DIMACS April, 2002 Nonlinear Dynamics, Chaos, and Complexity in Bedside Medicine

1
DIMACS April, 2002Nonlinear Dynamics, Chaos, and
Complexity in Bedside Medicine
Ary L. Goldberger, M.D. Harvard Medical
School NIH/NCRR Research Resource for Complex
Physiologic Signals (PhysioNet)
2
A Time Series Challenge
Heart Rate Dynamics in Health and Disease Which
time series is normal?
Heart Failure
Heart Failure
Normal
Atrial Fibrillation
3
Cardiac Electrical System
4
How is Heart Rate Dynamics Regulated?

• Coupled Feedback Systems Operating Over Wide
  Range of Temporal/Spatial Scales

5
Three Themes

• Healthy systems show complex dynamics, with
  long-range (fractal) correlations and multiscale
  nonlinear interactions.
• Life-threatening pathologies and aging are
  associated with breakdown of fractal scaling and
  loss of nonlinear complexity.
• Open-source databases and software tools are
  needed to catalyze advances in complex signal
  analysis.

6
Hallmarks of Complexity

• Nonstationarity
• Statistics change with time
• Nonlinearity
• Components interact in unexpected ways (
  cross-talk )
• Multiscale Variability
• Fluctuations may have fractal properties

7
Is the Physiologic World Linear or Nonlinear?

• Linear World
• Things add up
• Proportionality of input/output
• High predictability, no surprises
• Nonlinear World
• Whole ? sum of parts (emergent properties)
• Small changes may have huge effects
• Low predictability, anomalous behaviors

8
Whats Wrong with this Type ofSignal
Transduction Picture?
Answer No feedback No nonlinearity Complicated!
but Complex dynamics missing!
9
Danger
Linear Fallacy Widely-held assumption that
biological systems can be largely understood by
dissecting out micro-components and analyzing
them in isolation.
Rube Goldberg physiology
10
Nonlinear/Fractal Mechanisms in Physiology

• Bad news your data are complex!
• Good news there are certain generic mechanisms
  that do not depend on details of system
  (universalities)

11
Wonderful World of Complexity
Sampler of Nonlinear Mechanisms in Physiology

• Abrupt changes
• Bifurcations
• Bursting
• Bistability
• Hysteresis
• Nonlinear oscillations
• Multiscale (fractal) variability
• Deterministic chaos

• Nonlinear waves spirals scrolls solitons
• Stochastic resonance
• Time irreversibility
• Complex networks
• Emergent properties

Ref Goldberger et al. PNAS 2002 99 Suppl. 1
2466-2472.
12
Six Examples ofSpiral Waves in Excitable Media
From J. Walleczek, ed. Self-Organized Biological
Dynamics and Nonlinear Control Cambridge
University Press, 2000.
13
Multiscale Complexity and Fractals
Fractal A tree-like object or process, composed
of sub-units (and sub-sub-units, etc) that
resemble the larger scale structure. This
internal look-alike property is known
as self-similarity or scale-invariance.
14
Fractal Self-OrganizationCoronary Artery Tree
15
Fractal Self-OrganizationHis-Purkinje
Conduction Network
16
Fractal Self-OrganizationPurkinje Cells in
Cerebellum
17
Multiscale Complexity and Fractals
Fractal A tree-like object or process, composed
of sub-units (and sub-sub-units, etc) that
resemble the larger scale structure. This
internal look-alike property is known
as self-similarity or scale-invariance.
18
Loss of Multiscale Fractal Complexitywith Aging
Disease
Lancet 1996 3471312 Nature 1999 399461
19
Fractal Analysis of Nonstationary Time Series
20
Fractal Scaling in Health and Disease
21
Why is it Healthy to be Fractal?

• Healthy function requires capability to cope with
  unpredictable environments
• Fractal systems generate broad repertoire of
  response ? adaptability
• Absence of characteristic time scale helps
  prevent mode-locking (pathologic resonances)

22
Concept ofDE-COMPLEXIFICATION OF DISEASE

• The output of many systems becomes more regular
  and predictable with pathologic perturbations
• Clinical medicine not feasible without such
  stereotypic, predictable behaviors clinicians
  look for characteristic patterns/scales
• Healthy function multi-scale dynamics/scale-free
  behavior harder to characterize

23
Loss of Fractal ComplexityResolves Clinical
Paradox

• Patients with wide range of disorders often
  display strikingly predictable (ordered) dynamics
• Reorder vs. Disorder
• Examples Parkinsonism / Tremors
• Obsessive-compulsive behavior
• Nystagmus
• Cheyne-Stokes breathing
• Obstructive sleep apnea
• Ventricular Tachycardia
• Hyperkalemia ? Sine-wave ECG
• Cyclic neutropenia
• etc., etc.

24
(No Transcript)
25
Warning!
Excessive Regularity is Bad For Your
Health Example Photic (Stroboscopic) Stimulation
and Seizures
26
Whats the Cure?
27
Finding and Using Hidden Information

• Physiologic dynamics exhibit an extraordinary
  range of complexity that defies
• Conventional statistics
• Homeostatic models
• Important information hidden in
• complex signal fluctuations relating to
• Basic signaling mechanisms
• Novel biomarkers

28
The Bad News for Complex Signal Analysis

• Databases are largely unavailable
• or incompletely documented
• Investigators use different, undocumented
  software tools on different databases

29
NCRR Research Resource for Complex Physiologic
Signals - PhysioNet
www.physionet.org Start date September 1,
1999 100,000 visits to date 1 terabyte of data
downloaded!
30
Design of the PhysioNet Resource

• PhysioNet
• Dissemination portal
• Tutorials
• Discussion Groups

31
Design of the PhysioNet Resource

• PhysioBank
• Reference Datasets
• Multi-Parameter (e.g. sleep apnea intensive
  care unit)
• ECG
• Gait
• Other Neurological
• Images
• Data supporting publications
• 30 gigabytes currently online
• 1 terabytes online in 2003

32
Design of the PhysioNet Resource

• PhysioToolkit
• Open source software
• Data analysis packages
• Physiologic models
• Software from publications

33
PhysioNet Signal Analysis Competitions

• Challenge 2001
• Can you forecast an imminent
• cardiac arrhythmia (atrial fibrillation)
• during normal cardiac rhythm?
• Challenge 2002
• Can you simulate/model complex healthy
• heart rate variability?
• Future
• Seizure forecasting Biomedical image
  processing, etc.

34
Conclusions

• Homeostasis revisited
• Physiologic control
• Complex (fractal/nonlinear) dynamics
• Loss of fractal/nonlinear complexity
• New markers of life-threatening pathology/aging
• Needed Open-source data and software for basic
  mechanisms and bedside diagnostics

35
Welcome to PhysioNet!

• www.physionet.org
• Please visit and contribute
