MOLECULAR PATHWAY OF PLURIPOTENCY

1

• MOLECULAR PATHWAY OF PLURIPOTENCY

2
What is pluripotency

• At the blastocyst (day 5 after fertilization)
• An outer layer of cells, the trophectoderm (TE)
• A group of pluripotent cells, the ICM (inner
  cell mass).
• TE will develop into placental tissues
• ICM gives rise to all cells of the embryo proper
  as well as several extraembryonic tissues.
• ICM and embryonic stem (ES) cells, possess the
  remarkable property of PLURIPOTENCY, the ability
  to give rise to all cells of the organism.

3
Key transcription factors in pluripotency

• Key transcription factors such as Oct4, Sox2 or
  Nanog
• affect the cell cycle
• regulate gene expression
• modulate the epigenetic state
• repair DNA damage
• Resulting in
• regulate PLURIPOTENCY.
• functionally induce PLURIPOTENCY
• Besides transcription factors, microRNAs have
  recently been shown to play important roles in
  gene expression

4
Molecular mechanisms and key factors regulating
the specification of ICM and TE lineages

• At the morula stage, cells choose their fate
  depending on their position and polarity.
  Genetic, epigenetic and environmental factors
  play an important role in early cell-fate
• Yap, the co-activator for transcription factor
  Tead4
• (Yap localises in the nucleus and increases
  Tead4 activity)
• Tead4 subsequently activates the trophectoderm
  (TE) master factor Cdx2
• Embryos lacking either Tead4 or Cdx2 fail to
  produce functional trophectodermal tissue but ICM
  cells remain intact and ES cells can be derived
• The counter-activity between Oct4 and Cdx2
  allows the segregation of the first two embryonic
  lineages

5
Oct4 (octamer-binding transcription factor)

• Oocytes, fertilized embryo, embryonic carcinoma
  cells
• The expression of Oct4 was detected in TE as
  well as ICM cells
• Loss of Oct4
• There is inappropriate differentiation of the
  inner cell mass and ES cells.
• So, ES cells cannot be derived of blastocyst
• Overexpression of Oct4
• There is differentiation into primitive endoderm
  and mesoderm
• Oct4 can regulate gene expression by interacting
  with other factors within the nucleus, including
  the high mobility group (HMG)-box transcription
  factor Sox2

6
Nanog

• Morula, ICM, germ cells, embryonic carcinoma
  cells
• Required for the germline formation
• Cells lacking Nanog spontaneously differentiate
  into primitive endoderm
• Overexpression of Nanog promotes self-renewal
  independent of the cytokine leukemia inhibitory
  factor (LIF)
• Human and monkey ES cells seem to maintain the
  pluripotency in LIF/STAT3 independent manner

7
Sox2 (sex determining region Y)-box 2)

• Oocytes, ICM, epiblast,gut endoderm
• Sox2 plays an important role in the
  maintenance of pluripotency and lineage
  specification.
• may be found in early neural stages.
• One of the earliest expressed genes for
  pluripotency.

8
Gata4 and Gata6

• found in extraembryonic endoderm lineages
• work as transcription factors.
• Forced expression of Gata4 or Gata6 in ES cells
  leads to differentiation into primitive endoderm,
  an effect similar to that caused by the loss of
  Nanog function
• Gata4 and Gata6 expression was upregulated in
  the absence of Nanog

9
(No Transcript)
10

• Bone Morphogenetic Proteins (BMP)
• BMP are members of TGF-ß superfamily
• Receptors of the TGF-ß of ligands
• consist of a heteromeric complex of type I and
  type II receptor serine/ threonine kinases.
• Binding of BMP to the receptor induces
  phosphorylation of R-Smads by type I receptors.
• Phosphorylated R-Smads form complexes with
  Co-Smad and accumulate in the nucleus, where
  together they regulate gene transcription.
• In human ES cells, several groups reported that
  BMP4 induces DIFFERENTIATION.
• In mouse ES cells, BMP4 can induce expression of
  id (inhibitor of diffrerantiation) and suppress
  neural differentiation.
• The self-renewal of mouse ES cells is achieved by
  a delicate balance between the two cytokines, LIF
  and BMP.

