DoITT Service Offerings

1
DoITT Service Offerings

• Applications, Infrastructure and Capabilities

2

• Agenda
• Data Center Offerings
• Storage Management
• Backup and Data Protection
• Disaster Recovery and Data Replication
• Hosting Environment
• Mainframe Hosting
• UNIX Hosting (UNIX, Linux)
• WINTEL Hosting
• Database Management Oracle, SQL and Mainframe
• Identity and Enterprise Systems Management

3

• DoITT introduction
• Presenters
• Gregory Neuhaus, Assistant Commissioner, Unix
  Shared System Services
• Diane Sciabarra, Director, Database Technologies
• Donovan Hall, Directory Services Engineer
• Diane Witek, Director, CityServ - Enterprise
  Email and Application Hosting Services

4

• DoITT DataCenter Offering
• Datacenter Facilities, Storage Management,
• Disaster Recovery, Data Replication

5

• Data Center OfferingsFacilities Planning and
  Management
• Storage Management
• Enterprise Storage Area network Scalable
  storage Reduced cost over standalone storage
• Disaster Recovery and Data Replication
• Provide DR Infrastructure and data replication
  services. Using DWDM technologies to have a 2GB
  per second data replication channel.
• Backup and Recovery Services
• Protect data for hosted applications
• Facilities Planning and Management
• Network management

6

• Enterprise Storage
• Scalability of storage is critical for the Citys
  future application needs
• The efficiency and intelligence of storage
  management is key to the operation of city
  applications and related services
• The demand for storage capacity continues to grow
• Replication and Backup
• Data replication needs will increase as
  application availability increases
• Disaster recovery continues to increase
  replication and tape backup needs
• Design Considerations
• DoITT Overview Open Systems
• Design Considerations
• Management of Storage
• Storage Resource Management

7

• Replication and Backup
• Disaster recovery continues to increase
  replication and tape backup needs
• What is your timeframe to recover your
  application?
• Replication significantly increase storage and
  network requirements
• Tape Backups
• Do you have the capacity?
• What will be your legal requirements to store
  data?

8
Overview of DoITT Open System Storage
9

• SAN Reliability
• 2 independent fabrics, providing at least two
  independent paths for a particular host to its
  data
• Each fabric utilizes separate Brocade directors
  and separate Hitachi host access ports
• No single point of failure
• SAN subsystems are actively monitored on a
  24x7x365 basis
• Silkworm directors utilize Brocades FabricWatch
  monitoring software
• As a backup system, Sun Management Center modules
  actively monitor each director and each frame

10

• SAN Disaster Recovery
• SAN fabrics span three sites utilizing a DWDM
  ring
• Frame-to-frame replication utilizing Hitachi
  TrueCopy
• SAN-attached Veritas Netbackup environment
• Provides reliable and timely backup of hosts at
  MetroTech datacenter
• Direct to tape backup/restore options for
  SAN-attached hosts
• Multiple Sun servers in a clustered environment
• StorageTek silo utilizing 16 SAN-attached 9940b
  drives and approximately 6000 tape cartridges

11

• SAN Security
• Built to be managed and monitored over IP
  networks
• To minimize the risks, independent IP networks
  utilizing secure, independent switches have been
  configured at each site
• Access via a firewalled bastion host
• Within the Hitachi frames, storage allocation is
  handled via LUN masking
• Any LUN masking configuration changes are subject
  to peer review within DoITTs open systems group
• Within the Brocade directors, storage access is
  handled via hardware-enforced WWN zoning

12

• Application Hosting
• Applications (311, NYC.GOV), Email, GIS

13

• Hosting Services
• System design and capacity planning
• 24x7 Help Desk and Server Support
• System development and deployment - Projects are
  developed from business need to deployment with
  in-house skills
• High availability and disaster recovery planning
  and systems
• Facilities and Network Infrastructure
• Testing and deployment methodologies that allow
  for timely tested deployment of applications

14
UNIX Shared Services Greg Neuhaus gneuhaus_at_doit
t.nyc.gov(718) 403-8633 Ricardo
Browne rbrowne_at_doitt.nyc.gov [phone]
15
DoITT Mainframe Services and Facilities
16

• Mission
• To provide low-cost, efficient, centralized data
  processing infrastructure services for all City
  of New York entities
• DoITT is the custodian of 200 critical systems
  and applications for 40 City agencies
• Hosting service started April 1, 1979

17

• A Few Accomplishments
• Data Center Consolidations
• Dept of Finance 1991
• Dept of Sanitation 1992
• HPD 1995
• Dept of Transportation 1998
• HRA 1998
• Dept of Education 2005

18

• A Few Accomplishments (contd)
• Web Enabled Systems
• BIS -- 2001
• CFB 2005
• DOF -- 2001 ongoing
• Property Search
• Star Exemption
• Tax Rebate System
• Bar Codes for semi-automated Payment

