Home Fruit Production

1
Home Fruit Production
? Varieties ? Pruning ? Spraying
Full flavored fruit

• John Strang
• University of Kentucky
• Department of Horticulture

2
Site Selection Considerations

• Elevation slope (2-10)
• Soil Drainage (grey layer mottling)
• Tiling
• Soil Depth
• 2.5 for tree fruit grapes
• Small fruit
• Soil Type (sand vs clay)
• Soil pH
• 6.5 most fruit, 4.5-5.2 blueberries
• Soil Fertility
• Take a soil sample to County Ext. Office
• Water source
• Spray drift
• Children pets

3
(No Transcript)
4
Aspects to Consider in Selecting Fruit Varieties
5
Pests

• Deer
• apples, pears, grapes, blueberries, strawberries
• Birds
• blueberries, grapes, strawberries, raspberries,
  blackberries, Asian pears, apples
• Wild Turkey
• all small fruit
• Raccoons
• Grapes, plums
• Squirrels
• Peaches, plums, Asian pears
• Groundhogs
• apples, pears, plums
• Rabbits
• Girdle tree fruit trunks and eat blueberry wood
• Chipmunks
• strawberries

6
Fruit Season of Availability(Western Kentucky)
(Central Ky. Dates are about a week later)
7
Fruit Crop Bloom Sequence (Frost Injury
Susceptibility)

• Apricots
• Plumcots Apriums
• Japanese plums
• Hardy kiwi
• Sweet cherries
• Tart cherries
• European plums
• Peaches
• Pears
• Apples
• Strawberries Blueberries
• Raspberries
• Blackberries
• Grapes

Earliest
Latest
8
Frost Injury
9
Fruit Pollination Requirements
10
Pollination Charts

• Apples
• Pears
• Plums
• Sweet Cherries

11
Fruit Crops with Reduced Spray Requirements

• Fall Bearing Raspberries
• Blueberries
• Blackberries
• Gooseberries
• Strawberries
• Some Currants

• Pawpaws
• Persimmons
• Tart Cherries

12
Tree Fruit Expected Yields/Plant
13
Small Fruit Expected Yields/Plant
14
Tree Fruit Life Expectancy
15
Small Fruit Life Expectancy
16
Disease Insect Resistance

• Select varieties with disease and insect
  resistance to reduce spray requirements

Apple scab
17
Tree Planting

• Prune tree in the spring, not fall
• Rodent guard
• Gravel to reduce wallowing
• Weed control

• Maxine pear tree 25 years later

18
Apples

• Pome fruit
• Grow and survive well
• Requires considerable expertise and dedication to
  produce good fruit
• Many varieties to select from

19
Apple Rootstocks




G.11
20
Apple Rootstocks
21
Scion Variety Growth Differences
22
Plant SpacingDont Plant Too Close!
Poor soil Fertile soil
Poor soil Fertile soil
23
Apple Growth Types

• Conventional
• Spur type
• Stark Colonnade or Spire

20 yr-old Wellspur R.D./M.7
Wijcik Compact Mac
24
Color Sports or Strains
25
Scab Resistant Varieties
AS apple scab, CR cedar apple rust, FB fire
blight, PM powdery mildew
26
Scab Immune Varieties
Pristine
Redfree
27
Scab Immune Varieties
28
Scab Immune (Insecticide Sprays Only)
29
Scab Immune(No Sprays)
Total yield 6 year-old Liberty
30
PearsEuropean or Asian?

• Primary concerns
• Fire blight
• Pear psylla
• Codling moth

Anjou, Bosc, 20th Century
31
European Varieties(Fire blight resistant)
Magness
Honeysweet Potomac Blakes Pride Seckel -
small sugar pear
Heirloom -Kieffer
32
Asian Varieties

• Fire blight
• Stink bugs
• Birds

Korean Giant
Chojuro Shinko
33
Pear Rootstocks

• Quince A semi dwarf
• fire blight susceptible
• OH X F 333 50-65
• OH X F 87 65
• OH X F 97 full size also for Asian pears
• P. calleryana full size
• P. communis full sized
• Fire blight susceptible
• P. betualefolia full sized, Asian pears
• Increases fruit size on Asian pears

34
Peaches

• Stone fruit
• High sites - flower buds and wood are often
  winter injured
• Well drained sites

