ISA 562

1
ISA 562Internet Security Theory Practice
Information Security Management CISSP Topic 1
2
Objectives

• Roles of and responsibilities of individuals in a
  security program
• Security planning in an organization
• Security awareness in the organization
• Differences between policies, standards,
  guidelines and procedures as related to security
• Risk Management practices and tools

3
Introduction

• Purpose of information security is to protect an
  organization's valuable resources, such as
  information, hardware and software.
• Should be designed to increase organizational
  success.
• Information systems are often critical assets
  that support the mission of an organization

4
Information Security TRIAD

• The Overhanging goals of information security are
  addressed through the AIC TRIAD.

5
IT Security Requirements - I

• Security Solutions should be designed with two
  main focus areas
• Functional Requirements
• Defines security behavior of the control measures
• Selected based on risk Assessment
• Properties
• They should not depend on another control
• Why?
• They should fail safe by marinating security of
  the system in an event of a failure
• Why?

6
IT Security Requirements -II

• 2. Assurance Requirements
• Provides confidence that security functions is
  performing as expected.
• Examples
• Internal/External Audit.
• Threat Risk Assessments
• Third Party reviews
• Compliance to best practices
• 3. Example for Functional vs. Assurance
• Functional Requirement a network Firewall
  Permits or denies traffic.
• Assurance requirement logs are generated and
  monitored

6
7
Organizational Business Requirements

• Focus on organizational mission
• Business driven
• Depends upon organizational type
• Example Military , government and commercial.
• Must be sensible and cost effective
• Solutions must be developed with due
  consideration of the mission and environment of
  business

8
IT Security Governance

• Integral part of overall corporate governance
• Must be fully integrated into the overall
  risk-based threat analysis, it also
• Ensures that the IT infrastructure of the
  company
• Meets the AIC requirements.
• Supports the strategies and objectives of the
  company.
• Includes service level agreements when
  outsourced.

8
9
Security Governance Major parts

• Leadership
• Security leaders must be fully integrated into
  the company leadership where they can be heard.
• Structure
• it occurs at many different levels of the
  organization and is in a layered approach.
• Processes
• by following internationally accepted best
  practices
• Job rotation , Separation of duties, least
  privilege, mandatory vacations etc.
• Some Examples for standards ISO 17799 ISO
  270012005

10
Security Blueprints

• Provide a structure for organizing requirements
  and solutions.
• they are used to ensure that security is
  considered from a holistic view.
• Used to identify and design security requirements

• Infrastructure Security Blueprints

11
Policy overview

1. Operational environment is a complex web of laws,
   regulations, requirements, competitors and
   partners
2. Change frequently and interact with each other ,
   within this environment
3. Management must develop and publish overall
   security statements addressing
4. Security policies and their supporting elements
   such as standards , baselines and guidelines.

12
Policy overview
12
13
Functions of Security policy - I

1. Provides Managements Goals and objectives in
   writing
2. Documents compliance
3. Creates the security culture
4. Anticipates and protects others from surprises
5. Establishes the security activity/function
6. Holds individuals personally responsible/accountab
   le

13
14
Functions of Security policy-II

• Address foreseeable conflicts
• Ensures employees and contractors are aware of
  organizational policy and changes
• Mandates an incident response plan
• Establishes process for exception handling ,
  rewards, discipline

14
15
Policy Infrastructure

1. High level policies are interpreted into a number
   of functional policies.
2. Functional polices are derived from overarching
   policy of the organizations and
3. create the foundation for the procedures,
   standards, and baselines to accomplish the
   security objectives
4. Functional polices gain their credibility from
   senior managements buy-in.

15
16
Example Functional Policies

• Data classification
• Certification and accreditation
• Access control
• Outsourcing
• Remote access
• Acceptable Internet usage
• Privacy
• Dissemination control
• Sharing control

17
Policy Implementation

• Standards, procedures, baselines, and guidelines
  turn the objectives and goals established by
  management in the overarching and functional
  policies into actionable and enforceable actions
  for the employees.