19

• Services Include
• Large centralized mainframe operation
• 24 x 7 x 365 operations support
• Infrastructure support
• Security administration
• File backup/recovery
• Operating systems
• Database administration
• Transaction systems
• Network Services (different forum)
• Data management
• Disaster Recovery
• Offsite backup/recovery
• Hotsite services
• Data replication

20

• New Data Center - Mainframe Servers
• T-REX Technology
• IBM 2084-304 w/48GB
• IBM 2084-303 w/40GB
• Total MIPS 2863

21

• Virtual Tape Environment
• 23 TB cache
• 1,440 TB Tape Capacity
• 512 Virtual Tape Drives
• 24 High Speed/Density Tape drives (STK 9840)
• 120 GB of data on each tape
• FICON Cache Access (100 megabytes/sec)

22

• Drive Systems
• DASD Capacity and Throughput
• 45 TB capacity
• 3 IBM 2105-800 FICON SHARK subsystems
• 100 MB/SEC Data Transfer
• Logical volumes 8.4 and 25.6 GB each
• Synchronous replication to PPRC at 33rd St NYC

23

• Mainframe Security Administration
• RACF security
• Client agency administrators authorize updates
  via WITS system (intranet)

24

• Mainframe Operating Systems
• z/OS Release 1.5 (1.7 - soon)
• Batch job processing
• Transaction systems
• Unix System Services
• Web Services
• Linux
• Virtual servers
• Unix type environment
• Web Services

25

• Linux Environment
• IBM 2084-304
• IBM 2084-303
• 2 Dedicated IFL Engines
• 900 MIPS
• 8 GB Real Memory
• Runs Under VM
• Can define up to 130,000 Virtual Servers
• 8 - 1Gigabit Open system Adapters

26

• Backup/Restore Disk Files
• SMS Managed Files
• Incremental backup daily at file level
• Archive files not recently accessed
• Non-SMS Managed Files
• Backup to tape at volume level
• Five generations of backup
• ADABAS Backup
• Incremental backup daily

27

• Database Systems/Admin
• ADABAS/Natural
• DBA services
• Install/Customize Software AG products
• Support Entire-X for Web access to legacy
  databases
• SQL access to ADABAS
• ADABAS data replication to other environments
• DB2
• Install/Customize DB2 environments
• Provide technical assistance

28

• Transaction Systems
• Install/maintain CICS software
• Customize environment
• Install/maintain related software products
• Compuware
• Computer Associates
• Etc.
• Provide Client support

29

• LASTLY,
• A WORD ABOUT COBOL

30

• Supported Version of COBOL
• IBM currently supports COBOL LE (LANGUAGE
  ENVIRONMENT) for z/OS.
• VS/COBOL is not supported and will cease to
  function in the near future.
• COBOL II modules still run and will continue to
  run for the foreseeable future.
• Any new coding should be in COBOL LE for z/OS
  only.

31

• Status of VS COBOL
• VS COBOL has been unsupported for over two
  decades
• VS COBOL load modules will not function with
  Transaction Server 3.1
• VS COBOL code must be revised and recompiled
  preferably using LE
• There will be a User Meeting to discuss what
  steps DOITT is taking to help with application
  issues

32

• Disaster Recovery
• If DoITT Data Center experiences a prolonged
  outage
• We would restore backup tapes to disk at Hotsite
  in Philadelphia
• Process would take 2 days and data could be up to
  1 week old
• Planned Hotsite in Manhattan
• Data Replication via PPRC
• Data would be current
• Hotsite will be Citynet hub
• Network connectivity already established
• LPARs ready to IPL
• Applications available within 2 hours of disaster

33
Mainframe Walter Shelley wshelley_at_doitt.nyc.gov
[phone] Database (Mainframe) Diane
Sciabarra dsciabarra_at_doitt.nyc.gov [phone]
34
Identity Management(Formally Referred to as
LDAP)
35

• Identity Management
• Identity Management Definition
• Managing the information associated with an
  employee throughout the enterprise
• What is Employee Life Cycle Management?
• The management of identities across
• IT services

Name Employee ID Title Agency Department/Unit Man
ager Email Address Telephone Fax User
Name Password Cell-phone Pager
36

• Identity Management
• Identity Management Goals
• Consistent and up to date identity data
• Simplify access using reduced sign-on
• Improve efficiency of provisioning and
  de-provisioning
• Improve Security
• Identity Management provides a framework of
  services to deliver those goals.

