Information Extraction and Integration from Heterogeneous, Distributed, Autonomous Information Sourc

1
Information Extraction and Integration from
Heterogeneous, Distributed, Autonomous
Information Sources A Federated Ontology-
Driven Query-Centric ApproachBy Jaime Castillo,
Adrian Silvescu, Doina Caragea, Jyotishman
Pathak, Vasant Honavar Aritificial
Intelligence Research Laboratory,
Department of Computer Science IOWA State
University, USA

• Presented By
• Ronak Shah
• Graduate Student
• University of Southern California.

2
Presentation Overview

• Introduction
• Data Integration Systems
• Data Integration in INDUS
• Implementation of Indus
• Summary and Discussion

3
Introduction

• Development of High throughput Data Acquisition
• Advances in digital storage, computing and
  Communication technologies
• Opportunity in data-driven knowledge acquisition
  and decision making

4

• Challenges in use of increasing amounts of Data
  from disparate sources

5

• Issue
• Data Repositories are large in size, dynamic and
  physically distributed
• Neither desirable nor feasible to gather all data
  in centralized location for analysis
• Solution
• Algorithm to efficiently extract the relevant
  information from disparate sources on demand

6

• Issue
• Data sources are autonomously owned and operated
• Range of operations and precise mode of allowed
  interactions can be diverse
• Solution
• Strategy for obtaining required information
  within operational constraints

7

• Issue
• Data Sources are heterogenous in structure and
  content
• Each Data source uses its own ontology
• Solution
• Effective Integration of data from different
  sources bridging the semantic and syntactic
  mismatches among the data sources

8

• Issue
• No Single Universal Ontology
• Solution
• Methods for context-dependent dynamic information
  extraction and integration from distributed data
  based on user-specified ontologies for knowledge
  acquisition and decision making

9
Data Integration Systems

• Provide users with seamless and flexible access
  to information from multiple autonomous,
  distributed and heterogenous data sources
• Unified Query Interface
• Allow users to specify what information is needed
  without mentioning how and from where to obtain
  information

10
Data Integration Systems should provide
mechanisms for

• Communication and interaction with each data
  source
• Specification of a query, expressed in terms of
  user specified ontology across disparate sources
• Mapping between user and data source specific
  ontologies
• Transformation of a query into plan
• Integration and presentation of the results in
  the vocabulary known to the user

11
Two Classes of Approach to Data Integration

• Data Warehousing
• Data Federation

12
Data Warehousing

• Data is collected from disparate sources and
  mapped to the common structure and stored in the
  central location
• Need to periodically update the warehouse in
  order to ensure that the data is accurate
• Not possible to analyze same data from different
  perspective
• Each user queries warehouse using common
  vocabulary and a common query interface

13
Data Federation

• Data directly gathered from the data sources
• Results are up-to-date
• Allows user to impose their own ontology on data
  from disparate sources
• Provides two sets of operations
• get()
• transform()
• Operations capable of dealing with syntactic and
  semantic mismatches between global ontology and
  source specific ontology

14
Approaches to deal with semantic mismatches
between global and local ontologies

• Source Centric Approach
• Query Centric Approach

15
Source Centric Approach

• Individual data source determines how the
  concepts in local ontology are mapped to cpncepts
  on global ontology
• User has little control on the true meaning of
  concepts in the global ontology
• User is not responsible for specifying the
  transformation between global concepts and the
  local concepts

16
Query Centric Approach

• Concepts in global ontology are defined in terms
  of concepts in local ontology
• Suited for application which requires users to
  impose their own ontologies to flexibly interpret
  and analyze data from different sources
• User or administrator needs to specify precisely
  how global concepts can be composed from local
  concepts

17
INDUS

• Intelligent Data Understanding System
• Environment for data driven extraction and
  integration from Heterogeneous, distributed and
  autonomous information sources
• Users able to flexibly interpret and analyze the
  data from the various perspective
• Motivated by the requirements of application such
  as scientific discovery
• Provides Federated, Query Centric approach to
  data integration using user specified ontologies

18
Data Integration In INDUS

• 3-Layer Architecture
• Physical Layer
• Ontological Layer
• User Interface Layer

19
Physical Layer

• Allows system to communicate with the information
  sources
• Based on federated database architecture

20
Ontological Layer

• Contains global ontologies specified by the users
  and their mapping to local ontologies
• Transforms queries expressed in terms of global
  ontologies into execution plans

21
User Interface Layer

• Unables user to interact with the system
• Define ontologies
• Post query and receive information
• Hides the complexity from the user

22
Few INDUS related Terminologies

• Concepts
• Ground Concepts
• Compound concepts
• Global Ontology
• Queries

23
Concepts

• Equivalent to mathematical entity for a relation
• Is a Subset of cartesian product of a list of
  domains where each domain is finite
• Stored as an instances in the relational
  databases
• Two types of concepts
• Ground concept
• - Ground concepts are those whose
  instances can be retrieved from one or more
  data sources using a set of predefined operations

• Compound concept
• - The definition of a compound concept X
  specifies the set of operations that must be
  applied over a set of instances of other
  previously defined concepts in order to determine
  the set of instances of X
• - INDUS uses four operations to define new
  compound concepts namely, selection, projection,
  vertical integration and horizontal integration