18
Standards and procedure

• Standards Adoption of common hardware and
  software mechanism and products throughout the
  enterprise.
• Examples Desktop, Anti-Virus, Firewall
• Procedures required step by step actions which
  must be followed to accomplish a task.
• Guidelines recommendations for security product
  implementations, procurement and planning, etc.
• Examples ISO17799, Common Criteria, ITIL

19
Baselines

• Benchmarks used to ensure that a minimum level of
  security configuration is provided across
  multiple implementations and systems.
• They establish consistent implementation of
  security mechanisms.
• Platform unique
• Examples
• VPN Setup,
• IDS Configuration,
• Password rules

19
20
Three Levels of security planning

1. Strategic Planning long term
2. Focuses on the high-level, long-range
   organizational requirements
3. Examples overarching security policy
4. Tactical Level Planning medium-term
5. Focus on events that will affect the entire
   organization.
6. Examples functional plans
7. Operational planning short-term
8. Fighting fires at the keyboard level, this
9. Directly affects the ability of the organization
   to accomplish its objectives.

21
Organizational roles and responsibilities

• Every actor has a role
• Entails responsibility
• must be clearly communicated and
• understood by all actors.
• Duties associated with the role Specific must be
  assigned
• Examples
• Securing email
• Reviewing violation reports
• Attending awareness training

22
Specific Roles and Responsibilities (duties)- 1

• Executive Management
• Publish and endorse security policy
• establishing goals, objectives
• overall responsibility for asset protection.
• Information systems security professionals
• Security design, implementation, management,
• Review of the organization security policies.

22
23
Specific Roles and responsibilities - 2

• Owners
• information classification
• set user access conditions
• decide on business continuality priorities
• Custodians
• Security of the information entrusted to them
• Information System Auditor
• Auditing assurance guarantees.
• Users
• Compliance with procedures (AIC) and policies

24
Personal Security Hiring staff

• Background checks/Security clearances
• Check references/ educational records
• Sign Employment agreement
• Examples
• Non-disclosure agreements
• Non-compete agreements
• Low level Checks
• Consult the Human Resources (H.R.) department
• Termination procedures

25
Third party considerations

• Established procedures to address these groups on
  an individual basis.
• Examples of third party are
• Vendors/Suppliers
• Contractors
• Temporary Employees
• Customers

26
Personnel good practices

• Job description and defended roles and
  responsibilities
• Least privilege/Need to know
• Compliance with need to share
• Separation of duties
• Job rotation
• Mandatory vacations

27
Security Awareness

• Awareness training
• Provides employees with a reminder of their
  security responsibilities.
• Motivate personnel to comply with requirements
• Examples
• Videos
• Newsletters
• Posters
• Key-chains, etc.

27
28
Training and Education

• Job training
• Provides skills needed to perform the security
  functions in their jobs.
• Focus on security-related job skills
• Specifically address security requirements of the
  organization, etc.
• Professional Education
• Provides decision-making, and security management
  skills that are important for the success of an
  organizations security program.

29
Good training practices

• Address the audience
• Management
• Data Owner and custodian
• Operations personnel
• User
• Support personnel

30
Risk from NIST SP 800-30

• Risk is a function of the likelihood of a given
  threat-sources exercising a particular potential
  vulnerability,
• and the resulting impact of that adverse event
  on the organization (SP800-30)

30
31
Definitions Related to Risk

• Threat the Potential for a mal-actor to exercise
  a specific vulnerability.
• Vulnerability A Flaw or weakness in system
  security procedures, design, implementation or
  internal controls that could be exercised and
  could result in a security breach or violation of
  systems security policy.
• Likelihood the probability that a potential
  vulnerability may be exercised within the threat
  environment.
• Countermeasures A risk reduction control
• maybe technical, operational or management
  controls or a combination of these type

32
Risk Management concept flow
33
Risk Management Definitions

• Asset Something that is valued by the
  organization to accomplish its goals and
  objectives
• Threat Any potential danger to information or an
  information systems.
• Examples
• Unauthorized access, Hardware failure, Loss of
  key personnel
• Threat Agent Anything that has the potential of
  causing a threat.
• Exposure An opportunity for a threat to cause
  loss.
• Vulnerability Is a weakness that could be
  exploited.
• Attack An Intentional action trying to cause
  harm.
• Countermeasures and safeguards Are those
  measures and actions that are taken to protect
  systems.
• Risk The probability that some unwanted event
  could occur
• Residual Risk The amount of risk remaining after
  countermeasures and safeguards are applied