37

• Identity Management
• Password Management
• Password self-service - User ability to manage
  central authentication credentials
• Reduced sign-on by integration of applications
  and web services to support central
  authentication credentials
• User password management (Single Sign-On) -
  Automated sign-on to applications at desktop to
  provide
• Consistent password policy enforcement

38

• Identity Management
• Authentication and Authorization
• Support centralized authentication and
  authorization
• Future support for Web based SSO (City-Wide) and
  Federated Web SSO (External agencies)
• Future support for PKI and other strong
  authentication mechanisms

39

• Directory Services
• Services Supported By The Enterprise Directory

Directory Services
Now Single Sign-On City Directory City-Wide
White Pages VPN Services Remote Access Portal
Future Password Self-Service City Share
Portal Datashare DNAHits COIB City Time City-Wide
Applications Agency Applications
40

• Future Services

Directory Services
Password Self-Service City Share
Portal Datashare DNAHits COIB City Time City-Wide
Applications Agency Applications
41

• Identity Management Contacts
• Rakesh Patel
• Manager Enterprise Directory Services, IT
  Security
• rapatel_at_doitt.nyc.gov
• 718-403-8620
• Daniel Srebnick
• Assistant Commissioner, IT Security
• dsrebnick_at_doitt.nyc.gov
• 718-403-8610
• Directory Services Contact
• Donovan Hall
• Directory Services Engineer
• dhall_at_doitt.nyc.gov
• 718-403-8065

42

• Server and Desktop Services
• Wintel Services
• Hosting and Managed Services

43

• Mission
• To Provide highly available and scalable systems
  to service agencies based on the Wintel platform
• Leverage existing and future technologies
• Increased cost efficiencies with centralized
  management and architecture
• Follow best practice processes and strategies
  e.g. Microsoft Information Technology
  Infrastructure Library

44

• Overview of DoITT Wintel Hosting Systems

• Windows 2003 Servers
• Manage, maintain and support over 200 Windows
  based hosts
• Manage Wintel hosts across 3 different City
  datacenters

• Application and Database
• Manage, maintain, and support over 50 different
  SQL 2000 and Oracle database instances
• Ability to host and support enterprise web
  applications and web services

DoITT Wintel Services

• Server Hosting
• SharePoint Portal Server
• Exchange 2003
• Internet Security and Acceleration (proxy) server
• ePolicy Enterprise Virus control server
• Host Integration Server
• Internet Information Server (IIS 6.0)
• AD Hosting

Operations

• Provide 365 days x 24 hours x 7 days onsite
  support
• Support disaster recovery environments to ensure
  business continuity

45

• SDS Strategies
• Consolidated infrastructure and support
• R D of both new technologies and methodologies
  to ensure highest level service for all
  technology initiatives
• Strong Project Management across all SDS
  programs
• Leveraging use of current resources
• Includes both DoITT resources and agency Resources

46

• Current Cost Benefits
• No license fees for Microsoft Server based
  Technologies
• Microsoft Exchange Server Licenses
• Microsoft SQL Server Licenses
• Microsoft Host Integration Server Licenses (SNA
  connectivity)
• Lower Blackberry licensing fees Blackberry Web
  browsing
• No-cost storage, back-up and restoration services
• Reduced administrative overhead
• Increased staff productivity
• Platform upgrade without hardware cost
• No Microsoft licensing costs via Outlook Web
  Access

47

• SDS Hosting Services
• Messaging Services
• Exchange Hosting and migration services
• Blackberry
• eMail Archiving
• Right Fax Service
• Live Communication Server (AD Hosting Required)
• Secure Instant Messaging, Application Sharing,
  Video Conferencing
• Domain Hosting
• Citywide Active Directory Forest Integration
• Distributed Virus Protection
• Distributed Monitoring of Server Systems and
  Applications

48

• SDS Hosting Services (continued)
• Application Hosting
• Microsoft Windows SharePoint Services (with eGov)
• Microsoft SQL Server Hosting
• ASP and ASP.NET hosting
• .NET Frameworks 1.x and 2.x (Summer 2005)
• SNA Connectivity
• Host Integration Server
• Other Services
• McAfee ePolicy
• WUS (Windows Updating Service)

49

• SDS IT Collaboration
• Work with Unix team for SAN Storage and backup
  solutions
• Work with Mainframe team to provide offsite
  storage facilities and connectivity to Mainframe
  environment via Host Integration Server
• Work with eGov to provide the foundation for
  Wintel Based applications
• All teams communicate to determine best solutions
  across all platforms

50

• Participating Agencies
• Bronx District Attorney
• City Commission on Human Rights
• Civilian Complaint Review Board
• Department of Consumer Affairs
• Department of Buildings
• Department of Finance
• Department of Sanitation
• Department of Youth and Community Development
• Mayors Office of Film Broadcasting Theatre
• NYC Marketing
• Office of Administrative Trials and Hearings
• Office of Collective Bargaining
• Office of Payroll Administration
• Parks Department
• Department of Records and Information Services
• Taxi and Limousine Commission

