problem

• Weve seen that even with normalization and the
  same needs, different people will arrive at
  different schemas
• In fact, most people also have different needs!
• Often people build databases in isolation, then
  want to share their data
• Different systems within an enterprise
• Different information brokers on the Web
• Scientific collaborators
• Researchers who want to publish their data for
  others to use
• This is the goal of data integration tie
  together different sources, controlled by many
  people, under a common schema

6
Building a Data Integration System

• Create a middleware mediator or data
  integration system over the sources
• Can be warehoused (a data warehouse) or virtual
• Presents a uniform query interface and schema
• Abstracts away multitude of sources consults
  them for relevant data
• Unifies different source data formats (and
  possibly schemas)
• Sources are generally autonomous, not designed to
  be integrated
• Sources may be local DBs or remote web
  sources/services
• Sources may require certain input to return
  output (e.g., web forms) binding patterns
  describe these

7
Typical Data Integration Components
Query
Results
Data Integration System / Mediator
Mediated Schema
Source Catalog
Mappings in Catalog
Wrapper
Wrapper
Wrapper
Source Relations
8
Typical Data Integration Architecture
Source Descrs.
Query
Reformulator
Source Catalog
Query over sources
QueryProcessor
Results
Queries bindings
Data in mediated format
Wrapper
Wrapper
Wrapper
9
Challenges of Mapping Schemas

• In a perfect world, it would be easy to match up
  items from one schema with another
• Every table would have a similar table in the
  other schema
• Every attribute would have an identical attribute
  in the other schema
• Every value would clearly map to a value in the
  other schema
• Real world as with human languages, things
  dont map clearly!
• May have different numbers of tables different
  decompositions
• Metadata in one relation may be data in another
• Values may not exactly correspond
• It may be unclear whether a value is the same

10
A Few Simple Examples

• Movie(Title, Year, Director, Editor, Star1,
  Star2)
• Movie(Title, Year, Director, Editor, Star1,
  Star2)

• PieceOfArt(ID, Artist, Subject, Title, TypeOfArt)
• MotionPicture(ID, Title, Year)Participant(ID,
  Name, Role)

CustID CustName
1234 Ives, Z.
PennID EmpName
46732 Zachary Ives
11
How Do We Relate Schemas?

• General approach is to use a view to define
  relations in one schema (typically either the
  mediated schema or the source schema), given data
  in the other schema
• This allows us to restructure or recompose
  decompose our data in a new way
• We can also define mappings between values in a
  view
• We use an intermediate table defining
  correspondences a concordance table
• It can be filled in using some type of code, and
  corrected by hand

12
Mapping Our Examples

• Movie(Title, Year, Director, Editor, Star1,
  Star2)
• Movie(Title, Year, Director, Editor, Star1,
  Star2)

• PieceOfArt(ID, Artist, Subject, Title, TypeOfArt)
• MotionPicture(ID, Title, Year)Participant(ID,
  Name, Role)

PieceOfArt(I, A, S, T, Movie) - Movie(T, Y, A,
_, S1, S2), ID T Y, S S1 S2
Movie(T, Y, D, E, S1, S2) - MotionPicture(I, T,
Y), Participant(I, D, Dir), Participant(I, E,
Editor), Participant(I, S1, Star1),
Participant(I, S2, Star2)
T1
CustID CustName
1234 Ives, Z.
PennID EmpName
46732 Zachary Ives
T2
Need a concordance table from CustIDs to PennIDs
13
Two Important Approaches

• TSIMMIS Garcia-Molina97 Stanford
• Focus semistructured data (OEM), OQL-based
  language (Lorel)
• Creates a mediated schema as a view over the
  sources
• Spawned a UCSD project called MIX, which led to a
  company now owned by BEA Systems
• Other important systems of this vein Kleisli/K2
  _at_ Penn
• Information Manifold Levy96 ATT Research
• Focus local-as-view mappings, relational model
• Sources defined as views over mediated schema
• Requires a special
• Spawned Tukwila at Washington, and eventually a
  company as well
• Led to peer-to-peer integration approaches
  (Piazza, etc.)

14
TSIMMIS and Information Manifold

• Focus Web-based queryable sources
• CGI forms, online databases, maybe a few RDBMSs
• Each needs to be mapped into the system not as
  easy as web search but the benefits are
  significant vs. query engines
• A few parenthetical notes
• Part of a slew of works on wrappers, source
  profiling, etc.
• The creation of mappings can be partly automated
  systems such as LSD, Cupid, Clio, do this
• Today most people look at integrating large
  enterprises (thats where the is!) Nimble,
  BEA, IBM

15
TSIMMIS

• The Stanford-IBM Manager of Multiple Information
  Sources or, a Yiddish stew
• An instance of a global-as-view mediation
  system
• One of the first systems to support
  semi-structured data, which predated XML by
  several years

16
Semi-structured Data OEM

• Observation given a particular schema, its
  attributes may be unavailable from certain
  sources inherent irregularity
• Proposal Object Exchange Model, OEM
• OID ltlabel, type, valuegt
• How does it relate to XML?
• What problems does OEM solve, and not solve, in
  a heterogeneous system?