34
Risk Management

• The purpose of risk management is to identify
  potential problems
• Before they occur
• So that risk-handling activities may be planned
  and invoked as needed
• Across the life of the product or project

35
The Risk Equation
36
Risk Factors

• The Risk arises when threat-agent attack assets
  and vulnerabilities are present
• Residual Risk happens when threat-agent attack
  assets and countermeasures are in place but are
  not sufficient

37
Risk Management

• Risk Management identifies and reduces total
  risks ( threats, vulnerabilities, asset value)
• Mitigating controls Safeguards Countermeasures
  reduce risk
• Residual Risk should be set to an acceptable level

38
Purpose of risk Analysis

• Identifies and justifies risk mitigation efforts
• Identifies the threats to business processes and
  information systems
• Justifies the implementation of specific
  countermeasures to mitigate risk
• Describes current security posture
• Conducted based on risk to the organization's
  objectives/mission

39
Benefits of Risk Analysis

• Focuses policy and resources
• Identifies areas with specific risk requirements
• Part of good IT Governance
• Supports
• Business continuity process
• Insurance and liability decisions
• Legitimizes security awareness programs

40
Emerging threats factors

• Risk Assessment must also address emerging
  threats
• New technology
• Change in culture of the organization or
  environment
• Unauthorized use of technology, etc.
• Can come from many different areas
• May be discovered by periodic risk assessments

41
Sources to identity threats

• Users
• Systems administrators
• Security officers
• Auditors
• Operations
• Facility records
• Community and government records
• Vendor/security provider alerts
• Other types of threats
• Natural disasters flood, tornado, etc.
• Environment-overcrowding or poor moral
• Facility -physical security or location of
  building

42
Risk analysis key factors

• Obtain senior management support
• Establish the risk assessment team
• Define and approve the purpose and scope of the
  risk assessment team
• Select team members
• State the official authority and responsibility
  of the team
• Have management review findings and
  recommendations
• Risk team members
• Some of the areas which should be included
• Information System Security, IT Operations
  Management, Internal Audit, Physical security, etc

43
Use of automated tools for risk management

• Objectives is to minimize manual effort
• Can be time consuming to setup
• Perform calculations quickly
• Estimate future expected losses
• Determine the benefit of security measures

44
Preliminary security evaluation

• Identify vulnerabilities
• Review existing security measures
• Document findings
• Obtain management review and approval

45
Risk analysis types

• Two types of Risk analysis
• Quantitative Risk analysis
• Qualitative Risk analysis
• Both provide valuable metrics
• Both are often required to get a full picture

46
Quantitative risk analysis

• Assign independently objective numeric monetary
  values
• Fully quantitative if all elements of the risk
  analysis are quantified
• difficult to achieve
• Requires substantial time and personnel resources

47
Determining asset value

• Cost to acquire, develop, and maintain
• Value to owners, custodians, or users
• Liability for protection
• Recognize cost and value in the real world
• Price others are willing to pay
• Value of intellectual property
• Convertibility/negotiability

48
Quantitative analysis steps

• Estimate potential losses
• SLE Single Loss Expectancy
• SLE Asset Value () X Exposure Factor ()
• Exposure Factor of asset loss when threat is
  successful
• Types of loss to consider
• Physical destruction/theft, Loss data, etc
• Conduct threat analysis
• ARO-Annual Rate of Occurrence
• Expected number of exposures/incidents per year
• Likelihood of an unwanted event happening
• Determine Annual Loss Expectancy (ALE)
• Combine potential loss and rate/year
• Magnitude of risk Annual Loss Expectancy
• Purpose of ALE
• Justify security countermeasures
• ALESLE ARO