24
Global Ontology

• Global ontology consists of the set of concepts
  that are used to describe entities and
  relationships in the domain of discourse
• It can be customized to suit the need of the user
  or the group of users
• Queries are expressed in terms of concept
• Can be extended by defining new concepts
• Hides the complexity of accessing and retrieving
  the information from the data sources
• Mapping the semantics of concepts in global and
  user defined ontologies helps the resolve the
  semantic mismatches
• Its resides in the ontological layer

25
Queries

• Query allows to access the instances of the
  respective concept
• Generally specified by selection and projection
• The query is expressed in terms of an expression
  tree before getting answered
• Internal node represents operations and leaf node
  represents ground concept
• Query is executed after the plan (tree) is
  created
• INDUS provides instantiator that are able to
  interact with the data sources and retrieve the
  information from them

26
Implementation of INDUS

• Implementation of the Data Integration component
  of the INDUS
• Five principal modules
• Graphical User Interface
• Common Global Ontological Area
• Instantiator Library
• Query Resolution
• User Wrokspace

27
Implementation of Indus
28
Graphical User Interface

• Allows the user to interact with the INDUS
• Unables the user to describe ontologies,define
  operational definition of ground
  concepts,compound concepts and queries,register
  the iterators and execute queries

29
Common Global Ontology Area

• Manages the repositorywhere definition of
  ontologies,ground concepts,compound
  concepts,queries and iterator signatures are
  stored

30
Instantiator Library

• Contains Sets of function used to interact with
  the individual data sources
• Each instantiator based on iterator
• Iterator interacts direclty with the data sources
• Iterator is implemented as Java Class
• Instantiator suppies parameter to control
  behavior of iterator
• Maps the instances returned by the iterator to
  instances od corresponding ground concept
• Functionality corresponds to that of wrapper

31
Query Resolution Module

• Accepts query expressed in terms of concepts in
  global ontology as input
• Returns the answer to the query constructed from
  the relevant data sources

32
User Workspace

• Manage private workspace where users store
  answers to posted queries
• Partial Results are also stored
• Set of Instances associated with each ground
  concept present in the expression tree are stored
  as populated relational tables

33
Advantages 0f INDUS Design

• Modular design ensures that each module is
  updated and alternative implementation easily
  explored
• Unables INDUS to use different network
  architecture

34
Technologies used to develop INDUS

• JSP for developing Graphical User Interface
• Hosted in an Apache Tomcat 4.0 Web Server
• Relational database for common global ontology
  area
• ODBC and JDBC protocol to share the ontology with
  other applications
• Iterators and the resolution algorithm are
  implemented in Java
• All compoents of Indus are platform Independent

35
Different Roles

• Domain Scientist
• Ontology Engineer
• Administrator
• Developer
• Each user may place multiple role

36
Domain Scientist

• Define ontologies, compund concepts and queries
• Execute queries and manipulate the retrieved data
• Should be familiar with the relevant domain, data
  sources and thir capabilities
• No programming knowledge required

37
Ontology Engineer

• Programming new iterators
• Define ground concepts associated with new ground
  concepts
• Define new modes of interaction with existing
  data sources

38
Administrator

• Install INDUS software
• Set up and manage databases
• Adding new users to the system

39
Developer

• Add new compositional operations to INDUS
• Modify the graphical user interface module and
  query resolution module

40
Summary

• Described the design and implementation of data
  integration component of INDUS
• INDUS implements federated query centric approach
  for data integration
• Information extraction ioperations to be executed
  are dynamically determined on the basis of user
  supplied ontology and query

41
Related Work

• Early work on multi-database systems focused on
  relational and object oriented databases
• Recently, mediators and wrappers have been
  developed to integrate information from disparate
  sources

42
Information Manifold System

• Developed at AT T Bell laboratories
• Heterogenous data integration system offering
  unified interface for retrieving information from
  www and internal sources
• Source centric approach
• Allows definition of only one capability record
  per data source
• Only equality operator is supported

43
TSIMMIS

• Stanford IBM Manager of multiple information
  sources
• Based on concepts of wrappers and mediators
• Uses Object Exchange Model(OEM)
• Query centric approach

44
TAMBIS

• Transparent access to multiple Bioinformatics
  Information System
• Ontology centered system for evaluating query
• Offers access to multiple heterogeneous
  bioinformatics data sources
• Three layer wrapper/mediator architecture
• Uses description logic language GRAIL
• Returns the answer for the query as an HTML file

45
Work in Progress

• Development of the INDUS prototype into platform
  to support exploratory data analysis and
  knowledge acquisition from heteregenous,
  distributed information sources
• Extending the information extraction framework to
  support extraction of sufficient statistics
• Extending recently developed algorithms to work
  with heteregenous, distributed information
  sources
• Performance Improvements using more sophisticated
  query optimization methods
• Exploration of the use of emerging frameworks for
  data and meta data description, ontologies and
  registry services, being developed as part of the
  semantic web project
• Exploration of methods for automatically learning
  mapping between data sources
• Extension of INDUS to support information
  integration in peer to peer environments and
  distributed sendor network

46

• Thank You