Reliance
Very hardy tree Marginal quality fruit
35
Select Hardy Varieties

• Many Varieties
• Biscoe
• Blushing Star
• Contender
• Madison
• Redskin
• Encore
• White Lady (W)

Particularly winter hardy
White Lady (W)
36
Nectarines

• Varieties
• Harko
• Mericrest
• Redgold
• Sunglo

• Peaches w/o fuzz
• Differ from peaches in only one gene
• Much more susceptible to
• Brown rot
• Japanese beetles
• Green June bugs
• Less winter hardy than hardiest peaches

37
Peach Rootstocks

• Dwarfing rootstocks not used on peaches
• Hardy long lived rootstocks
• Lovell seedling
• Halford seedling

38
Genetic Dwarf Peaches
39
Primary Peach Pests

• Insects
• Peach tree borers
• San Jose scale
• Plant bugs
• Plum curculio
• Oriental fruit moth
• Green June bug
• Japanese beetle

• Diseases
• Peach leaf curl
• Brown rot
• Scab
• Bacterial spot
• Powdery mildew

40
Plums

• Stone fruit
• Plant European plums
• Usually on myrobalan or peach rootstocks

European Stanley
Japanese Santa Rosa
41
European Plum Varieties

• Stanley (prune plum)
• Bluebyrd
• Bluefre
• Green Gage

Myrobolan Rootstock
42
Primary Plum Pests

• Scale
• Peach tree borers
• Plum curculio
• European red mite
• Japanese beetle

• Black knot
• Brown rot

43
Tart Cherries

• Stone fruit
• Survive well
• Small trees

44
Tart Cherry Varieties

• New Varieties
• Balaton Sweeter fruit
• Surefire Late blooming

• Rootstock
• Mahaleb

Montmorency
Surefire
Balaton
45
Tart Cherry Pests

• Plum curculio

• Brown rot
• Leaf spot
• Powdery mildew

46
Sweet Cherries

• Stone fruit
• Do not survive well on heavy soils
• Crop loss due to winter and spring freezes
• Fruit crack in rain
• Brown rot
• Birds!

Compact Stella (Older variety)
47
Sweet Cherry Varieties

• Black Gold Late blooming, requires pollinator
• Hedelfingen Late maturing, crack resistant,
  requires pollinator
• Lapins Stella cross, self fertile, crack
  resistant
• Stark Gold Sweet Bird resistant, requires
  pollinator
• Starkrimson Dwarf, self fertile, crack resistant

48
Pawpaws

• Native American fruit, attractive small tree
• Few pests, no sprays
• Purchase grafted varieties
• Harvest when fruit begin to soften

49
Pawpaw Varieties

• NC-1
• Overlease
• Shenandoah
• Sunflower
• Susquehanna

50
American Persimmons(Oriental persimmons not
hardy)

• Native American Fruit
• Varieties
• Early Golden
• Morris Burton
• Yates

Oriental
American
No spraying required
51
Blackberries Raspberries
52
Terminology

• Bramble canes last for two seasons.
• Primocane The first year shoot or cane on a
  bramble (blackberry or raspberry).
• Floricane A flowering and fruiting cane the
  season after it was produced. (Often called
  fruiting cane.)

53
Erect Thorny Blackberry Characteristics

• Trellis not required
• Hardiest varieties winter injured at about -17 F
• First berries to be harvested
• Fruit are sweet
• Seeds are relatively small
• Most growers and pickers do not want to deal with
  the thorns

54
Erect Thornless Blackberry Characteristics

• Trellis ?
• Winter injured at about -10 F
• Second in sequence to be harvested
• Berry sweetness is as good or better than that of
  thorny varieties
• Seeds are larger than those of thorny erect
  varieties.
• Generally have the lowest production of the
  blackberry types

55
Semi-erect Thornless Blackberry Characteristics

• Trellis required
• Winter injured at about -10 F
• Third in the berry harvest sequence
• Fruit are generally tart until very ripe
• Berries and seeds are large
• Most productive varieties.

56
Blackberry Types Cultivars

• Erect Thorny
• Chickasaw
• Kiowa
• Erect Thornless
• Apache
• Ouachita
• Natchez (new) ?