49
Qualitative Risk analysis

• Scenario oriented
• Does not attempt to assign absolute numeric
  values to risk components
• Purely qualitative risk analysis is possible
• Qualitative risk analysis factors
• Rank seriousness of the threats and sensitivity
  of assets
• Perform a carefully reasoned risk assessment

50
Other risk analysis methods

• Failure modes and effects analysis
• Potential failures of each part or module
• Examine effects of failure at three levels
• Immediate level (part or module)
• Intermediate level (process or package)
• System-wide
• Fault tree analysis
• Sometimes called spanning tree analysis
• Create a tree of all possible threats to, or
  faults of the system
• Branches are general categories such as network
  threats, physical threats, component failures,
  etc.
• Prune branches that do not apply
• Concentrate on remaining threats.

51
Risk mitigation options

• Risk Acceptance
• Risk Reduction
• Risk Transference
• Risk Avoidance

52
The right amount of security

• Cost/Benefit analysis- balance between the cost
  to protect and asset value
• To estimate, need to know
• Asset value
• Threats, Adversary, means , motives, and
  opportunity.
• Vulnerabilities and Resulting risk
• Countermeasures
• Risk tolerance

53
Countermeasures selection principles

• Based on cost/benefit analysis, total cost of
  safeguard
• Selection and acquisition
• Construction and placement
• Environment modification
• Nontrivial operating cost
• Maintenance, testing
• Potential side effects
• Cost must be justified by the potential loss
• Accountability
• At least one person for each safeguard
• Associate directly with performance reviews
• Absence of design secrecy

54
Countermeasures selection principles (Continued)

• Audit capability
• Must be testable
• Include auditors in design and implementation
• Vendor Trustworthiness
• Review past performance
• Independence of control and subject
• Safeguards control/constrain subjects
• Controllers administer the safeguards
• Controllers and subject are from different
  populations
• Universal application
• Impose safeguards uniformly
• Minimize exceptions

55
Countermeasures selection principles (Continued)

• Compartmentalization and defense in depth
• Safeguards role
• Consider to improve security through layers of
  security
• Isolation, economy and least common mechanism
• Isolate from other safeguards
• Simple design is more cost effective and
  reliable, etc
• Acceptance and tolerance by personnel
• Care must be taken to avoid implementing controls
  that pose an unreasonable constrains
• Less intrusive controls are more acceptable
• Minimize human intervention
• Reduces the possibility of errors and
  exceptions by reducing the reliance on
  administrative staff to maintain the control

55
56
Countermeasures selection principles (Continued)

• Sustainability
• Reaction and recovery
• Countermeasures should do the following when
  activated
• Avoids asset destruction and stops further damage
• Prevents disclosure of sensitive information
  through a covert channel
• Maintains confidence in system security
• Captures information related to the attack and
  attacker
• Override and fail-safe defaults
• Residual and reset

57
Basis and origin of ethics

• Religion, law, tradition, culture
• National interest
• Individual rights
• Enlightened self interest
• Common good/interest
• Professional ethics/practices
• Standards of good practice

58
Ethics

• Formal ethical theories
• Teleology Ethics in terms of goals, purposes, or
  ends
• Deontology Ethical behavior is duty
• Common ethical fallacies
• Computers are a game
• Law-abiding citizen, Free information
• Shatterproof
• Candy-from-a-baby
• Hackers
• Difficult to define
• Start with senior management

59
Codes of ethics - examples

• Relevant professional codes of ethics include
• Internet Activities Board (IAB)
• Any activity is unethical unacceptable that
  purposely
• Seeks to gain unauthorized access to the internet
  resources
• Disrupts the intended use of the internet
• Wastes resources through such actions
• Destroys the integrity of computer-based
  information
• Compromises the privacy of users
• Involves negligence in the conduct of
  internet-wide experiments

60
Codes of ethics - examples

• Relevant professional codes of ethics include
• (ISC)2 and other professional codes
• ISC2 Code of ethics preamble
• Protect society, the commonwealth, and the
  infrastructure
• Provide diligent and competent services to
  principals,etc
• Auditors
• Professional codes may have legal importance

60
61
References

• ISC2 CBK Material
• ISC2 official Guide
• CISSP All-in-one
