Digital Information Displays

1
Digital Information Displays
Presenter Bob Tamburri TOA Training Manager
2
Introductions

• Welcome Audio Dealers Reps
• Keep it Open
• Ask Questions
• Chat Box
• QA
• 6 to Mute/Un-Mute

3
Digital Information Displays
Digital Signage Is
4
TOA Orion Images A Partnership..

• Orion is a major player in the commercial LCD
  market
• TOA is a major distributor for Orion Security
  monitors
• Orion has successfully sold and marketed digital
  signage solutions for over 6 years
• TOA and Orion have partnered to bring digital
  signage products to the US market
• Orion signage products will be available to AV
  dealers through TOA
• Product support will be provided by TOA

5
Benefits of TOA Digital Signage
6
Total Information Control
Use video displays monitors anywhere you can
imagine to capture and inform your
audience Customers, employees, individuals and
the public at large can now watch live customized
text, graphics, and video content wherever you
position a display
For Effective Information
Web Server NRS Server DB Server FTP Server
Software Hardware Contents Management
Manager
Client
Client
Client
7
One-Stop Shopping
No need for independent sourcing of HW, SW,
contents, administration. TOA is your source.
8
Turnkey Solution
9
More Efficient Digital Signage
Before

• Mail and/or visit for changing content

DVD or Memory
Play
Store
Content Creation

• Content display similar to cable network co

Manager
PDP
Server
PDP
Real Stream Server
PDP
Channel Manager
Limited control of distant clients Big
initial investment Low quality contents
World wide networking via internet Unmanned
station on/off control HD Multi Sync Play
world patent holder
10
Digital Signage Application Local
Network/Internet Network Structure
Central Control Manager
Los Angeles
New York
FTP Server DB Server Web Server
Local Clients
Tokyo
Seoul
Chicago
11
Digital Signage Application Local
Network/Internet Network Structure
Network System
Display Network
Control Room
FTP Server
Manager
Operation via Internet requires a separate server
Network (Internet or Local)
Location 1
Location 2
Location 3
Location N
Location 4
Local Manager
Local Manager
Location 5
Player
Player
Player
Display
Display
Location n
Welcome board
Display
12
Digital Signage Application Hardware System
Network System
Hardware System
Display
Player
Control Room
Local Manager
Player
Manager

• Various dynamic messages, (HD picture movie,
  Flash, Text)
• Display remote control via Manager Serial
  connection
• Coded command for security
• Self PC lock

• Panel Type LCD
• Panel Size 32-82
• Brand LG, Samsung

FTP Server

• Play dynamic messages
• High Definition Display
• Narrow bezel
• Contents provided separately

Only Managers commands-contents with schedule
will be received at each player location
Contents transfer to and are controlled at the
player through the Internet/Intranet