11

• Leukemia Inhibitory Factor (LIF)
• LIF is a heteromeric complex consisting of gp130
  and the LIF receptor
• Upon LIF binding, JAK(Janus kinase) kinase
  phosphorylates tyrosine residues of both gp130
  and LIFR.
• These phosphorylation recruits signal transducers
  and activators of transcription STAT 1 and STAT3
• The activated STAT (Signal transducer and
  activator of transcription 3) proteins
  translocate into the nucleus, where they function
  as transcription factors
• LIF and its downstream effector STAT3 are
  essential for maintenance of PLURIPOTENCY in
  mouse ES cells.
• Human and monkey ES cells seem to maintain the
  pluripotency in LIF/STAT3 independent manner

12
Wnt/ ß-catenin pathway

• The wingless gene had originally been identified
  as a recessive mutation affecting wing and
  haltere development in Drosophila melanogaster3

• ?eta-catenin is a cytoplasmic protein that
  functions in cell-cell adhesion by linking
  cadherins to the actin cytoskeleton.
• In the absence of Wnt(combination of Wg
  (wingless) and Int) activation, beta-catenin is
  phosphorylated by a complex consisting of APC
  gene, Axin, and glycogen synthase kinase (GSK)
  3b.
• Phosphorylated beta-catenin is degraded by the
  ubiquitin proteasome system, thereby keeping the
  level of cytoplasmic beta-catenin low.
• Neural differentiation of mouse ES cells was
  attenuated by the activation of Wnt signaling by
  overexpression of Wnt1 or treatment with lithium
• chloride, an inhibitor of GSK3b

13
13
14

• Wnt/ ß-catenin pathway may promote SELF-RENEWAL
  (in mouse and human ES cells)
• Wnt binds to its receptor (Frizzled, LRP5 or
  LRP6)
• Activated Dishevelled inactivates the APC/ Axin/
  GSK3b complex.
• Since this complex induces degradation of
  ß-catenin in the absence of Wnt ligand, its
  inactivation results in the stabilization and
  accumulation of ß-catenin protein in the nucleus.

• ?-catenin binds to and activates LEF/TCF
  transcription factors.

15
Phosphatidyl inositol 3 (PI3) kinase

• PI3 kinases are lipid kinases that catalyze the
  phosphorylation of inositol phospholipids
• PI3 kinase pathway is likely to be a crucial
  regulator of ES cell proliferation.
• PI3 kinase pathway may be involved in the
  maintenance of pluripotency in both mouse and
  human ES cells
• PI3 kinase inhibitor, suppressed progression of
  cells from the G1 to S phase and decreased cell
  proliferation
• PTEN is a negative regulator of the PI3 kinase
  pathway. In loss of negative regulations of PTEN
  promotes ES cell proliferation and tumorigenicity


16
Activation of the Ras/ERK pathway and PI3 kinase
pathway by growth factors

• .
• The PI3 kinase pathway can be activated via
  different routes.
• Gab1 can bind to Grb2, resulting in tyrosine
  phosphorylation and activation of the PI3 kinase
  pathway.
• The PI3 kinase-regulatory subunit p85 can bind
  to a phosphorylated tyrosine residue of the
  receptor.
• Activated Ras can induce membrane localization
  and activation of the p110 catalytic subunit of
  PI3 kinase.
• The PI3 kinase pathway is constitutively
  activated by ERas in mouse ES cells.
• The PI3 kinase pathway can promote self-renewal
  of mouse and human ES cells, possibly by
  suppression of the ERK pathway

17
Phosphatidyl inositol 3 (PI3) kinase

• Activation of PI3 kinases is induced by many
  different receptor tyrosine kinases for growth
  factors, such as FGF, EGF, and PDGF, and leads to
  PIP3
• Akt1 is a serine/threonine kinase. Akt1 binds to
  PIP3 and is translocated to the inner cell
  membrane, where it is phosphorylated and
  activated by another serine/threonine kinase PDK1
• Activated Akt1 modulates the function of
  numerous substrates, such as Mdm2, IKK, and mTOR,
  and elicits various cellular responses, including
  proliferation and suppression of cell death.
• (everolimus, sirolimus mTOR inhibitors in
  RCC and AML)