• Semi-erect Thornless
• Triple Crown
• Chester
• Trailing
• Boysen (not hardy)
• Marion (not hardy)
• Primocane Fruiting, Thorny
• Prime-Jim
• Prime-Jan

57
Raspberry Varieties

• June Bearing - Red
• Reveille (heirloom)
• Lauren
• Titan
• Taylor
• June Bearing - Black
• Bristol
• Jewel (most disease resistant)
• June Bearing - Purple
• Royalty

• Fall Bearing - Red
• Jaclyn (new early maturing)
• Autumn Bliss
• Caroline
• Autumn Britten
• Fall Bearing - Yellow
• Anne

58
Autumn Bliss Jaclyn(Fall Bearing)
59
Anne Recommended (Fall Bearing)
Fall Gold
60
Titan replaced by Lauren(June Bearing)
61
Jewel(June Bearing - Black)
62
Royalty(June Bearing)
63
Fall Bearing Red Raspberry
64
Bramble Flowering
65
Thornless Semi-Erect Blackberry Training

• Double T 4 Wire Trellis
• Reduces cane tying
• Lower wires 2 apart and 2.5-3 from ground
• Upper wires 4 apart and 5 from ground

66
Thornless Semi-Erect Blackberry Training
67
Blueberries

• One of the few native American fruit crops
• Increasing in popularity
• Types
• Lowbush
• Highbush
• Rabbiteye
• Southern Highbush Pentaploids
• Huckleberry

68
Recommended Varieties

• Late
• Nelson
• Brigitta
• Darrow
• Elliott
• Aurora ?
• Dwarf Container Grown
• Tophat
• Northblue

• Early
• Duke
• Spartan
• Patriot
• Midseason
• Bluejay
• Ozarkblue
• Sierra
• Bluecrop
• Chandler ?
• Bluegold
• Draper ?
• Toro

69
Purchasing Plants

• Purchase two-year-old bare root or potted plants.
• Purchase from reputable nurseries that practice
  virus testing.
• Blueberry viruses can destroy a planting if they
  are brought in.
• Plant more than one variety to provide for cross
  pollination and group varieties by ripening date
  to make harvest easier.

70
Flower Buds
71
Dont Crop Plants Too Early.
Expect 4 years for first fruit production
72
Recommended Varieties (Varieties are very site
specific)

• Early
• Earliglow
• Evangeline
• Midseason
• Darselect
• Redchief
• Allstar (C. W., Ky.)

• Late
• Jewel
• Ovation

Best tasting
73
Plant Disease Resistance
Ssusceptible, Ttolerant, Rresistant, Uunknown
74
Fruit Quality
75
Everbearing Strawberries(Dayneutral - flower
under long days)

• Three production peaks during summer
• Spring, Mid summer, Fall
• Varieties
• Tristar Small to Med. fruit
• Tribute Med. to large firm fruit
• Seascape (new)

Tristar
Tribute
76
Varieties
77
First Season Flowering

• Bloom removal important in matted row system
• Sacrifice second year yield

78
Renovation

• Mow plants above crowns 4 days later
• If serious foliage disease
• If using sinbar herbicide
• Rotovate to narrow rows twice if needed (row
  width 7- 18 in.).
• Apply N or complete fertilizer
• Apply herbicide and irrigate to activate

79
Insect Disease Control

• Rarely any insect or disease problems first
  season
• Strawberries are minimally sprayed in Ky. Must
  select disease resistant varieties
• Most important sprays are 1-3 fungicide sprays
  during bloom for botrytis fruit rot.
• Observe planting frequently looking for problems

80
Botrytis Fruit Rot Fungus

• Most serious disease problem
• 2-3 weekly fungicide sprays at bloom

81
Slugs

• Poison Bait
• Deadline M-Ps
• Prozap Snail Slug
• Sluggo
• Broadcast before berries form or apply between
  rows after berries form. Best in evening after a
  rain
• Beer traps

82
?
83
Strawberry Sanitation Measures

• Rotation - reduces diseases insects
• Weed control reduces insects mites
• Straw mulch reduces fruit diseases
• Remove overripe and diseased fruit
• Renovate beds after harvest