17
OEM Example
Show this XML fragment in OEM ltbookgt
ltauthorgtBernsteinlt/authorgt ltauthorgtNewcomerlt/aut
horgt lttitlegtPrinciples of TPlt/titlegtlt/bookgt ltbo
okgt ltauthorgtChamberlinlt/authorgt lttitlegtDB2
UDBlt/titlegtlt/bookgt
18
Queries in TSIMMIS

• Specified in OQL-style language called Lorel
• OQL was an object-oriented query language
• Lorel is, in many ways, a predecessor to XQuery
• Based on path expressions over OEM structures
• select bookwhere book.title DB2 UDB and
  book.author Chamberlin
• This is basically like XQuery, which well use in
  place of Lorel and the MSL template language.
  Previous query restated
• for b in AllData()/bookwhere b/title/text()
  DB2 UDB and b/author/text()
  Chamberlinreturn b

19
Query Answering in TSIMMIS

• Basically, its view unfolding, i.e., composing a
  query with a view
• The query is the one being asked
• The views are the MSL templates for the wrappers
• Some of the views may actually require
  parameters, e.g., an author name, before theyll
  return answers
• Common for web forms (see Amazon, Google, )
• XQuery functions (XQuerys version of views)
  support parameters as well, so well see these in
  action

20
A Wrapper Definition in MSL

• Wrappers have templates and binding patterns (X)
  in MSL
• B - B ltbook ltauthor Xgtgt // select
  from book where author X //
• This reformats a SQL query over Book(author,
  year, title)
• In XQuery, this might look like
• define function GetBook(x AS xsdstring) as book
  for b in sql(Amazon.DB, select
  from book where author x )return
  ltbookgtb/titleltauthorgtxlt/authorgtlt/bookgt

book
author
title


The union of GetBooks results is unioned with
others to form the view AllData()
21
How to Answer the Query

• Given our query
• for b in AllData()/bookwhere b/title/text()
  DB2 UDB and b/author/text()
  Chamberlinreturn b
• Find all wrapper definitions that
• Contain output enough structure to match the
  conditions of the query
• Or have already tested the conditions for us!

22
Query Composition with Views

• We find all views that define book with author
  and title, and we compose the query with each
• define function GetBook(x AS xsdstring) as book
  for b in sql(Amazon.DB, select
  from book where author x )return
  ltbookgt b/title ltauthorgtxlt/authorgtlt/bookgt
• for b in AllData()/bookwhere b/title/text()
  DB2 UDB and b/author/text()
  Chamberlinreturn b

book
author
title


23
Matching View Output to Our Querys Conditions

• Determine that b/book/author/text() ?? x by
  matching the pattern on the functions output
• define function GetBook(x AS xsdstring) as book
  for b in sql(Amazon.DB, select
  from book where author x )return
  ltbookgt b/title ltauthorgtxlt/author
  gtlt/bookgt
• let x Chamberlinfor b in
  GetBook(x)/bookwhere b/title/text() DB2
  UDB return b

book
author
title


24
The Final Step Unfolding

• let x Chamberlinfor b in ( for b in
  sql(Amazon.com, select from book where
  author x ) return ltbookgt b/title
  ltauthorgtxlt/authorgtlt/bookgt
• )/bookwhere b/title/text() DB2 UDB
  return b
• How do we simplify further to get to here?
• for b in sql(Amazon.com, select from
  book where authorChamberlin)where
  b/title/text() DB2 UDB return b

25
Virtues of TSIMMIS

• Early adopter of semistructured data, greatly
  predating XML
• Can support data from many different kinds of
  sources
• Obviously, doesnt fully solve heterogeneity
  problem
• Presents a mediated schema that is the union of
  multiple views
• Query answering based on view unfolding
• Easily composed in a hierarchy of mediators

26
Limitations of TSIMMIS Approach

• Some data sources may contain data with certain
  ranges or properties
• Books by Aho, Students at UPenn,
• If we ask a query for students at Columbia, dont
  want to bother querying students at Penn
• How do we express these?
• Mediated schema is basically the union of the
  various MSL templates as they change, so may
  the mediated schema