51

• SDS Future Initiatives
• Windows Web Farm for Application Hosting in
  Citynet and the DMZ (Public Facing)
• High Availability - Spans across DoITT FISA DCs
• Application Hosting on demand w/o hardware
• Replication, Managed Monitored 24X7
• Agency or DoITT Managed
• Rapid Development in virtualized environments
• Development
• Staging
• Production

52
Server and Desktop Services Christopher
Ianniello cianniello_at_doitt.nyc.gov (718)
403-8203 Web and Application Farm Marcos
Merced mmerced_at_doitt.nyc.gov (718)-403-8420
53

• Enterprise Systems Management
• ESM Vision and Rationale
• Manager of Managers (MOM) Overview and Features
• Business Service Management (BSM) Overview and
  Features
• ESM Prospective and Overview

54

• Enterprise Systems Management Vision
• The ESM systems will enable the City to
  proactively manage IT resources automate problem
  tracking monitor, maintain and enforce best
  practice change control manage physical assets
  to ensure high availability, reliability, improve
  ROI and leverage the current investments in
  existing resources.
• DoITT has chosen the ITIL certified products
• These solutions will be software driven and are
  intended to centralize the comparison, reporting
  and tracking of potential and ongoing network and
  application issues first internally, and then
  expanding these services to other agencies.

55

• Why Enterprise Systems Management?
• DoITT in conjunction with other city entities
  recognized the need for End-to-End Monitoring of
  IT resources to ensure high availability and
  reliability.
• By consolidating all of the alerts into a single
  console, it is possible to analyze the alert data
  to identify the root-cause of an incident, a
  problem or a potential problem and then achieve a
  quicker mean time to repair.
• Along with monitoring, the development of a
  multi-agency, comprehensive Service Desk will
  provide complete customer service, which allows
  for notification and tracking of both potential
  and current problems/issues. When faults occur
  in any system, rapid identification is forwarded
  to managers and/or technicians with the impact
  details of these end-to-end performance failures.

56
Mainframe
UNIX
OSS
OSS
Network
Network
?
?
Reports
Reports
Network
Network
Reports
Reports
?
?
OSS
OSS
Wintel
Other Systems
57
Network reporting will be the first platform to
deliver fully converged solution
OSS
OSS
Network
Network
Network Reporting System
Network
Network
OSS
OSS
58

• Enterprise Systems Management - Objectives
• An objective of the ESM project is to achieve
  economies of scale and produce the most cost
  effective technology solutions for the City of
  New York to achieve this objective, the project
  has been staged as a multi-agency initiative.
• Initially, DoITT will partner with FISA, but
  there is no limit to the number of agencies that
  can eventually benefit from the features of this
  service the enterprise-wide nature of this
  solution will permit any agency to participate
  when they have the need to improve
  serviceability, reliability and availability.
• The functions of Change Control and Asset
  Management will further ensure availability and
  will leverage the existing investment of all IT
  resources.

59

• Single Panel View

60

• ESM Products Service management software
  providing the ability to submit, monitor and
  manage help desk cases, change requests and asset
  inventory data.
• Features of a BSM Software Suite
• Premier Products in the Market Place (ITIL
  Certified)
• ITIL Best Practices built into an integrated IT
  Service Management application suite
• Incident and Problem Management
• Change Management
• Configuration and Asset Management
• All Applications reside on a workflow engine
  that delivers services that will track any asset
  with a lifecycle

61

• Enterprise Systems Management Prospective
• Each organizational units technical
  staff/management will be able to proactively
  address potential problems and will have the
  ability to view and review data for problem
  determination and resolution.
• In creating a centralized helpdesk at DoITT,
  experienced technicians can be dispatched to
  address problems at agencies requiring those
  skills, which may not be readily available
  internally and would require a financial outlay
  for the agency to source.
• In addition, agencies will be able to use a
  web-based interface to access the centralized
  helpdesk application - minimizing the cost of
  housing and maintaining the application for each
  agency and allow the development of a knowledge
  base of problems and likely solutions, as a
  reference guide.

62

• Enterprise Systems Management Overview

• Monitoring Suite
• Manager of Managers (MOM)
• Monitor our diverse architecture and inventory of
  hardware, software and the services that we
  currently provide
• Single View for Alerts

• Business Service Management
• Incident and Problem Management
• Change Management
• Configuration and Asset Management

ESM Services

• ITIL
• Optimize resources Utilization
• Reduce Cost
• Improve Availability
• Tune Capacity
• Increase Throughput
• Improve Scalability

Supported Agencies

• DoITT
• FISA
• Future Department of Sanitation, DCAS, the
  Buildings Department, the Department of Probation
  and others

63

• Questions and Answers?