84
Reasons for Pruning

• Reduce tree size
• Control tree shape
• Make trees structurally strong

85
Reasons for Pruning

• Improve light penetration
• Flower bud initiation
• Fruit color
• Pest control

86
Reasons for Pruning

• Removal of diseased wood
• Fruit rot control

87
Reasons for Pruning

• Partially reduce crop load

• Facilitate cultural operations

88
Reasons for Pruning

• Keep the crop close to the ground

89
When to Prune

• Dormant season
• February bloom
• Prune old trees first
• Young trees last
• Exceptions
• Peaches after bloom

90
Pruning Equipment
91
Types of Cuts
92
Types of Cuts
93
Avoid Leaving Branch Stubs
94
(No Transcript)
95
Pruning
96
Pruning
97
(No Transcript)
98
Remove Narrow Branch Angles
Strong
Weak
99
Branch Spreading
100
Branch Spreading
Too little

• Opens tree up for sunlight and spray penetration
• Reduces shoot and limb vigor
• Encourages flowering

Too much
101
Apple Limb Spreading
102
Apple Pruning
103
Central Leader Tree
104
Pear Pruning Multiple Leader
105
Pear Pruning Multiple Leader
106
Peach Pruning Open Center or Vase
107
Peach Pruning
108
Peach Pruning
55 Chevy?
109
Tart Cherry Pruning
110
Tart Cherry Pruning
111
Tart Cherry Pruning
112
Pruning ?
113
Spraying Home Fruit

• Early sprays are the most important
• Safety protective clothing
• Re-Entry Interval after spraying
• Home orchards exempt from worker protection
  standards
• All pesticides have a 12-96 hour REI for
  commercial growers
• Suggest that you stay out of sprayed areas for at
  least 12 hours and until pesticides are dry
• Immunox excellent for
• Apple scab, rust powdery mildew
• Grape black rot powdery mildew

114
Maintain Excellent Early Insect Control Program

• Dormant oil spray
• Scale, aphids, mites
• Apple
• Rosy apple aphid, tarnished plant bug, plum
  curculio, codling moth (1st generation)
• Peach
• Catfacing bugs, plum curculio, oriental fruit
  moth
• Plum
• Plum curculio

115
Maintain Excellent Early Disease Control Program

• Apple
• Scab, cedar apple rust, fire blight
• Stone fruit
• Peach leaf curl, brown rot, powdery mildew, black
  knot
• Grape
• Anthracnose, black rot, powdery mildew, downy
  mildew, phomopsis cane and leaf spot
• Strawberry
• botrytis

116
Bagging Apples, Pears Grapes

• An early spray schedule is necessary prior to
  bagging.

117




(Immunox)


(Thiophanate-methyl)
118







119
Pesticide Formulations

• Liquid
• Wettable Powder
• Dust

120
Carbaryl (Sevin)

• Works great on grapes for Japanese beetles and
  Green June bugs
• Component of many all purpose spray mixtures
• Flares Mites on Apples, Pears and Peaches
• Apple and Pear Thinning
• Sevin will only thin up to about 30 days after
  full bloom
• It will only thin apples and pears

121
(No Transcript)
122
(No Transcript)
123
(No Transcript)
124
(No Transcript)
125
Home Fruit Spray EquipmentHose end sprayer

• Inexpensive
• Easy to operate
• Not much range

126
Home Fruit Spray Equipment

• Improves spray distance
• Often runs spray on the operator

127
Home Fruit Spray EquipmentHand pump sprayers

• Relatively inexpensive
• Reduces spray drift on operator
• Short range spraying

128
Home Fruit Spray EquipmentBackpack sprayer

• 100 range
• Reduces spray drift on operator
• Improved spray height with spray wand extension

129
Home Fruit Spray Equipment Battery powered

130
Home Fruit Spray EquipmentBackpack mistblower

• Expensive
• Heavy
• Will concentrate spray
• Difficult to calibrate

131
Commercial FruitAir blast sprayer
It is difficult to justify this type of sprayer
for a small planting.
132
Fruit Video Tapes/DVDs

• Fruit Tree Pruning
• Pruning Apple Trees to A Central Leader System
• Training and Pruning Peaches for Maximum Quality
• Blueberry Pruning
• Pruning Grapes
• Bagging Apples for Insect and Disease Control
• Grafting and Budding Pecan, Fruit and Ornamental
  Trees

Available through County Extension Offices No
charge
133
(No Transcript)