27
An Alternate ApproachThe Information Manifold
(Levy et al.)

• When you integrate something, you have some
  conceptual model of the integrated domain
• Define that as a basic frame of reference,
  everything else as a view over it
• Local as View
• May have overlapping/incomplete sources
• Define each source as the subset of a query over
  the mediated schema
• We can use selection or join predicates to
  specify that a source contains a range of values
• ComputerBooks() ? Books(Title, , Subj), Subj
  Computers

28
The Local-as-View Model

• The basic model is the following
• Local sources are views over the mediated
  schema
• Sources have the data mediated schema is
  virtual
• Sources may not have all the data from the domain
  open-world assumption
• The system must use the sources (views) to answer
  queries over the mediated schema

29
Answering Queries Using Views

• Assumption conjunctive queries, set semantics
• Suppose we have a mediated schema author(aID,
  isbn, year), book(isbn, title, publisher)
• A conjunctive query might be q(a, t, p) -
  author(a, i, _), book(i, t, p), t DB2 UDB
• Recall intuitions about this class of queries
• Adding a conjunct to a query removes answers from
  the result but never adds any
• Any conjunctive query with at least the same
  constraints conjuncts will give valid answers

30
Query Answering

• Suppose we have the query
• q(a, t, p) - author(a, i, _), book(i, t, p)
• and sources
• s1(a,t) ? author(a, i, _), book(i, t, p), t
  123
• s5(a,i) ? author(a, i, _)
• s6(i,p) ? book(i, t, p)
• We want to compose the query with the source
  mappings but theyre in the wrong direction!

31
Inverse Rules

• We can take every mapping and invert it, though
  sometimes we may have insufficient information
• If
• s5(a,i) ? author(a, i, _)
• then we can also infer that
• author(a, i, ???) ? s5(a,i)
• But how to handle the absence of the 3rd
  (publisher) attribute?
• We know that there must be AT LEAST one instance
  of ??? in author for each (a,i) pair
• So we might simply insert a NULL and define that
  NULL means unknown (as opposed to missing)

32
But NULLs Lose Information

• Suppose we take these rules and ask for
• q(a,t) - author(a, i, _), book(i, t, p)
• If we look at the rule
• s1(a,t) ? author(a, i, _), book(i, t, p), t
  123
• Clearly q(a,t) ? s1(a,t)
• But if apply our inversion procedure, we get
• author(a, NULL, NULL) ? s1(a,t)
• book(NULL, t, p) ? s1(a,t), t 123
• and theres no way to kow to join author and book
  on NULL!
• We need a special NULL for each a-t combo so we
  can figure out which as and ts go together

33
The Solution Skolem Functions

• Skolem functions
• Conceptual perfect hash functions
• Each function returns a unique, deterministic
  value for each combination of input values
• Every function returns a non-overlapping set of
  values (Skolem function F will never return a
  value that matches any of Skolem function Gs
  values)
• Skolem functions wont ever be part of the answer
  set or the computation it doesnt produce real
  values
• Theyre just a way of logically generating
  special NULLs

34
Revisiting Our Example

• Query
• q(a,t) - author(a, i, _), book(i, t, p)
• Mapping rule
• s1(a,t) ? author(a, i, _), book(i, t, p), t
  123
• Inverse rules
• author(a, f(a,t), NULL) ? s1(a,t)
• book(f(a,t), t, p) ? s1(a,t), t 123
• Expand the query as follows
• q(a,t) - author(a, i, NULL), book(i, t, p), i
  f(a,t)
• q(a,t) - s1(a,t), s1(a,t), t 123, i f(a,t)

35
Query Answering Using Inverse Rules

• Invert all rules using the procedures described
• Take the query and the possible rule expansions
  and execute them in a Datalog interpreter
• In the previous query, we expand with all
  combinations of expansions of book and of author
  every possible way of combining and
  cross-correlating info from different sources
• Then we throw away all unsatisfiable rewritings
  (some expansions will be logically inconsistent)
• More efficient, but equivalent, algorithms now
  exist
• Bucket algorithm Levy et al.
• MiniCon Pottinger Halevy
• Also related chase and backchase Popa,
  Tannen, Deutsch

36
Summary of Data Integration

• Local-as-view integration has replaced
  global-as-view as the standard
• More robust way of defining mediated schemas and
  sources
• Mediated schema is clearly defined, less likely
  to change
• Sources can be more accurately described
• Methods exist for query reformulation, including
  inverse rules
• Integration requires standardization on a single
  schema
• Can be hard to get consensus
• Today we have peer-to-peer data integration,
  e.g., Piazza Halevy et al., Orchestra Ives et
  al., Hyperion Miller et al.
• Some other aspects of integration were addressed
  in related papers
• Overlap between sources coverage of data at
  sources
• Semi-automated creation of mappings and wrappers
• Data integration capabilities in commercial
  products BEAs Liquid Data, IBMs DB2
  Information Integrator, numerous packages from
  middleware companies