18
Akt signaling pathway
18
19
Activation of the Ras/ERK pathway and PI3 kinase
pathway by growth factors

• Binding of growth factors to their receptors
  induces autophosphorylation of receptors and/or
  phosphorylation of receptor-associated proteins.
• The adaptor protein Grb2 binds to the
  phosphorylated tyrosines through its SH2 domains
  and activates the Ras/ERK pathway through the
  GTP-GDP exchange factor SOS.
• Activation of the Ras/ERK pathway induces
  differentiation in mouse ES cells.

20
(No Transcript)
21
Molecular mechanisms of reprogramming

• Re-establishing pluripotency in a somatic cell
  is a complicated process.
• The most important changes include the
  activation of an ES-cell-specific transcription
  network
• re-setting the epigenetic landscape
• alteration of the cell cycle signature
• overcoming the DNA damage response triggered
  by these drastic changes

22
Induced pluripotency with key factors

• ES cell factors such as Oct4, Sox2, cMyc, and
  Klf4 in fibroblast cells can reprogram them to a
  pluripotent state.
• The most efficient method to make iPS cells is
  through viral transduction.
• Failure of silencing indicates incomplete
  reprogramming and raises the danger of
  carcinogenesis by the oncogene cMyc.
• To avoid insertional mutagenesis and transgene
  reactivation, other methods that do not alter the
  genome have been developed, such as
  non-integrating
• episomal vectors,
• minicircle vectors and
• PiggyBac transposon system

23
Differences between mouse and human ES cell

• The stem cells of teratocarcinoma are embryonal
  carcinoma (EC) cells, which express
  characteristics, similar to those of the inner
  cell mass (ICM)
• There are significant differences between mouse
  and human cells (EC and ES)
• Cell surface antigens of mouse EC and ES cells
• SSEA1()/SSEA3(-)/SSEA4(-)
• Cell surface antigens of Human EC cells
• SSEA1(-)/SSEA3()/SSEA4()
• (these phenotype is similar to that of human
  ES cells and human ICM cells)
• Human EC and ES cells have capacity to generate
  trophoblastic cells.
• This does not usually occur in mouse EC and
  ES cells.

24
24
25
25
26
Similarities and differences between mouse
andhuman ES cell genomic targets

• Heart and neural crest derivatives expressed 1
  (Hand1) and Myst3 genes were identified as
  targets of Oct4 and Nanog in human ES cells,
• whereas others such as Estrogen-related
  receptor b (Esrrb) were observed only in mouse
  cells
• Rif1 has been implicated in regulating telomere
  length and might be important for self-renewal
• Esrrb has been shown to be important for
  placental development and germ cell
  proliferation.
• Tcl1 is highly expressed in mouse ES cells,
  enhances cell proliferation and survival through
  augmentation of phosphoinositide-3 kinase
  PI3KAkt signaling

27
Core transcriptional regulatory circuitry in
pluripotent mouse and human ES cells.
28
Epigenetic control of pluripotency

• What is epigenetic?
• Each of the cells within our body contains the
  same genetic material, yet these cells can look
  and behave very differently
• Each cell contains the same genes but some are
  switched on (expressed) and some are switched off
  (not expressed).
• The specific complement of genes expressed and
  not expressed in a cell determines its
  characteristics and this is controlled by
  epigenetics.
• ES cell chromatin characteristics
• abundance of acetylated histone modifications
• increased accessibility to nucleases
• .

29
Epigenetic characteristics of pluripotent and
lineage committed cells

• ES cells lacking Eed can contribute to most cell
  lineages, suggesting that
• PcG proteins are not necessary for maintaining
  pluripotency
• Eed mutant ES cells spontaneously differentiate
• PcG proteins are necessary for ES cell identity
• Gene expression is influenced by enzymatic
  activities that can induce both global and local
  changes in chromatin structure

30
Epigenetic characteristics of pluripotent and
lineage committed cells.
31
(No Transcript)
32
.

• Thank you
